H0511

Tool Holder for CDN Station

INSTRUCTION MANUAL

Packing List

The following items are included:

Tool Holder for CDN .......... 1 unit Manual .................................. 1 unit

Ref. 0031092

This manual corresponds to the following reference:

0030511

Features

H0511 Tool Holder works with CDN Compact Stations and supports

NT115 Nano Handles. It detects whether the tool is inserted in it and

activates Sleep and Hibernation Modes.

2

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

OK

No Yes

OK

No Yes

OK

No Yes

First disassemble the tool holder

by loosening the set screw (1).

Remove the tool holder (2) and

replace it with the new one.

Insert the new tool holder bar

into the slot on the station (3) in

vertical position and as far as it

will go.

Note: The flat area on the tool

holder bar must align with the

threaded hole (4) on the back of

the station.

Finally, tighten the set screw to

fix the tool holder.

Set Scew

(inside)

Tool

Holder

Flat Area

Threaded

Hole

Replacing the Tool Holder

1

2

4

3

3

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

0031092-260623

Specifications

H0511

Tool Holder for CDN Station

Ref.: 0030511

- Total Net Weight: 20.66 g / 0.05 lb

- Package Dimensions / Weight: 96 x 55 x 46 mm / 38 g

(L x W x H) 3.78 x 2.17 x 1.81 in / 0.08 lb

Complies with CE standards.

This product should not be thrown in the garbage.

In accordance with the European directive 2012/19/EU, electronic

equipment at the end of its life must be collected and returned to an

authorized recycling facility.

Warranty

JBC’s 2 year warranty covers this equipment against all manufacturing defects,

including the replacement of defective parts and labour.

Warranty does not cover product wear or misuse.

In order for the warranty to be valid, equipment must be returned, postage paid, to

the dealer where it was purchased.
