Juniper SSR1300 Montageanleitung

SSR1300 Appliance Hardware Guide

Published

2022-08-30

Juniper Networks, Inc.

1133 Innovaon Way

Sunnyvale, California 94089

USA

408-745-2000

www.juniper.net

Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc.

in the United States and other countries. All other trademarks, service marks, registered marks, or registered service

marks are the property of their respecve owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right

to change, modify, transfer, or otherwise revise this publicaon without noce.

SSR1300 Appliance Hardware Guide

The informaon in this document is current as of the date on the tle page.

YEAR 2000 NOTICE

Juniper Networks hardware and soware products are Year 2000 compliant. Junos OS has no known me-related

limitaons through the year 2038. However, the NTP applicaon is known to have some diculty in the year 2036.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentaon consists of (or is intended for use

with) Juniper Networks soware. Use of such soware is subject to the terms and condions of the End User License

Agreement ("EULA") posted at hps://support.juniper.net/support/eula/. By downloading, installing or using such

soware, you agree to the terms and condions of that EULA.

Table of Contents

About This Guide | vi

Overview

SSR1300 Appliance Overview | 2

Benets of SSR1300 | 2

Field-Replaceable Units in SSR1300 Appliances | 3

SSR1300 Chassis | 3

Front Panel of an SSR1300 | 4

Rear Panel of an SSR1300 | 4

Chassis Physical Specicaons for SSR1300 | 5

Chassis Status LEDs | 5

Network Port LEDs | 6

Cooling System | 9

Power System | 10

Site Planning, Preparaon, and Specicaons

Site Preparaon Checklist for SSR1300 | 15

SSR1300 Site Guidelines and Requirements | 16

General Site Installaon Guidelines | 17

Site Electrical Wiring Guidelines | 17

Environmental Requirements and Specicaons for SSR1300 | 19

Clearance Requirements for Hardware Maintenance of SSR1300 | 19

Rack Requirements for SSR1300 | 20

Cable Specicaons and Pinouts for SSR1300 | 23

Transceiver Support for SSR1300 | 23

Inial Installaon and Conguraon

iii

Unpack and Mount an SSR1300 | 25

Tools and Parts Required to Unpack the SSR1300 Appliance | 25

Unpack an SSR1300 | 25

Verify Parts Received with the SSR1300 | 26

Install the SSR1300 in a Rack | 27

Connect SSR1300 to Power | 30

Connect Earth Ground to SSR1300 | 30

Connect Power to SSR1300 | 32

Power O the SSR1300 | 33

Connect SSR1300 to External Devices | 34

Connect SSR1300 to a Management Console | 34

Onboarding SSR Conductor Managed SSR1300 onto Mist | 35

Maintaining Components

Maintaining the SSR1300 Hardware Components | 45

SSR1300 Fan Maintenance | 45

Remove a Fan from the SSR1300 | 45

Install a Fan in the SSR1300 | 46

SSR1300 Power Supply Maintenance | 47

Replacing an AC Power Supply on the SSR1300 | 48

Removing the AC Power Supply from an SSR1300 | 48

Installing the AC Power Supply in an SSR1300 | 49

Unmount the SSR1300 Chassis | 50

Remove the SSR1300 from a Rack | 50

Contacng Customer Support and Returning the Chassis or Components

Contacng Customer Support and Returning the Chassis or Components | 53

How to Return a Hardware Component to Juniper Networks, Inc. | 53

Locate the Chassis Serial Number ID Label | 55

Contact Customer Support to Obtain Return Material Authorizaon | 55

Guidelines for Packing and Shipping Hardware Components | 56

Safety and Compliance Informaon

Denions of Safety Warning Levels | 58

General Safety Guidelines and Warnings | 59

Restricted Access Warning | 61

Qualied Personnel Warning | 62

Prevenon of Electrostac Discharge Damage | 63

Fire Safety Requirements | 64

Laser and LED Safety Guidelines and Warnings | 66

Chassis and Component Liing Guidelines | 69

Radiaon from Open Port Apertures Warning | 69

Maintenance and Operaonal Safety Guidelines and Warnings | 70

Acon to Take Aer an Electrical Accident | 76

Radiaon from Open Port Apertures Warning | 76

General Electrical Safety Guidelines and Warnings | 77

SSR1300 Agency Approvals | 79

FCC and EMC Declaraons | 81

Lithium Baery Declaraon | 81

About This Guide

Use this guide to install hardware and perform inial soware conguraon, roune maintenance, and

troubleshoong for the SSR1300 appliance. Aer compleng the installaon and basic conguraon

procedures covered in this guide, refer to the Session Smart Router soware documentaon for

informaon about further soware conguraon.

