Intel SSR212MC2 - Storage Server Hard Drive Array Leitfaden

Intel® Storage Server SSR212MC2

Spares / Parts List & Configuration Guide

A reference guide to assist customers in ordering the necessary components to configure the

Intel® Storage Server SSR212MC2 & SSR212MC2R

Revision 1.4

Subject to Change

October 2007

Revision History

Date Revision # Notes

4/16/2007 Revision 1.0 Initial Release

5/1/2007 Revision 1.1 Updated Product Configuration Tables (page 4)

6/28/2007 Revision 1.2 Updated new Material Master numbers & UPC codes for ECO1

(per PCN 107668-00)

10/9/2007 Revision 1.4 Added board refresh sku info including new Material Master

numbers and UPC codes.

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or

otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and

Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied

warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular

purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not

intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product

descriptions at any time, without notice.

*Other brands and names may be claimed as the property of others. Intel, Pentium, Itanium, and Xeon are trademarks or

registered trademarks of Intel Corporation.

All products, dates, and figures are preliminary and are subject to change without any notice.

CONTENTS

CONTENTS .........................................................................................................3

PRODUCTION CONFIGURATIONS ......................................................................... 4

Base Unit Description...................................................................................4

Production System Codes...........................................................................5

Supported Processors .................................................................................5

Production Hardware Accessories..............................................................6

Production Spares (Field Replaceable Units).............................................6

PRODUCTION CONFIGURATIONS

This section contains information needed to order and configure a production SSR212MC2 or SSR212MC2R. The unit is

shipped as a an integrated hardware platform, including enclosure, backplane, server board fan cooling module and power

supply. Drivers and enclosure management software is included, but no operating system or storage applications are

included. CPUs, hard disk drives (HDDs) and memory need to be added.

Base Unit Description

The SSR212MC2 has two SKU options:

SSR212MC2R and SSR212MC2RBR: ships with the Intel RAID controller SRCSAS144E and the Intel Battery

Backup Unit AXXRIBBU1

SSR212MC2 and SSR212MC2BR: ships without RAID controller or Battery Backup Unit

Details of each SKU configuration are listed in the table below.

SSR212MC2R and SSR212MC2RBR (with RAID

controller) SSR212MC2 and SSR212MC2BR (no RAID

controller)

1x 2U system chassis (including SAS backplane,

cooling module, power supply enclosure)

1x 850W power supply module

1x Intel® Server Board S5000PSLSAS

1x Intel RAID Controller SRCSAS144E

1x Intel Battery Backup Unit AXXRIBBU1

12x Intel hard disk drive carriers (for use with SAS or SATA HDDs)

1x 2.5” HDD internal boot drive enclosure

2x Boot Drive SATA cables

4 lane SAS cable

1x 2U system chassis (including SAS backplane,

cooling module, power supply enclosure)

1x 850W power supply module

1x Intel® Server Board S5000PSLSAS

12x Intel hard disk drive carriers (for use with SAS or SATA

HDDs)

1x 2.5” HDD internal boot drive enclosure

2x Boot Drive SATA cables

4 lane SAS to 4x SATA cable

12x HDD labels 12x HDD labels

1x Rail Kit 1x Rail Kit

1x printed Quick Start Guide 1x printed Quick Start Guide

1x Resource CD 1x Resource CD

1x Torx Driver 1x Torx Driver

Production System Codes

PRODUCT CODE MM # UPC DESCRIPTION

SSR212MC2R 891934 00735858196581 2U/Twelve 3 ½” SAS/SATA HDD storage server SSR212MC2R chassis with RAID

controller included.

Includes chassis, backplane,10 fans, 850W power supply, server board

BB5000PSLSAS and RAID controller SRCSAS144E with Intel Battery Backup Unit

AXXRIBBU1.

SSR212MC2RNA 892295

00735858196598 Production SSR212MC2R unit, with North American power cord.

SSR212MC2 891935

00735858196604 2U/Twelve 3 ½” SAS/SATA HDD storage server SSR212MC2 chassis with no

RAID controller.

Includes chassis, backplane, 10 fans, 850W power supply, and server board

BB5000PSLSAS.

SSR212MC2NA 892294

00735858196611 Production SSR212MC2 unit, with North American power cord.

SSR212MC2RBR 893519 00735858199063 2U/Twelve 3 ½” SAS/SATA HDD storage server SSR212MC2R chassis with RAID

controller included.

