Gefen COMPAUD-148 Bedienungsanleitung

1x8 Component

Audio DA

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday PST

Write To:

Gefen Inc.

C/O Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

[email protected]

www.gefen.com

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

1x8 Component Audio DA is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the 1x8 Component Audio DA

Speciﬁcations

Warranty

Congratulations on your purchase of the 1x8 Component Audio DA. Your complete sat-

isfaction is very important to us.

Gefen’s line of HDTV switches, extenders, and splitters are designed to make yourA/V

equipment use more comfortable, more productive and less expensive.

Gefen’s 1x8 ComponentAudio DAis a distribution hub that sends the same video out-

put to two or more HDTV digital screens. It is a ﬂexible solution that accommodates mul-

tiple displays. When two or more 1x8 Component Audio DAs are connected together,

they can be used to create a larger distribution.

The 1x8 Component Audio DA is connected using a Component video and audio cable

from the HDTV source to the 1x8 Component Audio DA input. There are eight Compo-

nent video and audio outputs. Digital and/or analog audio can be distributed using this

device.

The ex•tend•it line offers solutions for noise, space and security concerns, data center

control, information distribution, conference room presentation, school and corporate

training environments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime of support from a team of outstanding engineers.

INTRODUCTION

FEATURES

Features

• Connects up to eight component displays at the same time to one video source

• Allows simultaneous display

• Support SD(Composite, YCbCr) and HDTV(YPbPr, RGsB) Input signal

• Maintains 480i, 480p, 720p, 1080i, and 1080p resolutions

• Maintains high resolution video - beautiful HDTV resolutions up to 1080p are easily

achieved

• Installs in seconds

Includes:

(1) 1x8 Component Audio DA

(1) 6’ Component cable

(1) 5V DC 4 Amp Power Supply

(1) Users Manual

PANEL DESCRIPTIONS

Component

Video

Output 8

Component

Video

Output 7

Component

Video

Output 6

Component

Video

Output 5

Component

Video

Output 4

Component

Video

Output 3

Component

Video

Output 2

Component

Video

Output 1

Component

Video

Input

5V DC

Power

S/PDIF

Input

S/PDIF

Output 1

S/PDIF

Output 2

S/PDIF

Output 3

S/PDIF

Output 4

S/PDIF

Output 5

S/PDIF

Output 6

S/PDIF

Output 7

S/PDIF

Output 8

R/L

Audio

Input

R/L

Audio

Output 1

R/L

Audio

Output 2

R/L

Audio

Output 3

R/L

Audio

Output 4

R/L

Audio

Output 5

R/L

Audio

Output 6

R/L

Audio

Output 7

R/L

Audio

Output 8

LED Power Indicator

CONNECTING AND OPERATING THE 1x8 COMPONENT AUDIO DA

How to Connect the 1x8 Component Audio DA to your devices

1- Connect the supplied Component cable from the HDTV device into the Component

Input.

2- Connect either a SPDIF digital audio or RCA left and right analog audio cable into the

Component Audio Input.

3- Connect the cables from your displays (monitor or projector) into the Component Out

slots on the 1x8 Component Audio DA

4- Plug the 5v power supply into the 1x8 Component Audio DA.

5- Plug the 5v wallmount power supply into the wall outlet.

Note - Composite video can also be fed into the component video input to split and

distribute composite video.

SPECIFICATIONS

Input ................... YPbPr x1 or RGsB x1 (or RGBHV), or composite x3 1 Vp-p@ 75 ohm

Output ........................................... YPbPr x8, or RGsB(or RGBHV) x8, or composite 3x8

Audio input .......................................................................... Coaxial (SPDIF) x1 + R/L x1

Audio output ........................................................................ Coaxial (SPDIF) x8 + R/L x8

Analog audio input/output ..................................................... Audio 2 Vrms max 47k ohm

Bandwidth ................................................................................................. 480MHz (-3dB)

Video Range ........................................................................................................... 1080p

Differential gain ....................................................................................................... 0.05%

Differential phase ........................................................................................... 0.05 degree

Power Supply .............................................................................................. 5V DC 4 Amp

Dimensions .............................................................................. 17.5”W x 1.75”H x 6.75”D

Shipping Weight ....................................................................................................... 4 lbs.

Gefen Inc. warrants the equipment it manufactures to be free from defects in material

and workmanship.

If equipment fails because of such defects and Gefen Inc. is notiﬁed within two

(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace

the equipment, provided that the equipment has not been subjected to mechanical,

electrical, or other abuse or modiﬁcations.

Equipment that fails under conditions other than those covered will be repaired at the

current price of parts and labor in effect at the time of repair. Such repairs are warranted

for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or ﬁtness for any particular purpose,

all of which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cable must be free from any

scratches, markings, and neatly coiled.

The information in this manual has been carefully checked and is believed to be

accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may

be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,

special, incidental, or consequential damages resulting from any defect or omission

in this manual, even if advised of the possibility of such damages. The technical

information contained herein regarding 1x8 Component Audio DA features and

speciﬁcations is subject to change without notice.

WARRANTY
