ISP2150 2U Rack Server Platform

Quick Start Guide

A Guide for Technically Qualified Assemblers of Intel®Identified

Subassemblies/ Products

Before You Begin

FCC Declaration of Conformity.................................................................................................. 4

Cautions and Warnings...............................................................................................................6

Product Regulation Compliance..................................................................................................7

Safety Compliance......................................................................................................................7

Electromagnetic Compatibility (EMC)....................................................................................... 7

ISP2150

Opening and Closing the Front Bezel .........................................................................................8

Locking and Unlocking the Front Bezel .....................................................................................9

Attaching and Removing the Front Bezel...................................................................................9

Installation

Open the Cover...........................................................................................................................9

Installing a Microprocessor....................................................................................................... 10

Installing Memory..................................................................................................................... 11

Installing a Hard Drive..............................................................................................................13

Installing Add-in Cards............................................................................................................. 14

Installing a Slim-Line CD-ROM Drive.....................................................................................16

Removing a Diskette Drive.......................................................................................................17

Re-Installing a Diskette Drive...................................................................................................17

Close the Cover......................................................................................................................... 17

Installing the Front Bracket and Racking Your System............................................................18

Installing the Front Bracket in a Cabinet...................................................................................18

Installing the Front Bracket in a Center-Mount, Relay Rack .................................................... 20

Installing the Rail Kit and Racking Your System (Optional Accessory)...................................21

Technical Reference

Front Panel Controls and Indicators..........................................................................................25

Back Panel Connectors.............................................................................................................26

Jumpers..................................................................................................................................... 27

Server Board Components........................................................................................................ 29

Getting Help.......................................................................................................................................30

Order Number: A13687-001

4 ISP2150 2U Rack Server Platform Quick Start Guide

The ISP2150 2U Rack Server Platform Product Guide can be found at http://channel.intel.com/isp/

or by any means without prior written consent of Intel.

Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may

appear in this document. Intel makes no commitment to update nor to keep current the information contained in this

document.

†Third-party brands and trademarks are the property of their respective owners.

Before You Begin

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation

5200 N.E. Elam Young Parkway

Hillsboro, OR 97124

1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment to an outlet on a circuit other than the one to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

ISP2150 2U Rack Server Platform Quick Start Guide 5

ICES-003 (Canada)

Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils

numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils

Numériques”, NMB-003 édictée par le Ministre Canadian des Communications.

(English translation of the notice above) This digital apparatus does not exceed the Class B limits for radio

noise emissions from digital apparatus set out in the interference-causing equipment standard entitled

“Digital Apparatus,” ICES-003 of the Canadian Department of Communications.

BSMI (Taiwan)

The following EMC Warning along with the BSMI ID number 3882B139 is located on the outside rear

area of the product:

VCCI (Japan)

(English translation of the notice above.) This is a Class B product based on the standard of the Voluntary

Control Council For Interference (VCCI) from Information Technology Equipment. If this is used near a

radio or television receiver in a domestic environment, it may cause radio interference. Install and use the

equipment according to the instruction manual.

When used near a radio or TV receiver, it may become the cause of radio interference.

Read the instructions for correct handling.

This equipment has been tested for radio frequency emissions and has been verified to meet CISPR 22

Class B.

6 ISP2150 2U Rack Server Platform Quick Start Guide

Cautions and Warnings

WARNINGS

Pressing the power button does not turn off power to this server. Disconnect the

server from its power source and from any telecommunications links, networks, or

modems before doing any of the procedures described in this guide. Failure to do

this can result in personal injury or equipment damage. Some circuitry in the server

may continue to operate even though front panel power button is off.

This guide is for qualified technical personnel with experience installing and

configuring servers.

Read and adhere to all warnings, cautions, and notices in this guide and the

documentation supplied with the chassis, power supply, and accessory modules. If

the instructions for the chassis and power supply are inconsistent with these

instructions or the instructions for accessory modules, contact the supplier to find out

how you can ensure that your computer meets safety and regulatory requirements.

