GoMax Electronics VW-1312P Bedienungsanleitung

12-Display / 9-Display 4K2K Video Wall

Processor

User Manual

rev: 150409

Made in Taiwan

VW-1312P

Safety and Notice

The VW-1312P 12-Display / 9-Display 4K2K Video Wall Processor has been tested for

conformance to safety regulations and requirements, and has been certified for international use.

However, like all electronic equipments, the VW-1312P should be used with care. Please read and

follow the safety instructions to protect yourself from possible injury and to minimize the risk of

damage to the unit.

●Follow all instructions and warnings marked on this unit.

●Do not attempt to service this unit yourself, except where explained in this manual.

●Provide proper ventilation and air circulation and do not use near water.

●Keep objects that might damage the device and assure that the placement of this unit is on a

stable surface.

●Use only the power adapter and power cords and connection cables designed for this unit.

●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device

before cleaning.

TABLE OF CONTENTS

INTRODUCTION.................................................................................................................1

FEATURES.........................................................................................................................1

PACKAGE CONTENTS......................................................................................................1

SPECIFICATIONS..............................................................................................................2

HARDWARE INSTALLATION.............................................................................................3

CONNECTION DIAGRAM ..................................................................................................4

PANEL DESCRIPTIONS.....................................................................................................5

OPERATION APPROACH..................................................................................................7

EDID LEARNING..............................................................................................................17

WARRANTY .....................................................................................................................18

INTRODUCTION

The VW-1312P 12-Display / 9-Display 4K2K Video Wall Processor is a powerful, most cost

effective, and fully real time data/video processor for multiple flat panel displays or projectors. VW-1312P

can support up to 12 DVI/HDMI outputs to expand the spectrum of video wall applications. With add-on

card design concept, users can therefore adjust the number of output ports based on different scenarios.

Meanwhile, with the very same chassis of VW-1312P, the bandwidth of the video, the controllability of the

module, and the input complexity can be further explored to either cost down the project budget or

enhance with the new features from the new I/O cards.

Thru digital transmission, the quality of the outcome videos is guaranteed. The output display is

grained up to 255 by 255 squares. Virtually any setups for the display layout can be possible by the

provided software. The VW-1312P allows you to input DVI/HDMI, VGA, Component, wherever positions

and whatever sizes you want for viewing. The embedded scaler converts signals from two of input

sources to match the native resolution of monitors, flat panel displays, projectors as well as

user-selectable output settings up to WUXGA (1920x1200). The VW-1312P sends the resulting

processed video thru DVI/HDMI interface to the connected monitors/projectors based on the display

layout. The layout can be readily modified to fit your applications and optimize visual effects. Typical

applications include digital signage, and broadcasting/education/ surveillance systems, etc.

FEATURES

Up to 12 DVI outputs from 640x480 to 1920x1200 with a local loop out for monitoring

Support input rotation

PIP, side-by-side (PAP), full screen modes and adjustable size & position through software

Resize, position, flip, zoom output video

Each DVI output has an independent controllable display area

User-selectable output settings, up to 1920x1200

Image parameters and layouts are automatically saved in flash non-volatile of the device

and can be recalled for later use

Several image parameters and layouts can be saved in computers and can be loaded for

later use

Software control through RS-232 and Ethernet

Firmware upgradable for new features and technology enhancements

Support one of HDMI input resolution up to 4K2K@30Hz, other inputs up to 1080p/WUXGA

PCIE-interface add-on card design

Supports DVI/HDMI, VGA and Component input format from 640x480 to 1920x1200,

interfaced or progressive

Perfectly as a video screen splitter, a video converter and a video switcher

Can be cascaded to obtain more displays

HDCP compliant

Advanced video de-interlacer for improving 480i and 576i SD video input

2.5 RU size

PACKAGE CONTENTS

1x VW-1312P / VW-1312P-9X

2x DVI to HDMI adapter

1x User Manual

1x VGA to component breakout cable

1x Installation software CD

1x Rack-mounting ear set

1x AC power cord

1x USB to RS-232 cable

There are two kinds of the unit (9 outputs and 12 outputs), if you buy VW-1312P-9X, the output card

module cage #4 (output 10~12) is optionally available.

