Quick Specs HP Compaq dx2080 Micro tower Business PC

Available Technology and Featu

res

Rev 1.0 July 2007

HP Compaq dx2080 Microtower Business PC

Microtower

1.Monitor (sold separately) 6.2 external 3.5" drive bays for optional diskette drive

2.2-Button Scroll Mouse 7.2 PCI 2.2slots, 1 PCI-Ex1 slot.

3.HP Standard Keyboard 8.6 USB 2.0 ports, 1 serial port, 1 parallel port, 2 PS/2, 1 RJ-

45, 1 VGA, 1 audio in, 1 audio out, 1 MIC.

4.Front I/O –2 USB 2.0 ports & MIC, Headset 9.300-watt max power supply.

5.2 internal 3.5" drive bays

10.

2external 5.25" drive bays for optional optical drives

At A Glance

•Intel® Core 2 Duo,Pentium Dual Core,Pentium D, Celeron D,Celeron Conroe-L processors

•Choice of operating systems:

Microsoft Windows Vista Basic, Microsoft Windows Vista Business,

Microsoft Windows XP Professional, Microsoft Windows XP Home ,Free DOS , Red hat Linux WS

•Intel 945GZ Express chipset

•Maximum Memory support 2 GB

•Intel Graphics Media Accelerator 950

•Single or dual channel DDRII SDRAM system memory

•PCI Express I/O bus

•Integrated SATA II controller

•Integrated Ultra ATA/100 controller

•Integrated Realtek 10/100/1000 Network Connection

•Integrated Realtek High Definition Audio

•Choice of hard drives and optical drives

•Optional Internal Speaker

•UL and FCC certified

•Protected by HP Services. Terms and conditions vary by country. Certain restrictions & exclusions apply.

Quick Specs HP Compaq dx2080 Micro tower Business PC

Available Technology and Featu

res

Rev 1.0 July 2007

Intel Celeron D Processors:

Intel Celeron D-CM 352 Processor

3.2GHz,512KB L2 Cache, 533MHz FSB)

Intel Pentium D Processors

Intel Pentium D 925 Processor

(3.0-GHz, 2x2MB L2 cache, 800-MHz FSB)

Intel Pentium D 945 Processor

(3.4-GHz,2 x 2MB L2 cache, 800-MHz FSB)

Intel Core 2 Duo Processor

Intel Core 2 Duo E4300 Processor

(1.80GHz, 2MB L2 Cache, 800MHz)

Intel Core 2 Duo E4400 Processor

(2.0GHz, 2MB L2 Cache, 800MHz)

Intel Core 2 Duo E4500 Processor

(2.2GHz, 2MB L2 Cache, 800MHz)

Intel Pentium Dual Core Processor

Intel Pentium E2180 Processor

(2.0GHz, 1MB L2 Cache, 800MHz)

Intel Pentium E2160 Processor

(1.8GHz, 1MB L2 Cache, 800MHz)

Intel Pentium E2140 Processor

(1.6GHz, 1MB L2 Cache, 800MHz)

Intel Celeron Conroe-L Processor

Intel Celeron –Conroe-L 440

(2.0GHz, 512KB L2 Cache, 800MHz)

Intel Celeron –Conroe-L 430

(1.8GHz, 512KB L2 Cache, 800MHz)

Processor and Speed

One of the following

Intel Celeron –Conroe-L 420

(1.6GHz, 512KB L2 Cache, 800MHz)

Genuine Microsoft Windows XP

Genuine Microsoft Windows Vista Business 32 bit , Vista Business 64 bit , Vista Home Basic

Free DOS

Operating Systems and

Application Software

Symantec Antivirus (availability varies by region)

HP Insight Diagnostics (on documentation CD)

Desktop Management Tool (availability varies by region) Tool for Health management, Asset Management

and Remote Management

Smart Mon –SMART Disk Monitoring Tool (availability varies by region). Tool for Email Alert, Audio able

Sound Alert, Flexibility to configure Auto Launch Programs (e.g. Starting a backup program) , Alert Pop-Up

Window, View Event Log files

80-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

160-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

Hard Drives

250-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)

System Memory

–

Single Channel 256 MB DDRII Sync DRAM PC2-4200 (533-MHz) Non-ECC (1 x 256-MB)

256-MB DDR II Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 256-MB)

Quick Specs HP Compaq dx2080 Micro tower Business PC

Available Technology and Featu

res

Rev 1.0 July 2007

512-MB DDR II Synch DRAM PC2-4200 (533-MHz) Non-ECC (1 x 512-MB)