CAUTION

Electrostatic discharge (ESD) can damage server components. Do the described

procedures only at an ESD workstation. If no such station is available, you can provide

some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of

the computer chassis.

ISP2150 2U Rack Server Platform Quick Start Guide 7

Product Regulation Compliance

See the ISP2150 2U Rack Server Platform Product Guide for all applicable safety standards,

electromagnetic compatibility (EMC) regulations, and product certification markings.

Intended uses: This product was evaluated for use in computer rack cabinets within computer rooms and

similar locations. Other uses may require further evaluation.

Safety Compliance

USA: UL 1950 – CSA 950-95

Canada: UL certified to CSA 950-95 for Canada (product bears the single UL mark for U.S. and

Canada)

Europe: German GS Mark – ERG to EN60950

International: IEC60 950

Australian /

New Zealand:AS/NZ 3260 (IEC60 950 including national AU deviations)

Electromagnetic Compatibility (EMC)

USA: FCC CFR 47 Part 15, Class B

Canada: ICES-003 Class B

Europe: EN55022, Class B

EN55024 (Immunity)

EN61000-3-2 Limit for Harmonic Current Emissions

International: CISPR 22, Class B

Australian /

New Zealand:AS/NZ 3548, Class B limits (CISPR 22)

Japan: VCCI Class B (CISPR 22 B limit)

8 ISP2150 2U Rack Server Platform Quick Start Guide

ISP2150

Congratulations on the purchase of your new Intel®ISP2150 system. This Quick Start introduces you to

your new system, guides you through rack kit installation, and helps you get the system started.

The following procedures describe how operate the system’s front bezel, which covers the front panel

controls and indicators. For a description of the front panel features, refer to Front Panel Controls and

Indicators.

Opening and Closing the Front Bezel

With the bezel open you have access to all

of your system's front panel functions and

indicators. With the bezel closed you can

protect critical functions and still view the

system's indicators.

To open the bezel, do the following:

1. Stand in front of the chassis and grasp

the edges of the bezel from each side.

2. Gently pull the bezel towards you

until it begins to separate from the

chassis.

3. As the bezel separates from the

chassis, allow it to swing to its open

position situated below the chassis.

To close the bezel, gently raise it upwards.

The hinging mechanism will guide the

bezel into the correct position where it will

snap shut.

ISP2150 2U Rack Server Platform Quick Start Guide 9

Locking and Unlocking the Front Bezel

The bezel can be locked and unlocked to prevent unwanted access to the system.

To lock the bezel:

1. Remove the keys from inside the bezel (they should be taped to the inside).

2. Close the bezel and insert the key into the lock. Turn the lock counterclockwise until it stops (about a

quarter turn). The bezel is now locked and cannot be opened.

To unlock the bezel, insert the key into the lock and turn the lock clockwise until it stops (about a quarter

turn). The bezel is now unlocked and can be opened again.

Attaching and Removing the Front Bezel

The front bezel can be installed or removed from the system.

To attach the bezel:

1. With the LED light tunnels located at the top of the bezel, push in the arms on either side of the bezel

far enough so that the tabs on the ends of the arms can be inserted into the holes in the chassis.

2. Insert the tabs into the holes in the handles on the chassis. Make sure the tabs on each side of the

bezel are completely in the holes in the handles.

To remove the bezel:

1. With the bezel opened, gently push the metal hinge arms located on each side of the bezel in towards

the middle of the unit.

2. Push the arms far enough in so that the tabs on the end of the arms are completely out of the holes in

the handles on the chassis. The bezel should now be able to be removed.

3. The bezel should now be able to open and close easily and completely.

Installation

Follow these instructions to get your sever to the point where you can load an operating system on it.

Open the Cover

1. Loosen the three screws on the rear of the system.

2. Pull the cover back and remove it from the chassis.

10 ISP2150 2U Rack Server Platform Quick Start Guide

Installing a Microprocessor

The server supports up to two Intel®Pentium®II or Pentium III processors (with 100 MHz system bus).

