LCD DVR COMBO
(Model : GLM-154)
USER’S
MANUAL
Firmware Version 2.4
Revision Date : 2005. 03. 25
•INDEX
■CHAPTER 1 –System Structure
1.1 System Specification ----------------------------------------------- 4
1.2 Set and Accessories -------------------------------------------------- 5
1.3 External Organization of System ---------------------------------------6
■ CHAPTER 2 - Description
2.1 Front Panel ------------------------------------------------------- 7
2.2 Rear Panel ---------------------------------------------------- 8
2.3 Remote Controller -------------------------------------------- 9
■ CHAPTER 3 - Installation
3.1 Hard Disk Installation ------------------------------------------------ 10
3.2 Camera Connection ------------------------------------------------ 11
3.3 Monitor Connection ------------------------------------------------- 11
3.4 Network Connection ------------------------------------------------ 11
3.5 Alarm / Relay / PTZ Connection ------------------------------------------- 12
3.6 System initial START (Power Connection)-------------------------------- 13
※ Hard Disk Format ------------------------------------------------- 13
■CHAPTER 4 -Display
4.1 System Power ON --------------------------------------------------- 14
4.2 Select Screen Mode ------------------------------------------------- 14
4.3 Convert Screen Mode ------------------------------------------------ 15
4.4 Control PTZ / Focus Control --------------------------------------------- 15
4.4.1 PTZ / Focus Menu ---------------------------------------------------15
4.4.1.1 PTZ Control -------------------------------------------------------16
4.4.1.2 Focus / IRIS Control ------------------------------------------------16
4.4.1.3 PRESET Control ----------------------------------------------------17
4.4.1.4 Swing Control -----------------------------------------------------17
4.5 System Power OFF -------------------------------------------------- 18
■CHAPTER 5 -Search
◎ Go to Search ----------------------------------------------- 19
5.1 Search by Date/Time ------------------------------------------------ 19
5.2 Search by Event -------------------------------------------------- 20
1
•INDEX
■ CHAPTER 6 - Menu
◎ Go to Menu ----------------------------------------------------- 21
◎ Initial Menu Display ---------------------------------------------- 21
6.1 Display --------------------------------------------------- 22
6.2 Record ---------------------------------------------------- 22
6.2.1 Size/Rec. Rate/Quality ------------------------------------ 22
6.2.2 Timer Recording Setup ------------------------------------23
6.2.3 Motion Detection Setup -----------------------------------24
6.2.4 Alarm Recording Setup -------------------------------------- 24
◎ Time Recording Weekly Setup -------------------------------------- 25
◎ Partial Motion Region Setup ----------------------------------------- 26
6.3 Camera ---------------------------------------------------------- 27
6.3.1 Status/Title Setup ----------------------------------------------- 27
6.3.2 Covert/PTZ Setup --------------------------------------------- 27
6.3.3 Color Setup -------------------------------------------------- 28
6.4 AUDIO ------------------------------------------------------28
6.4.1 Audio Recording Setup ----------------------------------------- 28
6.4.2 Live Audio Setup ---------------------------------------------- 29
6.5 ALARM ---------------------------------------------------- 29
6.5.1 Alarm Input Setup ----------------------------------------------- 29
6.5.2 Relay Output Setup ---------------------------------------------- 30
6.6 SYSTEM -----------------------------------------------------30
6.6.1 Date/Time ----------------------------------------------- 30
6.6.2 Network Setup TCP / IP----------------------------------- 31 ~ 32
6.6.3 Buzzer Setup ----------------------------------------------- 33
6.6.4 Password -------------------------------------------------33
6.6.4.1 Administrator Password ---------------------------------33
6.6.4.2 Manager Password ------------------------------------- 34
6.6.4.3 Operator Password ------------------------------------ 34
6.6.4.4 Network Password ------------------------------------ 34
6.6.5 Disk Write Mode -------------------------------------------- 35
6.6.6 System Information -------------------------------------- 35
6.6.7 Factory Default --------------------------------------------- 35
2
•INDEX
■ CHAPTER 7 - Remote Agent
◎ System Requirement ------------------------------------------- 36
◎ DVR Remote Agent 1.0 Installation ------------------------------- 36 ~ 38
7.1 Monitoring
7.1.1 Function Introduction ---------------------------------------- 39
7.1.2 Screen Division Selection -------------------------------------- 40
7.1.3 PTZ Control ------------------------------------------------- 40
