Heinner V-Go Max Bedienungsanleitung

HCNF-V291F+/HCNF-

1SF+/

HCNF-V291BKF

•Vertical vacuum cleaner

•Power: 300 W

•Suction power: 90 W

VERTICAL VACUUM CLEANER

Model:

V-Go Max

HSVC-MB22.2BL

www.heinner.com

1. INTRODUCTION

Please read the instructions carefully and keep the manual for future information.

This manual is designed to give all necessary instructions concerning installation, use and maintenance of the

unit. In order to operate the unit correctly and safely, please read this instruction manual carefully before

installation and use.

2. CONTENT OF YOUR PACKAGE

➔Vacuum cleaner

➔User manual

➔Certificate of warranty

➔➔Declaration of conformity

3. SAFETY INSTRUCTIONS

GENERAL

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or

qualified persons in order to avoid a hazard.

This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the appliance in a safe way and

understand.

The hazards involved.

Cleaning and user maintenance shall not be done by children without supervision.

Children should not play with the appliance.

The appliance is only to be used with the power supply unit provided with the appliance.

The appliance must only be supplied at safety with extra low voltage corresponding to the

marking on the appliance.

If the batteries are damaged, it must be replaced by the manufacturer, its service agent or

qualified persons in order to avoid a hazard

The plug must be removed from the socket-outlet before cleaning or maintaining the

appliance.

Please keep the vacuum cleaner in a laid down position when storing.

www.heinner.com

The vacuum cleaner can't stand by itself, please put it to the base stand after use.

When you pause using the vacuum cleaner, please put it to the base stand or leave it in laid

down position.

Before charging, read the instructions.

For indoor use only, do not expose to rain.

WARNING: Explosive gases. Prevent flames and sparks. Provide adequate ventilation during

charging.

Disconnect the supply before making or breaking the connections to the battery.

Beware of the risk of being caught in hair and loose clothing.

The charger must not be used if the enclosure is damaged because this will cause hazard of

electric shock.

Damaged batteries must be replaced with new batteries of the same type provided by the

manufacturer.

The battery charger is designed for charging the rechargeable battery provided by the

manufacturer.

Do not use any other charger to recharge the battery provided by manufacturer and do not

try recharge other types of battery with this charger.

Also do not try to charge non-rechargeable batteries with this charger.

Before charging, check whether the voltage specified on the marking label corresponds to

the mains voltage.

During charging, the appliance must be placed in a well-ventilated area.

Keep the charger from all sources of heat.

Do not insert any item through the ventilation slots on the charger.

Do not expose the charger to rain, snow or any other environment of high humidity.

Do not immerse the appliance in water.

When separating the charger from the socket, pull the body of the plug rather than the

supply cord; this will avoid hazard.

Do not continue to use the appliance in such and similar cases: drop, impact by a heavy

object, other means of damage, etc. If it occurs, get the charger repaired by our service

agent.

Do not disassemble the battery charger by yourself to avoid fire hazard or electric shock.

Please remove the plug from the socket before cleaning or maintaining the charger.

www.heinner.com

4. PRODUCT DESCRIPTION

To clean higher spots, the accessory can be connected with the extension pipe.

5. OPERATION

Installation and use of wall mount

1. Place the wall mount horizontally on the wall and fix it with two screws. After cleaning the brush, reinstall

it in the reversed order as above.

Crevice nozzle

2-in-1 brush

Power adaptor

Extension tubes

Electric brush

Main body

www.heinner.com

2. Keep the cleaner in the power-off state and align the hook hole on the main body (back) to the hook of

the wall mount. After cleaning the brush, reinstall it in the reversed order as above.

Functional operation

1. Press the “Start Button” to start cleaning.

2. Press the “Start Button” again to stop cleaning.

3. The flashing of indicator 1, 2 and 3 at the same time indicates a warning requiring the service from

professionals.

4. The default mode after starting the cleaner is at Mid-level. Press the “Speed Regulation Button” to change

to the High-level. Press the button to change to the Low-level. The speed is regulated in the order of Mid-

level, High-level and Low- level in a circle.

5. Power indication during charging: indicator 1 blinks for low power, and the charging shall be continued.

The indicator 1 to indicator 3 are on at the same time for full power, which will be off after the cleaner has

been fully charged for a while.

6. Power indicator during operation (discharging): Indicator 1 to indicator 3 are on at the same time for

sufficient power, and the cleaner could be used. Indicator 1 blinks for low power and the cleaner shall be

charged timely.

