IKA C-MAG HS4 Bedienungsanleitung

CMAG_012016

20000005327

O  EN 

B DE 

M ’ FR 

I   PT 

I   ES 

C-MAG HS4 C-MAG HS7 C-MAG HS10

C-MAG HP4 C-MAG HP7 C-MAG HP10

C-MAG MS4 C-MAG MS7 C-MAG MS10

C-MAG HS 4

C-MAG HS 7

C-MAG HS 10

IKA® WERKE

Item Designation Pos. Bezeichnung Pos. Désignation

Pos. Descriçao

A Switch A Geräteschalter A Commutateur

A Switches Dispositivos

B LED heating B LED B DEL B LED

C Display C Display C Affichage C Display

D Rotary knob D Bedienknopf D Bouton rotatif D

Botão de regulação

motor Motor moteur motor

E Rotary knob E Bedienknopf E Bouton rotatif E

Botão de regulação

heater Heizung chauffage

aquecimento

F Threaded F Stativgewin- F Alésage fileté

F Buraco do tripé

support bore debohrung du statif

com rosca

G Mains socket G Netzbuchse G Prise secteur G

Power jack

H Contact- H Kontakt- H douille de H Contato termômetro

thermometer- thermometer- thermomêtre bucha

jack Buchse de contact

Fig. 1

ADE

FGH

KONFORMITÄTSERKLÄRUNG DE

Wir erklären in alleiniger Verantwortung, dass dieses Produkt den Bestimmungen der Richtlinien 2011/65/EU, 2014/30/EU und

2014/35/EU entspricht und mit den folgenden Normen und norminativen Dokumenten übereinstimmt:

EN 61010-1, EN 61010-2-010, EN 61010-2-051, EN 60529, EN 61326-1 und EN ISO 12100.

DECLARATION OF CONFORMITY EN

We declare under our sole responsibility that this product corrosponds to the regulations 2011/65/EU, 2014/30/EU and

2014/35/EU and conforms with the standards or standardized documents EN 61010-1,

EN 61010-2-010,

EN 61010-2-051,

EN 60529, EN 61326-1 and EN ISO 12100.

DÉCLARATION DE CONFORMITÉ FR

Nous déclarons sous notre propre responsabilité que se produit est conforme aux réglementations 2011/65/UE, 2014/30/UE et

2014/35/UE et en conformité avec les normes ou documents normalisés suivant EN 61010-1,

EN 61010-2-010,

EN 61010-2-051,

EN 60529, EN 61326-1 et EN ISO 12100.

DECLARAÇÃO DE CONFORMIDADE PT

Declaramos, sob responsabilidade exclusiva, que este produto cumpre as disposições das diretivas

2011/65/EU e 2014/30/

EU e 2014/35/EU

e está de acordo com as seguintes normas ou documentos normativos

EN 61010-1 e

EN 61010-2-010 e

61010-2-051 e EN 60529 e EN 61326-1 e EN ISO 12100.

Page

Declaration of conformity 2

Safety instructions 3

Unpack 4

Correct use 4

Commissioning 5

Error codes 6

Accessories 6

Maintenance 6

Warranty 7

Technical data 8

List of spare parts 9

Spare parts diagram 34/35

To your protection

Read the operating instructions in full before starting up

and follow the safety instructions.

• Keep the operating instructions in a place where they can be

accessed by everyone.

• Ensure that only trained staff work with the appliance.

• Follow the safety instructions, guidelines, occupational health

and safety and accident prevention regulations.

• Socket must be earthed (protective ground contact).

• Attention - Magnetism! Effects of the magnetic field have

to be taken into account (e.g. data cardiatic, carriers pacema-

kers...).

•

Risk of burns! The heating plate can reach temperatures in

excess of 500 °C. Pay attention the residual heat after swit-

ching off..

Please make sure that the mains cable does not contact the

heating plate

• Wear your personal protective equipment in accordance with the

hazard category of the medium to be processed. Otherwise

there is a risk of:

- splashing liquids

- projectile parts

- release any toxic or combustable gases.

•Set up the appliance in a spacious area on an even, stable, clean,

non-slip, dry and fireproof surface.

•The feet of the appliance must be clean and undamaged.

•Position the knob at the left stop before starting up. Gradually

increase the speed.