7.1.4 Selection Network ID ----------------------------------------- 40
7.1.5 AVI File Conversion ------------------------------------------- 41
7.1.6 Color Adjustment -------------------------------------------- 41
7.2. Search
7.2.1 Function Introduction ----------------------------------------- 42
7.2.2 Search Method ----------------------------------------------- 43
7.2.3 Search Option ----------------------------------------- 44 ~ 48
7.3. Setting
7.3.1 Connection ID Setup ------------------------------------------- 49
7.3.2 Option Setting ------------------------------------------------ 50
7.3.3 DVR Server Remote Setup -------------------------------------50 ~ 52
■CHAPTER 8 –Web Client --------------------------------------------- 53 ~ 54
3
1.1 System Specification
4
• Chapter 1 – System Structure
4 lnputAudio lnput
10/100BASE- TX EthernetLAN
Button or IR RemoconSystem Operation
Mono 1WSpeaker
4 lnput / 1 OutputAlarm / Relay
RS-485P/T/Z Control & Port
Composite Video (BNC x 1)Video Output
100/130(CR≥10)
Viewing Angel
[˚,U/D/L/R]
16Response Time [ms]
450Luminance [cd/㎡]
60Color Saturation(%)
600:1Contrast Ratio
1,024 x RGB x 768Resolution
32bit DSPCPU
?kgWeight
350(w)×315(H)×65(D)mm (Stand not included)Dimension
DC12V, 5A (Adaptor)Power
5~40˚C/ 20~80%RHOperating Temp and Humidity
-20~65˚C / 20~80%RHStorage Temp and Humidity
Auto- Rebooting, Auto- Scan and Recovery for Data System Recovery After Power Failure
Remote Pan/Tilt/Zoom/Focus/IrisRemote Control
Remote Live Viewing, Remote Playback and Remote File copy
Playback, Network Transmission, Recording (Triplex operation)
Remote Transmission
Supports the Setting of Motion Sensitivity per CameraMotion Detection
Setting Recording Schedule per cameraRecording Schedule
Continuous, Motion Detection and Sensor ActivatedRecording Modes
3~5Kbyte @352×240 (PAL :352×288)
5~10Kbyte @704×240 (PAL : 704×288)
6~16Kbyte @704×480 (PAL : 704×576)
Byte Size per image
MPEG4 (Modified)Compression Method
NTSC : 352×240, 704×240, 704×480
PAL : 352×288, 704×288, 704×576
Recording Resolution
30/25704×480
60/50704×240
120/100352×240
Recording
Speed
1/4 Channel ModeScreen Modes
Composite Video RJ45 x 4 or BNC x 4 (NTSC/PAL)Video Input
RTOSOS
80GBHDD
LCD PANEL
1.3 Set and Accessories
GLM-154 Set
Remote Controller
User’s
Manual
AAA Battery X 2
DC12V Adaptor Power Cord
• Packing Components
5
Please confirm accessories when you open packing box.
Installation CD
ROM Camera set (Optional)
• System Organization
1.4 External Organization of System
6
Remote Client PC
Image Printer
NETWORK
Alarm Sensor #1~4 Relay Out
GLM-154
Camera #1~4
Video In
Video Out
TCP/IP
Alarm
Input/Out
Remocon
Monitor
7
• Chapter 2 - Description
① Power : System Power On/Off.
② LED Indicator : Indicate System working Status
•POWER : System On/Off
• RECORD : Record On/Off
•NETWORK : Client Network Connect On/Off
•ALARM : Alarm Sensor On/Off
③ Channel Select Button : When Select Channel or Input Password
④ SCR Mode : When Select Screen Division Mode or Rotation Mode
⑤ Menu : Go to System Menu
⑥ Search : Go to Search Mode for Searching Recorded Video
⑦ PTZ/Focus : Go to Camera PTZ/Focus Control
⑧ Remote Controller Sensor Input (Refer to using of remote controller)
⑨ Search Controller & Volume Control :
Search Recorded video, Control Menu, PTZ/Focus and adjust volume of speaker
⑩ Enter : Press Enter to Apply Changing Setup
⑪ Return : Cancel Setup or Return Previous Mode
2.1 Front Panel
Tip • Channel Selection Button is prior to SCR mode.
• When Remote Controller Sensor Input is blocked by something, it cause
1remote controller do not work properly.
• When press any button, it operate with Beep Sound.
②⑤⑦⑨⑪
⑧①③ ④⑥⑩
VOL
8
• Description
① Video In : 4 Camera Connectable
(Reference to Page 60, GLM-154 PTZ available Camera Products)
② Monitor Out : Output DVR Video when connected AV Monitor
③ Ethernet (TCP/IP) : Connect Port for LAN Cable
(Possible to Remote Survey to Connect to Client)
④ Alarm / Relay / RS-485 : Connect Port for Sensor & Relay, PTZ (Pan / Tilt / Zoom)
⑤ DC Power Input Terminal : Power is Supplied by DC 12V Adaptor
2.2 Rear Panel
Tip • When System Installation, Please after System Off, connect Rear Panel
• Please Power Supply Use Specific Adaptor
①③④⑤
②
9
• Description
PTZ/IRIS
Mode
• Unused Button’s Description is Omitted.
• Every Button is Operated Same as Front Panel Button.
• Remote Controller can Operate when Remote Controller Sensor Input Part Reacted.
※Caution : If there are many DVRs at the same place,
they are operate together when press remote controller
Channel Select Button
(4ch Available, #1~4 Button)
POWER
System
ON/OFF
MENU: Open menu
RETURN
Cancel
Setup or
Return to
Previous
ENTER: Apply Setup Change
Change
Screen Mode
Open
Search Mode
Search Controller : Control Playback Option
(EX. Speed of Playback, Move on Menu,
1Control PTZ/Focus)
2.3 Remote Controller