512-MB DDRII Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 512-MB)

Configurations

1-GB DDR II Synch DRAM PC2-4200 (533-MHz) Non-ECC (1 x 1-GB)

1-GB DDR II Synch DRAM PC2-5300 (667-MHz) Non-ECC (1 x 1-GB)

512-MB DDRII Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 256-MB)

512-MB DDR II Synch DRAM PC2-4200 (533-MHz) Non-ECC (2 x 256-MB)

1-GB DDRII Synch DRAM PC2-4200 (533-MHz) Non-ECC (2 x 512-MB)

1-GB DDRII Synch DRAM PC2-5300 (667-MHz) Non-ECC (2 x 512-MB)

System Memory –

Dual Channel

Configurations

NOTE: For best performance, memory speeds and sizes should not be mixed. See memory section for

more information.

Diskette Drive

1.44-MB Diskette Drive

Optical Drives

SATA 52X CD-ROM drive

SATA 16X/48X DVD-ROM drive

SATA 48X/32X Combo CD-RW/DVD-ROM Drive

SATA 16X DVD+/-RW

Storage Support

One or more of the

following (see Storage

section below)

* For Vista OS only DVD/COMBO/DVDRW will be supported.

Keyboard –

One of the following HP PS/2 Standard Keyboard

HP USB Standard Keyboard

PS/2 2-Button Scroll MouseMouse –

One of the following USB 2-Button Optical Scroll Mouse

PS2 –Optical Mouse

Audio8-channel High definition audio ( Realtek ALC 883)

Integrated Realtek 10/100/1000 Network Connection (8110SC)

Communication Agere 56K PCI Modem

Graphics On board Intel Graphics Media Accelerator 950

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

Base Unit •Micro ATX Micro tower chassis, including power supply and front bezel

•Six (6) drive bays and three expansion slots

•Microsoft operating system CD

•System board with Intel 945GZ Express chipset, integrated Realtek 10/100/1000 Network

Connection, integrated graphics and audio, 2 PCI slots, ,1 PCI Express x1 slot,2DDR II DIMM

memory slots

•(2) Serial ATA data cable

•System fan

•Product documentation on CD

•HP system restore DVD

•Power cord

•Chassis intrusion alert

PCI Two (2) PCI 2.2slots on PCA

One (1) PCI Express x1 slot on PCA

Slots

Memory Expansion Two(2) DIMM slots (2GB maximum memory support)

Internal Two (2) 3.50" internal

Bays External Two (2) 5.25" external

Two (2) 3.50" external

High-speed USB 2.0 controller

USB Support Two (2) front ports; Four (4) rear ports

One (1) parallel port

One (1) serial port

One (1) PS/2 keyboard port

One (1) PS/2 mouse port

One (1) analog VGA video port

One (1) line in; one (1) line out; one (1) mic in

Interfaces

One (1) RJ45 network port

Front Audio

One (1) Speaker

One (1) MIC

Châssis Dimensions

(H x W x D) 14.37 x 7.08 x 15.75 in

(36.5 x 18.0 x 40.0 cm)

Packaged Dimensions

(L x W x H) 23.2 x 19.6 x 10.9 in

(58.9 x 49.9 x 27.8 cm)

System Weight ~ 12.0 kg ( depend on configuration)

Weight & Dimensions

Shipping Weight ~ 13.0 kg ( depend on configuration)

Coprocessor Integrated

Intel Pentium Conroe

Processor CPU Socket Type/Number Socket T

LGA775 socket

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

CPU Package LGA775

Front Side Bus Speed 533/800MHz

Cache Memory 1-MB L2 /2 MB /4 MB Advanced Transfer –depending on CPU

Coprocessor Integrated

CPU Socket Type/Number Socket T

LGA775 socket

CPU Package LGA 775

Front Side Bus Speed 533-MHz

Intel Celeron D

Processor

Cache Memory 256-KB /512 KB L2 Advanced Transfer Cache

Front Panel •Power button

•Power On LED

•HDD Activity LED

Cooling Solutions

Supported •Power Supply Fan

•Active heat sink fan (variable speed)

•System fan

Slots Supported Two PCI & One x1 PCIe expansion slots

Front I/O Two (2) USB 2.0 ports

Two (2) Front Audio ports (1 Headphone, 1 MIC)

Rear I/O Standard Micro ATX I/O connectors, including four (4) USB 2.0 ports

Drive Bays •Two (2) 5-1/4" external

•Two (2) 3-1/2" external

•Two (2) 3-1/2" internal

Chassis

Power Supply 300-watt ATX Power Supply –non-PFC

General Unit Operating Guidelines

Unit Environment and

Operating Conditions •Keep the computer away from excessive moisture, direct moisture and the extremes of heat and

cold, to ensure that unit is operated within the specified operating range.

•Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required

airflow.

•Never restrict airflow into the computer by blocking any vents or air intakes.

•Do not stack computers on top of each other or place computers so near each other that they are

subject to each other's re-circulated or preheated air.

•Occasionally clean the air vents on the front, back, and any other vented side of the computer.

Lint, dust and other foreign matter can block the vents and limit the airflow.

•If the computer is to be operated within a separate enclosure, intake and exhaust ventilation

must be provided on the enclosure, and the same operating guidelines listed above will still

apply.

Temperature Range Operating Temperature: (0°C to 45 ° C)

Non-operating Temperature: (-30° to 60° C)

Relative Humidity Operating Humidity: 10% to 95% (non-condensing at ambient)

Non-operating Humidity: 5% to 95% (non-condensing at ambient)

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea

level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be

limited by the type and number of options installed.

Socket LGA775 industry standard Micro ATX form factor

Processor •Socket T; LGA775

•Support single Intel Core 2 Duo,Pentium Dual Core, Pentium D ,

Celeron D ,Celeron Conroe-L

Chipset •Intel 945GZ Express

•Intel ICH7

Super I/O •ITE IT8718

Front Side Bus Frequency •533/800MHz

Memory •PC4200/5300 DDRII SDRAM

•2x DIMM slots

•Support for single or dual-channel configurations

Clock Generator •Cypress CY28411

Integrated Graphics •Intel Graphics Media Accelerator (GMA) 950

Audio •Realtek ALC883 8 channel High definition audio

LAN •Integrated Realtek 10/100/1000 ( 8110SC ) network controller

IDE •Support all PIO modes

•1 x IDE ports support up to 2 devices

•Support Ultra ATA 33/66/100 ( no ODD is approved on this

product)

SATA •Four Serial ATA interfaces support data transfer rates up to 3.0

Gb/s

Expansion Slots •2 x PCI 2.2slots

•1 x PCI Express x1 slot

BIOS •4Mbit flash EEPROM

Manageability •WfM 2.0, SMBus, DMI 2.0, WOL, PXE

Industrial Standard •PCI 2.2compliant

•USB 2.0

System Board

Rear Side I/O Ports •1 x PS/2 keyboard port

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

•1 x PS/2 mouse port

•8x USB 2.0 ports

•1 x RJ-45 10/100/1000 port

•1 x serial port

•1 x parallel port

•1 x DB 15 pin analog VGA port

•3 x audio ports

On Board I/O Interfaces •1 x ATX power connector

•1 x +12V power connector

•1 x Floppy connector

•1 x Front panel connector, Switch, LED (ON/Flash/OFF)

•2 x Fan headers for CPU, chassis, with voltage/fan speed control

•1 x ATAPI headers-CD IN

•1 x header to support 2 USB 2.0 ports at front side

Board Size •Micro-ATX,

Additional Features •Support S3, S4 and S5

•ACPI status

•Hardware monitor capability

•CPU fan speed control

•Wake on LAN

Integrated Realtek 8110S Network Connection

Hardware Highlights •Realtek 8110SCPlatform LAN Connect device

•10/100/1000 mbps

•IEEE 802.3 10BASE-T compliant physical layer interface

•IEEE 802.3u Auto-Negotiation and 100BASE-TX support

•10BASE-T auto-polarity correction

•1:1 transmit transformer ratio support

•Low power (300 mW) typical in active transmit mode

•Reduced power(less than 50 mW) in "unplugged mode"

•Automatic detection of "unplugged mode"

Network Interface

Features •ACPI support

•Magic Packet filtering for Wake on LAN support

•Automatic detection of "unplugged mode"

•Low power (less than 300 mW in active transmit mode)

•Platform LAN connect interface support

•Low power 3.3 V device

Power Supply •ATX Power Supply - non-PFC

•220 to 230VAC input voltage range

•50-60 Hz rated line frequency

•300 watt maximum power

•power supply fan

•Over Voltage Protection

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

•Over Current Protection

•Short Circuit Protection

•FCC ,UL approved

Power Conservation

‘Energy Saver‘ •ACPI 2.0 support

•Screen blanking

•Hard drive 'Idle' mode

•System Idle mode

•Processor/Cache memory power-down (S3)

•Values are subject to change without notification and are for reference only.

