Grundig GD-RT-BC30004N Bedienungsanleitung

Quick Guide

About this guide

The guide includes instructions for using and managing the product.

Pictures, charts, images and all other information hereinafter are for

description and explanation only. The information contained in the

guide is subject to change, without notice, due to firmware updates

or other reasons.

Please find the latest version at WWW.GRUNDIG-SECURITY.COM

Limitation of Liability / Legal Disclaimer

Abetechs GmbH (Grundig Security) undertakes all reasonable efforts

to verify the integrity and correctness of the contents in this

document, but no formal guarantee shall be provided. Use of this

document and the subsequent results shall be entirely on the user’s

own responsibility. Abetechs GmbH (Grundig Security) reserves the

right to change the contents of this document without prior notice.

Design and specifications are subject to change without prior notice.

The product described herein, with its hardware, software and

documentation is provided “as is”, without any warranty, expressed

or implies, including without limitation, merchantability, satisfactory

quality, fitness for a particular purpose, and non-infringement of a

third party.

In no event will our company and its employees or agents be liable to

you for any special, consequential, incidental, or indirect damages,

including among others, damages for loss of business profits,

business interruption, or loss of data or documentation, in

connection with the use of this product, even if our company has

been advised of the possibility of such damages.

Regarding to products with internet access, the use of the product

shall be wholly at your own risks. Our company shall not take any

responsibilities for abnormal operation, privacy leakage or other

damages resulting from cyber-attack, hacker attack, virus inspection,

or other internet security risks; however our company will provide

timely technical support if required. Surveillance laws vary by

jurisdiction before using this product in order to ensure that your use

conforms to the applicable law. Our company shall not be liable in the

event that this product is used with illegitimate purposes.

In the event of any conflicts between this manual and the applicable

law, the later prevails.

Trademark

Each of trademarks herein is registered. The name of this product and

other trademarks mentioned in this manual are the registered

trademark of their respective company.

reproduced, distributed or changed, partially or wholly, without

formal authorization.

OPEN SOURCE SOFTWARE LICENSE INFORMATION

The software components provided with Grundig products may

contain copyrighted software that is licensed under various open-

source software licenses. For detailed information about the

contained open-source software packages, the used package

versions, license information and complete license terms, please

refer to the product detail pages on our website. The complete open-

source software license information is also included in firmware files

of affected products. Please also check your product’s CD-ROM and

manuals for additional information.

You may obtain the complete corresponding open-source part of a

specific product from us for a period of three years after our last

shipment of this product by sending an email to: info@grundig-

security.com

Safety and Installation Instruction

Introduction

Please read these instructions carefully and keep them for future

reference. You must heed all the warnings and cautions as well as

follow all the safety and installation instructions.

The appearance of the products, functions and firmware or software

upgrade may differ from this manual.

GRUNDIG reserves the right to perform needed changes without prior

notice.

Safety Instructions

Make sure that you only use the power adapter that is specified in the

specifications sheet of the product. If you use any other adapter or

connect the power supply incorrectly, this may cause explosion, fire,

electric shocks or damage the product. Do not connect several

devices to one power adapter as this may cause an adapter overload

and can lead to over-heating and fire. Make sure that the plug of the

power adapter is firmly connected to the power socket.

Do not place containers with liquids on the product. Do not place

conducting items like tools, screws, coins or other metal items on the

product. These may fall from the product or can cause fire or electric

shocks or other physical injuries.

Do not push or insert any sharp items or any objects into the device

as this may cause damage to the product, fire, electric shocks and/or

physical injuries.

Do not block any ventilation openings, if there are any. Ensure that

the product is well ventilated to prevent any over-heating. Do not

subject the device to physical shock or drop the product.

If the product uses batteries, please use a battery type that is

recommended by the manufacturer. Improper use or replacement of

the battery may result in the hazard of explosion.

Do not use any accessories that are not recommended by GRUNDIG.

Do not modify the product in any way.

If the product starts to smell or smoke comes out of the device,

immediately stop using the product and disconnect it from the power

supply to prevent fire or electric shocks. Then contact your dealer or

the nearest service center.

If the product does not work correctly, contact your dealer or nearest

service center. Never open, disassemble or alter the product yourself.

GRUNDIG cannot accept any liability or responsibility for problems

caused by attempted and unauthorized repair and maintenance.

Installation Instructions

It is necessary to fix the device firmly if the product is installed on a

wall or ceiling. Do not install the product on surfaces or in places that

are vibrating. Do not install the product near radiation sources.

Do not install the product near heat sources, like radiators or other

equipment that produces some heat. If the product is not classified

by any IP class, do not install the product in very cold or hot

temperatures (please refer to the working temperature specified in

the specification sheet of the product), dusty, dirty or damp

environment.

If the product is classified by any IP class, never touch the product

cover directly with your fingers, because the acidic sweat of the

fingers may damage the surface coating of the product cover. To clean

the inside and outside of the product cover, use a soft and dry cloth.

