Freescale Semiconductor

Reference Manual Addendum MPC5607BRMAD

Rev. 1, 05/2012

Table of Contents

This addendum document describes corrections to the

MPC5607B Microcontroller Reference Manual, order

number MPC5607BRM. For convenience, the addenda

items are grouped by revision. Please check our website

at http://www.freescale.com/powerarchitecture for the

latest updates.

The current version available of the MPC5607B

Microcontroller Reference Manual is Revision 7.1.

MPC5607B Microcontroller

Reference Manual Addendum

by: Microcontroller Solutions Group

1 Addendum List for Revision 7.1 . . . . . . . . . . . . . . 2

2 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . 10

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

Freescale Semiconductor2

1 Addendum List for Revision 7.1

Table 1. MPC5607BRM Rev 7.1 Addenda

Location Description

Chapter 1, Preface, page 22 In Table 1-1, Guide to this reference manual, Line 12 WKUP, change the description to read:

Always-active analog block. Details configuration of 2 internal (API/RTC) and 27 external (pin)

low power mode wakeup sources.

Chapter 1, Preface, page 23 In Table 1 (Guide to this reference manual),Line 17, eDMA Channel Multiplexer (DMA_MUX),

change the description to read:

“Operation and configuration information for the eDMA multiplexer, which takes the 59

possible eDMA sources (triggers from the DSPI, eMIOS, I2C, ADC and LINFlexD) and

multiplexes them onto the 16 eDMA channels.” (59 sources, 16 channels)

Chapter 1, Preface, page 27 In Section 1.6.1, The MPC5607B document set, remove bullet item

“e200z4 Power Architecture Core Reference Manual.”

Chapter 1, Preface, page 27 In Section 1.6.1, The MPC5607B document set, change bullet item “Configuring CPU memory,

branch and cache optimizations” to “Configuring CPU memory and branch optimizations.”

Chapter 1, Preface, page 30 In Section 1.7.3, Software design, remove the paragraph “The MMU translates physical memory

addresses for use by the CPU and it must be configured before any peripherals or memories

are available for use by the CPU. See the e200z4 Power Architecture Core Reference Manual

for details on how to configure the MMU.”

Chapter 6, Clock Description,

page 132 Add Note: to Section 6.8.4.1, Crystal clock monitor:

Note: Functional FXOSC monitoring can only be guaranteed when the FXOSC frequency is

greater than (FIRC / 2RCDIV)+0.5MHz.

Add Note: to Section 6.8.4.2, FMPLL clock monitor:

Note: Functional FMPLL monitoring can only be guaranteed when the FMPLL frequency is

greater than (FIRC / 4) + 0.5 MHz.

Chapter 9, Reset Generation

Module (MC_RGM), page

232

Replaced Section 9.4.7, Boot Mode Capturing, with the following:

The MC_RGM samples PA[9:8] whenever RESET is asserted until fiveFIRC (16 MHz internal

RC oscillator) clock cycles before its deassertion edge. The result of the sampling is used at

thebeginning ofreset PHASE3forboot modeselection andis retainedafter RESET hasbeen

deasserted for subsequent boots after reset sequences during which RESET is not asserted.

Note: In order to ensure that the boot mode is correctly captured, the application needs to

apply the valid boot mode value the entire time that RESET is asserted.

RESET can be asserted as a consequence of the internal reset generation. This will force

re-sampling of the boot mode pins. (See Table 9-12 for details.)

Chapter 13, Real Time Clock /

Autonomous Periodic

Interrupt (RTC/API),page 270

In Table 13-3 (RTCC field descriptions), update the Note in the RTCC[APIVAL] field description:

Note: API functionality starts only when APIVAL is nonzero. The first API interrupt takes two

more cycles because of synchronization of APIVAL to the RTC clock, and APIVAL + 1 cycles

for subsequent occurrences. After that, interrupts are periodic in nature. Because of

synchronization issues, the minimum supported value of APIVAL is 4.

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

FreescaleSemiconductor 3

Chapter 16, Enhanced Direct

Memory Access (eDMA),

page 330

Replace Section 16.5.8, Dynamic programming, with the following:

16.5.8 Dynamic programming

16.5.8.1 Dynamic channel linking

Dynamic channel linking is the process of setting the TCD.major.e_link bit

during channel execution. This bit is read from the TCD local memory at the

end of channel execution, thus allowing the user to enable the feature during

channel execution.