SPECIFICATIONS

Model Name

VW-1312P

VW-1312P-9X

Technical

Role of usage

Video Wall Processor

Output displays

12 outputs

9 outputs (up to 12)

Number of module cage

Input Format Support

DVI/HDMI / VGA/ Component

Output support

DVI/HDMI

HDCP compliance

Yes

Video bandwidth

DVI [Single-link 4.95Gbps[

HDMI [2.25G to 6.75Gbps]

Component [30MHz]

VGA [165MHz]

Input video support

Up to 1920x1200@60 / 4K2K@30

Audio Support

Control

RS-232 / Ethernet

Input TMDS signal

1.2 Volts [peak-to-peak]

ESD protection Human body model — ±15kV [air-gap discharge] & ±8kV [contact

discharge]

Input

2x DVI/HDMI + 1x VGA + 1x Component +1x RS-232 + 1x RJ-45

DVI connector

DVI-I [29-pin female, digital only]

VGA connector

HD-15 [15-pin D-sub female]

RS-232 connector

DE-9 [9-pin D-sub female]

RJ45 connector

WE/SS 8P8C

Mechanical

Enclosure

Metal enclosure

Dimensions

(L x W x H)

Model

44 x 37.47 x 13.12 cm

Carton

57 x 47 x 26.5 cm

Weight

Model

9.5 kg

9.16 kg

Package

11 kg

10.66 kg

Fixedness 2.5RU rack-mount with ears

Power supply

AC Power 100-240V

Power Consumption

30 Watts [max]

Operation temperature

0~40°C [32~104°F]

Storage temperature

-20~60°C [-4~140°F]

Relative humidity

20~90% RH [no condensation]

HARDWARE INSTALLATION

VW-1312P as master

1. Connect all sources to DVI/HDMI, VGA or Component Inputs on the VW-1312P.

2. Connect all displays to DVI/HDMI Outputs on the VW-1312P.

3. Connect the AC Power cord (100-240V) to the VW-1312P.

4. Power up the VW-1312P.

5. Switch on all devices connected and then control the display output through RS-232, Ethernet and

software.

CONNECTION DIAGRAM

PANEL DESCRIPTIONS

VW-1312P

Front Panel

Rear Panel

1. AC Power Supply

2. Input Port: DVI/HDMI input

3. Input Port: DVI/HDMI input, supports input resolution up to 4K2K@30

4. Input Port: VGA/Component input

5. RS-232 control: RS-232 control port

6. Power Switch: Power ON/OFF switch

7. Ethernet control: Ethernet control port

8. Output Port 1-12: DVI/HDMI outputs

The output card module cage #4 (output 10~12) is optionally available

SUPPORTED RESOLUTION

Input resolution supported

HDMI 1

HDMI 2

VGA

Component (YPbPr)

640x480

800x600 @60Hz

EIA 720x480p @59.95(60)Hz

720x480

1024x768 @60Hz

EIA 720x576p @50Hz

720x576 720x576 1280x720 @60Hz EIA 1280x720p @59.94 (60)Hz

800x600

1280x768 @60Hz

EIA 1920x1080i @59.94(60)Hz

1024x768

1280x960 @60Hz

EIA 1920x1080p @59.94(60)Hz

1152x864

1280x1024 @60Hz

1280x720

1360x768 @60Hz

1280x768

1400x1080 @60Hz

1280x800

1600x1200 @60Hz

1280x960

1920x1080 @60Hz

1280x1024

1360x768

1366x768

1400x1050

1440x240

1440x288(576i)

1440x900

1600x900

1600x1200

1680x1050

1920x540(1080i)

1920x1080

1920x1200

4K2K@30Hz

Output resolution supported

800x600@60

1024x768@60

1280x720@60

1280x1024@60

1366x768@60

1440x900@60

1440x1050@60

1600x1200@60

1920x1080@60

1920x1200@60

OPERATION APPROACH

Software Operation

System Requirements and Precautions

1. Whenever power off VW-1312P, please stay unpowered at least 5 to 10 seconds to allow power

capacitors to discharge.

