Operating Manual - English

PRIMERGY CX270 S2

Server Node

Operating Manual

Edition July 2013

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]su.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any form without the prior written permission

of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

CX270 S2 Operating Manual

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the

product is used in a hot environment. The customer shall bear the cost of

replacing replaceable components which have exceeded their operating life.

Note that these are only guidelines, and do not constitute a guarantee of

trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured to be used in commercial

and/or industrial areas as a server.

When used as visual display workplace, it must not be placed in the direct field

of view to avoid incommoding reflections (applies only to TX server systems).

The device has not been designed or manufactured for uses which demand an

extremely high level of safety and carry a direct and serious risk of life or body

if such safety cannot be assured.

Operating Manual CX270 S2

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance

control in weapons systems (hereafter, "high safety use"). Customers should

not use this product for high safety use unless measures are in place for

ensuring the level of safety demanded of such use. Please consult the sales

staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market:

About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://jp.fujitsu.com/platform/server/primergy/harddisk/

CX270 S2 Operating Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Concept and target groups for this manual . . . . . . . . . . 8

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 9

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 10

2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 11

2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Server node specification . . . . . . . . . . . . . . . . . . . 14

3 Installation steps, overview . . . . . . . . . . . . . . . . . . 19

4 Important information . . . . . . . . . . . . . . . . . . . . . 21

4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 21

4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 30

4.4 Transporting the server node . . . . . . . . . . . . . . . . . 31

4.5 Environmental protection . . . . . . . . . . . . . . . . . . . 31

5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 33

5.1 Unpacking the server node . . . . . . . . . . . . . . . . . . 34

5.2 Installing a server node to the server enclosure . . . . . . . 35

5.3 Connecting devices to the server node . . . . . . . . . . . . 37

5.4 Notes on connecting/disconnecting cables . . . . . . . . . 39

Operating Manual CX270 S2

Contents

6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 41

6.1 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 41

6.1.1 Controls of the server node . . . . . . . . . . . . . . . . . . . . 41

6.1.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 42

6.1.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 42

6.1.1.3 LAN indicators . . . . . . . . . . . . . . . . . . . . . . . . . 43

6.2 Switching the server node on and off . . . . . . . . . . . . . 45

6.3 Configuring the server node . . . . . . . . . . . . . . . . . . 48

6.3.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 48

6.3.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 48

6.3.3 Operating system installation . . . . . . . . . . . . . . . . . . . 49

6.4 Cleaning the server node . . . . . . . . . . . . . . . . . . . . 50

7 Property and data protection . . . . . . . . . . . . . . . . . . 51

7.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 51

8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 53

8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 53

8.2 Server node switches itself off . . . . . . . . . . . . . . . . . 53

8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 54

8.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 54

8.5 No screen display or display drifts . . . . . . . . . . . . . . . 55

8.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 56

8.7 System will not boot . . . . . . . . . . . . . . . . . . . . . . . 56

8.8 Error message on screen . . . . . . . . . . . . . . . . . . . . 56

CX270 S2 Operating Manual 7

1 Introduction

Two PRIMERGY CX270 S2 server nodes, each in a half-wide, 2U form-factor,

are embedded as a set into a single 2U PRIMERGY CX400 multi-node server

enclosure, thus providing an aggregated scale-out performance of a total of 4

CPUs of the Intel® Xeon® processor E5-2600v2 product family. The dual

socket server nodes combine high performance and attractive purchase costs

with high energy efficiency while coming without any local fans or power supply

units. With up to 16 high bandwidth memory modules for up to 1024 GB capacity

and two top-bin CPUs out of the Intel® Xeon® processor E5-2600v2 family,

CX270 S2 server nodes have a great versatility to match very ambitious server

profiles and workload scenarios. Two main usage scenarios are high

performance computing and virtual client computing, the latter utilizing e. g.

Citrix XenDesktop, VMware View Premier, or Microsoft Windows VDS as

enabling software bases.

