König SEC-DVR20 Bedienungsanleitung

—1—

Ⅰ. DVR Feature ........................................................................................2

Ⅰ. Outlook................................................................................................ 2

2.1. Front Panel.............................................................................................................................2

2.2. Rear Panel..............................................................................................................................3

2.3. Remote Controller............................................................................................................3

2.4. Removable HDD Box Introduction..............................................................................4

Ⅰ. DVR Installation .................................................................................. 5

3.1. Install Hard Disk ....................................................................................................................5

3.2. Connect Camera and Monitor..............................................................................................6

3.3. Connect Power Cord.............................................................................................................6

Ⅰ. DVR System Boot ............................................................................... 6

4.1. Detect installed Hard Disk....................................................................................................6

4.2. Recover Lost Data.................................................................................................................7

4.3. Restore Recording Process.................................................................................................7

4.4. Main Screen ...........................................................................................................................8

Ⅰ. DVR Setup ........................................................................................... 9

5.1. Setup Menu............................................................................................................................9

5.2. Camera Select .....................................................................................................................10

5.3. Record Select ......................................................................................................................10

5.4. Record Mode........................................................................................................................10

5.5. Record Frame Rate ............................................................................................................. 11

5.6. Record Quality..................................................................................................................... 11

5.7. Record Schedule................................................................................................................. 11

5.8. Sub Menu－Password Change.......................................................................................... 11

5.9. Sub Menu－Time set...........................................................................................................12

5.10. Sub Menu－Motion set .......................................................................................................12

5.11. Sub Menu－Password Set..................................................................................................13

5.12. Sub Menu－Buzzer time .....................................................................................................13

5.13. Hard Drive Setup.................................................................................................................14

5.14. Sensor Setup .......................................................................................................................15

5.15. NTSC/PAL Output Select....................................................................................................16

Ⅰ. Record ............................................................................................... 17

6.1. Start Recording ...................................................................................................................17

6.2. Stop Recording....................................................................................................................18

6.3. Recording Length ...............................................................................................................18

Ⅰ. Playback ............................................................................................ 19

Ⅰ. A/B Page Switch ............................................................................... 20

8.1. Introduction .........................................................................................................................20

8.2. Switch Function ..................................................................................................................20

Ⅰ. Specification ..................................................................................... 21

