HySecurity Nice 1500 Series Installations- und Betriebsanleitung
816 LA
1500 Series 816 actuator
Vehicular swing gate actuator
Installation Reference Manual
IMPORTANT!
These instructions apply only to the 816 actuator.
Control box installation/operation is described in a separate control box manual.
816 LA Actuator
INSTALLATION REFERENCE MANUAL
2
TABLE OF CONTENTS
LIST OF INSTRUCTIONS
INSTRUCTION 1A: INSTALL PIVOT ARM TO GATE (PULL-TO-OPEN) ............... 5
INSTRUCTION 1B: INSTALL PIVOT ARM TO GATE (PUSH-TO-OPEN) ............... 6
INSTRUCTION 2: MOUNT ACTUATOR TO PIVOT ARM ..................................... 7
INSTRUCTION 3: AFFIX GATE BRACKET TO ACTUATOR ARM ........................ 8
INSTRUCTION 4: POSITION GATE BRACKET ON GATE ................................... 9
INSTRUCTION 5: AFFIX GATE BRACKET TO GATE .......................................... 10
INSTRUCTION 6: RUN ACTUATOR CABLE(S) TO THE CONTROL BOX .......... 11
INSTRUCTION 7: REMOVE CONNECTOR FOR WIRING TO 936/1050 ........... 12
INSTRUCTION 8: 936 CONTROL BOARD WIRING: PULL-TO-OPEN ............... 13
INSTRUCTION 9: 936 CONTROL BOARD WIRING: PUSH-TO-OPEN .............. 14
INSTRUCTION 10: 1050 CONTROL BOARD WIRING: PULL-TO-OPEN ........... 15
INSTRUCTION 11: 1050 CONTROL BOARD WIRING: PUSH-TO-OPEN .......... 16
INSTRUCTION 12: SETTING MOTOR 1 OPEN/CLOSE LIMITS .........................17
INSTRUCTION 13: SETTING MOTOR 2 OPEN/CLOSE LIMITS..........................18
SECTION 1: 816 ACTUATOR OVERVIEW .........................................3
SECTION 2: INSTALLATION SAFETY................................................4
SECTION 3: TOOLS NEEDED FOR INSTALLATION...........................4
SECTION 4: ACTUATOR MECHANICAL INSTALLATION...................5
SECTION 5: ACTUATOR TO CONTROL BOARD CONNECTIONS....12
5.1 WIRING ACTUATOR TO 936 CONTROL BOARD...................................13
5.2 WIRING ACTUATOR TO 1050 CONTROL BOARD.................................15
5.3 SETTING OPEN/CLOSE LIMITS..................................................................17
SECTION 6: PART DRAWINGS ........................................................19
SECTION 7: WARRANTY .................................................................22
816 LA Actuator
INSTALLATION REFERENCE MANUAL
3
• 816-1 - Actuator with 12’ harness
• 816-2 - Actuator with 42’ harness
PIVOT ARM (P/N 1116)
ACTUATOR
HARDWARE KIT
(P/N 1125)
GATE BRACKET,
BLACK
(P/N 10025215)
816 ACTUATOR PARTS IDENTIFICATION
PART# DESCRIPTION QTY
816-1 ACTUATOR WITH 12 FOOT HARNESS 1
816-2 (DUAL GATE ONLY) ACTUATOR WITH 42 FOOT HARNESS 1
1116 PIVOT ARM 1
10025215 GATE BRACKET 1
1125 ACTUATOR HARDWARE KIT 1
816 ACTUATOR SPECIFICATIONS
DRIVE Electromechanical
GATE LENGTH MAX. 16 ft (5 m ) leaf
GATE WEIGHT MAX 600 lb (272 kg)
OPEN/CLOSE TIME (TO 90°) 14 - 16 seconds (adjustable)
TEMPERATURE RATING -4º to 122º F (-20º to 50º C)
OPERATING VOLTAGE 12VDC
ACTUATOR DIMENSIONS 42” retracted - 66” extended
USER CONTROLS 636, 936, or 1050 control board
LISTED TO UL325 936 & 1050 Control Boards: Usage Class I, II,
Congratulations on selecting a Nice 816 LA actuator for your gate opener system. With proper selection, sys-
tem design, installation, and maintenance this actuator should provide years of reliable operation. This manual
covers ONLY the installation of the 816 actuator.
