HySecurity Nice 3501 Bedienungsanleitung

Residential | Commercial | Industrial | Anti-Ram | Parking

800-321-9947 •253-867-3700 • www.hysecurity.com

3501 Swing

CHBOX35:

ACTUATOR

MOTOR

CHASSIS

ABOX35: ARTICULATING ACTUATOR

Vehicular swing gate articulating actuator/motor

Installation Manual

3501 Actuator

INSTALLATION REFERENCE MANUAL

TABLE OF CONTENTS

LIST OF INSTRUCTIONS

INSTRUCTION 1: DETERMINE LOCATION OF MOUNTING POST ..................... 5

INSTRUCTION 2: DETERMINE HEIGHT OF MOUNTING POST ........................... 6

INSTRUCTION 3: WELD MOUNTING BRACKET TO POST ................................... 7

INSTRUCTION 4: MOUNT CHASSIS TO POST ...................................................... 8

INSTRUCTION 5: MOUNT PRIMARY ARM COLLAR TO DRIVE SHAFT................. 9

INSTRUCTION 6: ATTACH PRIMARY ARM TO ARM COLLAR ............................. 10

INSTRUCTION 7: ASSEMBLE ARM ASSEMBLY .....................................................11

INSTRUCTION 8: AFFIX GATE BRACKET TO ACTUATOR ARM ..........................13

INSTRUCTION 9: INSTALL GATE BRACKET TO GATE SUPPORT ........................15

INSTRUCTION 10: WIRE ACTUATOR CABLE TO CHASSIS TERMINAL STRIP ....16

INSTRUCTION 11: RUN ACTUATOR CABLE(S) TO CONTROL BOX ...................17

INSTRUCTION 12A: WIRE ACTUATOR CABLE TO CONTROL BOARD (LEFT) ...18

INSTRUCTION 12B: WIRE ACTUATOR CABLE TO CONTROL BOARD (RIGHT) .19

INSTRUCTION 12C: WIRE ACTUATOR CABLE TO CONTROL BOARD (DUAL) .. 20

INSTRUCTION 13: INSTALL CONTROL BOX AND APPLY POWER ................... 20

INSTRUCTION 14: SET OPEN AND CLOSE LIMIT COLLARS ................................. 21

INSTRUCTION 15: WELD OR BOLT GATE BRACKET TO GATE ......................... 22

INSTRUCTION 16: MANUALLY OPENING THE GATE ....................................... 23

SECTION 1: 3501 ACTUATOR OVERVIEW ..........................................................3

SECTION 2: INSTALLATION SAFETY ..................................................................4

SECTION 3: TOOLS NEEDED FOR INSTALLATION ............................................4

SECTION 4: 3501 ACTUATOR MECHANICAL INSTALLATION ...........................5

SECTION 5: ACTUATOR WIRING CONNECTIONS ...........................................16

5.1 CHASSIS WIRING .........................................................................................16

5.2 CONTROL BOARD WIRING...........................................................................18

SECTION 6: PART DRAWINGS..........................................................................24

SECTION 7: WARRANTY .................................................................................. 26

3501 Actuator

INSTALLATION REFERENCE MANUAL

ABOX35 ACTUATOR:

CHBOX35

ACTUATOR

MOTOR

CHASSIS

ACTUATOR HARDWARE

KIT (P/N 1125-35)

ADJUSTABLE ALUMI-

NUM ARM INSERT (P/N

3500AAA)

GATE BRACKET,

(P/N 10025215)

3501 ACTUATOR PARTS IDENTIFICATION

PART# DESCRIPTION QTY

ABOX35 ACTUATOR, ARTICULATING ARM 1

CHBOX35 ACTUATOR CHASSIS 1

10025215 GATE BRACKET 1

1125-35 ACTUATOR BOLT KIT 1

3500AAA ARM INSERT, ADJUSTABLE, ALUMINUM 1

3501 ACTUATOR SPECIFICATIONS

DRIVE Electromechanical Motor Driven Articulated Arm

GATE LENGTH MAX. Up to 20 feet (6 m ) leaf

GATE WEIGHT MAX Up to 1000 lbs (453 kg)

OPEN/CLOSE TIME (TO 90°) 12 - 20 seconds (adjustable)

TEMPERATURE RATING -4º to 122º F (-20º to 50º C)

OPERATING VOLTAGE 12VDC

INPUT VOLTAGE 10 - 32VDC

ACTUATOR DIMENSIONS (WxHxD) 17.8” x 12” x 8.3”

USER CONTROLS 1050 control board

Congratulations on selecting a Nice swing gate actuator for your gate opener system. With proper selection,

system design, installation, and maintenance this actuator should provide years of reliable operation. This

manual covers ONLY the installation of the actuator.