CHAPTER

Overview

SSR1300 Appliance Overview | 2

SSR1300 Chassis | 3

SSR1300 Appliance Overview

IN THIS SECTION

Benets of SSR1300 | 2

Field-Replaceable Units in SSR1300 Appliances | 3

The Juniper Networks SSR1300 is a 1-U xed-conguraon appliance that is ideal for medium data

center or campus deployments. Powered by the Juniper Session Smart Router (SSR) soware, the

SSR1300 provides secure and resilient WAN connecvity.

NOTE: To use the SSR1300, you must purchase the SSR soware subscripon license that is sold

separately. You can onboard and monitor the SSR1300 in a cloud network by using Juniper

Mist™.

Benets of SSR1300

•Zero Trust Security (ZTS)—The SSR1300 ensures ZTS by authencang all routes and encrypng all

session trac. Applicaons, devices, or users cannot iniate any session that does not comply with

the authencaon policies and access rules. The SSR1300 supports Layer 2 through Layer 5 stateful

rewall funcons, including DoS/DDoS protecon, NAT, encrypon, VPN, and trac ltering.

•Adapve encrypon—The SSR1300 automacally detects trac encrypted using HTTPS or IPsec

and does not re-encrypt such trac. This capability results in improved performance and reduced

overhead due to double encrypon.

•Simplied onboarding and monitoring with Juniper Mist WAN Assurance—You can quickly onboard

the SSR1300 to the Mist Cloud using the claim code (QR code). This helps in reducing the

operaonal complexity and simplifying the deployment and conguraon process.

NOTE: Starng from SSR Release 6.0, you can manage the SSR1300 using Juniper Mist WAN

Assurance.

Field-Replaceable Units in SSR1300 Appliances

Field-replaceable units (FRUs) are components that you can replace at your site. Following are the two

types of the SSR1300 FRUs:

• Hot-insertable and hot-removable—You can remove and replace these components without powering

o the appliance or disrupng the appliance funcon.

• Hot-pluggable—You can remove and replace these components without powering o the appliance,

but the appliance funcon is interrupted unl you replace the component.

The FRUs in SSR1300 appliances are:

• Fans (hot-insertable and hot-removable)

• Power supplies (hot-insertable and hot-removable)

• Transceivers (hot-pluggable)

SSR1300 Chassis

IN THIS SECTION

Front Panel of an SSR1300 | 4

Rear Panel of an SSR1300 | 4

Chassis Physical Specicaons for SSR1300 | 5

Chassis Status LEDs | 5

Network Port LEDs | 6

Cooling System | 9

Power System | 10

Front Panel of an SSR1300

Figure 1 on page 4 shows the front panel of an SSR1300. The SSR1300 comes with a claim code (QR

code) that you can use to onboard the SSR1300 to Juniper Mist.

Figure 1: Front Panel Components of SSR1300

1—Chassis LEDs 6—1 GbE Ethernet ports (1/0 through 1/3)

2—RJ-45 Console port 7—Micro-USB Console port

3—10 GbE SFP+ ports (0/0 through 0/3) 8—USB 3.0 ports

4—1 GbE management port (for Mist operaons) 9—RESET buon

5—1/10 GbE SFP+ ports (2/0 through 2/3) 10—Claim code

Rear Panel of an SSR1300

Figure 2 on page 4 shows the rear panel of an SSR1300.

Figure 2: Rear Panel Components of SSR1300

1—Alarm switch 4—Power switch

2—AC power supply units 5—Earth grounding