•Performance of system, options, and ancillary equipment will vary depending on the system

configuration.

•Levels presented do not account for non-HP/Compaq installed hardware.

Operating (0° to 45°C) at sea level with an altitude de-

rating of 1.0°C per every 1000 ft (300 m) above

sea level to a maximum of 8000 ft (2500 m), no

direct sustained sunlight. Maximum rate of

change is 77°F/Hr (25°C/Hr). The upper limit

may be limited by the type and number of

options installed.

Ambient Air

Temperature

Storage -22° to 140°F (-30° to 60°C) –

Maximum rate of change: 410°F/Hr (210°C/Hr).

Operating 10% to 90% relative humidity (Rh), 86°F (30°C)

maximum wet bulb temperature, non-condensing

Humidity

Storage 10% to 95% relative humidity (Rh), 101.66°F

(38.7°C) maximum wet bulb temperature, non-

condensing

Operating 0 to 8,000 feet (0 to 2438.4 meters) –This value

may be limited by the type and number of

options installed. Maximum allowable altitude

change rate is 1,000 ft/min (304.8 m/min).

Altitude

Non-Operating 0 to 30,000 feet (0 to 9,144 meters) –Maximum

allowable altitude change rate is 1200 ft/min

(365.76 m/min).

Listed are the levels of shock the product can withstand with NO damage

being incurred? The values represent peak input acceleration during a2~3

ms half-sine shock pulse, 11 ms trapezoidal shock pulse.

Shock

Non-Operating 40G's (Half-sine Shock)

40G's (Trapezoidal Shock)

Listed are the levels of vibration the product can withstand with NO damage

being incurred? The values represent a flat random vibration input

acceleration profile across the given frequency range.

Operating Random vibration at [email protected]2/Hz,

[email protected]2/Hz, [email protected]2/Hz,

[email protected]2/Hz

5Hz to 300Hz, (0.25G's nominal).

System Environmental

Specs

Vibration

Non-Operating Random vibration at 0.008G²/Hz,

10Hz to 500Hz, (2 Grms nominal).

Quick Specs HP Compaq dx2080 Microtower Business PC

System Details

Rev 1.0 July 2007

Listed are the declared A-WEIGHTED SOUND POWER LEVELS (LWAd)

and declared average desktop seated operator position A-WEIGHTED

SOUND PRESSURE LEVELS (LpAm) when the product is operating in a

73.4°F (23°C) ambient environment.

IDLE (Fixed disk drive

spinning) Desktop Average LpAm = 35dBA

Acoustic Noise

Operating (Random

write) Desktop Average LpAm = 42dBA

On-site WarrantyNote 1: One-year (1-1-1) limited warranty delivers one year of on-site, next business day

or second business-dayNote 2 service for parts and labor and includes free telephone supportNote 3 24 x 7.

Additional configurable warranty options (sold separately) include: three years parts and one year labor

(3/1/1), or 3 years next business day, three years parts and three years labor (3/3/3).

NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.

NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized

HP third-party provider, and is not available in certain countries. Global service response times are based

on commercially reasonable best effort and may vary by country.

Service and Support

NOTE 3: Technical telephone support applies only to HP-configured Compaq and third-party HP-

qualified hardware and software. Toll-free calling and 24 x 7 support may not be available in some

countries.

Quick Specs HP Compaq dx2080 Microtower Business PC

Rev 1.0 July 2007

Communication Modems

Agere PCI Hi-Speed 56K International SoftModem

RJ11 Modem adapter Kit ( country /network) specific EK694AA

DC131C

250-GB SATA 3.0-Gb/s Hard Drive PY278AA

160-GB SATA 3.0-Gb/s Hard Drive PY277AA

Hard Disk Drives

80-GB SATA 3.0-Gb/s Hard Drive PY276AA

Diskette Drive

1.44-MB Internal Diskette Drive for dx2080 EY084AA

1.44-MB USB Diskette Drive –External DC141B

USB Drive Key

512-MB HP Drive Key II (USB 2.0) ED516AA

Removable Storage

Devices

1GB HP Drive Key II (USB 2.0) AG382AA

Keyboards

HP PS/2 Standard Keyboard DT527A

HP USB Standard Keyboard

HP USB Smart Card Keyboard DT528A

ED707AA

Mice

HP PS/2 2-Button Scroll Mouse DD440B

HP PS2 2 Button Optical scroll mouse EY703AA

Input Devices

HP USB 2-Button Optical Scroll Mouse DC172B

1-GB PC5300 (DDRII-667) DIMM PX976AA

512-MB PC5300 (DDRII-6677) DIMM PX975AA

Memory

256-MB PC5300 (DDRII-667533) DIMM PX974AA

HP 52X SATA CD-ROM (APJ) AH045AA

HP 48X/32X SATA Combo Drive (CDRW/DVD) AH046AA

HP 16X/48X SATA DVD-ROM Drive AH047AA

Optical Drives ( only

SATA)