Besides two onboard 1 GbE ports, three PCIe Gen3 I/O slots are provided, one

for an x16 GPGPU card and the other for two x8 low profile card. Diverse

interfaces from 1 to 10 Gb Ethernet, 10 Gb Fibre Channel over Ethernet, up to

56 Gb FDR Infiniband may be used with LP cards.

Access to local storage drives is granted by assignment of up to six HDDs or

SSDs that are physically located in the PRIMERGY CX400 server enclosure.

Four SATA drives can flexibly be accessed via onboard controller with software

RAID 0, 1 (six w/o RAID); more drives, SAS drives, or additional RAID 5, 50, 6

is realized via RAID card with cache and optional BBU. Local system boot for

VMware ESXi is possible via USB Flash Module.

The highly compact server node occupies two height units (HU) in the server

enclosure.

8 Operating Manual CX270 S2

Introduction

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server

node.

This operating manual is intended for those responsible for installing the

hardware and ensuring that the system runs smoothly. It contains all the

information you need to put your PRIMERGY CX270 S2 server node into

operation.

To understand the various expansion options, you will need to be familiar with

the fields of hardware and data transmission and you will require a basic

knowledge of the underlying operating system.

CX270 S2 Operating Manual 9

Introduction

1.2 Documentation overview

More information on your PRIMERGY CX270 S2 server node can be found in

the following documents:

– "Quick Start Hardware - PRIMERGY CX270 S2 Server Node"

– "Quick Start Software - Quick Installation Guide"

– "Safety Notes and Regulations" manual

"安全上のご注意 " for the Japanese market

– "Warranty" manual

"保証書 " for the Japanese market

– "Returning used devices" manual and "Service Desk" leaflet

"サポート＆サービス " for the Japanese market

– "PRIMERGY CX270 S2 Server Node Upgrade and Maintenance Manual"

Further information

The PRIMERGY CX270 S2 Server Node is a multi-node system. For

information on the server enclosure please refer to the following manuals:

– PRIMERGY CX400 S2 Server Enclosure Operating Manua

– PRIMERGY CX400 S2 Server Enclosure Upgrade and Maintenance

manual

IAll documentation on PRIMERGY hardware and ServerView software is

available online from the Fujitsu manuals server at:

–http://manuals.ts.fujitsu.com (global market)

–http://jp.fujitsu.com/platform/server/primergy/manual (Japanese market)

The complete PRIMERGY documentation set can also be downloaded

as a DVD ISO image at:

–ftp://ftp.ts.fujitsu.com/images/serverview/manuals (global market)

–http://jp.fujitsu.com/primergy/downloads (Japanese market)

IFor the Japanese market:

Before using the product, please check for additional information that

may be available under the following URL:

http://jp.fujitsu.com/platform/server/primergy/products/note/

10 Operating Manual CX270 S2

Introduction

Further sources of information:

– ServerView Suite Glossary

– Manual for the monitor

– Documentation for the boards and drives

– Operating system documentation

– Information files in your operating system

1.3 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands or menu items.

"Quotation marks" indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.

Andere Handbücher für Primergy CX270 S2

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu PRIMEQUEST 3000 Series Bedienungsanleitung

Fujitsu

Fujitsu FUTRO S700 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M8000 Installationsanleitung

Fujitsu

Fujitsu SPARC Enterprise M4000 Technisches Datenblatt

Fujitsu

Fujitsu PRIMERGY TX1320 M3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 480 Technisches Handbuch

Fujitsu

Fujitsu PRIMERGY ECONEL 30 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2400E3 Bedienungs- und Wartungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M8000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX900 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX300 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX2550 M5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX620 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX600 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2450 M1 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX4770 M1 Bedienungsanleitung

Fujitsu

Fujitsu FUTRO S550 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX2550 M1 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 580A Technisches Handbuch

Fujitsu

Fujitsu Primergy BX900 S2 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
