Janitza UMG 511 Leitfaden

Dok Nr. 1.037.029.3.h from ﬁrmware rel. 2.0 / hardware rel. 20

Power Quality Analyser

UMG 511

Installation and

commissioning

Article no. 33.03.089

Janitza electronics GmbH

Vor dem Polstück 6

D-35633 Lahnau

Support Tel. +49 6441 9642-22

Fax +49 6441 9642-30

e-mail: [email protected]

Internet: http://www.janitza.com

www.janitza.com

UMG 511

Index of Contents

General 3

Goods-in check 6

Description 8

Intended use 8

Features of UMG511 9

Measurement process 10

Operating concept 10

Programming software „GridVis“ 11

Assembly 12

Installation 14

Protective Wire Connection 14

Supply Voltage 14

Voltage measurement 16

Frequency measurement 25

Current measurement 26

Current direction 27

RS485 30

Ethernet 34

Digital outputs 36

Digital inputs 38

Operation 40

Measurement value displays 41

„Home“ measurement value display 42

Select measurement value display 43

Call up additional information 44

Delete min/max values individually 45

List of transients 46

List of events 47

Conﬁguration 48

Language 49

Communication 50

Measurement 52

Transients 56

Events 58

Voltage mode 60

Nominal frequency 61

Flicker 62

System 63

Password 64

Delete power meters 65

Delete min. and max. values 66

Delivered condition 67

Reset 67

Display 68

Extensions 71

Initialization 74

Applying the supply voltage 74

Apply the measurement voltage 74

Frequency measurement 75

Rotary ﬁeld direction 75

Apply measurement current 76

Checking the power measurement 78

Checking communication 78

Proﬁbus 80

Service and Maintenance 84

Technical data 87

UMG 511

General

This handbook is subject to the legal regulations

for copyright protection and may not be fully, or

partially, photocopied, reprinted or reproduced,

mechanically or electronically or in any other way,

without the legally binding signature of

Janitza electronics GmbH, Vor dem Polstück 1,

D 35633 Lahnau, Germany

and may not be copied or republished in any way.

Protected trademarks

All trademarks, and the resulting rights, belong to

the respective owner of these rights.

Disclaimer

Janitza electronics GmbH does not accept any re-

sponsibility for errors or mistakes within this hand-

book and is not obliged to keep the contents of

this handbook updated.

Comments on the handbook

We are pleased to receive your comments. If there

are any parts of this handbook that are not clear,

please let us know and send an e-mail to:

[email protected]

UMG 511

Explanation of symbols

The following pictogrammes are used in this

handbook.

Caution!

Please observe the documentation.

This symbol warns about possible

dangers that can occur during as-

sembly, commissioning and use.

Danger - voltage!

Danger of death or major injury.

Disconnect the system and device

before beginning any work.

CNote.

Earth terminal.

Inductive.

The current lags the voltage.

Capacitive.

The voltage lags the current.

UMG 511

Application Information

Please read this operating manual and all other

publications that have to be consulted to work

with this product (particularly for installation, ope-

ration or maintenance).

Please pay attention to all safety regulations and

warning information. If you fail to follow the infor-

mation, it can result in personal damage and/or

damages to the product.

Any unauthorized change or use of this device be-

yond the speciﬁed mechanical, electrical or other

operating limits can cause personal damage and/

or damage to the product.

Any such unauthorized change represents „misu-

se“ and/or „negligence“ in the sense of guarantee

for the product and therefore makes the guarantee

covering possible consequential damages void.

This device is to be exclusively operated and

maintained by a specialist.

Specialists are persons who, due to their relevant

training and experience, are capable of recogni-

zing risks and avoiding possible hazards that can

be caused when operating or servicing the device.

When using the device, the necessary legal and

safety regulations should be considered additio-

nally for the respective application case.

Caution!

If the device is not operated accor-

ding to the operating manual, pro-

tection is no longer ensured and the

device may cause dangers.

Cables with single wires must be

provided with ferrules.

Only screw plugs with the same

pole number and the same type of

construction can be plugged toge-

ther.

UMG 511

Goods-in check

The correct and safe operation of this device re-

quires appropriate transport, correct storage, po-

sitioning and assembly as well as careful opera-

tion and maintenance. If it can be assumed that

risk-free operation is no longer possible, the de-

vice should be immediately taken out of operation

and secured against being unintentionally being

reinitialised.

Unpacking and packing should only be under-

taken with the usual care with the application of

force, while using suitable tools. The correct me-

chanical condition of the devices should be che-

cked with visual tests. Please pay attention to the

installation instructions included with the device.

It can be assumed that risk-free operation is no

longer possible if, for example, the device:

• displays visible damages,

• does not work despite being connected to the

mains,

• has been subject to unfavourable conditions

(e.g. storage outside of the authorised climate

limits without adaptation to the climate, tha-

wing etc.) or transport stresses (e.g. fall from

a height - even if there are no visible external

damages).

Please check the completeness of the delivery be-

fore beginning with installation of the device.

CAll of the screw clamps belonging

to the supplied device are already

attached.

CThe installation and commissioning

instructions also describe options

that are not part of the scope of

supply.

CAll supplied options and versions

are described on the delivery note.

UMG 511

Scope of supply

Available accessories

1) Article number - see delivery note.

Number Art.no. Designation

1 52 19 xxx 1) UMG511

1 33 03 089 Installation and commissioning instructions.

1 10 01 818 screw clamp, pluggable, 2 pin (auxiliary energy).

1 10 01 824 screw clamp, pluggable, 5 pin (voltage measurement 1-4).