IMPORTANT!

For control box installation, wiring, operation, programming, maintenance, and all safety information, refer

to the appropriate 1050 control box installation manual used for the system being installed.

SECTION 1: 3501 ACTUATOR OVERVIEW

ACTUATOR

HARNESS CABLE

3501 Actuator

INSTALLATION REFERENCE MANUAL

Below is a list of tools suggested for installation of the 3501 actuator:

• Welder (option for gate bracket)

• Drill and assorted bit sizes

• 1/2” and 3/8” wrench and/or nut driver

• Basic hand tools (screwdrivers, pliers, etc..)

• Bubble Level (for leveling actuator)

• Measuring tape (for locating post position)

• 1/8” and 5/32” hex keys (for set screws)

IMPORTANT!

• The gate operator installation is NOT a “do-it-yourself” project. Contract a qualied gate operator instal-

lation company to install this system to ensure a safe and reliable installation.

• It is the responsibility of the property owner to ensure the installer is qualied to carry out the installation

in a safe and professional manner.

• Consult local government agencies for up-to-date rules and regulations to satisfy licensing, codes or

regulations that regulate automated gate system design and installation.

• The gate for which the gate operator is intended to be used should itself be installed correctly so that it

is level and plumb and the gate opens easily and evenly.

• Note that Nice swing gate systems are not intended for installation on an incline.

SECTION 2: INSTALLATION SAFETY

SECTION 3: TOOLS NEEDED FOR INSTALLATION

WARNING!

READ ALL SAFETY INFORMATION IN THE CONTROL BOX INSTALLATION MANUAL WHEN

INSTALLING A SWING GATE SYSTEM!

BE AWARE OF ALL MOVING PARTS AND AVOID CLOSE PROXIMITY TO ANY PINCH POINTS.

3501 Actuator

INSTALLATION REFERENCE MANUAL

OPTIMUM

DIMENSIONS

TABLE 1-1: MOUNTING POST LOCATION CHART

DETERMINE LOCATION OF MOUNTING POST

1. Determine the angle that the gate will travel to (A) in IMAGE 1-1.

2. Select the coordinates (B & C) as shown in the IMAGE 1-1. Distances of “B” are from the center of gate

hinge to the center of the mounting post. Longer gates should operate at slower speeds.

3. Refer to TABLE 1-1 for optimum dimensions.

SECTION 4: 35-1 ACTUATOR MECHANICAL INSTALLATION

Open

Degrees

Inches

Approx.

sec. to

open

90 10 31.2 46.3 40.6 15

90 10 30 47.1 42 16

92 15 30 42.1 34 15

97 13.5 25.5 46.3 46.8 17

97 15 25 45 47.1 16

100 20 25 40 43.7 13

107 20 20 42.4 53.5 17

110 25 20 37.4 50.6 13

116 25 15 39.3 58.4 16

117 20 15 44.3 50.3 20

3501 Actuator

INSTALLATION REFERENCE MANUAL

IMAGE 2-1: DETERMINING HEIGHT OF MOUNTING POST

• The top of the post should be 2” above the centerline of the

location where the gate attach bracket will be mounted to the

gate (IMAGE 2-1).

• The gate attach bracket should be mounted to a structural

member on the gate. DO NOT attach the bracket to pickets.

• The mounting post should be square to the gate in the closed

position and level for proper operation.

