HURTLE HURVBTR30 Bedienungsanleitung

Standing Vibration Fitness Machine

HURVBTR30

Vibrating Platform Exercise & Workout Trainer

www.PyleUSA.com www.PyleUSA.com

2 3

Before using, please read this USER MANUAL carefully, and pay special

attention to the safety precaution to ensure proper operation and use.

Please keep this USER MANUAL for further reference.

CONTENTS

Safety Precautions ............................................................. 3-4

Product Name and Functions ................................................... 5

Controller Name and Functions ................................................. 6

Using Method ................................................................... 7

Moving Method ................................................................. 8

Cleaning and Maintenance ...................................................... 9

Common Problems and Solutions .............................................. 10

Technical Specication ......................................................... 11

Safety Precautions

Environment for use

• Do not use the Product in humid or dusty environment to avoid electric shock or

breakdown ofthe mechanical parts.

• Do not use the Product when indoor temperature is over 104°F.

• Do not use the Product in the oper air or under the direct sunlight.

• Place the Product on at oor.

PIease wait for one hour before using the Product when it is moved from low to

high temperature, so as to prevent water vapor from condensing on the machine

and resulting in any failure.

People under these conditions below are not suggested to use the Product

• It is strongly advised to consult your doctor before use

• Patients who are under treatment or feel not good;

• Patients with malignant tumor;

• Pregnant women or women in menstrual period;

• People with heart disease;

• Osteoporosis patients;

• People with heart pacemaker or other medical electronic instrument implanted;

• People with articial limb;

• People who are sensitive to vibration and strenuous exercise.

Notices during Operation

Before use, please undress watch, bangle, cell phone or other valuable objects, and

keys, knife or other incisive objects, so as to avoid damage or body injury. Do not

smoke while using the Product. Please do not use the Product together with other

medical equipments. Please do not use the Product for medical treatment purpose.

Do not use the Product right after a meal or drink. During use, please keep child or

pet away from the Product. lt is forbidden to put ngers or other foreign bodies

into the gap between the middle cover and base cover. Supervision is needed for

child under 10 years and the aged over 60 years using the Product. The load

capability ofthe Product is 100KGS; people over this weight are not suggested to

use the Product. This product is only limited for one-person use.

www.PyleUSA.com www.PyleUSA.com

4 5

Warning:

Unauthorized dismantle, disassembly or renovation is not allowed to prevent

electrical shock or any malfunctions. Please contact manufacturer or local dealer

immediately if there is any service work needed.

Stop using the Product under below conditions, then power o and remove

the plug from power supply

• Water or other liquid is accidentally splashed onto the Product or controller.

• Any accessory is found damaged or internal component is exposed

• Feel abnormal or severe pain during use. Power failure.

• Thundering or lighting weather.

Plug and Power Cord

• Check if the voltage complies with the one specied for the Product.

• Do not retract the power plug with wet hand to prevent electric shock.

• Hold the plug rather than the power cord to pull out the power cord.

• Turn o the power switch and remove the plug from the power supply in case of

electrical failure of not in use for a long time.

• Stop using the Product if the power cord has any damage, turn o the power

switch, pull out the plug, and contact technicians for repair.

Product Name and Functions

1. Name and Components

Case Base Platform

Moving Wheel Cover Power Plug Feet

www.PyleUSA.com www.PyleUSA.com

6 7

Controller Name and Functions Using Method

Functions and Features:

Body Beauty

By reposeful and high-frequency vibration and sway, combined with various

exercise postures, this machine can deeply stimulate muscle tissue, lower fat

accumulation, rehabilitate elasticity of muscle, sculpture beautiful body shape,

then make users vitalized and feel condent.

Exercise

Borrow health and tness ideas from Chinese traditional culture like Kung Fu,

Buddhism, Taoism, it advocates passive exercise, which allow you to exercise

indoor in a relatively static manner to get mind and body relaxed, pain and

soreness relieved, fatigue swept away, inner circulation improved, then make you

stronger and healthier.

Start/Stop: Insert the power plug, switch ON

power, then press the button to start the

product. In the operation of the machine,press

this button to stop working.

Time - : Time decrease: the default working

time is 10 minutes, divided into 10 levels, press

this button to decrease time.

Speed + : Speed increase: Manual 1 -20. Press

this button to increase the speed when the

machine is operating.

Time + : Time increase: the default working

time is 10 minutes, divided into 10 levels, press

this button to increase time.

Speed - : Speed decrease: Manual 1-20. Press

this button to decrease the speed when the

machine is operating.

M: QUICK BUTTON for Levels 1610 6, press

once for Level16 and twice for Level 10 and 3

times for Level 6 repeatly.

