Juniper JSA5800 Montageanleitung

Juniper Secure Analycs 5800 Hardware

Guide

Published

2021-06-03

Juniper Networks, Inc.

1133 Innovaon Way

Sunnyvale, California 94089

USA

408-745-2000

www.juniper.net

Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc.

in the United States and other countries. All other trademarks, service marks, registered marks, or registered service

marks are the property of their respecve owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right

to change, modify, transfer, or otherwise revise this publicaon without noce.

Juniper Secure Analycs 5800 Hardware Guide

The informaon in this document is current as of the date on the tle page.

YEAR 2000 NOTICE

Juniper Networks hardware and soware products are Year 2000 compliant. Junos OS has no known me-related

limitaons through the year 2038. However, the NTP applicaon is known to have some diculty in the year 2036.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentaon consists of (or is intended for use

with) Juniper Networks soware. Use of such soware is subject to the terms and condions of the End User License

Agreement ("EULA") posted at hps://support.juniper.net/support/eula/. By downloading, installing or using such

soware, you agree to the terms and condions of that EULA.

Table of Contents

About This Guide | vi

Overview

JSA5800 System Overview | 2

JSA5800 Appliance Descripon | 2

JSA5800 Appliance Transceiver Interface | 3

Field-Replaceable Units on the JSA5800 Appliance | 4

JSA5800 Chassis | 4

JSA5800 Appliance Front Panel Descripon | 5

JSA5800 Appliance Back Panel Descripon | 9

Site Planning, Preparaon, and Specicaons

JSA5800 Site Guidelines and Requirements | 13

General Site Installaon Guidelines for the JSA5800 Appliance | 13

JSA5800 Appliance Physical Specicaons | 14

JSA5800 Appliance Rack Requirements | 16

Addional Hardware Requirements | 17

Inial Installaon and Conguraon

JSA5800 Installaon Overview | 21

Overview of Installing the JSA5800 Appliance in a Rack | 21

Tools and Parts Required for Installing the JSA5800 Appliance | 21

Installing the JSA5800 in a Rack | 22

Installing the JSA5800 Appliance | 23

Installing the JSA5800 Appliance Using Front-and-Rear-Mounng Flush to a Rack | 26

Connecng the JSA5800 to Power | 32

Connecng the JSA5800 Appliance to Ground | 32

iii

Connecng the JSA5800 Appliance to a DC Power Source | 32

Connecng the JSA5800 Appliance to a Management Device | 35

Conguring the JSA5800 | 36

Conguring Basic Sengs on the JSA5800 Appliance | 36

Accessing the JSA Interface | 39

Maintaining Components

Maintaining the JSA5800 RAID Array | 42

Maintaining JSA5800 Power System | 42

Maintaining the JSA5800 Power Supply | 43

Replacing an AC Power Supply on the JSA5800 Appliance | 44

Replacing AC Power Supply Cables on the JSA5800 Appliance | 44

Replacing a DC Power Supply on the JSA5800 Appliance | 45

Replacing DC Power Supply Cables on the JSA5800 Appliance | 46

Troubleshoong Hardware

Contacng Juniper Networks Technical Assistance Center | 49

Safety and Compliance Informaon

Denions of Safety Warning Levels | 52

General Safety Guidelines and Warnings | 53

Restricted Access Warning | 55

Qualied Personnel Warning | 56

Prevenon of Electrostac Discharge Damage | 57

Warning Statement for Norway and Sweden | 58

Fire Safety Requirements | 59

Installaon Instrucons Warning | 60

Chassis Liing Guidelines for the JSA5800 Appliance | 61

Ramp Warning | 61

Rack-Mounng and Cabinet-Mounng Warnings | 62

Grounded Equipment Warning | 66

Laser and LED Safety Guidelines and Warnings | 67

Radiaon from Open Port Apertures Warning | 70

Maintenance and Operaonal Safety Guidelines and Warnings | 71

Acon to Take Aer an Electrical Accident | 76

General Electrical Safety Guidelines and Warnings | 77

AC Power Electrical Safety Guidelines | 78

AC Power Disconnecon Warning | 79

DC Power Electrical Safety Guidelines | 80

DC Power Disconnecon Warning | 81

DC Power Grounding Requirements and Warning | 83

DC Power Wiring Sequence Warning | 84

Mulple Power Supplies Disconnecon Warning | 86

TN Power Warning | 87

Agency Approvals for the JSA5800 Appliance | 87

Compliance Statements for EMC Requirements for the JSA5800 Appliance | 89

Compliance Statements for Acousc Noise for the JSA5800 Appliance | 92

About This Guide

Use this guide to install hardware and perform inial soware conguraon, roune maintenance, and

troubleshoong for JSA5800.

Aer compleng the installaon and basic conguraon procedures covered in this guide, refer to the

JSA soware documentaon for informaon about further soware conguraon. See Juniper Secure

Analycs.

RELATED DOCUMENTATION

Introducing JSA5800

JSA5800 Quick Start Guide

Release Notes

STRM Series to JSA Series Migraon Guide

Juniper Secure Analycs Migraon Guide

CHAPTER

Overview

JSA5800 System Overview | 2

JSA5800 Chassis | 4

JSA5800 System Overview

IN THIS SECTION

JSA5800 Appliance Descripon | 2

JSA5800 Appliance Transceiver Interface | 3

Field-Replaceable Units on the JSA5800 Appliance | 4

JSA5800 Appliance Descripon

The Juniper Secure Analycs 5800 (JSA5800) is an enterprise and carrier-class appliance that provides a

scalable network security management soluon for medium-sized companies up to large global

organizaons.

The JSA5800 appliance is a 2-U, rack-mountable chassis with AC power supplies (or oponal DC power

supplies), eight hot-swappable hard drives, 128 GB memory, and two 10 Gigabit and four Gigabit

Ethernet interfaces.

The JSA5800 appliance:

• Responds to the right threats at the right me through eecve analysis of networks, events, and

audit log les.

•Idenes environmental anomalies in the network, an aack path, and the source of a threat.

• Provides network remediaon for threat responses across all security products.

The JSA5800 appliance provides the following features:

• Monitor ulity for power supply unit (PSU) and fans

• Add setup logs automacally

• Support high availability (HA)

• Hot-swappable hard disk supporng RAID

•Automac RAID rebuild on HDD swap

• Support hot-swappable dual-AC (or oponal dual-DC power supplies) with a redundant conguraon

in the chassis

The JSA5800 appliances use the following drivers for security analysis of external and internal threats:

• Security Informaon Management (SIM)—SIM provides reporng and analysis of data from host

systems, applicaons, and security devices to support security policy compliance management,

internal threat management, and regulatory compliance iniaves.

• Security Event Management (SEM)—SEM improves security incident response capabilies by

processing data from security devices and network devices. It helps network administrators to

provide eecve responses to external and internal threats.