•Reduce the speed if

- the medium splashes out of the vessel because the speed is

too high

- the appliance is not running smoothly

the container moves on the set-up surface.

• Caution! Only process and heat up any media that has a flash

point higher than the adjusted target temperature (0 to 550 °C)

that has been set.

The target temperature must always be set to at least 25 °C

lower than the fire point of the media used.

•

When using PTFE-coated magnetic bars, the following hase

to be noted:

Chemical reactions of PTFE occur in contact with

molten or dissolved alkaline and alkaline - earth metals, as well

as with fine-particled powders of metals of the 2. and 3. group

of the periodical system at temperatures above 300-400°C.

Only elementary fluorine, chlorine trifluoride und alkaline metals

do attack PTFE, halogen hydrocarbons have a reversibly swelling

effect.

Source: Römpps Chemie-Lexikon and „Ullmann“ Bd.19

•Check the appliance and accessories beforehand for damage

each time you use them. Do not use damaged components.

• Only replace damaged parts with spare parts identical to the ori

ginal in function and quality.

•Do not use the device if the ceramic set-up surface is damaged

e.g. scratches, splinters or corrosion. A damaged set-up surface

could break if used.

•Beware of the risk of

Contents

Safety instructions

- flammable materials

- glass breakage as a result of mechanical shaking power

- incorrect container size

- too much medium

- unsafe condition of container

•Only process media that will not react dangerously to the extra

energy produced through processing. This also applies to any

extra energy produced in other ways, e.g. through light irradiation.

•Do not operate the appliance in explosive atmospheres, with

hazardous substances or under water.

•A seperation from the line is made with the equipment only by

pulling net and/or device plug.

•Safe operation is only guaranteed with the accessories described

in the ”Accessories” chapter.

•Always disconnect the plug before fitting accessories.

•Accessories must be securely attached to the device and cannot

come off by themselves. The centre of gravity of the assembly

must lie within the the set-up surface.

•The appliance starts up again automatically following a cut in the

power supply.

•The appliance may heat up when in use.

•Abrasion of the dispersion equipment or the rotating accessories

can get into the medium you are working on.

To the protection of the equipment

•The voltage stated on the nameplate must correspond to the

mains voltage.

•Do not cover the device, even partially e.g. with metallic plates

or film. This results in overheating.

•Protect the appliance and accessories from bumps and impacts.

•Observe the minimum distances between devices, between the

device and the wall as given in the Fig. 2 and above the assem-

bly (min. 800mm)

> 100 mm > 100 mm

> 100 mm

•

Unpack

- Please unpack the device carefully

- In the case of any damage a fact report must be sent

immediately (post, rail or forwarder)

•

Delivery scope

- Heating magnetic stirrer or

Magnetic stirrer or

Heating device

- Mains cable

- Operating instructions

•

Use

For mixing and/or heating liquids

•

Range of use

- Laboratories - Schools

- Chemical industry - Pharmacies

Unpack

Correct use

Fig. 2

Commis-

sioning

Stirring

Heating

Contact-

thermometer

connection

MS 4 MS 7 MS 10 HS 4 HS 7 HS 10 HP 4 HP 7 HP 10

Put device switch (A) in the OFF position

Plug in (G) mains cable

Once connected to the power supply the device is in “stand-by” mode

The right decimal point on the display (C) is lit

Commissioning

Put device switch (A) in the ON position

Any set values are retained when device is switched off and even after the device is

disconnected from the power!

Set the engine speed with the operating button (E) on the right

Put device switch (A) in the ON position

Any set values are retained when device is switched off and even after the device is disconnected from the power!

Set the target temperature for the heating plate using operating button (D) [for VHP (E)]

The set value is indicated on the display (C). If energy is being supplied to the heating plate,

the red LED (B) lights up

In the stir and stand-by modes, “hot” flashes on the display after the heat has been switched off

for as long as the temperature of the set-up surface exceeds 50°C

Put device switch (A) in the OFF position, unplug contact plug

Safety contact thermometer acc. to DIN 12878 class 2 connected with jack (H)

Put device switch (A) in the ON position

Beware the instruction manual of the contact thermometer

Important: Display (C) also indicates the target temperature of the heating plate when the cont-

act thermometer is connected

Installing the support rod

The support rod is attached using the thraeded support bore (F).

• Screw nut M10 on to the support rod as far

as the stop

• Screw on the support rod as far as the

stop by hand

• Tighten the support rod and nut M10

using a flat wrench (SW17).