Because the user is allowed to change the configuration during execution, a

coherency model is needed. Consider the scenario where the user attempts to

execute a dynamic channel link by enabling the TCD.major.e_link bit at the

same time the eDMA engine is retiring the channel. The TCD.major.e_link

would be set in the programmer’s model, but it would be unclear whether the

actual link was made before the channel retired.

The coherency model in Table 16-24 is recommended when executing a

dynamic channel link request.

For this request, the TCD local memory controller forces the TCD.major.e_link

bit to zero on any writes to a channel’s TCD.word7 after that channel’s

TCD.done bit is set, indicating the major loop is complete.

NOTE

The user must clear the TCD.done bit before

writingtheTCD.major.e_linkbit.TheTCD.done

bit is cleared automatically by the eDMA engine

after a channel begins execution.

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Table 16-24. Coherency model for a dynamic channel link request

Step Action

1 Write 1b to the TCD.major.e_link bit.

2 Read back the TCD.major.e_link bit.

3 Test the TCD.major.e_link request status:

• If TCD.major.e_link = 1b, the dynamic link attempt was successful.

• If TCD.major.e_link = 0b, the attempted dynamic link did not succeed (the channel

was already retiring).

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

Freescale Semiconductor4

Chapter 16, Enhanced Direct

Memory Access (eDMA),

page 330 (cont.)

16.5.8.2 Dynamic scatter/gather

Dynamic scatter/gather is the process of setting the TCD.e_sg bit during

channel execution. This bit is read from the TCD local memory at the end of

channel execution, thus allowing the user to enable the feature during channel

execution.

Because the user is allowed to change the configuration during execution, a

coherency model is needed. Consider the scenario where the user attempts to

execute a dynamic scatter/gather operation by enabling the TCD.e_sg bit at the

same time the eDMA engine is retiring the channel. The TCD.e_sg would be

set in the programmer’s model, but it would be unclear whether the actual

scatter/gather request was honored before the channel retired.

Two methods for this coherency model are shown in the following subsections.

Method 1 has the advantage of reading the major.linkch field and the e_sg bit

with a single read. For both dynamic channel linking and scatter/gather

requests, the TCD local memory controller forces the TCD.major.e_link and

TCD.e_sg bits to zero on any writes to a channel’s TCD.word7 if that channel’s

TCD.done bit is set indicating the major loop is complete.

NOTE

The user must clear the TCD.done bit before

writing the TCD.major.e_link or TCD.e_sg bits.

TheTCD.donebitiscleared automatically by the

eDMA engine after a channel begins execution.

16.5.8.2.1 Method 1 (channel not using major loop channel

linking)

For a channel not using major loop channel linking, the coherency model in

Table 16-25 may be used for a dynamic scatter/gather request.

When the TCD.major.e_link bit is zero, the TCD.major.linkch field is not used

by the eDMA. In this case, the TCD.major.linkch bits may be used for other

purposes. This method uses the TCD.major.linkch field as a TCD identification

(ID).

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

FreescaleSemiconductor 5

Chapter 16, Enhanced Direct

Memory Access (eDMA),

page 330 (cont.)

16.5.8.2.2 Method 2 (channel using major loop linking)

For a channel using major loop channel linking, the coherency model in

Table 16-26 may be used for a dynamic scatter/gather request. This method

uses the TCD.dlast_sga field as a TCD identification (ID).

For a channel using major loop channel linking, the coherency model in

Table 16-26 may be used for a dynamic scatter/gather request. This method

uses the TCD.dlast_sga field as a TCD identification (ID).

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Table 16-25. Coherency model for method 1

Step Action

1 When the descriptors are built, write a unique TCD ID in the TCD.major.linkch field for

each TCD associated with a channel using dynamic scatter/gather.

2 Write 1b to theTCD.d_req bit.

Note: Should a dynamic scatter/gather attempt fail, setting the d_req bit will prevent a

future hardware activation of this channel. This stops the channel from

executing with a destination address (daddr) that was calculated using a

scatter/gather address (written in the next step) instead of a dlast final offset

value.

