Fujitsu ScanSnap fi-5110EOXM Handbuch

P3PC-1412-02ENZ0

Color Image Scanner

fi-5110EOXM for Macintosh

Operator’s Guide

ScanSnap fi-5110EOXM Operator's Guide i

Introduction

Thank you for purchasing the ScanSnap fi-5110EOXM Color Image Scanner.

ScanSnap fi-5110EOXM is a color image scanner and office applications. It is a complete office

solution designed to improve your productivity and to solve your office scanning problems. The

ScanSnap product has the following features.

■Converting paper documents into PDFs by pressing a single botton!

You can turn the documents that clutter up your desktop into PDFs, and manage and

archive them on your computer.

The ScanSnap fi-5110EOXM can also automatically recognize the content of docu-

ment, color or black & white, so scanned image files can be made smaller when scan-

ning documents containing a mixture of color and black & white pages. You can also

have the scanner automatically remove blank pages in documents in order to further

reduce the size of files.

■Effortless scanning!

The ScanSnap fi-5110EOXM can scan double-sided color documents of A4 or Letter

size at a speed of 15 sheets/minute (when Scanning quality is set to Normal (Fastest),

Color mode is set to Auto Color Detection, and Compression rate is set to 3). (*1)

■Small desktop footprint!

Having a footprint smaller than the size of A4 or Letter paper, the ScanSnap scanner

can be left on your desk all the time.

(*1) - Depending on the document, the scanning speed may become slower in "B&W"

(Black&White) mode (due to the conversion of data scanned in color to

monochrome data).

Example: Scanning color brochures in "B&W" mode. Scanning quality: Normal

(Fastest), Compression rate: 3, about 12 sheets/minute.

- When "Allow automatic blank page removal" or "Allow automatic image deskew" is

enabled, scanning speed may become slower.

(*2) - ScanSnap fi-5110EOXM does not support the TWAIN and ISIS standards.

This document describes how to handle ScanSnap fi-5110EOXM and the basic operation methods.

Before you start using ScanSnap fi-5110EOXM, be sure to thoroughly read this manual to ensure

correct use.

ScanSnap fi-5110EOXM is referred to as ScanSnap hereafter in this document.

CONTENTS

■Regulatory Information ......................................................... v

■Note, Liability ...................................................................... viii

■Preface ................................................................................ viii

■Safety Precautions ............................................................... xi

Chapter 1 Before You Start Using Your Scanner................... 1

1.1 Names and Functions of Parts .......................................... 2

Front Side ............................................................................................. 2

Operation Button................................................................................... 3

Rear Side.............................................................................................. 3

Chapter 2 Connecting ScanSnap ............................................ 5

2.1 Installing ScanSnap............................................................ 6

Before Installing ScanSnap................................................................... 6

Installing Adobe Acrobat....................................................................... 7

Installing ScanSnap Manager............................................................. 10

2.2 Connecting ScanSnap to your Computer ...................... 16

Connecting the AC Adapter ................................................................ 16

Connecting the USB Cable................................................................. 17

Chapter 3 Basic Scanner Operations.................................... 19

3.1 Flow of Operations ........................................................... 20

Preparation ......................................................................................... 20

Scanning documents .......................................................................... 22

Turning the Scanner ON/OFF............................................................. 25

End of Operation................................................................................. 26

3.2 Scanning Different Document Types.............................. 27

ScanSnap fi-5110EOXM Operator's Guide iii

3.3 Loading Documents ......................................................... 29

How to load documents ...................................................................... 29

3.4 Changing Scan Settings .................................................. 32

3.5 Various settings according to your needs ..................... 50

Scanning only one side of a document............................................... 51

Scanning color document in black and white...................................... 53

Skipping blank pages.......................................................................... 54

Correcting skewed documents............................................................ 56

Rotating the page view of a PDF file................................................... 58

Saving scanned images in multiple files ............................................. 60

Merging scanned images into one PDF file ........................................ 62

Converting scanned images to searchable text with OCR.................. 64

Chapter 4 Uninstalling ScanSnap ......................................... 65

4.1 Uninstalling Supplied Programs .................................... 66

To uninstall ScanSnap Manager in Mac OS X v10.2.......................... 66

To uninstall ScanSnap Manager in Mac OS X v10.3/v10.4 ................ 67

Chapter 5 Troubleshooting .................................................... 69

5.1 Clearing Document Jams................................................. 70

5.2 Troubleshooting Checklist .............................................. 72

Chapter 6 Daily Care............................................................... 77

6.1 Cleaning Materials............................................................ 78

6.2 Cleaning the Scanner Exterior & Stacker....................... 79

6.3 Cleaning the Inside of the Scanner................................. 80

Chapter 7 Replacing Consumables....................................... 85

7.1 Replacing Consumables .................................................. 86

Part Nos. and Replacement Cycles of Consumables ......................... 86

7.2 Replacing the Pad ASSY.................................................. 88

7.3 Replacing the Pick Roller................................................. 92

Appendix A Installation Specifications ................................... 99

Index........................................................................................... 101

Repairs....................................................................................... 103

ScanSnap fi-5110EOXM Operator's Guide v

■Regulatory Information

FCC declaration

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver

is located.

