Intel®Server System SC5400RA User’s

Guide

A Guide for Technically Qualified Assemblers of Intel® Identified Subassemblies/

Products

Intel Order Number D36227-002

ii Intel® Server System SC5400RA User’s Guide

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by

estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's

Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any

express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to

fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property

right. Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining

applications or for any other application in which the failure of the Intel product could create a situation where

personal injury or death may occur. Intel may make changes to specifications and product descriptions at any time,

without notice.

Intel server boards contain a number of high-density VLSI and power delivery components that need adequate

airflow for cooling. Intel's own chassis are designed and tested to meet the intended thermal requirements of these

components when the fully integrated system is used together. It is the responsibility of the system integrator that

chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to

determine the amount of airflow required for their specific application and environmental conditions. Intel

Corporation can not be held responsible if components fail or the server board does not operate correctly when used

outside any of their published operating or non-operating limits.

Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States and other countries.

* Other names and brands may be claimed as the property of others.

Intel® Server System SC5400RA User’s Guide iii

Safety Information

Important Safety Instructions

Read all caution and safety statements in this document before performing any of the

instructions. See also Intel Server Boards and Server Chassis Safety Information on the

Intel®Server Deployment Toolkit 2.0 CD and/or at http://support.intel.com/support/

motherboards/server/sb/cs-010770.htm.

Wichtige Sicherheitshinweise

Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor

Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu

Intel-Serverplatinen und Servergehäusen auf der Intel®Server Deployment Toolkit 2.0 CD

oder unter http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.

Consignes de sécurité

Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce

document avant de suivre toute instruction. Consultez Intel Server Boards and Server

Chassis Safety Information sur le Intel®Server Deployment Toolkit 2.0 CD ou bien

rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs-

010770.htm.

Instrucciones de seguridad importantes

Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar

cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety

Information en el Intel®Server Deployment Toolkit 2.0 CD y/o en http://

support.intel.com/support/motherboards/server/sb/cs-010770.htm.

iv Intel® Server System SC5400RA User’s Guide

Warnings

Heed safety instructions: Before working with your server product, whether you are

using this guide or any other resource as a reference, pay close attention to the safety

instructions. You must adhere to the assembly instructions in this guide to ensure and

maintain compliance with existing product certifications and approvals. Use only the

described, regulated components specified in this guide. Use of other products /

components will void the UL listing and other regulatory approvals of the product and

will most likely result in noncompliance with product regulations in the region(s) in which

the product is sold.

System power on/off: The power button DOES NOT turn off the system AC power. To

remove power from system, you must unplug the AC power cord from the wall outlet.

Make sure the AC power cord is unplugged before you open the chassis, add, or remove

any components.

Hazardous conditions, devices and cables: Hazardous electrical conditions may be

present on power, telephone, and communication cables. Turn off the server and

disconnect the power cord, telecommunications systems, networks, and modems attached

to the server before opening it. Otherwise, personal injury or equipment damage can

result.

Electrostatic discharge (ESD) and ESD protection: ESD can damage disk drives,

boards, and other parts. We recommend that you perform all procedures in this chapter

only at an ESD workstation. If one is not available, provide some ESD protection by

wearing an antistatic wrist strap attached to chassis ground any unpainted metal surface on

your server when handling parts.

ESD and handling boards: Always handle boards carefully. They can be extremely

sensitive to ESD. Hold boards only by their edges. After removing a board from its

protective wrapper or from the server, place the board component side up on a grounded,

static free surface. Use a conductive foam pad if available but not the board wrapper. Do

not slide board over any surface.

重要安全指导

Intel® Server System SC5400RA User’s Guide v

Installing or removing jumpers: A jumper is a small plastic encased conductor that slips

over two jumper pins. Some jumpers have a small tab on top that you can grip with your

fingertips or with a pair of fine needle nosed pliers. If your jumpers do not have such a

tab, take care when using needle nosed pliers to remove or install a jumper; grip the

narrow sides of the jumper with the pliers, never the wide sides. Gripping the wide sides

can damage the contacts inside the jumper, causing intermittent problems with the

function controlled by that jumper. Take care to grip with, but not squeeze, the pliers or

other tool you use to remove a jumper, or you may bend or break the pins on the board.

vi Intel® Server System SC5400RA User’s Guide

vii

Preface

About this Manual

Thank you for purchasing and using the Intel® Server System SC5400RA.