IMPORTANT!
For control box installation, wiring, operation, maintenance instructions and all safety information, refer to
the appropriate control box installation manual used for the system being installed.
SECTION 1: 816 ACTUATOR OVERVIEW
816 LA Actuator
INSTALLATION REFERENCE MANUAL
4
•DISCONNECT POWER AT THE CONTROL PANEL BEFORE MAKING ANY ELECTRIC SERVICE POWER
CONNECTIONS.
• BE AWARE OF ALL MOVING PARTS AND AVOID CLOSE PROXIMITY TO ANY PINCH POINTS.
Below is a list of tools necessary for installation of the 816 actuator:
• Welder (for pivot arm) unless optional bolt-on pivot arm (P/N 446) is used.
• Basic hand tools (screwdrivers, wrenches, pliers, etc..)
• Bubble Level (for ensuring pivot arm and actuator are level).
• Framing square (for determining pivot arm location)
IMPORTANT!
•The gate operator installation is NOT a “do-it-yourself” project. Contract a qualied gate operator instal-
lation company to install this system to ensure a safe and reliable installation.
•It is the responsibility of the property owner to ensure the installer is qualied to carry out the installation
in a safe and professional manner.
•Consult local government agencies for up-to-date rules and regulations to satisfy licensing, codes or
regulations that regulate automated gate system design and installation.
•The gate for which the gate operator is intended to be used should itself be installed correctly so that it
is level and plumb and the gate opens easily and evenly.
• Note that Nice swing gate systems are not intended for installation on an incline.
SECTION 2: INSTALLATION SAFETY
SECTION 3: TOOLS NEEDED FOR INSTALLATION
WARNING!
READ ALL SAFETY INFORMATION IN THE CONTROL BOX INSTALLATION MANUAL WHEN
INSTALLING A SWING GATE SYSTEM!
816 LA Actuator
INSTALLATION REFERENCE MANUAL
5
IMAGE 1A-1: "PULL TO OPEN" PIVOT ARM INSTALLATION
INSTALL PIVOT ARM TO GATE: PULL-TO-OPEN
1A
1. Securely mount the pivot arm to the hinge post (IMAGE 1A-1).
2. If necessary, cut pivot arm for correct placement of the actuator mounting
hole. Measurements are taken from the center of pivot of the gate hinge.
3. It is strongly recommended to weld the pivot arm to the hinge post.
SECTION 4: ACTUATOR MECHANICAL INSTALLATION
CAUTION!
NEVER WELD PARTS TO THE GATE OR POSTS WHEN THE CONTROL BOARD IS
POWERED TO AVOID IRREPAIRABLE DAMAGE TO THE CIRCUIT BOARD!
LEFT SIDE VERTICAL VIEW
TOP VIEW
6” 6”
13” 13”
NOTE: Welding is much
preferred but Nice offers an
optional bolt-on pivot arm
(P/N 446) for when welding
is not possible.
PIVOT ARM PIVOT ARM
PIVOT ARM
1/2”
HINGE POST
CENTER OF HINGE
CENTER LINE OF
ATTACHMENT POINT
FOR GATE BRACKET
CENTER OF HINGE
GATE CLOSED
DIRECTION OF OPENING
HINGE POST HINGE POST
816 LA Actuator
INSTALLATION REFERENCE MANUAL
6
IMAGE 1B-1: "PUSH TO OPEN" PIVOT ARM INSTALLATION
1B
1. Securely mount the pivot arm to the hinge post (IMAGE 1B-1).
2. If necessary, cut pivot arm for correct placement of the actuator mounting
hole. Measurements are taken from the center of pivot of the gate hinge.
3. It is strongly recommended to weld the pivot arm to the hinge post.
INSTALL PIVOT ARM TO GATE: PUSH-TO-OPEN
CAUTION!