3 Write theTCD.dlast_sga field with the scatter/gather address.

4 Write 1b to the TCD.e_sg bit.

5 Read back the 16 bit TCD control/status field.

6 Test the TCD.e_sg request status and TCD.major.linkch value:

• If e_sg = 1b, the dynamic link attempt was successful.

• If e_sg = 0b and the major.linkch (ID) did not change, the attempted dynamic link

did not succeed (the channel was already retiring).

• If e_sg = 0b and the major.linkch (ID) changed, the dynamic link attempt was

successful (the new TCD’s e_sg value cleared the e_sg bit).

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

Freescale Semiconductor6

Chapter 16, Enhanced Direct

Memory Access (eDMA),

page 330 (cont.)

Chapter 19, Crossbar Switch

(XBAR), throughout

chapter

Correct “two master ports” to “three master ports” as necessary.

Chapter 19, Crossbar Switch

(XBAR), page 379 Replace Figure 19-1 (XBAR block diagram) with the following.

Chapter 19, Crossbar Switch

(XBAR), page 379 Add the following row for eDMA to Table 19-1 (XBAR switch ports for MPC5607B).

Chapter 19, Crossbar Switch

(XBAR), page 380 In Section 19.4, Features, add a bullet item for eDMA.

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Table 16-26.Coherency model for method 2

Step Action

1 Write 1b to theTCD.d_req bit.

Note: Should a dynamic scatter/gather attempt fail, setting the d_req bit will prevent a

future hardware activation of this channel. This stops the channel from

executing with a destination address (daddr) that was calculated using a

scatter/gather address (written in the next step) instead of a dlast final offset

value.

2 Write theTCD.dlast_sga field with the scatter/gather address.

3 Write 1b to the TCD.e_sg bit.

4 Read back the TCD.e_sg bit.

5 Test the TCD.e_sg request status:

• If e_sg = 1b, the dynamic link attempt was successful.

• If e_sg = 0b, read the 32 bit TCD dlast_sga field.

• If e_sg = 0b and the dlast_sga did not change, the attempted dynamic link did not

succeed (the channel was already retiring).

• If e_sg = 0b and the dlast_sga changed, the dynamic link attempt was successful

(the new TCD’s e_sg value cleared the e_sg bit).

CPU

Crossbar Switch

Flash

Master modules

Slave modules

CPU data

Internal Peripheral

bridges

instructions

memory SRAM

eDMA

Module Port Physical master ID

Type Logical number

eDMA Master 1 2

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

FreescaleSemiconductor 7

Chapter 19, Crossbar Switch

(XBAR), page 382 Replace Table 19-2 (Hardwired bus master priorities) with the following.

Chapter 20, Memory

Protection Unit (MPU),

page 389

In Section 20.5.2.1 MPU Control/Error Status Register (MPU_CESR), in Figure 20-2 (MPU

Control/Error Status Register (MPU_CESR)), expand the SPERR field to an 8-bit field

stretching from bit 0 to bit 7.

Chapter 23, LINFlex, p. 494 Insert the following after Section 20.8.2.1.6, Error handling:

23.8.2.1.6 Overrun

Once the message buffer is full, the next valid message reception leads to an

overrun and a message is lost. The hardware sets the BOF bit in the LINSR to

signal the overrun condition. Which message is lost depends on the

configuration of the RX message buffer:

• If the buffer lock function is disabled (LINCR1[RBLM] = 0) the last

message stored in the buffer is overwritten by the new incoming

message. In this case the latest message is always available to the

application.

• Ifthe bufferlock function isenabled (LINCR1[RBLM] = 0) themostrecent

message is discarded and the previous message is available in the buffer.

Chapter 24, LINFlexD, p. 514 Insert the following after Section 24.7.1.5, Error handling and detection:

21.7.1.6 Overrun

Once the message buffer is full, the next valid message reception leads to an

overrun and a message is lost. The hardware sets the BOF bit in the LINSR to

signal the overrun condition. Which message is lost depends on the

configuration of the RX message buffer:

• If the buffer lock function is disabled (LINCR1[RBLM] = 0) the last

message stored in the buffer is overwritten by the new incoming

message. In this case the latest message is always available to the

application.