This manual is written for system technicians who are responsible for troubleshooting,

upgrading, and repairing this server system. This document provides a brief overview of

the features of the server system, a list of accessories or other components you may need,

troubleshooting information, and instructions on how to add and replace components on

the Intel® Server System SC5400RA. For the latest version of this manual, see http://

support.intel.com/support/motherboards/server/SC5400RA/.

Manual Organization

Chapter 1 provides a brief overview of the Intel® Server System SC5400RA. In this

chapter, you will find a list of the server system features, photos of the product, and

product diagrams to help you identify components and their locations.

Chapter 2 provides instructions on adding and replacing components. Use this chapter for

step-by-step instructions and diagrams for installing or replacing components such as the

fans, power supply, drives, and other components.

Chapter 3 provides instructions on using the utilities that are shipped with the board or

that may be required to update the system. This includes how to navigate through the

BIOS Setup screens, how to perform a BIOS update, and how to reset the password or

CMOS. Information about the specific BIOS settings and screens is available in the

Technical Product Specification. See “Additional Information and Software” on page ix

for a link to the Technical Product Specification.

Chapter 4 provides technical reference information on cable routing, power supply

specifications, and system environment requirements.

At the back of this document, you will find appendices on safety, regulatory, "getting

help", and warranty information.

viii Intel® Server System SC5400RA User’s Guide

Product Contents, Order Options, and

Accessories

Your Intel® Server System SC5400RA ships with the following items:

•One Intel®server board SC5400RA, installed in the chassis

•One 830-watt power supply, installed in the chassis

•One box of hardware components, referred to in this list as the "server system

hardware box"

•Fans, pre-installed in your server system

•One chassis intrusion switch and cable, installed in your server system

•Attention document, in the server system product box

•One Intel® Server System SC5400RA Quick Start User's Guide, in the server

system hardware box

•One USB cable, installed in the server system

•One IDE cable, in the hardware box

•One COM2 cable, in the hardware box

•Four 24-inch and two 34-inch SATA cables, in the hardware box

•One accessory kit that contains screws and wire ties.

•One Intel®Server Deployment Toolkit 2.0 CD

•Two CD package of system management software:

—OneIntel®System Management Software 1.5 CD

—OneIntel®Deployment Assistant CD

In addition, you may need or want to purchase one or more of the following accessory

items for your server:

Processor, memory DIMMs, hard drive, floppy drive, CD-ROM or DVD-ROM drive,

RAID controller, operating system.

For information about which accessories, memory, processors, and third-party hardware

have been tested and can be used with your board, and for ordering information for Intel

products, see http://support.intel.com/support/motherboards/server/SC5400RA/

compat.htm.

Intel® Server System SC5400RA User’s Guide ix

Additional Information and Software

If you need more information about this product or information about the accessories that

can be used with this server system, use the following resources. These files are available

at http://support.intel.com/support/motherboards/server/SC5400RA/.

Unless otherwise indicated in the table below, once on this Web page, type the document

or software name in the search field at the left side of the screen and select the option to

search "This Product."

For this information or

software Use this Document or Software

For in-depth technical

information about this

product, including BIOS

settings and chipset

information

Intel® Server System SC5400RA Technical Product Specification

If you just received this

product and need to install

Intel® Server System SC5400RA Quick Start User's Guide in the

product box

For virtual system tours

and interactive repair

information

A link to the SMaRT Tool is available under "Other Resources" at the

right side of the screen at:

http://support.intel.com/support/motherboards/server/SC5400RA/

Accessories or other Intel

server products Spares and Configuration Guide

Hardware (peripheral

boards, adapter cards) and

operating systems that

have been tested with this

product

Tested Hardware Operating Systems List

For software to manage

your Intel®server Intel®System Management Software

For diagnostics test

software Search for “Diagnostics”

xIntel® Server System SC5400RA User’s Guide
