Intel SR1560SFHS - Server System - 0 MB RAM Bedienungsanleitung

Intel®Server System SR1560SF

Service Guide

A Guide for Technically Qualified Assemblers of Intel® Identified Subassemblies/

Products

Intel Order Number D92960-004

ii Intel®Server System SR1560SF Service Guide

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by

estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's

Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any

express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to

fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property

right. Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining

applications or for any other application in which the failure of the Intel product could create a situation where

personal injury or death may occur. Intel may make changes to specifications and product descriptions at any time,

without notice.

Intel server boards contain a number of high-density VLSI and power delivery components that need adequate

airflow for cooling. Intel's own chassis are designed and tested to meet the intended thermal requirements of these

components when the fully integrated system is used together. It is the responsibility of the system integrator that

chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to

determine the amount of airflow required for their specific application and environmental conditions. Intel Corporation

can not be held responsible if components fail or the server board does not operate correctly when used outside any

of their published operating or non-operating limits.

Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States and other countries.

* Other names and brands may be claimed as the property of others.

Intel®Server System SR1560SF Service Guide iii

iv Intel®Server System SR1560SF Service Guide

Preface

About this Manual

Thank you for purchasing and using the Intel® Server System SR1560SF.

This manual is written for system technicians who are responsible for troubleshooting,

upgrading, and repairing this server system. This document provides reference

information, feature information, and step by step instructions on how to add and replace

components on the server system. For the latest version of this manual, see

http://support.intel.com/support/motherboards/server/s5400sf.

Manual Organization

Chapter 1 provides a list of reference resources. In this chapter you will find a list of

technical documents that give additional details on the Intel® Server System SR1560SF,

and the location where they can be found.

Chapter 2 provides a brief overview of the server system. In this chapter, you will find a

list of the server system features, illustrations of the product, and product diagrams to help

you identify components and their locations.

Chapter 3 provides instructions on adding and replacing components. Use this chapter for

step-by-step instructions and diagrams for installing or replacing components such as the

fans, power supply, drives, and other components.

Chapter 4 provides instructions on using the utilities that are shipped with the board or

that may be required to update the system. This includes how to navigate through the

BIOS Setup screens, how to perform a BIOS update, and how to reset the password or

CMOS. Information about the specific BIOS settings and screens is available in the Intel®

Server Board S5400SF Technical Product Specification. See “Server System References”

for a link to the Intel®Server Board S5400SF Technical Product Specification.

At the back of this manual, you will find technical specifications, regulatory information,

"getting help" information, and the warranty.

vi Intel®Server System SR1560SF Service Guide

Product Contents

The Intel® Server System SR1560SF ships with the Intel®Server Board S5400SF. For

further information, see the following documents:

•Intel®Server Board S5400SF Technical Product Specification

•Intel® Server System SR1560SF Technical Product Specification

There are two versions of the Intel®Server System SR1560SF: product codes SR1560SF

and SR1560SFHS. The contents of each server system are listed below.

Intel®Server System SR1560SF - Product Code SR1560SF

Contents

Your Intel®Server System SR1560SF ships with the following items:

•Intel®Server Board S5400SF, installed in the server system

•One 600 W power supply, installed in the server system

•A box of hardware components, referred to below as the "hardware box"

•PCIe* riser card assembly, installed in the server system

•Optical drive tray assembly (tray and interposer board), in hardware box

•Optical drive cable, in hardware box

•Attention document, in the server system product box

•Quick Start User's Guide, in the server system product box

•One 32-6mm flat screw for installing the optical drive component, in the hardware

box

•Rack handles, in hardware box

•Slimline peripheral bay filler panel, in the hardware box

•Standard control panel module and cables (I/O and USB), installed in the server

system

•Two fixed mount drive trays and drive filler blanks, installed in the server system

•System fan board and fan board I/O cable, installed in the server system

•System fan assembly, including five dual-rotor fans, installed in the server system

•Two SATA cables, in hardware box

•Processor air duct, installed in the server system

•Blue plastic air baffle, installed in the server system

•Intel®Server Deployment Toolkit 2.0 CD

•Intel®System Management Software CD

Intel®Server System SR1560SF Service Guide vii

Intel®Server System SR1560SF - Product Code

SR1560SFHS Contents

Your Intel®Server System SR1560SF ships with the following items:

•Intel®Server Board S5400SF, installed in the server system

•One 600 W power supply, installed in the server system

•A box of hardware components, referred to below as the "hardware box"

•PCIe* riser card assembly, installed in the server system

•Optical drive tray assembly (tray and interposer board), in the hardware box

•Bridge board, in the hardware box

•Optical drive cable, in the hardware box

•Attention document, in the server system product box

•Quick Start User's Guide, in the server system product box

•One 32-6mm flat screw for installing the optical drive component, in the hardware

box

•Rack handles, in the hardware box

•Slimline peripheral bay filler panel, in the hardware box

•Standard control panel module and cable, installed in the server system

•Three hot-swap drive trays and drive filler blanks, installed in the server system

•System fan assembly, including five dual-rotor fans, installed in the server system

•Processor air duct, installed in the server system

•Blue plastic air baffle, installed in the server system

•Intel®Server Deployment Toolkit 2.0 CD

•Intel®System Management Software CD

Note: One of two hot-swap backplane kits must be ordered separately in order to make the

system operational. The following kits are available for purchase.

•Passive hot-swap backplane. Order code: ASR1500PASBP

•Active hot-swap backplane. Order code: ASR1500SASBP

viii Intel®Server System SR1560SF Service Guide

Safety Information

Important Safety Instructions

Read all caution and safety statements in this document before performing any of the

instructions. See also Intel Server Boards and Server Chassis Safety Information on the

Intel®Server Deployment Toolkit 2.0 CD and/or at

http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.

Wichtige Sicherheitshinweise

Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor

Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu

Intel-Serverplatinen und Servergehäusen auf der Intel®Server Deployment Toolkit 2.0 CD

oder unter http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.

Consignes de sécurité

Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce

document avant de suivre toute instruction. Consultez Intel Server Boards and Server

Chassis Safety Information sur le Intel®Server Deployment Toolkit 2.0 CD ou bien

rendez-vous sur le site

http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.

Instrucciones de seguridad importantes

Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar

cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety

Information en el Intel®Server Deployment Toolkit 2.0 CD y/o en

http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.

xIntel®Server System SR1560SF Service Guide

重要安全指导

在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。和/或

http://support.intel.com/support/motherboards/server/sb/CS-010770.htm

上的 Intel

Server Boards and Server Chassis Safety Information（《Intel

服务器主板与服务器机箱安全信息》）。
