Haicom HI-604X Bedienungsanleitung

HI-604X

Easy Manual

HI-604X GPS Tracking Device with 3-years

Standby Battery/IP56 waterproof

INTRODUCTIONS:

This is a multi-function state-of-the-art GPS tracking solution offering you all in one solution

GPS/GSM/GPRS/SMS all in real time - the most flexible tracking device in the world - a great

marriage of the latest technology and affordability.

With HI-604X multi function tracker, one can track, remote control, tapping any object

globally in real time on the map. User can check the real time location from the GPRS

tracking web site or using the Haicom Tracking software installed on the PC and check the

real time position on the map via the regular dial tone transmission.

HI-604X tracking Device is the best tracking solution for use in the widest range of

applications, from motor homes to mobile home, from cars to caravans, from agricultural

machinery to construction equipment, from containers to golf carts – all the assets that you

feel could be at risk, especially if they do not have their own source of power.

Just place the tracker where there is no metal material on above, user can see his valuable

anytime, anywhere from any computer. The waterproof case allows the tracker still

functioning even though under tough and harsh environment. The build in big battery

provide the independent power supply even if there is no external power supply. The moving

sensor will let the tracker totally switch off (only the microchip standby: 2 mAh) and the

tracker can operate very long, could be years, if there is not much movements. With the

moving sensor, the tracker will not drain the car battery when the tracker connected to

external battery power.

Features

Haicom Asset Tracking Solution offers you a lot of advantages

Quad band 850/900/1800/1900 MHz GSM system

External SiRF Star III high performance GPS receiver

Internal GSM active antennas

Advanced communication via SMS/TCP/UDP/HTTP

Program, control and update firmware the tracker from the OTA (Over the Air) web

tracking platform and also USB configurations

Build in motion sensor for power saving

Support emergency/ over speed/ motion/ power lost alarm

Real time location report on preferred interval and vehicle status monitoring

Premium functions: Fast GPS Fixed/ A-GPS/ Geo-Fencing/ Hands free Kit/ Anti-Theft/ Data

Logger function with 8MB memory size with 100,000 records or more

Low battery alarm and battery voltage status

• Our GPRS tracking software Platform and server is free; if you have your own server we

can program our tracker with your server protocol

• Worldwide coverage with NO additional programs to buy or install - no additional or hidden

costs!

• Built-in moving sensor with deep sleeping mode (2mA)

• Built in 5,500 mAh battery for independent power

• Stand-by deep sleeping time up to 180Days (depending on tracking frequency)

• Very high sensitivity GPS fixed

• Multi-ways tracking software plate form available

• Waterproof case for harsh condition environment

• Customizations for different tracking applications

• Comes with strong Magnetic mounting for easy attachment

• Stand alone (Internal Antenna - Self Contained Unit)

• Worldwide coverage using GSM/GPRS/SMS

• allow you to monitor both on demand or at regular intervals

• Ultra low power GPS.

• All-in-one design.

• Provides you 24/7 access to the location of all your assets.

• LIVE real-time tracking, configurable from every 20 second to 72hour GPRS updates!

• Give complete supervision into your operations by seeing how long

assets are sitting around in one place, when they start moving / stop moving etc.

• Establish how long the assets are being used (actual operations time).

• Warns when unauthorized/unwanted movement happens.

• Provides security and accountability.

• Enable the recovery of any stolen assets.

• View asset's history online from any computer

Applications

• Police Force and law enforcement Sector

• Private Investigations Sector

• GPS Asset Tracking

• GPS Cargo Tracking

• Surveillance Work

• Anti theft – both domestic and commercial

• Asset recovery

HI-604X Characteristics

Items

ItemsItems

Items

Specification

SpecificationSpecification

Specifications

Power Supply DC 5V

Backup Battery 5500mAh

Normal power consumption

Dimension 90.8mm x 52.3mm x 38.9mm

Operating temperature -20℃ to 55℃

Humidity 5% to 95% Non-condensing

Frequency GSM 850/900/1800/1900Mhz

GPS Chipset latest GPS SIRF-Star III chipset

GPS Sensitivity -159Db

GPS Frequency L1,1575.42 MHz

C/A Code 1.023MHz chip rate

Channels 20 channel all-in-view tracking

Position Accuracy 10 meters, 2D RMS

Velocity Accuracy 0.1 m/s

Time Accuracy 1 us synchronized to GPS time

Default datum WGS-84

Reacquisition 0.1 sec. , average

Hot start 1 sec. , average

Warm start 38sec. , average

Cold start 42 sec. , average

Altitude Limit 18,000 meters (60,000 feet) max.

Velocity Limit 515 meters / second (1000 knots ) max

Interface One input and one output

How The HI-604X GPS Tracker Works:

Once fully charged, the HI-604 battery can last up to 180 Days, depending on usage

frequency, it has a built-in movement sensor that can be configured directly to alert you on

your mobile phone and our server automatically when the object is moved or touched. The

owner can locate the asset at any time using our free of charge GPRS web tracking

platform or from your smart phone or real time SMS address hyperlink solutions. The

HI-604X can also be programmed to automatically report its position at regular pre-set

time intervals, which could be from every 30 seconds to every 72 hours. Also, set up to

weak up and send location back during the long sleep mode.

Getting Started:

1. Take out the waterproof side rubber seal and connect the 18 pin cable to HI-604 and plug

another end to the USB port from computer or to the AC power outlet with the AC

adaptor for power charging.

2. Place the SIM card on the SIM card tray and slid in the SIM card tray in. When the SIM

card tray inserted in place, the HI-604X power will switch on.

3. To switch off HI-604 power, simply push in the yellow dot with any pen.

Dimensions:

LED Indicator:

Standard Packing:

1. HI-604X main unit

2. SIM card tray

3. 18 pin to USB set up cable

4. AC power adaptor

5. DC cigarette lighter

6. mini CD with user manual