2. The VW-1312P provides software control program which runs under Microsoft Windows 98, 2000,

XP, 7, 8 through the interface of RS-232 serial control.

3. Before you click on the icon of the software, make sure you have secured the connection between

your computer COM port and the VW-1312P.

Start the Software Control Program

When clicking on the executable file, the following dialog will pop-up. There are two ways to control the

VW-1312P device (under Microsoft Windows 7, please run as administrator).

RS-232 serial Mode: Use RS-232 to connect the port on device and computer. Select correct COM port

and click the button.

Ethernet Mode: Enter the device IP address and click the button.

After the software control setting is accomplished, it will enter the control interface directly.

Control Interface

1. Connection Status:

Show the connect information and status. If you use RS-232 serial control Mode to connect device,

the graph is . In contrast, the graph of Ethernet is .

2. Input Control:

In this part, you can set up the input source, source display mode and screen rotation.

(1) Source setting

Set the Input source. You can select at most two input source.

(2) Display mode

In here, we provide 7 default mode and one customize mode for you to select.

In the right part of control interface, users can customize the display mode thru controls.

The different colors of frame represents the different input sources. The information of

coordinate shows the position of input source screen. In different color frame, it will show a

white circle in the right corner. User can slide the white circle to resize the input source screen

or adjust the position by setting coordinate. Besides, user can also click the button

to make the window precedence.

(3) Input Rotation

Please take a closer look at this function. This function is only for full screen mode to use.

When selecting the full screen mode, the following window will pop-up. It has two directions to

rotate the input screen.

3. Output control

In this part, user can set up the output resolution, display setting and the output’s brightness and

contrast.

(1) Output Resolution

Set the output resolution. User can choose the desired display icon to select the output port*

and setup resolution. When setting the different resolution, the coordinate of output will also

be changed.

* If you buy VW-1312P-9X, the display output port will only show output 1~9.

(2) Display setting

There are two modes.

Custom

In Custom define mode, user can slide the white circle to adjust the size of the output

screen or enter the number to adjust the coordinate. In addition, if user wants to

understand or estimate which part you may select, it also can select the button

to show grid on the graph. After the setting, please click the button.

Quick Select

In Quick Select mode, user can define how to cut in both directions and the part you

desired to show on output TV.

(3) Contrast/Brightness

In here, user can adjust the brightness and contrast of output.

4. Advanced setting

(1) File Options

User can click the button to save all the configuration for future use. You can also

click the button to load and read back the configuration from the existing file.

(2) Learn EDID

Select Default EDID (1-4 default EDID).

(The default EDID of 4K2K only suit for HDMI 2)

Select Input.

Click button to learn EDID.

(3) View EDID content

Select the EDID input source (HDMI 1, HDMI 2).

Click button to read the EDID description and analysis.

(4) Input Card firmware update

Make sure your RS-232 is connected and the connection status is

Click the button to enter the interface.

Click button to select the firmware file which you want to update.

Click button and the firmware will start to update.

(5) Output Card firmware update*

* If you buy VW-1312P-9X, the output card will only show output 1~9.

Make sure your RS-232 is connected and the connection status is

Click the button to enter the interface.

Click button to select the firmware file which you want to update.

Click button and the firmware will start to update.

After firmware update, it will display the status of each output card.

(6) Factory Reset

Click button to do factory default reset.

This default reset process will take about 10 seconds.

After pop-up a dialog indicates “Finished”, please restart this machine.

5. IP Configure

You can also use the Ethernet to control software program. First, you should click the

button to setup network set. Next, you can read the Ethernet setting from device

or manually set to device. After the step of IP configuration, please restart the machine.

6. Info

Read the software and firmware version.

7. Refresh

This function can not only refresh the information of setting but also reconnect this device. You can

click button to update the control connection. After you click this button, pop-up a

“Reconnect” window, shows you can select the approach to connect this device.