• Conduit should be considered at this time for cable routing

from the control box to the chassis assembly

DETERMINE HEIGHT OF MOUNTING POST

CENTERLINE

OF GATE

BRACKET

POSITION

TOP OF POST

2” ABOVE

BRACKET

CENTERLINE

GATE

STRUCTURAL

SUPPORT

MOUNTING

POST

2”

NEVER WELD PARTS TO THE

GATE OR POSTS WHEN THE

CONTROL BOARD IS POWERED

TO AVOID IRREPAIRABLE DAM-

AGE TO THE CIRCUIT BOARD!

CAUTION!

The 3501 actuator chassis is designed for installation on top of a 4”x4” square post with 1/4” wall thickness

(not supplied).

3501 Actuator

INSTALLATION REFERENCE MANUAL

IMAGE 3-2: WELD MOUNTING BRACKET TO POST

IMAGE 3-1: REMOVING COVER AND MOUNTING BRACKET FROM CHASSIS

3WELD THE MOUNTING BRACKET TO POST

POST

MOUNTING

BRACKET

1/2”-13x3/4” HEX BOLT (x4)

1/2” LOCK WASHER (x4)

LOOSEN BOTH MIDDLE

SCREWS (x2)

LIFT COVER

REMOVE BOTH END

SCREWS (x2)

1. To remove 3501 cover, loosen middle screws (x2), remove end screws (x2), and lift off cover.

1. Remove the mounting bracket from the CHBOX35 chassis bottom by removing the four bolts and lock

washers (IMAGE 3-1). Retain the hardware for later reassembly.

2. Weld the mounting bracket to the top of the mounting post (IMAGE 3-2):

• The bracket should be level and square to the post.

• Tack welds may be made from the top inside of the bracket and post.

• Bottom welds should be made for permanent rigidity.

MOUNTING

BRACKET

3501 Actuator

INSTALLATION REFERENCE MANUAL

MOUNT CHASSIS TO POST

Set the chassis on the mounting bracket as shown and secure using (4) 1/2”-13x3/4” hex bolts and lock

washers removed in the previous instruction.

IMAGE 4-1: MOUNTING CHASSIS TO MOUNTING BRACKET

IMAGE 4-2: PROPER ORIENTATION OF CHASSIS TO GATE

Chassis should be mounted to

plate so that the shaft for the arm

connection is on the opposite

side of mounting plate from the

gate when in the closed position.

DRIVE CHASSIS

MOUNTING

BRACKET

POST

MAIN DRIVE

SHAFT

SHAFT AT

OPPOSITE

SIDE FROM

CLOSED

GATE

3501 Actuator

INSTALLATION REFERENCE MANUAL

MOUNT PRIMARY ARM COLLAR TO DRIVE SHAFT

IMAGE 5-1: MOUNTING PRIMARY ARM COLLAR TO MAIN DRIVE SHAFT

IMAGE 5-2: PRIMARY ARM COLLAR MOUNTED TO MAIN DRIVE SHAFT

1. Install the primary arm collar to the main drive shaft using the 1/4” key stock (IMAGE 5-1, Detail A).

2. The collar should be installed on the shaft as far up as possible (IMAGE 5-2). Use 5/32” hex key to

tighten set screw. Insert 1/2”-13x3” hex bolt into collar and afx with 1/2” hex nut (IMAGE 5-2) using

1/2” wrench.

3. Use retaining ring pliers to insert the retaining ring into groove on driveshaft (IMAGE 5-2, DETAIL).

PRIMARY

ARM

COLLAR

GROOVE ON

DRIVE SHAFT FOR

RETAINING RING

DETAIL

RETAINING RING

INSTALLED IN

DRIVE SHAFT

GROOVE

RETAINING RING

DRIVE SHAFT

RETAINING RING

MAIN DRIVE

SHAFT

MAIN

DRIVE

SHAFT

1/4” KEY STOCK

SET SCREW (5/32” HEX)

1/2”-13x3”

HEX BOLT

1/2” HEX NUT

DETAIL A

BOTTOM VIEW

DRIVE SHAFT

RETAINING RING

NOTE: retaining

ring is included in

hardware kit 1125-

35.