•Consult your dealer or an experienced radio/TV technician.

FCC warning: Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

Canadian DOC Regulations

This digital apparatus does not exceed the Class B limit for radio noise emissions from

digital apparatus set out in the Radio interference Regulations of the Canadian Department

of Communications.

This Class B digital apparatus complies with Canadian ICES-003.

Le pésent appareil numérique n’ément pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de la classe B prescridtes dans le Réglesment sur le

brouillage radioélectrique dicté par le ministere des Communications du Canada.

Cet appareil numérique de la classe B est conformme à la norme NMB-003 du Canada.

Bescheinigung des Herstellers / Importeurs

Für den ScanSnap fi-5110EOXM wid folgendes bescheinigt:

•In Übereinsstimmung mit den Bestimmungen der EN45014(CE) funkentstört

CAUTION

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

ATTENTION •The use of a shielded interface cable is required to comply with the Class B limits of

Part 15 of FCC rules.

•The length of the AC cable must be 3 meters (10 feet) or less.

•Maschinenlärminformationsverordnung 3. GPSGV, 06.01.2004: Der höchste

Schalldruckpegel beträgt 70 dB (A) oder weniger, gemäß EN ISO 7779.

International ENERGY STAR® Program

As an ENERGY STAR® Partner, PFU LIMITED has determined that

this product meets the ENERGY STAR® guidelines for energy

efficiency.

The International ENERGY STAR® Office Equipment Program is an

international program that promotes energy saving through the penetration of energy

efficient computers and other office equipment. The program backs the development and

dissemination of products with functions that effectively reduce energy consumption. It is an

open system in which business proprietors can participate voluntarily. The targeted products

are office equipment such as computers, monitors, printers, facsimiles, copiers, scanners, and

multifunction devices. Their standards and logos ( ) are uniform among participating

nations.

Use in High-safety Applications

This product has been designed and manufactured on the assumption that it will be used in

office, personal, domestic, regular industrial, and general-purpose applications. It has not

been designed and manufactured for use in applications (simply called "high-safety

applications" from here on) that directly involve danger to life and health when a high degree

of safety is required, for example, in the control of nuclear reactions at nuclear power

facilities, automatic flight control of aircraft, air traffic control, operation control in mass-

transport systems, medical equipment for sustaining life, and missile firing control in

weapons systems, and when provisionally the safety in question is not ensured. The user

should use this product with adopting measures for ensuring safety in such high-safety

applications. PFU LIMITED assumes no liability whatsoever for damages arising from use

of this product by the user in high-safety applications, and for any claims or compensation

for damages by the user or a third party.

About the use of mercury

The scanner lamp contains mercury.

To avoid unexpected injury, read the following carefully.

Failure to complying with the following may result in serious personal injuries:

•Do not put the substance in the lamp in your mouth as it contains mercury.

•Do not incinerate, crush, or shred the scanner.

•Do not inhale or drink the chemical liquid contained in the scanner parts.

Lamp(s) inside this product contain mercury and must be recycled or

disposed of according to local, state, or federal laws.

ScanSnap fi-5110EOXM Operator's Guide vii

Trademarks

Mac, and Mac OS are trademarks of Apple Computer, Inc., registered in the United States

and other countries.

Adobe, the Adobe logo, and Acrobat are either registered trademarks of Adobe Systems

Incorporated in the United States and/or other countries.

Other product names are the trademarks or registered trademarks of the respective

companies.

How Trademarks Are Indicated In This Manual

References to operating systems (OS) are indicated as follows:

Mac OS X v10.1:Macintosh operating system version 10.1

Mac OS X v10.2:Macintosh operating system version 10.2

Mac OS X v10.3:Macintosh operating system version 10.3

Mac OS X v10.4:Macintosh operating system version 10.4

Where there is no distinction between the different versions of the above operating system,

the general term "Mac OS" is used.

Adobe Acrobat 7.0:Adobe®Acrobat®7.0 Standard.

Where there is no distinction between the different versions of the above application, the

general term "Adobe Acrobat" is used.