EDID LEARNING

The EDID learning function is only necessary whenever you encounter any display on the HDMI

output port that cannot play video properly. Because the HDMI sources and displays may have various

level of capability in playing video, the general principle is that the source will output the lowest standards

in terms of video resolutions to be commonly acceptable among all HDMI displays. In this case, a 720p

HDMI signal output would be probably the safest choice. Nevertheless, the user can force the matrix to

learn the EDID of the lowest capable HDMI display among others to make sure all displays are capable to

play the HDMI signals normally.

There is a methodto do EDID Learning as below:

Software Control: Please refer to the Operation Approach\ Software Operation (Page 13.)

There are four embedded default EDIDsas below,

1. Full-HD(1080p@60)-24bit 2D | 2ch

2. Full-HD(1080i@60)(720p@60)-24bit 2D & 2ch

3. Full-HD(1080p@60)-30bit 2D | 2ch

4. 4K2K@30-24bit 2D & 2ch

WARRANTY

The SELLER warrants the VW-1312P 12-Display / 9-Display 4K2K Video Wall Processor free

from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or

an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,

The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to

accident, disaster, abuse or any unauthorized modifications including static discharge and power surge.

This warranty is offered by the SELLER for its BUYER with direct transaction only. This warranty is void if

the warranty seal on the metal housing is broken.

Unit that fails under conditions other than those covered will be repaired at the current price of parts

and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment

to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss

or damage in transit. Under no circumstances will a unit be accepted without a return authorization

number.

The warranty is in lieu of all other warranties expressed or implied, including without limitations, any

other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly

disclaimed.

Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible

for shipping charges to and from the SELLER. Cables and power adapters are limited to a 30 day

warranty and must be free from any markings, scratches, and neatly coiled.

The content of this manual has been carefully checked and is believed to be accurate. However, The

SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The

SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting

from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the

technical information contained herein regarding the VW-1312P features and specifications is

subject to change without further notice.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere GoMax Electronics Medienkonverter Handbücher

GoMax Electronics

GoMax Electronics CV-53A Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-5004MZ2-UF Bedienungsanleitung

GoMax Electronics

GoMax Electronics SP-9112 Bedienungsanleitung

GoMax Electronics

GoMax Electronics SP-5008PZ Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-5022 Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-300 Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-1004PF Bedienungsanleitung

GoMax Electronics

GoMax Electronics SP-2003 Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-503MLR Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-5004MZF Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-509 Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-305MLR Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-3004F Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-503M Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-523 Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-5004MZ2E-CF Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-3004 Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-105S Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-511 Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-910S Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-35AK Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-1010 Bedienungsanleitung

GoMax Electronics

GoMax Electronics MX-5004MZ2F Bedienungsanleitung

GoMax Electronics

GoMax Electronics CV-513ZK-BI Bedienungsanleitung

Beliebte Medienkonverter Handbücher anderer Marken

SoundTraxx

SoundTraxx Blunami BLU-2200 Bedienungsanleitung

SPROLINK

SPROLINK VA1 Bedienungsanleitung

Acclaim Lighting

Acclaim Lighting DDC-1-AC Bedienungsanleitung

Nikon

Nikon AF-S TC-20E III Bedienungsanleitung

Axis

Axis AXIS Q7406 Bedienungsanleitung

Omega

Omega TAC80B-J Bedienungsanleitung

Zoom

Zoom Thunderbolt TAC-2R Bedienungsanleitung

OST

OST iConverter 10/100M Bedienungsanleitung

Vertiv

Vertiv Netsure Bedienungsanleitung

birddog

birddog MINI Bedienungsanleitung

Roland

Roland GI-10 Bedienungsanleitung

Wallenstein

Wallenstein WX310 Bedienungsanleitung

Pace

Pace MSS 200-1 Bedienungsanleitung

Solar Converters

Solar Converters EQ 12/24-50 Bedienungsanleitung

CYP

CYP EL-7400V Bedienungsanleitung

TIE

TIE MIDI 1i1o Bedienungsanleitung

DCS

DCS Vivaldi Upsampler Bedienungsanleitung

Westermo

Westermo MCW-211 SERIES Bedienungsanleitung