Screw hole

Host hook hole

Wall-mounted hook

www.heinner.com

6. CLEANING AND MAINTANANCE

Disassembly, installation, and cleaning of dust cup

Disassembly of dust cup

Place the cleaner in the way shown in the picture with the hand grabbing the bottom of the dust cup.

Press the dust cup release button and pull down the dust cup to remove it.

Installation of dust cup

Push the dust cup upward into with the suction port facing outward, until a click could be heard.

Switch button

Indicator

Speed control

button

Lamp 2

(power indicator)

Lamp 3

(power indicator)

Lamp 1

(power indicator)

Dust cup release button

www.heinner.com

Cleaning of dust cup

Press the button and the bottom lid of the dust cup will open automatically, enabling one-touch dust to

empty.

Disassembly and cleaning of filter components

Ensure that the components are installed in place, otherwise product failure may be caused.

Do not let water get into the electrical components of the vacuum cleaner, otherwise product failure may be

caused.

1. Gently remove the filter components from the dust cup assembly by holding the tendon positions on both

sides with hands.

2. Remove the filter sponge and pat it; (filter sponge must not be tapped in reverse) (filter sponge must not

be tapped in reverse)

3. Remove the cyclone by rotating it as shown in the picture and clean it Clean (filter sponge must not be

tapped in reverse)

Dust cup release button

Filter

Flap down

Disassembly

Assembly

www.heinner.com

Disassembly and cleaning of electric brush

To ensure the normal operation of the electric brush, please clean it timely in case the rolling brush and

wheels are tangled or dirty.

When disassembling it for maintenance, please be sure to stop the operation of the electric brush.

Water is not recommended for cleansing the electric brush. The hairs winding on it could be removed with

scissors or a knife. The dust on the rolling brush could be removed with a hairbrush.

1. Press the button to remove the electric brush:

2. Rotate the brush end cap upward and remove it, then remove the brush and clean it. After cleaning the

brush, reinstall it in the reversed order as above. After cleaning the brush, reinstall it in the reversed order as

above.

Press

Brush end cup

www.heinner.com

7. TROUBLESHOOTING

In case of any abnormal conditions when using this product, please read the following table first.

Abnormal condition

Possible cause

Action

Three indicators blink

Floor brush or mite brush is entangled.

Ambient temperature is too high or too

low

Clean the floor by brushing or mite

brush.

Use the cleaner in a proper

environment

Electric brush does

not work

Any large garbage (e.g., packing film) is

rolled into the cleaner.

The brush is tangled by hair

Remove the hair on the brush.

Remove the garbage

Operation duration

shortened

Aged battery

The ambience temperature is too high

or too low.

The battery is not fully charged

Contact the store or post- sales

service to purchase a new battery.

Use the cleaner in a proper

environment.

Charge the cleaner

Suction power

weakened

Too much dust in dust cup

Filtering sponge is blocked.

Brush or accessory suction port is

blocked.

Not fully dried after washing with

water

Remove the garbage timely.

Clean the filtering sponge.

Remove the blocking things!

Put the components in a cool place

for drying after washing them with

water

The cleaner could

not be charged

Ambient temperature is too low or too

high during charging

Put the cleaner in a proper place for

charging at appropriate

temperature

Battery liquid

leakage

The battery is not used for a long time

Change the battery

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data available: Model

and Serial Number.

The information can be found on the rating plate. Subject to change without notice.

www.heinner.com

TECHNICAL DATA

Voltage

220-240V~50/60Hz

Power

300W

Suction power

90W

Noise level

82 dB

Thank you for purchasing this product. If you need support with your product, visit our website using the

links below.

Get User manuals: https://www.heinner.ro

Get Service information: https://www.heinner.ro

Environment friendly disposal

You can help protect the environment!

Please remember to respect the local regulations: hand in the non-working electrical

equipment’s to an appropriate waste disposal center.

HEINNER is a registered trademark of Network One Distribution SRL. Other brands and

product names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to

make any derivative such as translation, transformation, or adaptation without permission

from NETWORK ONE DISTRIBUTION.

www.heinner.com, http://www.nod.ro

This product is in conformity with norms and standards of European Community.

Importer: Network One Distribution

Marcel Iancu Street, 3-5, Bucharest, Romania

Tel: +40 21 211 18 56, www.heinner.com , www.nod.ro
