GE 94902 Bedienungsanleitung
Universal
Remote Control
RM94902
INSTRUCTION
MANUAL
94902 Revised Size 2/25/02 4:03 PM Page 1
Table Of Contents
Button Description . . . . . . . . . . . . . . . . . . .1-3
Battery Installation . . . . . . . . . . . . . . . . . . . . .2
ProgrammingYour Universal Remote
TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Cable Box . . . . . . . . . . . . . . . . . . . . . . . .6
AUX/DVD or Other Device . . . . . . . . . . .7
Code Search . . . . . . . . . . . . . . . . . . . . . . . . . .8
Code Retrieval . . . . . . . . . . . . . . . . . . . . . . . .9
Menu Functions . . . . . . . . . . . . . . . . . . . . . .10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . .12
LostYour Codes? . . . . . . . . . . . . . . . . . . . . .13
Button Description
INDICATOR LIGHT
The Indicator Light flashes to show that the
remote is working.
POWER
The POWER button operates the same as your
original remote (note: some RCA, GE and
Proscan models require you to press the
device key to turn the device on and the power
key to turn the device off).
SETUP
Used to program the remote or to search
through codes.
TV,VCR, CABLE, DVD/AUX
TheTV,VCR, CABLE and DVD/AUX buttons are
used to select the device you want to control.
VOL & CHANNEL
The VOL (Volume) and CHANNEL buttons
operate the same as on your original
remote.The CHANNEL buttons are also used
to control the SKIP function for DVD and CD
Players.
1
94902 Revised Size 2/25/02 4:03 PM Page 2
MUTE
The Mute button operates the same as on
your original remote.
PREV CH
The PREV CH (Previous Channel) button oper-
ates the same as on your original remote.
0-9
The number buttons operate the same as on
your original remote, and are used for enter-
ing device codes.
TV•VCR
The TV•VCR button operates the TV•VCR func-
tion of your VCR.
ENTER
The ENTER button operates the same as on
your
original remote.
REV, PLAY, FOR, REC, STOP, PAUSE
The REV (Rewind or Reverse), PLAY, FOR
(Forward), REC (Record), STOP, and PAUSE
buttons operate the same as on your original
VCR or remote.You must press the REC button
twice to begin recording. TheVCR buttons can
also be used to control the functions for DVD
or CD Players.
MENU
The MENU button call ups the TV, DVD, and
Satellite set-up menus.
Battery Installation
Your RM94902 Remote requires two (2) new
AAA alkaline batteries.To install the batteries:
1. On the back of the remote, push down on
the tab and lift the cover off.
2.Match the batteries to the + and - marks
inside the battery case, then insert the
batteries.
3.Press the battery cover back into place.
2
94902 Revised Size 2/25/02 4:03 PM Page 3
Special Programming Feature
This remote can be programmed to control
any of these devices:
TV Satellite Receiver MiniShelf System
VCR DVD Player Audio Receiver
Cable Box CD Player
The TV device button is dedicated for a TV
only.The remaining buttons can be assigned
to any of the above devices (even though the
remote device buttons are screen-printed for
specific devices. Satellite and audio receiver
functions would be limited with this remote.
Button Description
3
94902 Revised Size 2/25/02 4:03 PM Page 4
Programming ForTV
1. Manually turn
on the TV.
2. Press and hold
the SETUP
button until the
INDICATOR LIGHT
lights, then release
the SETUP
button.
3. Press and release the
TV button (the
INDICATOR LIGHT will
blink then remain lit).
4. Find the three digit
code for your TV in
the code list in the
back of this book
and enter it using the
Number Buttons.
After your code
is entered, the
INDICATOR LIGHT
will turn off.
5. Aim the remote at
your TV and press
the POWER button.Your TV should turn off.
Note: If your TV does not respond, try all the codes for your
brand. If the codes do not work, or your brand is not listed,
try the Code Search method on page 8. NOTE: Sometimes
a code listed will only include limited functions. Try other
codes which may include more functionality.
6. With your TV on, press
CHANNEL UP. If the TV
responds, no further
programming is
required.
7. Enter your code here
for easy reference.
BLINK
OFF
TV CODE
4
94902 Revised Size 2/25/02 4:03 PM Page 5
Programming ForVCR
1. Manually turn
on the VCR.
2. Press and hold
the SETUP
button until the
INDICATOR LIGHT
lights, then release
the SETUP
button.
3. Press and release
theVCR button (the
INDICATOR LIGHT
will blink then remain
lit).