• If the buffer lock function is enabled (LINCR1[RBLM] = 0) the most

recent message is discarded and the previous message is available in the

buffer.

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Table 19-2. Hardwired bus master priorities

Module Port Priority level

Type Master #

e200z0 core–CPU instructions Master 0 7

e200z0 core–CPU data Master 1 6

eDMA Master 2 5

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

Freescale Semiconductor8

Chapter 25, FlexCAN,

throughout chapter Remove references throughout the chapter to “low-cost MCUs.”

Chapter 25, FlexCAN, page

594 Remove Note: above Table 25-2:

Note: The individual Rx Mask per Message Buffer feature may not be available in low cost

MCUs. Please consult the specific MCU documentation to find out if this feature is supported.

If not supported, the address range 0x0880-0x097F is considered reserved space,

independent of the value of the BCC bit.

Chapter 25, FlexCAN, page

596 Added this Note in the RTR field description of Table 25-4 (Message Buffer Structure field

description):

Note: Do not configure the last Message Buffer to be the RTR frame.

Chapter 25, FlexCAN, page

619 Remove Note: in Section 25.4.4.13 Rx Individual Mask Registers (RXIMR0–RXIMR63):

Note: The individual Rx Mask per Message Buffer feature may not be available in low cost

MCUs. Please consult the specific MCU documentation to find out if this feature is supported.

If not supported, the RXGMASK, RX14MASK and RX15MASK registers are available,

regardless of the value of the BCC bit.

Chapter 25, FlexCAN, page

624 Remove Note: at end of Section 25.5.6, Matching process:

Note: The individual Rx Mask per Message Buffer feature may not be available in low cost

MCUs. Please consult the specific MCU documentation to find out if this feature is supported.

If not supported, the RXGMASK, RX14MASK, and RX15MASK registers are available,

regardless of the value of the BCC bit.

Chapter 25, FlexCAN, page

629 In Section 25.5.9.4, Protocol timing, update the Note following Figure 25-16 (CAN Engine

Clocking Scheme) to read: “This clock selection feature may not be available in all MCUs. A

particular MCU may not have a PLL, in which case it would have only the oscillator clock, or

it may use only the PLL clock feeding the FlexCAN module. In these cases, the CLK_SRC bit

in the CTRL Register has no effect on the module operation.”

Chapter 25, FlexCAN, page

631 Update the table title of Table 25-22 from “CAN Standard Compliant Bit Time Segment Settings”

to “Bosch CAN 2.0B standard compliant bit time segment settings.”

Chapter 25, FlexCAN, page

631

In Section 25.5.9.4, Protocol timing, update the Note following Table 25-22 to read: “Other

combinations of Time Segment 1 and Time Segment 2 can be valid. It is the user’s

responsibility to ensure the bit time settings are in compliance with the CAN standard. For bit

time calculations, use an IPT (Information Processing Time) of 2, which is the value

implemented in the FlexCAN module.”

Chapter 28, Analog-to-Digital

Converter (ADC), page 771 In Section 28.3.4.2, CTU in trigger mode, replace the sentence:

If another CTU conversion is triggered before the end of the conversion, that request is

discarded.

with:

If another CTU conversion is triggered before the end of the conversion, that request is

discarded. However, if the CTU has triggered a conversion that is still ongoing on a channel,

it will buffer a second request for the channel and wait for the end of the first conversion before

requesting another conversion. Thus, two conversion requests close together will both be

serviced.

Chapter 28, Analog-to-Digital

Converter (ADC), page 772 In Section 28.3.5.2, Presampling channel enable signals, in Table 28-7, Presampling voltage

selection based on PREVALx fields, in the 01 row, change the “Presampling voltage” field to:

V1 = VDD_HV_ADC0 or VDD_HV_ADC1.

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Addendum List for Revision 7.1

MPC5607B Reference Manual Errata, Rev. 1

FreescaleSemiconductor 9

Chapter 28, Analog-to-Digital

Converter (ADC), page 776 Add Note to Section 28.3.11, Auto-clock-off mode:

Note: The auto-clock-off feature cannot operate when the digital interface runs at the same

rate as the analog interface. This means that when MCR.ADCCLKSEL = 1, the analog clock

will not shut down in IDLE mode.