Auto/Mode: Auto/Mode: Default to manual

mode, automatic mode is activated once

pressing this button. Press the button repeatedly

to cycle through the 'Pl" P2" P3' automatic

operating mode or '88 'manual mode. Auto

mode, humanized programming, automatically

adjusting vibration frequency. In automatic

mode, speed and time is not adjustable. In the

manual mode, the standby can adjust the time,

the speed is not adjustable; when operating,-

speed adjustable, but time is not adjustable.

Note: The eective reception range of the

remote control signal is 2.5 meters, the infrared

emission indicator of the controller should be

aligned the infrared receiving window on the

product..

1. Stand upright on the Product, with two legs apart, the distance

of two legs is mostly the same as width of shoulder. This position

can exercise waists and buttocks to relieve stress on waists and

sculpture beautiful curve of buttocks

2. Stand on the Product with two legs apart and knees bent.

The posture can exercise thighs to sweep pain and soreness,

improve blood circulation, and reduce fat deposits.

3. Seat on chair or sofa, with feet put on the Product. This posture

can exercise both thigh and calf.

4. Seat on carpet,with two legs put on the Product.

This posture can exercise leg.

5. Kneel on the carpet, put hands onto the Product, with body lean

forward, this posture can exercise shoulder joint and arms.

www.PyleUSA.com www.PyleUSA.com

8 9

Moving Method

Two handles are designed on both ends of the middle cover.

When moving the Product, lift the end opposite ofthe castor, grasp the handle

and move the Product to the desired place.

Storage and Maintenance

Surface Cleaning

Before cleaning, ensure the power switch is turned o, and the attaching plug is

pulled out of the socket

The rubber pedal and covers can be cleaned with a wet cloth containing detergent,

and the detergent should be removed with a cloth

Notice

Do not clean the Product with corrosive detergent such as benzene or thinner, as it

may cause fading, corrosion or crack on the Product. Do not splash water into the

Product to avoid short circuit.

Controller

As wet cloth may cause malfunction of the controller, only dry cloth can be used.

Storage and Maintenance

Make sure that the power switch is turned o and the plug is removed from the

power supply. Clean o the dust and dirt on the Product and keep it clean and

away from places with high temperature or high humidity. If the Product is not

going to be used for a long period of time, a dustproof cover (sold separately)

should be applied on the Product to prevent the entry of dust.

HANDLE

www.PyleUSA.com www.PyleUSA.com

10 11

Common Problems & Solutions HURVBTR30

Standing Vibration Fitness Machine

Vibrating Platform Exercise & Workout Trainer

Features:

• Revolutionary Design for Fitness that's Fun

• Vibration Assisted Exercise for Full Body Training

• Excellent Toning for Abs, Thighs & Buttocks

• Dynamic Oscillating Motion Technology

• High-Powered Vibrations do the Hard Work

• Accelerated Fat Burning & Weight Loss

• Incorporates Upper Body, Lower Body & Core Workouts

• Lab Tested to Improve Muscle Strength, Flexibility & Circulation

• Detachable Handheld Resistance Bands for More Versatile Routines

• Reduce Appearance of Cellulite, Improves Metabolic Rates

• Simple Operation: Stand On & Power On

• Ideal for All Body Types & Age Groups

• (20) Level Adjustable Speeds

• Digital Touch Button Controls

• Rubber Grip 'Anti-Slip' Surface Pad

• Perfect for Sports Training, Weight Loss, Burning Fat

• Includes Remote Control

Technical Specs:

• High Power Output: 200 Watt

• RPM (Revolutions Per Minute): 2300+

• Construction Material: Engineered ABS

• Maximum Session Time Setting: 10 Minute

• Load Capacity: 265 lbs.

• Power: 120V

• Dimensions (L x W x H): 26.8'' x 15.5'' x 5.5''

• Sold as: 1

• Weight: 35.02 lbs.

S/N Problems Causes Solutions

The Product can

not be started

The plug is not in place Insert the plug

The power switch is o Turn switch on,

the indicator

The fuse is burnt Replace with a new

fuse of the same model

Sound like phew

or Da-da is heard

during working

Normal sound generated

by the motor or from the

abrasion between

mechanical units

No additional

treatment is required

Operate the

controller, but

the Product has

no action

The electricity of batteries

is worn out Replace batteries

The controller is too far

away from the Product

The eective

distance of infrared

signal is 2.5M

Sudden stop

Can not operate

Default working time is up Restart it after

10 minutes interval

Too many commands sent

to the Product and they

can not be responded in

time

Power o and

then restart