1 10 01 822 screw clamp, pluggable, 8 pin (current measurement 1-4).

1 10 01 810 screw clamp, pluggable, 6 pin (digital outputs).

2 10 01 809 screw clamp, pluggable, 5 pin (digital inputs).

1 08 01 505 patch cable 2m, twisted, (connection UMG - PC/switch).

1 52 19 301 ﬁxing clamps.

Art.no. Designation

13 10 539 Proﬁbus plug, 9-pin DSUB, with integrated switchable terminating resistors.

29 01 903 Sealing, 144x144.

UMG 511

Description

Intended use

The UMG511 is intended for the measurement of

voltage quality according to EN61000-4-30 in the

building installation, to distributors, power swit-

ches and busbars.

Measurement voltages and measurement currents

must come from the same network.

The UMG511 is suitable for installation in stationa-

ry and weather-protected control panels. Conduc-

tive control panels must be earthed.

The UMG511 can be used in 2, 3 and 4 conductor

networks and in TN and TT networks.

The current mesaurement inputs of the UMG511

are connected using external ../1A or ../5A current

converters.

Measurement in medium and high voltage net-

works generally takes place through current and

voltage converters.

The UMG511 can be used in residential and in-

dustrial areas.

Measurement results can be displayed and saved

then read out and processed further by serial in-

terfaces.

UMG 511

Features of UMG511

• Front panel installation, 144x144mm,

• Working temperature range - 10°C .. +55°C,

• Colour graphics display 320x420, 256

colours, 6 push buttons

• 8 digital inputs, 5 digital outputs,

• 16Bit A/D converter, data memory

256MByte ﬂash, SDRAM 32Mbyte,

• Continual scanning of voltage and current

measurement inputs with 20kHz,

• Frequency of fundamental oscillation

15Hz..440Hz

• 4 voltage measurement inputs, 4 current

measurement inputs,

• Measurement in TN and TT networks,

• RS485

- Proﬁbus DP/V0 (Option),

- Modbus RTU, Modbus-Master,

BACnet (Option)

• Ethernet Web-Server, EMAIL, BACnet

(Option),

• Collection of transients >50µs and storage

with up to 16000 scanning points,

• Collection of more than 2000 measurement

values,

• Measurement of the power quality accor-

ding to DIN EN61000-4-30, class A,

• Flicker measurement according to

DIN EN61000-4-15:2011, class F1,

• Analysis and assessment according to

DIN EN50160 with the GridVis program-

ming software.

• Working measurement, measurement

uncertainty according to DIN EN50470-3:

- Class C for ../5A converter,

- Class B for ../1A converter,

• Measurement of harmonics 1 to 63 accor-

ding to DIN EN 61000-4-7 class 1 for

- Ull, Uln, I, P (receipt/supply) and

- Q (ind./cap.),

• Measur. of intermediate harmonics 1

to 63 for (Uln, Ull, I) according to

DIN EN61000-4-7 cl. 1,

• programming of own applications in Jasic

UMG 511

Measurement process

The UMG511 measures without gaps and calcu-

lates all effective values over a 200ms interval.

The UMG511 measures the real effective value

(TRMS) of the voltages and currents applied to the

measurement inputs.

Operating concept

You can programme and call up measurement va-

lues with the UMG511 in a variety of ways.

• Directly on the device using 6 push buttons

and the display.

• Using the GridVis programming software,

• Using the UMG511 homepage for devices

with an Ethernet interface.

• Using the RS485 with the modbus protocol.

You can change and call up the data with the

help of the modbus address list (stored on the

enclosed data carrier).

This operating manual only describes operation of

the UMG511 using the integrated display and the

6 push buttons.

The GridVis programming software and the home-

page have their own „online help“.

Andere Handbücher für UMG 511

Inhaltsverzeichnis

Andere janitza Messgerät Handbücher

janitza

janitza UMG 96-PA Bedienungsanleitung

janitza

janitza UMG 96-PQ-L Bedienungsanleitung

janitza

janitza FBM Series Bedienungsanleitung

janitza

janitza UMG 96-S2 Bedienungsanleitung

janitza

janitza UMG 804 Gebrauchsanweisung

janitza

janitza EM3-80 Bedienungsanleitung

janitza

janitza UMG 96RM-P Gebrauchsanweisung

janitza

janitza UMG 96-S2 Bedienungsanleitung

janitza

janitza UMG 96-PA Gebrauchsanweisung

janitza

janitza 800-CT8-A Bedienungsanleitung

janitza

janitza UMG 96S 24V Bedienungsanleitung

janitza

janitza UMG 512-Pro Gebrauchsanweisung

janitza

janitza MRG 96RM-E Flex RCM Bedienungs- und Montageanleitung

janitza

janitza UMG 511 Bedienungsanleitung

janitza

janitza UMG 509-PRO Gebrauchsanweisung

janitza

janitza UMG 96S Bedienungsanleitung

janitza

janitza UMG 804 Bedienungsanleitung

janitza

janitza UMG 96 RM-E Bedienungsanleitung

janitza

janitza UMG 96-PA Bedienungsanleitung

janitza

janitza UMG 104 Gebrauchsanweisung

janitza

janitza UMG 96 RM Gebrauchsanweisung

janitza

janitza UMG 604-PRO Gebrauchsanweisung

janitza

janitza UMG 103-CBM Gebrauchsanweisung

janitza

janitza UMG 96-PA Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung

janitza UMG 511 Leitfaden

Beliebte Messgerät Handbücher anderer Marken
