UserManual ViVOpay KioskII

631-0071-00

Page2of19

ID TECH

10721 Walker Street

Cypress CA90630

USA

This document, as well as the hardwareand software it describes, is furnished under licenseand

may only be used in accordance with the terms of such license. The content of this paper is

furnished for informationaluse, subject to changewithout notice, and not to be construed as a

commitment by ID TECH. ID TECH assumes no responsibility or liability for any errorsor

inaccuracies that may appear in this document.

Except as permitted by such license, nopartof this publication may be reproduced or

transmitted byelectronic, mechanical, recorded, or any other method, or translated into

another language or language form without the express written consent of ID TECH. ID TECH

is a registered trademark of International Technologies and Systems Corporation. ViVOpay

and Value through Innovation are trademarks ofInternational Technologies andSystems

Corporation.Other trademarks are the property of the respective owner.

Warranty Disclaimer: Theservices andhardware areprovided "asis" and "as-available," and the

use of theseservices andhardware areat theuser’sown risk. ID TECH does notmake, and hereby

disclaims, any andall other express or implied warranties,including, butnot limited to warranties

ofmerchantability,title, fitness fora particular purpose, and any warranties arising from any course

of dealing,usage, or trade practice. ID TECH does not warrant that the services or hardware will

be uninterrupted, error-free, orcompletely secure.

Page3of19

FCC Regulatory Compliance

Notices Class B Equipment

This equipment has been tested and found to comply with the limits for a Class B digital

device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

Reasonable protection against harmful interference in residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

And used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. This device complies with part 15 of the FCC rules. Operation is

subject to two conditions: (1) This device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off an on, the user is encouraged to try and

correct the interference by one ormoreof the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes ormodifications to the ViVOpay Kiosk II not expressly approved by ID TECH

could void the user’s authority to operate the ViVOpay Kiosk II.

ICComplianceWarning

Operation issubject to twoconditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

CautionsandWarnings

根據

NCC

低功率電波輻射性電機管理辦法

規定:

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、

加大功率或變更原設計之特性及功能。

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即

停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。

低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

Page4of19

Table of Contents

Overview..............................................................................................................5

Features............................................................................................................5

ValidCard Types...............................................................................................5

Kiosk II Specifications.......................................................................................6

ViVOpayKioskIIInstallation.............................................................................7

PartList.............................................................................................................7

Mounting the ViVOpay KioskIIExternal Antenna.............................................8

Flush- Mounting the Square BezelAntenna................................................10

Mounting the ViVOpay KioskIIController.......................................................10

MountingtheViVOpayKioskII ControllerUsingScrews.............................10

MountingtheViVOpayKioskIIControllerUsingMountingTape.................11

AttachingtheCablesfromtheAntennatothe Controller................................11

Connectingto Power.......................................................................................12

Connecting to the Data Port............................................................................13

UsingtheViVOpayKioskIIto Make a Purchase.............................................14

PresentingCards,Fobs,orNFCPhones ....................................................14

Making a Purchase......................................................................................14

InstallationPoints.............................................................................................14

RFInterference..................................................................................................15

Troubleshooting................................................................................................16

Firmware Upgrade............................................................................................17

Serial Firmware Download Process................................................................17

Preparation..................................................................................................17

Load the ViVOpay KioskFirmware..................................................................17

USB FirmwareDownload................................................................................18

Symbols explanations.......................................................................................19

Page5of19

Overview

The ViVOpayKiosk II is a compactstand-alone contactless readerdesigned to support

contactless transactions based on ISO 14443Type A/Type B/MiFare compatible cards,

fobs, and tags aswell as NFC phones.The ViVOpay Kiosk II is comprised of a compact

controller module and an antenna module packaged individually. This two-part design

allows the controller module to be installedwithin thecabinetry of a kiosk and the

antenna installed on an exterior surface witha separation of up to 1 meter. The antenna

is availablewith a square or angled bezel.

The ViVOpayKiosk II supportsUSB andserialRS232host communication usingthe

protocol defined in theGlobal Reader Serial InterfaceDevelopers Guide. The ViVOpay

Kiosk II is designed to support a wide input power range. Both dataand powercan be

supplied via asinglecable to reducing the effort and complexity of installation.

