jbc DSH Bedienungsanleitung
INSTRUCTION MANUAL
DSH
Heating Element
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
Heating
Element
Filter
Fixing
Screw
Fixing
Screw
Changing Heating Element
1. Remove the filter before
changing the heating element.
2. Remove the fixing screw
and take out the heating
element.
Note: For the following operations, turn off the station or
disconnect the tool and wait until the tool temperature drops
to room temperature.
Desoldering Iron Maintenance
3. Insert the new heating
element into the tool.
4. Tighten the fixing screw
and insert the filter.
Filter
Heating
Element
2
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
DR560
DS360
DR560
DR560
DR560
DR560
DR560
Tube
Filter
Filter
Tube
Changing Iron Filter
1. Remove the tube from
the filter.
2. Remove the filter form
the tool.
3. Insert a new filter (ref.
0008473) into the tool and
mount the tube onto the filter.
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life must be collected and returned to an
authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against all manufacturing defects,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
DSH
Heating Element for DS360
Ref.: DSV-DS
- Total Net Weight: 11.4 g / 0.03 lb
- Package Dimensions/Weight: 127 x 31 x 31 mm / 20 g
(L x W x H) 5.00 x 1.22 x 1.22 in / 0.04 lb
Complies with CE standards.
ESD safe.
008958-161222
Specifications