3501 Actuator

INSTALLATION REFERENCE MANUAL

Attach the primary arm to the collar using 1/2”-13x1-3/4” hex bolts (x2), 1/2” at washers (x4) and 1/2-

13 hex nuts (x2) per the images below:

6ATTACH PRIMARY ARM TO ARM COLLAR

IMAGE 6-1: INSTALL PRIMARY ARM TO COLLAR OF THE MAIN DRIVE SHAFT

(BOTTOM VIEW)

IMAGE 6-2: PRIMARY ARM INSTALLED TO COLLAR OF THE MAIN DRIVE SHAFT

(BOTTOM VIEW)

PRIMARY

ARM

COLLAR

EARS POINTING

TOWARD GATE

INSTALL USING

1/2”-13x1-3/4” HEX BOLT (x2)

1/2” WASHERS (x4) & 1/2”-13 HEX NUTS (x2)

NOTE: The two ears on the primary arm should point toward the direction of the gate.

BOLT

WASHER

NUT

WASHER

BOTTOM VIEW

Inhaltsverzeichnis

Andere HySecurity Toröffner Handbücher

HySecurity

HySecurity SlideDriver 15 Bedienungsanleitung

HySecurity

HySecurity SwingSmart DC Series Bedienungsanleitung

HySecurity

HySecurity SlideDriver II Bedienungsanleitung

HySecurity

HySecurity SlideSmart DC 15 Handbuch

HySecurity

HySecurity StrongArm 14F Bedienungsanleitung

HySecurity

HySecurity SlideSmart DC Bedienungsanleitung

HySecurity

HySecurity HydraSwing 40 Bedienungsanleitung

HySecurity

HySecurity StrongArmPark DCS 14 Bedienungsanleitung

HySecurity

HySecurity SlideDriver 15 Bedienungsanleitung

HySecurity

HySecurity SlideDriver II Bedienungsanleitung

HySecurity

HySecurity UL 325 Bedienungsanleitung

HySecurity

HySecurity SwingSmart DC 20 Installations- und Betriebsanleitung

HySecurity

HySecurity Nice 1500 Series Installations- und Betriebsanleitung

HySecurity

HySecurity HTG 320-8 Handbuch

HySecurity

HySecurity SlideDriver 50VF2 Installations- und Betriebsanleitung

HySecurity

HySecurity StrongArmPark DC Bedienungsanleitung

HySecurity

HySecurity UL 325-2016 Bedienungsanleitung

HySecurity

HySecurity SwingSmart DC 20 Handbuch

HySecurity

HySecurity SlideSmart DC 15 Installations- und Betriebsanleitung

HySecurity

HySecurity HRG 220 ST Handbuch

HySecurity

HySecurity SwingSmart DC Bedienungsanleitung

HySecurity

HySecurity SlideSmart DC 15 Handbuch

HySecurity

HySecurity SwingRiser 14 Installations- und Betriebsanleitung

HySecurity

HySecurity HydraSwing 40F Bedienungsanleitung

Beliebte Toröffner Handbücher anderer Marken

Elite

Elite CSW200UL Bedienungsanleitung

CAME

CAME FROG-PM4 Bedienungsanleitung

SOMFY

SOMFY FX230 Bedienungsanleitung

Aprimatic

Aprimatic ONDA 500 Bedienungsanleitung

Turnstiles

Turnstiles FSW 900 Bedienungsanleitung

Erreka

Erreka BUL BL33 Betriebsanleitung

Erreka

Erreka VULCAN S Bedienungsanleitung

Beninca

Beninca R1-2 WBV Bedienungsanleitung

Erreka

Erreka VULCAN D Bedienungsanleitung

Motorline professional

Motorline professional FORT Bedienungsanleitung

Beninca

Beninca BOB5024 Bedienungsanleitung

AGA

AGA GATEMASTER 900 HD Bedienungsanleitung

Chamberlain

Chamberlain MotorLift HC280ML Bedienungsanleitung

SOMFY

SOMFY Dexxo RTS Pro Bedienungsanleitung

Cardin

Cardin BL Series Bedienungsanleitung

Westfalia

Westfalia 85 27 06 Bedienungsanleitung

CAME

CAME F500 Bedienungsanleitung

Extel

Extel VERA Bedienungsanleitung
