HISCO HD DVR User's Manual
1. INTRODUCTION DVR SYSTEM
This system is PC Architecture HD Digital Video Security System digitizing, compressively saving,
retrieving and generating output image information from cameras. Also, this system is Digital Video
Security System of Next Generation improving strong points and significantly complementing defects of
existing analog CCTV.
1-1. Digital Video Security System features
•Video Capture with variable bitrate or constant bitrate compression and recording directly on to
Hard Drive.
•Display Screen: Full screen, 4, 6, 9, 10, 13, 16, 20 split screen.
•Easy selectable for recording image resolution: 352x240, 704x240 and 704x480
•HD camera resolution is auto selected and recording by ratio of 1, 1/4, 1/6 .
•Pentaplex DVR: Live view, record, playback, backup and remote access
•Color Quality control: brightness, contrast, hue, saturation
•Multiple recording:
oMounting maximum 20 cameras, the system can record images onto HDD in the PC GUI
VCR style playback control. You can quickly retrieve images in files.
•Easy to set up the DVR system configuration:
oOn screen setup dialog allows you to set functions easily.
oExamples: the amount of Camera to operate, select camera position onto Screen in the
PC.
•Printing images: You can reproduce the selected images as JPG file, which can be printed out
with the PC printer.
•Archived Images can be backed up on to DVD+/-RW and USB HDD for long-term storage.
•Image recording directory managing (specify the recording directory on the HDD and check
function of the minimum capacity disk storage).
•Sensor/Motion Detector functions:
oWhen a sensor signal is received by the system or Motion detection is triggered, the
system immediately starts recording images onto the HDD. Sensor recording interval
and frame rate control can be adjusted.
•Optimized File System for image saving:
oFile System is to minimize the access time of the Disk and allows the maximum capacity
of the Disk to be utilized preventing the occurrence of Disk fragments. Because of
optimized file system for image saving was self-developed and applied by the DVR s/w,
damaged files can be recovered easily, and increased security is assured.
•Image retrieval:
oRecorded images of each camera can be extracted after retrieval of recorded images
on multiple cameras.
oPartial enlargement of retrieved image is possible and compensation function for image
quality allows sharpening and softening images.
oImages can be printed by a color printer and copied to a Flash drive.
•Supports remote access (Ethernet LAN (TCP/IP) as well as Pan/Tilt, Zoom in/out functions.