•

Use bossheads to assemble

accessory parts or acces-

sory devices.

The appliance is maintenance-free.

Cleaning

Only use cleansing agents which have been recommended by

IKA®

Use to remove:

Dyes isopropyl alcohol

Construction materials water containing tenside/

isopropyl alcohol

Cosmetics water containing tenside/

isopropyl alcohol

Foodstuffs water containing tenside

Fuels water containing tenside

- Do not allow moisture to get into the appliance when cleaning

- Wear protective gloves during cleaning the devices.

Footstep during the enterprise a disturbance up, is indicated these

with the devices to HS and HP by an error message in the display (C).

Whenever an error message appears switch the device off to cool down.

Error codes

Error Cause Solution

code

E1 Inner temperature • switch off the unit and allow it

too high cool down

E6 Motor seized • Stirring bars inappropriate

• Reduce the viscosity

• Foreign bodies in the equipment

remove

E9 Safety circuit • Plug the contact plug (G)

ETC • Plug the contact thermometer

• Connecting cable, plug or

contact tthermometer defect,

exchange

Have the device repaired if the error is not corrected using the measures

described or if another error code is displayed.

Stirring organs

stirring bars: Ø 6 mm, lengts to 15mm

Ø 8 mm, lengts to 50mm

Ø10mm, lengt to 80mm

Any other accessories

RSE stirring bar remover

H36 holding rod

H16V support rod

H44 cross sleeve

ETS-D5 electrical contact thermometer

Accessories

Maintenance

Fig. 3

- Before using another than the recommended method for clean-

ing or decontamination, the user must ascertain with IKA®that

this method does not destroy the instrument.

Spare parts order

When ordering spare parts, please give:

- Machine type

- Manufacturing number, see type plate

- Item and designation of the spare part,

see spare parts list and diagram

Repair

Please only send devices in for repair that have been cleaned

and are free of materials which might present health hazards.

For this, use the “certificate of compliance” form which you can

obtain from IKA®or can download a version for printing from the IKA®

website at www.ika.com.

If your appliance requires repair, return it in its original packaging.

Storage packaging is not sufficient when sending the device - also use

appropriate transport packaging.

In accordance with IKA®warranty conditions, the warranty period is

24 months. For claims under the warranty please contact your local

dealer. You may also send the machine direct to our works, enclosing

the delivery invoice and giving reasons for the claim. You will be liable

for freight costs.

The warranty does not cover wearing parts, nor does it apply to faults

resulting from improper use or insufficient care and maintenance con-

trary to the instructions in this operating manual.

Warranty

230 ±10%

120 ±10%

100 ±10%

230 / 50Hz

120/ 60 Hz

100/ 60 Hz

50/60

30 270 255 30 1020 1005 30 1520 1505

30 270 255 30 1020 1005 30 1070 1055

2,5

100

+5 to +40

IP 21

max. 2000

150 x 260 x 105 220 x 335 x 105 300 x 415 x 105

3 5 6

100-1500 100-1500 - 100-1500 100-1500 - 100-1500 100-1500 -

Scale Scale - Scale Scale - Scale Scale -

15 15 - 15 15 - 15 15 -

1,5 1,5 - 1,5 1,5 - 1,5 1,5 -

5 5 - 10 10 - 15 15 -

100x100 100x100 100x100 180x180 180x180 180x180 260x260 260x260 260x260

- 250 250 - 1000 1000 - 1500 1500

- 250 250 - 1000 1000 - 1050 1050

- 50 50 - 50 50 - 50 50

- 500 500 - 500 500 - 500 500

- ±5 ±5 - ±5 ±5 - ±5 ±5

- 550 550 - 550 550 - 550 550

MS 4

HS 4

HP 4

MS 7

HS 7

HP 7

MS 10

HS 10

HP10

Operating voltage VAC

VAC

Nominal voltage VAC

VAC

Design frequence Hz

Input power max. at 230 and 120 VAC

100 VAC

Power consumption in stand-by mode W

Perm. duration of operation %

Perm. ambient temperature °C

Perm. relative humidity %

Protection type acc. to DIN EN 60529

Protection class

Overvoltage categorie

Contamination level

Operation at a terrestrial altitude m

Dimensions (W x D x H) mm

Weight kg

Motor

Speed range (infinitely) rpm

Speed display

Power input W

Power output W

Max. stirring quantity (water) ltr

Heating plate

Heating plate dimension mm

Heating power at 230 and 120 VAC W

at 100 VAC

Surface temperature min. C°

Surface temperature max. C°

Temperature fluctuation* C°

Limit of safety temperaure C°

Technical data

* On a certain point, without vessel, heating plate centre at 100 °C.