If you are installing two processors, make sure they are the same speed, voltage, and stepping.

OM09315

OM09328

1. Remove the new processor from its

anti-static package and place it on a

grounded, static free surface or

conductive foam pad.

2. Attach the small end of the power

cable to the fan connector on the

S.E.C. cartridge, then attach the large

end (B) to the 3-pin connector on the

server board.

3. Orient the processor so that the heat

sink faces the I/O connectors. Slide

the processor into the retention module.

Push down firmly, with even pressure

on both sides of the top, until the

processor is seated.

4. To lock in the processor, push the

latches inward on the retention module

until they click into place. The latches

must be secured for proper electrical

connection of the processor.

5. After you have installed the processor,

you must configure its speed in BIOS

set-up.

CAUTION, Single-Processor

Configurations

If you install only one processor in a

system, it must go in the primary

connector (closest to the DIMM

sockets). With a single-processor

configuration, you must install a

termination board and termination

latch assembly (A) in the empty

secondary connector (B) to ensure

proper operation of your system. A

termination board is provided with

your system.

ISP2150 2U Rack Server Platform Quick Start Guide 11

Installing Memory

OM09318

The server only supports 100 MHz

PC/100-compliant SDRAM.

•Install from 32 MB to 2 GB of

unbuffered memory, using up to four

single or double-banked DIMMs

•Install from 32 MB to 2 GB of

registered memory, using up to four

single or double-banked DIMMs

12 ISP2150 2U Rack Server Platform Quick Start Guide

Installed DIMMs must be the same speed and either all registered or all unbuffered. For a list of supported

memory, call your service representative or visit the Intel Support website:

http://support.intel.com/support/motherboards/server/l440gx/compat.htm

CAUTION

Use extreme care when installing a DIMM. Applying too much pressure can damage the socket.

DIMMs are keyed and can be inserted in only one way.

Mixing dissimilar metals may cause later memory failures resulting in data corruption. Only install

DIMMs with gold-plated edge connectors in gold-plated sockets.

To install your memory:

1. Open your server.

2. Holding the DIMM only by its edges, remove it from its anti-static package.

3. Orient the DIMM so that the two notches in the bottom edge of the DIMM align with the keyed

socket.

4. Insert the bottom edge of the DIMM into the socket, and press down firmly on the DIMM until it

seats correctly.

5. Gently push the plastic ejector levers on the socket ends to the upright position.

6. Repeat the steps to install each DIMM.

7. Ensure that no cables are protruding from the server chassis and then close the server.

8. Connect all external cables and the power cord to the server.

9. Turn on the monitor and then the server.

Inhaltsverzeichnis

Andere Intel Server Handbücher

Intel

Intel SR1530AHLX - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel R2000SC Bedienungsanleitung

Intel

Intel AP450GX MP Bedienungsanleitung

Intel

Intel P4000RP Bedienungsanleitung

Intel

Intel S7000FC4UR - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR2625UR - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel AC450NX Bedienungsanleitung

Intel

Intel P4304BT series Bedienungsanleitung

Intel

Intel ISP1100 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel R1000EP series Bedienungsanleitung

Intel

Intel MFSYS25 - AXXPSU 1000W Power Supply Module Bedienungsanleitung

Intel

Intel SR1530CL - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel R2000LH2 Bedienungsanleitung

Intel

Intel AXX6DRV3GEXP Bedienungsanleitung

Intel

Intel 320014-003US Bedienungsanleitung

Intel

Intel D40AMP Series Bedienungsanleitung

Intel

Intel SBXD132 - Server Compute Blade Bedienungsanleitung

Intel

Intel SR1435VP2 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel TSRMT2 Bedienungsanleitung

Intel

Intel ISP1100 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel H2000WP Bedienungsanleitung

Intel

Intel R1304BTLSHBN Einrichtungshandbuch

Intel

Intel R1304BTSSFAN Bedienungsanleitung

Intel

Intel SR1520ML - Server System - 0 MB RAM Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