HP 16X SATA DVD+/-RW Drive (Dual Format, Double Layer, Light Scribe)AH048AA

Miscellaneous

Accessories Adaptec Fire Connect 2100 FireWire (1394) PCI Card

USB to Serial Adaptor PA997A

EM449AA

HP L1506 Flat Panel Monitor (15" analog only)

PX848AA

HP L1506S Flat Panel Monitor (15" analog only) GL831AA

HP L1706 Flat Panel Monitor (17" analog only)

PX849AA

HP L1906 Flat Panel Monitor (19" analog only)

PX850AA

HP L1740 Flat Panel Monitor (17" analog only) PL766AA

HP L1755 Flat Panel Monitor (17" analog only)

HP L1940TFlat Panel Monitor (19" analog only) PL777AA

EM869AA

HP L1955 Flat Panel Monitor (19" analog only) PD974AA

HP L2065 Flat Panel Monitor 20" analog only) EF227A4

Monitors

HP S5502 15” CRT

HP S7540 17” CRT PQ560AA

PF997AA

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HP Desktop Handbücher

HP EliteDesk 800 G1 Tower Bedienungsanleitung

HP Presario SR1200 - Desktop PC Bedienungsanleitung

HP Xw6400 - Workstation - 4 GB RAM Gebrauchsanweisung

HP Pavilion t100 - Desktop PC Gebrauchs- und Wartungshandbuch

HP EliteDesk 800 G2 Desktop Mini Montageanleitung

HP Pro 3120 Minitower PC Bedienungsanleitung

HP TouchSmart IQ540 - Desktop PC Anleitung zur Verwendung

HP DC7600 - HP Programmierhandbuch

HP TouchSmart IQ510 Montageanleitung

HP Net PC 20 Handbuch

HP Vectra VE 6/xxx - 8 Bedienungsanleitung

HP Compaq dx2700 Microtower and Small Form... Einrichtungshandbuch

HP Pavilion t400 - Desktop PC Bedienungsanleitung

HP Pavilion a5000 - Desktop PC Anleitung zur Verwendung

HP KAYAK XM600 Stücklistenhandbuch

HP Xw4300 - Workstation - 2 GB RAM Bedienungsanleitung

HP Compaq Presario Bedienungsanleitung

HP Pro 3400 Series Handbuch

HP Compaq Business Desktop dc7100 Series Montageanleitung

HP Media Center Technisches Datenblatt

HP ProDesk 400 G1 Handbuch

HP Presario CQ3200 - Desktop PC Gebrauchs- und Wartungshandbuch

HP Elitebook 8560W Handbuch

HP Z420 Series Referenzhandbuch

Beliebte Desktop Handbücher anderer Marken

Asus

Asus E210 Series Bedienungsanleitung

Dell

Dell Inspiron 600m Bedienungsanleitung

Dell

Dell Inspiron 3662 Bedienungsanleitung

TotalFlow

TotalFlow uFLO Bedienungsanleitung

Logitech

Logitech MK320 Bedienungsanleitung

Dell

Dell XPS 730 H2C Bedienungsanleitung

Sony

Sony Vaio Series Bedienungsanleitung

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Bedienungsanleitung

Alto

Alto MD 250 Bedienungsanleitung

Lenovo

Lenovo ThinkCentre Edge 72 Handbuch

Lenovo

Lenovo ThinkStation D20 Handbuch

Arbor Technology

Arbor Technology FPC-7800 Series Bedienungsanleitung

Sony

Sony VAIO VGX-TP1 Series Bedienungsanleitung

Asus

Asus Eee Box B204 Bedienungsanleitung

Dell

Dell Optiplex 9010 All In One Bedienungsanleitung

Everex

Everex eXplora Bedienungsanleitung

Lenovo

Lenovo ThinkCentre M75e Bedienungsanleitung

Dell

Dell Alienware Area-51 R4 Bedienungsanleitung
