JVC DRMV100B - DVDr/ VCR Combo Bedienungsanleitung

Included Accessories

Connection : Antenna or Wall

ack (Cable TV)

DR-MV100B

DVD VIDEO RECORDER

Basic Operation

Remote control Audio cable

AC Outlet

DR-MV100B

After connections,

Power On.

Need Help? Please call the JVC Customer Service

TOLL FREE CUSTOMER CARE HOTLINE: 1(800)252-5722

http://www.jvc.com

QUICK

START

GUIDE

Video cable

"AAA" battery x 2

(For remote control)

Connect with

your TV

INSTRUCTIONS

pg. 10

DVD/VCR

OUT

INPUT

Video

Audio (L)

Audio (R)

RF cable

Antenna or cable

Connect

the arial.

Connect your TV

Go to " Initial Setup Wizard"

(INSTRUCTIONS pg. 14)

LVT1877-001A

0208SKMLGEEGL

- 1 -

Connection: With Cable Box Or DBS Receiver

INSTRUCTIONS

pg. 9

AC Outlet

DR-MV100B

DVD/VCR

OUT

INPUT

Video

Audio (L)

Audio (R)

ANTENNA OUT

(RF. OUT)

ANTENNA IN

(RF. IN) Cable or Satellite Box

Video

(R) - Audio - (L)

Antenna

or cable

INPUT 1

Video(R) - Audio - (L)

OUTPUT

(AV OUT)

ANTENNA IN

(RF. IN)

ANTENNA OUT

(RF. OUT)

ANTENNA IN

(RF. IN)

Connect the arial.

After connections, Power On.

When STEP is connectted: Select Input "AV1" of your recorder.

When STEP is disconnectted: Select "Ch 3 or 4" of your recorder.

- 2 -

Initial Setup Wizard INSTRUCTIONS

pg. 14

STANDBY/ON

Select Language

Move next step

Press "ENTER"

Finish

Select "Tuning Band"

Moves the cursor to the previous or

next column.

Changes the setting at the current

cursor position.

Set the "Date,Year

and Time"

Press

"STANDBY/ON"

- 3 -

Select "DVD"

Select "VCR"

BASIC PLAYBACK

DVD VHS

Stop Playback

Playable Discs: DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-RAM, CD-R, CD-RW,

Video CD, Audio CD

(One-Touch Recording)

Start Recording

5Stop Recording

Start Playback

Select Mode

INSTRUCTIONS

pg. 24

BASIC RECORDING INSTRUCTIONS pg. 34

Select "DVD or VCR"

DVD: XP, SP, LP or EP

VCR: SP or SLP

Note:

To playback the recorded disc

with other DVD players, it is

necessary to finalize the disc.

(INSTRUCTIONS pg. 21)

Recordable Discs: DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-RAM

Select Input

(AV1, AV2, DV IN or Ch)

2or Channel

- 4 -

TIMER RECORDING

(Munual Timer Programming) INSTRUCTIONS

pg. 35

Select "Timer

Record"

Select "HOME"

Press "ENTER"

to check on the

Timer Record List

Press "RETURN"

Finish

Select "NEW" and

Press "ENTER"

STANDBY/ON

Enter the necessary information for you timer

recording(s).

Changes the setting at the current cursor position.

Note:

To playback the recorded disc

with other DVD players, it is

necessary to finalize the disc.

(INSTRUCTIONS pg. 21)

- 5 -

Dubbing from VCR to DVD

DVD

VHS

Insert Blank Disc

and Cassette

Find the place

on the VHS tape

from which you

want to start

dubbing.

Access the

Dubbing

menu screen.

Stop Dubbing.

Preparation : Set the resolution to 480i using the OUTPUT STATUS button before dubbing.

Press VCR button to set the VCR mode.

6Start Dubbing.

4Select the desired

Record Mode.

You can copy the contents of a VHS tape to a DVD using the DUBBING

button. This allows you to archive your old VHS tapes to DVD.

INSTRUCTIONS

pg. 37

5Select [Dubbing].

Note:

To playback the recorded disc with other DVD players, it is necessary to finalize the disc.

(INSTRUCTIONS pg. 21)

Select XP, SP, LP or EP

- 6 -