In any case, do not use alkaline detergents. The correct configuration

of all passwords and other security settings is the sole responsibility

of the installer and/or end-user (this applies especially to IP Cameras

and Recorders).

Special Installation Instructions for Recorders (NVRs and DVRs)

Make sure that the last actual firmware is installed on the IP Device.

You may get the actual firmware from www.grundig-security.com

website or from tech-support@grundig-security.com.

Make sure that the product is secured after installation and locate the

recorder in safe places where children are not able to reach it.

Make sure the device is properly secured to a rack or shelf. Major

shocks or jolts to the unit as a result of dropping it may cause damage

to the sensitive electronics within the unit.

Make sure the device is installed in a room that is well-ventilated and

dust-free.

Power down the unit before connecting and disconnecting

accessories and peripherals.

Only use an HDD for this device that is recommended by GRUNDIG.

The USB flash drive can only be connected to the USB-port of the

device.

Use the device in conjunction with an UPS if possible.

To clean the product, gently wipe the outside with a clean dry cloth.

Table of content

1 Rear Panel Interfaces Description .................................................. 9

2 Installation and Connections ....................................................... 10

DVR Installation ................................................................. 10

HDD Installation ................................................................ 10

Bracket Installation ............................................ 10

Fix-on-Bottom Installation ................................. 11

RS-485 and Camera Connection ........................................ 12

3 Menu Operation .......................................................................... 13

3.1 Startup .............................................................................. 13

Activate Device .................................................................. 13

Set Unlock Pattern ............................................................. 15

User Login ......................................................................... 16

User Logout, Shutdown and Reboot .................................. 17

Configure Signal Input ....................................................... 17

Network Settings ............................................................... 18

Configure General Settings ................................ 18

SCMS 19

Add IP Cameras ................................................................. 20

Connect PoC Cameras ....................................................... 21

Live View ......................................................................... 22

Recording Settings ........................................................... 23

Playback .......................................................................... 23

4 Accessing by Web Browser .......................................................... 24

1 Rear Panel Interfaces Description

The rear panel interfaces vary with different models. Refer to Table

1-1 for the common interface description of rear panels.

Common Interfaces Description of Rear Panels

Item Description Item Description

VIDEO IN

BNC interface

for Turbo HD

and analog

video input

VIDEO

OUT

BNC connector

for video output

AUDIO IN RCA connector AUDIO

OUT RCA connector

LINE IN

Connector for

two-way audio

input

USB

Interface

USB port for

additional

devices

VGA

DB15 connector

for VGA output.

Displays local

video output

and menu.

HDMI

HDMI video

output

connector

RS-485

Interface

Connector for

RS-485 devices

RS-232

Interface

Connector for

RS-232 devices

LAN Connector for

network eSATA

Storage and

expansion

interface for

record or backup

ALARM

IN/OUT

Connector for

alarm

input/output

GND Ground

Power

Switch

Switch for

turning on/off

the device

Power

Supply

100 to 240 VAC,

48 VDC, or 12

VDC for different

models

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Grundig DVR Handbücher

Grundig

Grundig GDVR-3080 Bedienungsanleitung

Grundig

Grundig GV 6400 HiFi/5 Bedienungsanleitung

Grundig

Grundig VIVANCE GV 3143 HIFI Bedienungsanleitung

Grundig

Grundig GPVR1250 Bedienungsanleitung

Grundig

Grundig GRA-D2208B Bedienungsanleitung

Grundig

Grundig Freeview GDVR1TBFV Bedienungsanleitung

Grundig

Grundig GDVR501FV Bedienungsanleitung

Grundig

Grundig VIVANCE GV 3200 VPS Bedienungsanleitung

Grundig

Grundig XERIA GV 6263 HIFI Bedienungsanleitung

Grundig

Grundig XERIA GV 5153 HIFI Bedienungsanleitung

Grundig

Grundig GV 26 Series Bedienungsanleitung

Grundig

Grundig GRH-K1004A Bedienungsanleitung

Grundig

Grundig VIVANCE GV 3042 NIC Bedienungsanleitung

Grundig

Grundig VIVANCE GV 3242 NIC/2 Bedienungsanleitung

Grundig

Grundig GV 640 HiFi Bedienungsanleitung

Grundig

Grundig GV9000 Bedienungsanleitung

Grundig

Grundig GDV-B2208A Bedienungsanleitung

Grundig

Grundig GRT-K1104A Bedienungsanleitung

Grundig

Grundig GV 403 Bedienungsanleitung

Grundig

Grundig GV 400 Bauanleitung

Grundig

Grundig GUFSDTR320HD Bedienungsanleitung

Grundig

Grundig GV 464 HIFI VPT Bedienungsanleitung

Grundig

Grundig GV 709 M Bedienungsanleitung

Grundig

Grundig DVR Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