Features

Supports ISO14443 TypeA, Type B, MiFareand NFC basedcontactless

transactions

32-bit Microcontroller withample memory capable of supporting future

application upgrades

Crypto data processing forcontactless EMV cards

RS232(9600,19200, 38, 400, 57, 600,115, 200 baud) host interface

RS232 or USB data communications

Small antenna flush-mounted on external cabinetry with square or angled bezel

Internal mounted controller board with1meter controller/antenna separation

Valid CardTypes

ViVOpay Kiosk II supports the followingcontactless payment applications in thelatest

release of firmware:

ISO 14443

PayPass M/Stripe

PayPass M/Chip

PayPass MXI

VisaWave 1 and 2

VisaPay/Wave MSD and qVSDC

JCBJ/Speedy

JCB Mobile/QuicPay

American Express- ExpressPay

Discover Zip

MiFare ePurse

Page6of18

KioskII Specifications

Hardware

MTBF 500,000 hrsbased on TelcordiaTechnologies

SR-332 modeled at 40°C.

Transmitter F

equency 13.56 MHz +

-0.01%

TransmitterModulation ISO 14443-2Type

Rise/Fall Time: 2-3 µsec.Rise, <1 µsec fall

ISO 14443-2Type B

Rise/Fall Time: <2 µsec. each; 8%-14%ASK

Receiver Subcarrier F

equency 847.5 KHz

Receiver Subcarrier Data ISO 14443-2Type A: Modified Mancheste

ISO 14443-2Type B: NRZ-l, BPSK

Typical ReadRange 4-6 cm (1.5 to 2.3 inches)

sical

Controlle

Height 105 mm (4.13 inches)

Width 76.2 mm (3.00 inches)

Depth 22.5 mm (0.88 inches)

Square BezelAntenna Height 75 mm (2.95 inches)

Width 60 mm (2.36 inches)

Depth 16.8 mm (0.66 inches)

ngle Bezel Antenna Height 96.2 mm (3.787 inches)

Width 82.3 mm (3.24 inches)

Depth 16.8 mm (0.66 inches)

ironmental

Operating Temperature -25° to 70° C(-13° to 158° F)

Storage Temperature -40° to 85° C(-40° to 185° F)

Operating Humidity 10% to 90% non-condensing

Electrical

Reader Input Voltage +7.5v to 36 VDC (by AC to DC adapter)

Page7of18

ViVOpay Kiosk II Installation

Thissection provides information on how to install the ViVOpay Kiosk II on a kiosk.

PartList

Verify that you have the following hardwarefor the installation of the ViVOpay Kiosk II:

ViVOpay Kiosk II Controller

ViVOpay Kiosk II Antenna(either square or angle bezel)

Antenna LED power and data cable

ViVOpay Kiosk II to ECR/POS cable(customer supplied). This USB or serial

cable varies based on thehost to be used.

Drill Template for the antenna (630-1046-00)

Page8of19

MountingtheViVOpayKioskII ExternalAntenna

Use the following instructions to mount the antenna on the exteriorof the kiosk:

Note: Verify the orientationof the ViVOpay Kiosk II Antenna beforemarking anddrilling

the holes. The two larger holesshould be located towards the top ofthe mounting

location to ensure that the ViVOpay KioskII Antennais oriented correctly with the LEDs

at the top.

1. Using the Drill Template for the antenna(630-1046-00), locate and mark the four

4.4mm (0.173 inch) mounting holes.

2. Using the Drill Template, locate and mark the two 14.0 mm (0.551 inches) across

holes (used for connectingthe antennapower and the LED power and datacable to

the ViVOpay Kiosk II).

3. Drill the four 4.4 mm (0.173) mounting holes using a number 17 drill bit.

4. Drill the two 14.0 mm (0.551 inch) holesusing a 35/64 drill bit.

5. Remove thenuts from thefour mountingscrews.

6. Route the end of the cable(220-2457-00) with the RJ45 connectorthrough the left

14.0 mm (0.551 inch) hole in to the kiosk. Make sure that the front of the antenna will

be properly oriented(not upside down)on the kiosk before inserting the fourscrews

into the mounting holes.

Page9of19

7. Align the four screwswith the mounting holes and attach the ViVOpay Kiosk II to the

outside surface. Make sure that the cable is not pinched or binding.

8. Use the fournuts to secure the ViVOpayKiosk II to the outside surface of thekiosk.

Makesure to tighten the nuts securely sothat the ViVOpay Kiosk II does not move

on the outside surface of the kiosk.

If you are installing the Angle Bezel Antenna, tighten the nuts to 5-7in/lbs. for a good

weather seal.