Pos. Designation MS-C4/C7/C10 HP-C4/C7/C10 HS-C4/C7/C10

7 Contersunk srew X X X

8 Connect distributer X X X

12 Insulating X X

13 Danger sign X X

17 Distance hoderLP X X X

18 Clip-Triac fastening X X X

19 Angel connector X X X

20 Cover X X X

21 Mounting plug X X X

31 Placing plate X X X

32 Heating foil X X

33 Insulating X X

35 Ceramic bushing X X

37 Holding bracket X X X

38 Protectione sheet X X X

40 Distance bushing X X X

41 Distance bushing X X X

45 Mylar-foil X X X

46 Color filter foil X X

47 Front foil X X X

51 Control knob X X X

53 Contact plug X X

54 Magnet X X

59 Shaded pole asynchron motor X X

65 Device pedestal X X X

66 Impulse disk X X

70 Distance bushing X X

71 Magnett holder X X

75 Temperature sensor X X

76 Pressure sheet X X X

80 Contact thermometer bushing X X

80 Cap (Contact-thermometer) X

81 Connecting cable X X X

100 Label X X X

2001 PCB compl. X X X

2002 PCB accessories consisting of: X X X

Poti (motor); Poti (heating); Opto-

coupler and LED-display

List of spare parts

Seite

Konformitätserklärung 2

Sicherheitshinweise 10

Auspacken 11

Bestimmungsgemäßer Gebrauch 11

Bedienung 12

Fehlercodes 13

Zubehör 13

Instandhaltung 13

Gewährleistung 14

Technische Daten 15

Ersatzteilliste 16

Ersatzteilbild 34/35

Zu Ihrem Schutz

Lesen Sie die Betriebsanleitung vor Inbetriebnahme voll-

ständig und beachten Sie die Sicherheitshinweise.

• Bewahren Sie die Betriebsanleitung für Alle zugänglich auf.

•

Beachten Sie, dass nur geschultes Personal mit dem Gerät arbeitet.

•

Beachten Sie die Sicherheitshinweise, Richtlinien, Arbeitsschutz-

und Unfallverhütungsvorschriften.

• Steckdose muss geerdet sein (Schutzleiterkontakt).

• Achtung - Magnetismus! Beachten Sie die Auswirkungen

des Magnetfeldes (Herzschrittmacher, Datenträger...).

•

Verbrennungsgefahr! Die Heizplatte kann über 500 °C

heiß werden. Restwärme nach dem Ausschalten beachten.

Stellen Sie sicher, dass das Netzkabel die Heizplatte nicht

berührt!

• Tragen Sie Ihre persönliche Schutzausrüstung entsprechend der

Gefahrenklasse des zu bearbeitenden Mediums. Ansonsten be-

steht eine Gefährdung durch:

- Spritzen und Verdampfen von Flüssigkeiten

- Herausschleudern von Teilen

- Freiwerden von toxischen oder brennbaren Gasen

• Stellen Sie das Gerät frei auf einer ebenen, stabilen, sauberen,

rutschfesten, trockenen und feuerfesten Fläche auf.

• Die Gerätefüße müssen sauber und unbeschädigt sein.

• Stellen Sie vor Inbetriebnahme die Drehknöpfe auf Linksan-

schlag. Steigern Sie die Drehzahl langsam.

• Reduzieren Sie die Drehzahl, falls

- Medium infolge zu hoher Drehzahl aus dem Gefäß spritzt

- unruhiger Lauf auftritt

- sich das Gefäß auf der Aufstellplatte bewegt.

•Achtung! Mit diesem Gerät dürfen nur Medien bearbeitet bzw.

erhitzt werden, deren Flammpunkt über der eingestellten

Solltemperatur (0 ... 550 °C) liegt.

Die eingestellte Solltemperatur muss immmer mindestens 25 °C unter-

halb des Brennpunktes des verwendeten Mediums liegen.

