Flycam Galaxy Bedienungsanleitung
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Galaxy Steadycam Arm & Vest (GLXY-AV)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Ass e mb l y M a n u a l
Locking Buckles
So Chest
Padding
Arm Connector
So Shoulder
Padding
Height Adjustment
Knob
Flexible Joint
Tension Adjustment
Knob
2pc Heavy Tension
Springs (Red & Blue) 1x 16mm Plasc Bush
1x 19mm Plasc Bush
1x 3mm Allen Key
2
Having put your vest on, insert the hooks of
the 26’’ long straps into the appropriate
buckle. Then ghten both straps with Velcro
for a comfortable t and lock both with the
buckles.
The length of the chest plate can be adjusted
according to the height of the person by using
this adjusng screw.
Steadycam Arm & Vest Setup
Loosen the knobs & insert Arm’s male socket
into female socket of vest as shown in image.
Now, your Galaxy Steadycam Arm & Vest
assembly is ready to use.
NOTE: Properly set up and custom t, your vest should look like the provided picture. Straps are made
of through nylon and industrial strength Velcro and can be easily replaced or adjusted to suit individual
needs.
The arm tension is adjusted for the heaviest camcorder, so when you apply the camcorder and sled on the
arm for the first time it does not stay down. Now adjust the arm for the weight of your camcorder:
Move the arm to the middle of its booming (up and down range) and let go. (If it stays where it is, you
are probably close to the right adjustment).
Keep making small adjustments until the camcorder does not rise or fall when you let go of it in the
middle of its booming range.
Arm Adjustment
Posion arm
Move the camcorder to your left so the arm crosses your body.
Adjust the arc of your arm so the rig feels comfortable to you.
Keep the camcorder close to your body.
3
For Interchanging the spring, Follow this
https://bit.ly/34o0fgk
Bearing Maintenance
The Flycam GALAXY Arm contains the bearings. If aer some period of me your bearings don’t turn
smoothly as when new, you can oil it lightly with light lubricang oil. We recommend that you use a
minimum amount. Only a few drops are required, plus anything more than a lile will end up dripping
from the bearing and onto the rest of your Galaxy Arm. Be sure to keep the oil away from your Camera,
and clean up any over spill when done.
Cleaning
Do not use solvents or harsh cleaners of any kind on your Flycam Galaxy Arm & Vest. If the unit becomes
dirty, use only a cloth or sponge with water and a very mild detergent to gently rub the unit clean. Rinse
well.
Storage
If you are going to store your Flycam Galaxy Arm & Vest for a long period of me then please store the
unit up right in a dry or low to normal humidity area whenever possible.
If you are unable to nd an environment like this, then we suggest you store the unit in an airght plasc
container or bag. Standing the unit upright helps to alleviate stress on the system.
Maintenance
YOUR FLYCAM GALAXY STEADYCAM ARM & VEST
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
4
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