9. Attach the end of the cablewith the SMB connector through the right 14.0 mm (0.551

inch) hold and attach it to the socketonthe back of the ViVOpay Kiosk II antenna. The

SMB connector pushes on the socket of the antenna.

Page10of19

10.Attach the RJ45 connectorcoming fromthe ViVOpay Kiosk II Antenna to the RJ45

receptacle onthe 220-2457-00cable.

Flush- Mounting the Square Bezel Antenna

The RF fieldof the antenna is sensitiveto the proximity of metal.Ifyou are flush-

mounting theantenna in a metal surfaceor bezel, you have three options:

Mount with the RF emittingsurface of the antenna at least 1 cm forward of any

metal.

Mount with the RF emittingsurface of the antenna at least 1 cm behind any

metal. This will reduce theeffective range of the antenna.

Mount flushwith the metal but allow aminimum of 1cm spacing between the

antenna and the metal.

In all cases, test the antenna mounting before engaging in a full scale installation.

MountingtheViVOpayKioskII Controller

Note: The ViVOpay Kiosk II Controller must be mounted within 1meter of the antenna. If the

antenna is mounted on a surface that opens (such asa door), make sure the controller and

antenna areclose enough that there is no tension on the cable when the enclosure is open.

If it is acceptable, the installer can drill four holes for mounting thecontroller if screw

heads can appear on the outside of thekiosk.In thiscase, it wouldbe advisableto use

security screws to preventtampering with the screws.

If drilling additional holes on the outside ofthe kiosk surface is notacceptable, the

installer can use double-sided tape to mountthe controller to any clean surface.

Mounting the ViVOpayKiosk II Controller Using Screws

1. Position theViVOpay Kiosk II controller on the interior of the kiosk making sure that

there issufficient room for the antenna mountingsurface to be fully opened.

Inhaltsverzeichnis

Andere IDTECH Kartenleser Handbücher

IDTECH

IDTECH Spectrum IIa Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP5200 Bedienungsanleitung

IDTECH

IDTECH UniPay Gebrauchsanweisung

IDTECH

IDTECH ViVOpay VP5300M Bedienungsanleitung

IDTECH

IDTECH iMag Bedienungsanleitung

IDTECH

IDTECH VP3300 Bedienungsanleitung

IDTECH

IDTECH OMNI Bedienungsanleitung

IDTECH

IDTECH MiniMag RS232 Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP3350 Gebrauchs- und Pflegehandbuch

IDTECH

IDTECH BT Mag Bedienungsanleitung

IDTECH

IDTECH MINIMAG Gebrauchsanweisung

IDTECH

IDTECH ViVOpay VP3600 Bedienungsanleitung

IDTECH

IDTECH Kiosk V Bedienungsanleitung

IDTECH

IDTECH MINIMAG Gebrauchsanweisung

IDTECH

IDTECH BT Mag Bedienungsanleitung

IDTECH

IDTECH SmartPIN L80 Bedienungsanleitung

IDTECH

IDTECH EzWriter Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP5300 Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP6300 Bedienungsanleitung

IDTECH

IDTECH SecureMag Bedienungsanleitung

IDTECH

IDTECH SREDKey Bedienungsanleitung

IDTECH

IDTECH MINIMAG Bedienungsanleitung

IDTECH

IDTECH EasyMag Bedienungsanleitung

IDTECH

IDTECH VP3300 OEM Bedienungsanleitung

Beliebte Kartenleser Handbücher anderer Marken

Lindy

Lindy 43185 Bedienungsanleitung

Lindy

Lindy 43185 Bedienungsanleitung

ViziT

ViziT RD-4F Bedienungsanleitung

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Bedienungsanleitung

AVID ID

AVID ID AVID1043 Bedienungsanleitung

Conrad

Conrad PCMCIA Bedienungsanleitung

Rosslare

Rosslare DR-6255 Bedienungsanleitung

Lindy

Lindy 51541 Bedienungsanleitung

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Bedienungsanleitung

Johnson Controls

Johnson Controls Kantech tyco ioSmart Bedienungsanleitung

ACS

ACS ACR122L Bedienungsanleitung

Secukey

Secukey S2-MF Bedienungsanleitung

Elecom

Elecom MR-SMC07 series Bedienungsanleitung

Alien

Alien ALR-9800 Bedienungsanleitung

ACS

ACS ACR310 Bedienungsanleitung

Datamars

Datamars R-IN1300 MID Bedienungsanleitung

Alarm Lock

Alarm Lock AL-PRE2 Bedienungsanleitung

xpr

xpr B100PROX-AH Benutzerhandbuch