•Bei Verwendung von PTFE-ummantelten Magnetstäbchen ist

Folgendes zu beachten: Chemische Reaktionen von PTFE treten

ein im Kontakt mit geschmolzenen oder gelösten Alkali- und Erd-

alkalimetallen, sowie mit feinteiligen Pulvern von Metallen aus

der 2. und 3. Gruppe des Periodensystems bei Temperaturen

über 300-400 °C. Nur elementares Fluor, Chlortrifluorid und Al-

kalimetalle greifen es an,Halogenkohlenwasserstoffe wirken

reversibel quellend.

(Quelle: Römpps Chemie-Lexikon und „Ullmann“ Bd.19)

• Prüfen Sie vor jeder Verwendung Gerät und Zubehör auf Be-

schädigungen. Verwenden Sie keine beschädigten Teile.

•Ersetzen Sie beschädigte Teile nur durch Ersatzteile, die dem

Original in Funktion und Qualität gleich sind.

•Verwenden Sie das Gerät nicht, falls die keramische Aufstell-

platte Beschädigungen z.B. Kratzer, Absplitterungen oder Ver-

ätzungen aufweist. Eine beschädigte Aufstellplatte kann bei Be-

nutzung brechen.

• Beachten Sie eine Gefährdung durch

- entzündliche Materialien.

- Glasbruch

- falsche Dimensionierung des Gefäßes

- zu hohen Füllstand des Mediums

Inhaltsverzeichnis

Sicherheitshinweise

Andere Handbücher für C-MAG HS4

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IKA Laborausrüstung Handbücher

IKA

IKA KS 4000 i control Bedienungsanleitung

IKA

IKA EUROSTAR digital Bedienungsanleitung

IKA

IKA RV 10 basic Bedienungsanleitung

IKA

IKA MICROSTAR digital Bedienungsanleitung

IKA

IKA ULTRA-TURRAX T 18 digital Bedienungsanleitung

IKA

IKA C-MAG HS7 Bedienungsanleitung

IKA

IKA HBR 4 control Bedienungsanleitung

IKA

IKA RO 10 Bedienungsanleitung

IKA

IKA H 29 Handbuch

IKA

IKA G-L Bedienungsanleitung

IKA

IKA RCT basic Bedienungsanleitung

IKA

IKA WERKE IKAMAG RET control-visc Bedienungsanleitung

IKA

IKA IKATRON ETS-D6 Bedienungsanleitung

IKA

IKA HB ECO Bedienungsanleitung

IKA

IKA myPlate Bedienungsanleitung

IKA

IKA S 25 KD-18 G Bedienungsanleitung

IKA

IKA MS 3 digital Bedienungsanleitung

IKA

IKA RW 47 D Bedienungsanleitung

IKA

IKA Big Squid Bedienungsanleitung

IKA

IKA ULTRA-TURRAX T 18 basic Bedienungsanleitung

IKA

IKA MTS 2/4 digital Bedienungsanleitung

IKA

IKA MultiDrive MI 250 Bedienungsanleitung

IKA

IKA I-MAG 300 Bedienungsanleitung

IKA

IKA IKAMAG RET basic Bedienungsanleitung

Beliebte Laborausrüstung Handbücher anderer Marken

Qiagen

Qiagen DML 3000 Bedienungsanleitung

Queensgate

Queensgate NANOSCAN OP400 Programmierhandbuch

Conviron

Conviron GEN1000-GE Bedienungsanleitung

Parr Instrument

Parr Instrument 4560 Bedienungsanleitung

Integra

Integra DOSE IT Bedienungsanleitung

Agilent Technologies

Agilent Technologies 5800 ICP-OES Bedienungsanleitung

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Bedienungsanleitung

NI PXI-5422 Handbuch

Collomix

Collomix Aqix Bedienungsanleitung

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Bedienungsanleitung

Ocean Insight

Ocean Insight FLAME-NIR+ Bedienungsanleitung

Parker

Parker ALIGN-MG-NA Bedienungsanleitung

BD 644787 Bedienungsanleitung

DENTAURUM

DENTAURUM Compact Megaplus Bedienungsanleitung

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Bedienungsanleitung

VWR

VWR SAS Super IAQ Bedienungsanleitung

illumina

illumina MiSeqDx Bedienungsanleitung

Yamato

Yamato BM510 Bedienungsanleitung