4. Find the three digit
code for your VCR
in the code list in
the back of this book
and enter it using
the Number Buttons.
After your code is
entered, the INDICATOR
LIGHT will turn off.
5. Aim the remote at your
VCR and press the
POWER button.Your
VCR should turn off.
Note: If yourVCR does not respond, try all the
codes for your brand. If the codes do not work,
or your brand is not listed, try the Code Search
method on page 8.
6. With your VCR on, press
CHANNEL UP. If theVCR
responds, no further
programming is
required.
7. Enter your code
here for easy
reference.
BLINK
OFF
VCR CODE
5
94902 Revised Size 2/25/02 4:03 PM Page 6
Programming for Cable Box
1. Manually turn on
the Cable Box.
2. Press and hold the
SETUP button until
the INDICATOR
LIGHT lights, then
release the SETUP
button.
3. Press and release
the CAB button (the
INDICATOR LIGHT
will blink then
remain lit).
4. Find the three digit
code for your
Cable Box in the
code list in the
back of this book
and enter it using
the Number Buttons.
After your code is
entered, the INDICATOR
LIGHT will turn off.
5. Aim the remote at
your Cable Box and
press the POWER
button.Your Cable
Box should turn off.
Note: If your Cable Box does not respond, try
all the codes for your brand. If the codes do
not work, or your brand is not listed, try the
Code Search method on page 8.
6. With your Cable Box
on, press CHANNEL
UP. If the Cable Box
responds, no further
programming is
required.
7. Enter your code here
for easy reference.
BLINK
OFF
CABLE BOX CODE
6
94902 Revised Size 2/25/02 4:03 PM Page 7
The DVD/AUX Button
The DVD/AUX button can be used for a DVD
player. It can also be assigned to any other
type of device you have (another TV, VCR,
Cable Box, Satellite Receiver, CD Player, Mini
System, or Audio Receiver).
1. Manually turn on
the the device you
wish to assign to
the DVD/AUX button
(TV, VCR or Cable
Box).
2. Press and hold
the SETUP
button until the
INDICATOR LIGHT
lights, then release
SETUP button.
3. Press and release
the DVD/AUX button.
The INDICATOR LIGHT
will blink.
4. Find the three digit
code for the device
you wish to program in
the code list in the
back of this book. Enter
the code using the Number
Buttons. After your code
is entered, the INDICATOR
LIGHT will turn off.
5. Aim the remote at your
device and press the
POWER button.Your
device should turn off.
Note: If your device does not respond, try all
the codes for your brand. If the codes do not
work, or your brand is not listed, try the Code
Search method on page 8.
6. With your device on,
press CHANNEL UP.
If the device responds,
no further program
ming is required.
7. Enter your code here
for easy reference.
BLINK
OFF
DVD/AUX CODE
7
94902 Revised Size 2/25/02 4:03 PM Page 8
8
Programming With Code Search
IfyourTV,VCR, or Cable Box does not respond
after you have tried all the codes for your
brand, or if your brand is not listed, try search-
ing for your code by following the steps
below.
1. Turn on the device
you wish to program.
2. Press and hold
SETUP until the
INDICATOR LIGHT
lights, then release
SETUP.
3. Press and release the
device button for the
device you are
programming (TV,VCR,
CAB/SAT, DVD/AUX).
The INDICATOR
LIGHT will blink once.
For AUX, press AUX
then the device button
you are assigning to AUX.
4. Press and release POWER
until your device turns
off. Important:You
may have to press
POWER up to 200 times.
5. When your device turns
off, press the ENTER
button, the INDICATOR
LIGHT will go off.
BLINK
94902 Revised Size 2/25/02 4:03 PM Page 9
Retrieving Codes
If you need to find the three-digit code for
your device, after your device is set-up using
Code Search, use this procedure.
1. Press and hold SETUP
until the INDICATOR
LIGHT lights, then
release SETUP.
2. Press and release the
device button for the
device’s code you
are retrieving (TV,
VCR or CAB). The
INDICATOR LIGHT
will blink once.
3. Press and release
SETUP. The
INDICATOR LIGHT
will turn off.
4. Starting with 0
on the keypad,
press the number
buttons in order (0-9)
until the INDICATOR
LIGHT blinks.
5. The number which
causes the
INDICATOR LIGHT
to blink is the first
digit of your code.
6. Repeat step 4 until you
have retrieved all three
numbers in the code.
9
BLINK
OFF
. . .
94902 Revised Size 2/25/02 4:03 PM Page 10
