Heinner VARIO 700 Bedienungsanleitung

VACUUM CLEANER

VARIO 700

Model: HVC-V700BK

www.heinner.ro

Vacuum cleaner

Power: 1200W

Suction power: ≥270 W

www.heinner.com 1200W, 50Hz, 220-240V

Before using the appliance, please read carefully this instruction manual and keep it for future

reference.

This instruction manual is designed to provide you with all required instructions related to the

installation, use and maintenance of the appliance.

In order to operate the unit correctly and safety, please read this instruction manual carefully

before installation and usage.

I. INTRODUCTION

II. PACKAGE CONTENT

Vacuum cleaner

Furniture brush

2 in 1 nozzle

User manual

Warranty card

Va multumim pentru alegerea acestui produs!

www.heinner.com 1200W, 50Hz, 220-240V

III. SAFETY MEASURES

1. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

2. Children should be supervised to ensure that they do not play with the appliance.

3. If the supply cord is damaged, it must be replaced by the manufacture or its service

agent or a similarly qualified person in order to avoid a hazard.

4. For household use only.

5. Do not use for absorbing detergent, kerosene, glass, needle, cigarette ash, water,

match etc.

6. The appliance should not be exposed to heat.

7. Unplug the appliance from the mains supply Socket after use and before every

cleaning pull the mains cable, in order to disconnect the appliance from the mains.

8. Do not put any object into openings. Do not use with any opening blocked. Keep the

appliance free of dust, lint, hair etc.

9. Do not use the vacuum cleaner without dust container or dust filter in place.

10. Do not vacuum any flour, cement etc, in order to avoid the overloads.

11. The appliance should only be cleaned with a dry or damp cloth ,it should never

immersed in water. Do not use any solvents for cleaning.

WARNING:

If the suction openings of the unit, the hose or the tube are blocked, switch off the

vacuum clearer and remove the blocking substance before you start the unit again.

1. Do not operate the vacuum cleaner too close to hearter or radiators.

2. Before inserting the power plug into the wall outlet, make sure that your hands are

dry.

3. Before you start the unit, make sure to remove large or sharp objects that might

damage the dust tank and hose.

4. When pulling out the power plug from the wall outlet, pull the plug not the power

cord.

5. Do not use without all filters in place.

Note: If the supply cord is damaged, it must be replaced by manufacture, its service

agent or similarly qualified person in order to avoid a hazard.

WARNING:

Hold the plug when rewinding the cord. Do not allow the cord to whip when rewinding

www.heinner.com 1200W, 50Hz, 220-240V

IV. DESCRIPTION

www.heinner.com 1200W, 50Hz, 220-240V

V. USING INSTRUCTIONS

1. Connect the hose with vacuum cleaner.

Insert flexible hose into the air-intake. Press the knob until it clicks into the position.

Remove the flexible hose. Unplug the appliance and press the knob at the end of the

hose. Remove it from the air-intake opening.

2. Fit the telescopic to the angled pipe.

3. Fit the floor brush to the telescopic tube.

OPERATION

1. A yellow mark on power cord shows the ideal cable length. Do not expend the

cable beyond the red mark.

2. To rewind the power cord, press the rewinder pedal with one hand and guide the

cord with the other hand.

3. Press the power switch to switch the appliance on.

4. Use the electronic speed adjusting to control the suction power of the cleaner.

5. The suction power can be adjusted with the sliding control on the angled pipe too.

6. Put the telescopic tube into the fixing hook of the appliance when you have a

break.

Caution: Do not transfer the appliance when the fixing hook is used.

Crevice tool

For cleaning corner edge and draws etc. Where is difficult to reach, such as gaps and

the keyboard, bookshelf and windows.

Floor brush

Use of the selector on floor brush. Bristles extended for carpets. Bristles retracted for

hard floors.

If the angled pipe has blockage. Insert it into the air-intake and switch the appliance

on.

www.heinner.com 1200W, 50Hz, 220-240V

Empty the dust container

⑴After removing the flexible hose, press the cover lock button and open the dust

container.

⑵Remove the dust filter form the container

⑷Replace the dust filter in the container

⑷Close the dust container until it is locked in the position

Change filter

Replace the motor filter. Open the dust container and remove the motor filter. Fix the

new filter in the position.

Detach the grille by pulling firmly away form the appliance, remove the outlet filter and

replace remove the outlet filter and new filter. Fix the grille again

Clean the filter

Clean the filter in water and allow them to dry completely before replace them. Clean

the cloth dustbag with water and a little detergent (if needed). Allow the filter to dry

completely before replacing.

VI. CLEANING AND MAINTENANCE

www.heinner.com 1200W, 50Hz, 220-240V

Problem

Possible reason

Active

Motor does not start

-Power card not firmly plugged

into outlet

-Outlet damaged

-Cleaner not switch on

-Plug unit firmly

-Check the outlet

-Switch on the appliance.

Suction power is weaker

-unit clogged

-Dust filter needs cleaning

-Dust container not in position

-Filter blocked

-Remove the blockage

-Clean the dust filter

-Close the dust container

-Clean the filter

The wire can not be

winded completely.

The wire may diverge the wire

wheel.

Draw the wire a little then

rewind.

The wire can not be draw

out.

The wire may wind disorder

Press the rewinder button

and try again.

Speed adjust does not

work

Appliance is defective

Repair the appliance (only

specialist)

Power card winds

unwanted back

Rewind mechanisms is defective

Repair the appliance

(only specialist)

The dust container can

not be closed

Dust filter is not in the position

Fix the dust filter and try

again

Power

1200W

Suction power

≥270W

Voltage:

220-240 V, 50 Hz

Noise level

82 dB

Dust capacity:

1,5 L

VIII. TECHNICAL DETAILS

VII. TROUBLESHOOTING

www.heinner.com 1200W, 50Hz, 220-240V

Environment friendly disposal

You can help protect the environment!

Please remember to respect the local regulations: hand in the non-working electrical equipment’s to

an appropriate waste disposal center.

HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product

names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from NETWORK

ONE DISTRIBUTION.

www.heinner.com, http://www.nod.ro

http://www.heinner.com, http://www.nod.ro

This product is in conformity with norms and standards of European Community.

Importer: Network One Distribution

Marcel Iancu Street, 3-5, Bucharest, Romania

Tel: +40 21 211 18 56, www.heinner.ro, www.heinner.com

www.heinner.com 1200W, 50Hz, 220-240V

ASPIRATOR

VARIO 700

Model: HVC-V700BK

www.heinner.ro

Aspirator

Putere: 1200W

Putere de aspirare: ≥ 270 W

www.heinner.com 1200W, 50Hz, 220-240V

Înainte de a utiliza acest aparat, citiți cu atenție manualul de instrucțiuni și păstrați-l pentru

consultări ulterioare.

Acest manual este conceput pentru a vă oferi toate instrucţiunile necesare referitoare la

instalarea, utilizarea şi întreţinerea aparatului.

Pentru utilizarea corectă şi în siguranţă a aparatului, vă rugam să citiţi cu atenţie acest manual de

instrucţiuni înainte de instalare şi utilizare.

I. INTRODUCERE

II. CONȚINUTUL PACHETULUI DUMNEAVOASTRĂ

Aspirator

Perie de praf

Accesoriu 2 în 1 pentru spații înguste

Manual de utilizare

Certificat de garanție

Vă mulțumim pentru alegerea acestui produs!
