TELESCOPING I.V. ROD KIT

Assembly, Installation and Operating Instructions

Kit No. 1110154

SAVE THESE INSTRUCTIONS

NOTE: Check ALL parts for shipping damage. In case of shipping damage, DO NOT use. Contact

Carrier/ Dea er for further instruction.

SAFETY SUMMARY

To ensure the safe installation and adjustment of the Telescoping I.V. Rod Kit,

these instructions UST be followed:

GENERAL WARNINGS

DO NOT install or use this equipment without first reading and understand-

ing this instruction sheet. If you are unable to understand the Warnings,

Cautions or Instructions, contact a healthcare professional, dealer or techni-

cal personnel before attempting to install this equipment  otherwise, injury

or damage may occur.

DO NOT pull/push the wheelchair by the I.V. rod assembly. Injury to the

assistant/occupant and/or damage to the I.V. rod assembly may occur.

DO NOT place any objects on the I.V. rod assembly other than those deter-

mined by a healthcare professional.

INSTALLATION WARNING

After any adjustments, repair or service and BEFORE use, make sure all

attaching hardware is securely tightened  otherwise injury or damage may

result.

This kit contains the following items:

DESCRIPTION QUANTITY

Telescoping Tube 1

Short Hex Screw 1

Small Locknut 1

Long Hex Screw 1

Large Locknut 1

djustment Knob 1

Support Bracket 1

Washer 1

NOTE: The I.V. Rod can be insta ed to either the right or eft side of the whee chair. The right side

insta ation is shown in a figures. The eft side insta s in a simi ar manner.

FIGURE 1  INSTALLING THE SUPPORT BRACKET

INSTALLING THE SUPPORT BRACKET (FIGURE 1)

1. Determine the side of the wheelchair to which the I.V. Rod is to be mounted.

2. On the side determined in ST P 1, remove the rear wheel (D TAIL A of FIGUR 1)

by performing the following steps:

A. Remove the dust cover.

B. Remove the locknut.

C. Remove the axle screw, washer, spacer and rear wheel from the offset bracket.

NOTE: Retain a hardware for future use.

3. Remove the XISTING locknut from the XISTING hex screw securing the reclining

back tube to the clevis.

4. Support the reclining back tube with one hand.

5. With the remaining hand, remove the XISTING hex screw from the reclining back tube

and clevis.

NOTE: The EXISTING hex screw is rep aced by the ong hex screw contained in this kit.

6. Install the N W long hex screw through the clevis and reclining back tube.

7. Install the washer, XISTING spacer (removed in ST P 2C) and support bracket onto

the N W long hex screw.

8. Install the N W large locknut onto the N W long hex screw. Finger tighten.

9. Install the XISTING axle screw through the XISTING washer, rear wheel, support

bracket, and axle lug.

10. Install the XISTING locknut onto the axle screw. Finger tighten.

11. Torque the N W large locknut securing the support bracket to the clevis to 120 in./lbs.

12. Torque the XISTING locknut securing the rear wheel to 40 ft./lbs.

DETAIL A - REMOVING THE

REAR WHEEL

Rear

Wheel

Axle

Screw

Dust Cap

Washer Spacer

Offset Bracket

Long Hex Screw

Clevis

Reclining Back Tu e

Spacer

Support Bracket

Axle Screw

Dust Cap

Washer

Locknut

Locknut Washer

Large

Locknut

Axle Lug

INSTALLING THE TELESCOPING TUBE (FIGURE 2)

NOTE: The support bracket must be mounted to the whee chair BEFORE insta ing the te escoping

tube.

1. Insert the telescoping tube into the support bracket.

2. Rotate the telescoping tube until the mounting holes at the bottom align with the mount-

ing holes in the support bracket.

NOTE: The adjustment knob shou d point towards the outside of the whee chair.

3. Install the short hex screw and small locknut to secure the telescoping tube to the

support bracket. Torque to 120 in/lbs.

4. Adjust I.V. rod to desired height. Refer to ADJUSTING TH I.V. ROD H IGHT in this

instruction sheet.

FIGURE 2  INSTALLING THE TELESCOPING TUBE/ADJUSTING THE

I.V. ROD HEIGHT

ADJUSTING THE I.V. ROD HEIGHT (FIGURE 2)

1. Loosen the adjustment knob.

2. Adjust I.V. rod to desired height.

3. Securely tighten adjustment knob.

Telescoping

Tu e

Short Hex

Screw

Support

Bracket

Small Locknut

Mounting

Hole

Adjustment

Kno

Telescoping

Tu e

NOTE: Rear whee not shown

for c arity.

Invacare Corporation www.invacare.com

USA Canada

One Invacare Way 570 Matheson Blvd E Unit 8 Invacare is a registered trademark o

Elyria, Ohio USA Mississauga Ontario Invacare Corporation.

44036-2125 L4Z4G4 Canada Yes, you can. is a trademark o Invacare

800-333-6900 800-668-5324 Corporation.

Part No. 1114820 Rev A - 11/02