NEVER WELD PARTS TO THE GATE OR POSTS WHEN THE CONTROL BOARD IS
POWERED TO AVOID IRREPAIRABLE DAMAGE TO THE CIRCUIT BOARD!
TOP VIEW
6” 6”
11” 11”
PIVOT ARM
PIVOT ARM
PIVOT ARM
1/2”
HINGE POST
CENTER OF HINGE
HINGE POST HINGE POST
CENTER LINE OF
ATTACHMENT POINT
FOR GATE BRACKET
CENTER OF HINGE
GATE CLOSED
DIRECTION OF OPENING
LEFT SIDE VERTICAL VIEW
NOTE: Welding is much
preferred but Nice offers an
optional bolt-on pivot arm
(P/N 446) for when welding
is not possible.
816 LA Actuator
INSTALLATION REFERENCE MANUAL
7
IMAGE 2-1: ACTUATOR INSTALLATION
2MOUNT ACTUATOR TO PIVOT ARM
LOCK
NUT
ACTUATOR
BOLT
PIVOT
ARM
WASHER
1. Mount the actuator to the pivot arm as shown (IMAGE 2-1). Note that the washer goes above the ac-
tuator ange.
2. Tighten the lock nut to prevent movement or shifting when the actuator is running. This will also pre-
vent excessive “bounce” or “wobble” when the gate stops moving.
816 LA Actuator
INSTALLATION REFERENCE MANUAL
8
AFFIX GATE BRACKET TO ACTUATOR ARM
1/2”x 3” BOLT
GATE
BRACKET
ACTUATOR
ARM
1/2” WASHER
1/2” LOCK NUT
3
IMAGE 3-1: GATE BRACKET TO ACTUATOR ARM USING BOLT, WASHER, & NUT
IMAGE 3-2: GATE BRACKET TO ACTUATOR ARM USING HITCH PIN AND R-CLIP
If security is of the utmost importance then the bracket may be connected to the actuator arm using the
1/2” x 3” bolt, washer, and lock nut (IMAGE 3-1).
However, to enable quick manual opening of the gate in case of power failure, it is recommended to use
the quick release hitch pin with R-clip (IMAGE 3-2).
HITCH PIN
R-CLIP (INSERT INTO HITCH
PIN HOLE)
HOLE FOR R-CLIP
816 LA Actuator
INSTALLATION REFERENCE MANUAL
9
3: AFFIX GATE BRACKET TO ACTUATOR ARM (CONT.)
ACTUATOR
ARM
ACTUATOR
ARM
GATE BRACKET
GATE BRACKET
IMAGE 3-3: GATE BRACKET WITH BOLT, WASHER, NUT
IMAGE 3-4: GATE BRACKET WITH HITCH PIN AND R-CLIP
1/2”x 3” BOLT
HITCH PIN
1/2” WASHER
1/2” LOCK NUT
R-CLIP
816 LA Actuator
INSTALLATION REFERENCE MANUAL
10
1. Place gate in:
a) OPEN position for PULL-TO-OPEN conguration (IMAGE 4-1).
b) CLOSED position for PUSH-TO-OPEN congurations ( IMAGE 4-2).
2. With actuator arm fully retracted, rotate entire actuator on the pivot arm around until the gate
bracket attached to the actuator is positioned on a supporting structure of gate.
3. Mark position of gate bracket on gate or clamp into position.
4POSITION GATE BRACKET ON GATE
NOTES:
Do not attach gate bracket to gate pickets. Attach only to structural supports.
If unsure of exact bracket location, tack weld or clamp until gate can be tested.
IMAGE 4-2: GATE BRACKET LOCATION (PUSH-TO-OPEN)
IMAGE 4-1: GATE BRACKET LOCATION (PULL-TO-OPEN)
ACTUATOR
(RETRACTED)
ACTUATOR
(RETRACTED)
PIVOT ARM
PIVOT ARM
WALL
WALL
GATE BRACKET
LOCATION
GATE BRACKET
LOCATION
GATE OPEN
GATE
CLOSED
