Flycam FLCM-FLN-PA Bedienungsanleitung

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Flowline with Stabilizing Arm (FLCM-FLN-PA)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

A s s e m b l y M a n u a l

Tensioner Spring Safety Shock Cord

Flowline Placid

Body Suppport Storage Bag

 Join support bar with secon of support

jacket by push-t technique. Similarly, join

front secon with support bar as shown.

 Wear support jacket and ghten the buckles

provided at waist and chest and adjust as per

your convenience.

NOTE: The four knobs provided on back of

support jacket allows height adjustment of

support bar.

Flowline Vest Setup

 Aach camera to hook and ghten with

provided knob to ensure slip-free connecon.

 Use spring at back of support jacket to adjust

tension of rope as required.

 Loosen knob at support bar to adjust posion

of camera according to eye-level, if required.

 Rotate the knob to release the spring tension.

 Loosen the knob of Hook and remove the

spring of Hook.

 Now loosen the knot of rope in order to

remove the rope from hook. Remove

extension arm of Flowline. Re-aach arm

upside down and ghten the knob properly

 Now pass the rope through Placid adapter as

shown in the image. Mount Placid on

Flowline arm and ghten the Allen bolt with

help of Allen key.

 Loosen Allen bolt of Placid Arm with help of

Allen Key.

 Align the rope with the pulley of Placid Arm.

Placid Arm + Flycam Vest Setup

 Then insert the rope into Hook and e the

knot of Rope properly.

 Aach the spring to Hook and ghten the

knob to secure it properly.

 Secure the Placid on Flowline Arm with

provided e to ensure slip-free connecon.

 Now mount your camera setup on hook of

Flowline and ghten the knob to secure it

properly.

YOUR FLYCAM FLOWLINE WITH STABILIZING ARM

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