Manufacturer

PFU LIMITED

International Sales Dept., Imaging Business Division, Products Group

Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563,

Japan

Phone : (81-44) 540-4538

viii

■Note, Liability

READ ALL OF THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT. IF

THIS PRODUCT IS NOT USED CORRECTLY, UNEXPECTED INJURY MAY BE

CAUSED TO USERS OR BYSTANDERS.

While all efforts have been made to ensure the accuracy of all information in this manual,

PFU assumes no liability to any party for any damage caused by errors or omissions or by

statements of any kind in this manual, its updates or supplements, whether such errors are

omissions or statements resulting from negligence, accidents, or any other cause. PFU

further assumes no liability arising from the application or use of any product or system

described herein; nor any liability for incidental or consequential damages arising from the

use of this manual. PFU disclaims all warranties regarding the information contained herein,

whether expressed, implied, or statutory.

■Preface

Safety Precautions

This manual describes important details for ensuring the safe and correct use of this product.

Thoroughly read this manual before you start to use this product. In particular, be sure to

read and fully understand the Safety Precautions described in this manual before you use this

product.

Also, store this manual in a safe place so that it can be easily referred to during use of this

product.

Warning Indications Used In This Manual

This manual uses the following indications to ensure safe and correct use of this product, and

to prevent possible danger and injury to the operator and other persons.

Symbols Used In This Manual

This manual uses the following symbols in explanations in addition to warning indications.

WARNING

This indication alerts operators to an operation that, if not strictly observed, may

result in severe injury or death.

CAUTION

This indication alerts operators to an operation that, if not strictly observed, may

result in safety hazards to personnel or damage to equipment.

ATTENTION This symbol alerts operators to particularly important information. Be sure to read this

information.

Andere Handbücher für ScanSnap fi-5110EOXM

Inhaltsverzeichnis

Andere Fujitsu Scanner Handbücher

Fujitsu

Fujitsu S510M - ScanSnap - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu ScanPartner 15C Referenzhandbuch

Fujitsu

Fujitsu ScanSnap fi-5110EOX Bedienungsanleitung

Fujitsu

Fujitsu FI-5900C Handbuch

Fujitsu

Fujitsu FI-6000NS Handbuch

Fujitsu

Fujitsu ScanSnap iX500 Handbuch

Fujitsu

Fujitsu fi-680PRB Handbuch

Fujitsu

Fujitsu FI-5015C Handbuch

Fujitsu

Fujitsu fi 5750C - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu FI-4120C Referenzhandbuch

Fujitsu

Fujitsu fi-7160 Bedienungsanleitung

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Handbuch

Fujitsu

Fujitsu S510M - ScanSnap - Document Scanner Handbuch

Fujitsu

Fujitsu fi-4340C Konfigurationshandbuch

Fujitsu

Fujitsu SP-1120N Handbuch

Fujitsu

Fujitsu FI-5530C2 Referenzhandbuch

Fujitsu

Fujitsu FI-5530C2 Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap S1300i Handbuch

Fujitsu

Fujitsu fi-4340C Handbuch

Fujitsu

Fujitsu ScanSnap iX500 Bedienungsanleitung

Fujitsu

Fujitsu fi-65F Handbuch

Fujitsu

Fujitsu Fi-4750c - Color Duplex Document Scanner 50ppm 90ipm... Handbuch

Fujitsu

Fujitsu 6010N - fi - Document Scanner Handbuch

Beliebte Scanner Handbücher anderer Marken

Plustek

Plustek Scanner Bedienungsanleitung

Z/I Imaging

Z/I Imaging PhotoScan 2001 Bedienungsanleitung

Renkforce

Renkforce DS100-5M Bedienungsanleitung

Image Access

Image Access WideTEK A2 Bedienungsanleitung

Canon

Canon imageFORMULA CR-120N Bedienungsanleitung

GeoSlam

GeoSlam ZEB Horizon Montageanleitung

Kodak

Kodak i5800 Scanner Bedienungsanleitung

Kodak

Kodak i7300 Bedienungsanleitung

Revopoint

Revopoint POP Bedienungsanleitung

Eddyfi Technologies

Eddyfi Technologies Floormap X Bedienungsanleitung

Faselase

Faselase F6 Bedienungsanleitung

Uniden

Uniden BC340CRS Bedienungsanleitung

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Bedienungsanleitung

Mustek

Mustek PageExpress 4800 Pro Bedienungsanleitung

Optex

Optex 750830 Bedienungsanleitung

Innova

Innova 5210 Bedienungsanleitung

Visioneer

Visioneer CardReader 100 Kurzanleitung

Rohde & Schwarz

Rohde & Schwarz TSME6 Bedienungsanleitung