Chapter 29, Cross Triggering

Unit (CTU), page 825 At the end of Section 29.4.1, Event Configuration Registers (CTU_EVTCFGRx) (x = 0...63), add

the following Note:

NOTE

The CTU tracks issued conversion requests to the ADC. When the ADC

is being triggered by the CTU and there is a need to shut down the ADC,

the ADC must be allowed to complete conversions before being shut

down. This ensures that the CTU is notified of completion; if the ADC

is shut down while performing a CTU-triggered conversion, the CTU is

not notified and will not be able to trigger further conversions until the

device is reset.

Chapter 30, Flash Memory,

page 833 Replace Figure 30-1. Flash memory architecture with the following.

Chapter 31, Static RAM

(SRAM), page 933 In Table 31-2, Low power configuration, in the STANDBY line, change the description

“Either all or just 8 KB of the SRAM remains powered. This option is software-selectable.”

“Either 32 KB or just 8 KB of the SRAM remains powered. This option is software-selectable.”

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Crossbar switch

Bank0 (CFlash) Bank1 (DFlash)

data

(for EEPROM

Array 0

512 KB

Array 1

1x128 page buffer4x128 page buffer

PFlash controller

emulation)

CFLASH_PFCR0[B0_P0_BFE]

CFLASH_MCR

...

CFLASH_UMISR4

CFLASH_PFCR1[B1_P0_BFE]

DFLASH_MCR

...

DFLASH_UMISR4

Flash memory flash memory

128 128

64 KB

Bank0 (CFlash)

512 KB

Array 2

Flash memory

Bank0 (CFlash)

512 KB

Array 0

Flash memory

Revision History

MPC5607B Reference Manual Errata, Rev. 1

Freescale Semiconductor10

2 Revision History

Table 3 provides a revision history for this reference manual addendum document.

Chapter 32, Register

Protection, page 954 In Table 32-5, Protected registers, change the module base address for the CMU_CSR register

from C3FE00E0 to C3FE0000.

Table 2. Revision History Table

Rev. Number Substantive Changes Date of Release

1.0 • Initial release. 05/2012

Table 1. MPC5607BRM Rev 7.1 Addenda (continued)

Location Description

Inhaltsverzeichnis

Andere Freescale Semiconductor Mikrocontroller Handbücher

Freescale Semiconductor

Freescale Semiconductor i.MX51 EVK Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MC68881 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MPC5634M Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor Kinetis TWR-K21D50M Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor PXR4030 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MCF52230 ColdFire Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor KV31F Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MMA7260QT Gebrauchsanweisung

Freescale Semiconductor

Freescale Semiconductor MC9S12XHY Series Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MC9S12VR Series Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor RS08 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MC9S12C Family Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor Kinetis K40 MCUs Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor FRDM-KL03Z Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MPC5604B Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor Flexis Series Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MC9S12DJ128E Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MC9S12ZVHL64 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor HCS12 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor TWR-KL46Z48M Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor T4240 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor MPC5553 Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor KL02 Series Bedienungsanleitung

Freescale Semiconductor

Freescale Semiconductor SABRE MCIMX6Q-SDP Bedienungsanleitung

Beliebte Mikrocontroller Handbücher anderer Marken

AMS

AMS AS7261 Demo Kit Bedienungsanleitung

Novatek

Novatek NT6861 Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266 SDK Einrichtungshandbuch

Nuvoton

Nuvoton ISD61S00 ChipCorder Leitfaden

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Bedienungsanleitung

Texas Instruments

Texas Instruments Chipcon CC2420DK Bedienungsanleitung

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Bedienungsanleitung

NEC

NEC 78GK0S/K 1+ Series Montage- und Bedienungsanleitung

Mikroe

Mikroe SEMITECH N-PLC Click Montage- und Bedienungsanleitung

Intel

Intel Agilex Bedienungsanleitung

Cypress

Cypress CY4607 HX2VL Bedienungsanleitung

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320F2837 D Series Bedienungsanleitung

CYPRES

CYPRES CY14NVSRAMKIT-001 Bedienungsanleitung

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266EX Betriebsanleitung

Abov

Abov AC33M8128L Bedienungsanleitung

Laird

Laird BL654PA Bedienungsanleitung
