IBASE Technology IP315 Bedienungsanleitung

IP315

Backplane for PICMG 1.3

User’s Manual

Version 1.0

(JAN 2020)

ii IP315 User’s Manual

No part of this publication may be reproduced, copied, stored in a retrieval system,

translated into any language or transmitted in any form or by any means,

electronic, mechanical, photocopying, or otherwise, without the prior written

consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).

Disclaimer

IBASE reserves the right to make changes and improvements to the products

described in this document without prior notice. Every effort has been made to

ensure the information in the document is correct; however, IBASE does not

guarantee this document is error-free.

IBASE assumes no liability for incidental or consequential damages arising from

misapplication or inability to use the product or the information contained herein,

nor for any infringements of rights of third parties, which may result from its use.

Trademarks

All the trademarks, registrations and brands mentioned herein are used for

identification purposes only and may be trademarks and/or registered trademarks

of their respective owners.

IP315 User’s Manual

iii

Compliance

In a domestic environment, this product may cause radio interference in which

case users may be required to take adequate measures.

This product has been tested and found to comply with the limits for a Class A

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer’s instructions, may cause

harmful interference to radio communications.

WEEE

This product must not be disposed of as normal household

waste, in accordance with the EU directive of for waste

electrical and electronic equipment (WEEE - 2012/19/EU).

Instead, it should be disposed of by returning it to a

municipal recycling collection point. Check local

regulations for disposal of electronic products.

Green IBASE

This product is compliant with the current RoHS

restrictions and prohibits use of the following substances

in concentrations exceeding 0.1% by weight (1000 ppm)

except for cadmium, limited to 0.01% by weight (100 ppm).

• Lead (Pb)

• Mercury (Hg)

• Cadmium (Cd)

• Hexavalent chromium (Cr6+)

• Polybrominated biphenyls (PBB)

• Polybrominated diphenyl ether (PBDE)

iv IP315 User’s Manual

Important Safety Information

Carefully read the precautions before using the board.

Environmental conditions:

•Use this product in environments with ambient temperatures between -20˚C

and 70˚C.

•Do not leave this product in an environment where the storage temperature

may be below -40° C or above 90° C. To prevent from damages, the product

must be used in a controlled environment.

Care for your IBASE products:

•Before cleaning the PCB, unplug all cables and remove the battery.

•Clean the PCB with a circuit board cleaner, degreaser, or use cotton swabs

and alcohol.

•Vacuum the dust with a computer vacuum cleaner to prevent the fan from

being clogged.

WARNING.

Attention during use:

•Do not use this product near water.

•Do not spill water or any other liquids on this product.

•Do not place heavy objects on the top of this product.

Anti-static precautions

•Wear an anti-static wrist strap to avoid electrostatic discharge.

•Place the PCB on an anti-static kit or mat.

•Hold the edges of PCB when handling.

•Touch the edges of non-metallic components of the product instead of the

surface of the PCB.

•Ground yourself by touching a grounded conductor or a grounded bit of metal

frequently to discharge any static.

CAUTION

Danger of explosion if the internal lithium-ion battery is replaced by an incorrect

type. Replace only with the same or equivalent type recommended by the

manufacturer. Dispose of used batteries according to the manufacturer’s

instructions or recycle them at a local recycling facility or battery collection point.

IP315 User’s Manual

Warranty Policy

•IBASE standard products:

24-month (2-year) warranty from the date of shipment. If the date of shipment

cannot be ascertained, the product serial numbers can be used to determine

the approximate shipping date.

•3

-party parts:

12-month (1-year) warranty from delivery for the 3rd-party parts that are not

manufactured by IBASE, such as CPU, CPU cooler, memory, storage

devices, power adapter, panel and touchscreen.

＊ PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,

IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE

TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED

FOR REPAIR AND SHIPPING CHARGES.

Technical Support & Services

1. Visit the IBASE website at www.ibase.com.tw to find the latest information

about the product.

2. If you need any further assistance from your distributor or sales

representative, prepare the following information of your product and

elaborate upon the problem.

•Product model name

•Product serial number

•Detailed description of the problem

•The error messages in text or in screenshots if there is any

•The arrangement of the peripherals

•Software in use (such as OS and application software, including the

version numbers)

3. If repair service is required, you can download the RMA form at

http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and

contact your distributor or sales representative.

vi IP315 User’s Manual

Table of Contents

Chapter 1

General Information ............................................. 1

1.1

Introduction .........................................................................................2

1.2

Features..............................................................................................2

1.3

Specifications ...................................................................................... 3

1.4

Overview .............................................................錯誤! 尚未定義書籤。

1.5

Dimensions .........................................................................................5

Chapter 2

Hardware Configuration.......................................... 6

2.1

Setting the Jumpers ............................................................................7

2.2

Connector Locations on IP315 ............................................................ 8

2.3

Jumpers Quick Reference ...................................................................9

2.3.1

USB 2.0 Connector (USB1,USB2).............................................9

2.3.2

ATX Power ON Pin Header (J3) .................................................9

2.3.3

Reset Pin Header (J4)................................................................9

2.4

Connectors Quick Reference.............................................................11

2.4.1

ATX Power Connector (J1)...................................................... 11

2.4.2

ATX 12V Power Connector (ATX_12V_2X1) ........................... 12

2.4.3

System Fan Power Connector (FAN1,FAN2) .......................... 12

2.4.4

SHB Express™ Connector Pinout(BP_CONNA1, BP_CONNB1,

BP_CONNC1,BP_CONND1)............................................................... 12

2.4.5

PCI Routing (PCI1,PCI2,PCI3,PCI4) ........................................ 14

IP315 User’s Manual

vii

This page is intentionally left blank.

Chapter 1

General Information

The information provided in this chapter includes:

•Features

•Specifications

•Board Picture

•Board Dimensions

2 IP315

User’s Manual

1.1 Introduction

IP315 is a Backplane for PICMG 1.3 CPU module. Measuring 310 mm x 327

mm (12.2” x 12.9”), it provides expansion slots connectors including one

PICMG 1.3 slot, one PCIe(16x) slot (x8 signal), two PCIe(8x) slot (x4 signal),

four PCIe(4x) slot (x1 signal), four PCI slot, two USB 2.0, and two SATA3.0.

Photo of IP315

1.2 Features

•1 x PICMG 1.3 slot

•1 x PCIe(16x) slot (x8 signal)

•2 x PCIe(8x) slot (x4 signal)

•4 x PCIe(4x) slot (x1 signal)

•4 x PCI slot

•2 x USB 2.0 (2x 4-pin header)

•2 x SATA3.0,