Includes chassis, backplane, 10 fans, 850W power supply, server board

BB5000PSLSASR and RAID controller SRCSAS144E with Intel Battery Backup

Unit AXXRIBBU1.

SSR212MC2RBRNA 894040

00735858199070 Production SSR212MC2RBR unit, with North American power cord.

SSR212MC2BR 893628

00735858199087 2U/Twelve 3 ½” SAS/SATA HDD storage server SSR212MC2 chassis with no

RAID controller.

Includes chassis, backplane, 10 fans, 850W power supply, and server board

BB5000PSLSASR.

SSR212MC2BRNA 894041

00735858199094

Production SSR212MC2BR unit, with North American power cord.

Supported Processors

For a full list of CPUs that are supported on the SSR212MC2, SSR212MC2BR, SSR212MC2R and SSR212MC2RBR,

please refer to the Supported Processor List on the SSR212MC2 Product Support website:

http://support.intel.com/support/motherboards/server/ssr212mc2/index.htm

Production Hardware Accessories

PRODUCT CODE MM # UPC DESCRIPTION

AMC850WPS

890400 00735858193856 850W power supply for the SSR212MC2

AMCSAS300

890438 00735858193863 300GB 10k RPM SAS hard disk drives for the Intel SSR212MC2

AMCSATA750 890441 00735858193870 750GB 7.2k RPM SATA II hard disk drive for the Intel SSR212MC2

Production Spares (Field Replaceable Units)

PRODUCT CODE MM # UPC DESCRIPTION

FMCCHASSIS

890449

00735858193887 SSR212MC2 chassis FRU: including backplane, enclosure management card , front panel

board, power supply cage

FMCCABLES

890452

00735858193894 SSR212MC2 cable kit, including: BBU cable, boot drive SAS, front panel flex cable, front

panel SSI

FMCSAS4XCBL

890454

00735858193900 SSR212MC2 4 lane SAS fan out cable with four 7 pin SATA connectors (mini-SAS to 4x

SATA)

FMCSASCBL

890489

00735858193917 SSR212MC2R 4 lane SAS cable (mini-SAS to mini-SAS)

FXSDRVCARR

873884 00735858177726 12 pack HDD carrier set, along with 1 torx driver and HDD label set

FMCBOOTENCL

890490

00735858193924 SSR212MC2 2.5” boot drive enclosure

FMCRAILKIT

890491

00735858193931 SSR212MC2 Rail kit

FMCFANS

890497

00735858193948 SSR212MC2 fans (5 pack) – NON HOT SWAP

FMCPKG

890500

00735858193955 SSR212MC2 packaging (external box assembly)

FMCSASX

890501

00735858193962 SSR212MC2 SAS expander card

FMCAIRBAFFLE

890502 00735858193979 SSR212MC2 processor and memory air baffles

BB5000PSLSAS

886315 00735858182911 10-pack of Intel Server Board S5000PSLSAS with integrated 4-port SAS, G1 Blackford

Chipset

BB5000PSLSASR 892051 007358196154 10-pack of Intel Server Board S5000PSLSASR with integrated 4-port SAS, 45nm compat

SRCSAS144E

883470 00735858182621 Intel® RAID Controller SRCSAS144E - PCIe x4, 8P (4 int/4 ext) SAS RAID Controller -

Intel 80333 IOP @ 500 MHz, 128MB embedded memory. RoHS Compliant.

AXXRIBBU1 879073 00735858171649 Battery Backup unit for Intel RAID controller SRCSAS144E

NOTES

1) Unless noted otherwise, all items are individually orderable.

2) Reference base unit description (page 3) to determine components that initially ship with the SSR212MC2R or

SSR212MC2 system.

Additional RequiredAccessories

Installing operating systems and applications from CD will require one or more of the following components. Note that

Microsoft Windows Server 2003 and Microsoft Storage Server 2003 Release 2 require the presence of a floppy drive to

install certain device drivers.

USB CD ROM Drive (supported devices listed on THOL)

USB Floppy Drive (supported devices listed on THOL)

USB Hub (supported devices listed on THOL)

Please choose devices, such as HDDs, adapters, boot drives and JBODs from the Tested Hardware and Operating

systems List (THOL). These devices have been verified to be compatible with the Intel® Storage Server SSR212MC2.

Also, compatible memory may be selected from the Tested Memory List for the Intel Storage Server SSR212MC2.