Directory

—2—

8 Channel BNC Camera Input

2Channel BNC Monitor / VCR Output

A / B Page Switch Function

NTSC / PAL

Video Loss Alarm

Motion Detection

4Sets NO / NC Sensor Input

1 Alarm Output (2A 28VDC / 2A 125 VAC)

One ATA-100 Hard Disk Interface, Support Over 200G Byte

With Removable HDD Box

Time Schedule record / Sensor Triggered Record / Motion

Triggered Record

1 Channel 1 7 Move up 13 Play 19 Swap HDD

2 Channel 2 8 Select /Edit 14 Pause 21 Press-button

3 Channel 3 9 Move Down 15 Rewind 22 Key Locker

4 Channel 4 10 Record 16 HDD Access Indicator

23 Key

5 Quad View 11 Stop 17 Power Indicator 24 Active-handle

6 Menu /Exit 12 Forward 18 IR Window 25 Radiator

20 Enter/Exit the switchable state

Ⅰ DVR Feature

Ⅰ Outlook 2.1FrontPanel

—3—

1. Video Output

2. Video Input

3. Sensor Input/Alarm Output

4. DC Power

5. Grounding

1.CH1 Select or enlarge CH1

2.CH2 Select or enlarge CH2

3.CH3 Select or enlarge CH3

4.CH4 Select or enlarge CH4

5.QUAD Quad View

6.REW Rewind

7.PLAY Play record list

8.FWD Forward

9.RECORD Record

10.PAUSE Pause

11.STOP Stop recording or playing

12.MENU Enter or exit setup menu

13.Sel/Edit Modify item

14.UP Move up prompt

15.DOWN Move down prompt

16.CH1 Switch between CH1A and CH1B

17.A / B Switch between Quad1 and Quad2

18.CH2 Switch between CH2A and CH2B

19.CH3 Switch between CH3A and CH3B

20.CH4 Switch between CH4A and CH4B

Ⅰ Outlook 2.2 Rear Panel

Ⅰ Outlook 2.3 Remote Controller

—4—

1 .Power Indicator

2 .HDD Access Indicator

3 .Key Lock

4 .PVC Frame

5 .Active-handle

6 .Radiator

7 .HDD data cable

8 .HDD power cable

Ⅰ Outlook 2.4 Removable HDD Box Introduction

—5—

Fig1

Fig2

Fig3

(HDD is recommend to be provided by user)

Ⅰ DVR Installation 3.1 Install Hard Disk

Push carrier body further into cartridge

frame until fully inserted (Fig3)

Slide the carrier body out of the

cartridge frame (Fig1)

CAUTION

DON’T take out HDD when DVR running!

Connect the HDD data cable and the

power cable to the HDD(Fig2)

—6—

There are 8camera input and 2 monitor output with BNC connector.

Please use the power adapter supplied with DVR.

Ⅰ DVR Installation 3.3 Connect Power Cord

HDD Checking………..

MASTERHARDDRIVE

IBM—DHEA—36481

SLAVE HARD DRIVE

Ⅰ DVR Installation 4.1 Detect Installed Hard Disk

After the power is connected,

system will boot-up and detect

installed hard disk. Monitor will

show Master and Slave hard-disk

information.

Please refer to hard disk manual

to configure hard disk sequence.

(Master or Slave)

Ⅰ DVR Installation 3.2 Connect Camera and Monitor

A: Locked (Non-removable)

B: Unlocked (Removable)

Key Locker

—7—

Ⅰ DVR Installation 4.2 Recover Lost Data

SLAVE: RECOVER HDD?

04811-101735

(SELECT) YES/(MENU)NO

Power-Error will cause data lost

and system will ask for ‘recover

data’at the next step process,

Please press

[Select] to proceed.

Ⅰ DVR Installation 4.3 Restore Recording Process

POWER ERROR DETECHED

RESTO REHARD

DISK(MASTER) OK

RESTORE REC MODE… OK

When power-error happen

during recording process, system

will automatically restore recording

process after power reconnected.

—8—

Ⅰ DVR Installation 4.4 Main Screen

At first time DVR boot-up, all

cameras are OFF, please

follow chapter 5-2 to switch on

all cameras.

Upper left Ratio

of Hard Disk Space Used

MiddleChannel

Name( CH1 ～CH4)

Bottom rightDate and

Time At the moment, DVR

is waiting for command,

press [ Menu] into DVR

setup process .

—9—

Menu Directory

Camera Select

Record Select

Record Mode

Record Frame Rate

Video Quality

Record Schedule

Sub Menu

Hard Drive Setup

Sensor Setup

V DVR Setup 5.1 Setup Menu

0% MAIN MENU

＞CAMERA SELECT 1234

RECORD SELECT 1234

RECORD MODE EACH

REXORD FRAMERATE 30

VIDEO QUALETY NORMAL

RECORD SCHEDULE

SUB MENU

HARD DRIVE SETUP

SENSOR SETUP

PRESS（＜、＞）. THEN(SELECT)

PRESS(MENU) TO EXIT

Password Change

Time Set

Main Menu

Password Change

Time Set

Motion Set

Password Set

Buzzer Time

Press [ Menu] into setup

menu, use [Up]and

[Down]

to select item, press

[Select]to modify setting and

[Menu] to confirm and exit.

—10 —

System can display 4 camera video in one screen (Quad Mode). User

can configure which camera to display.

Press [ Select ] to modify setting and press [ CH1 ],[ CH2 ],

[ CH3 ],[ CH4 ] to set each channel separately. If no channel is open,

system will display [OFF] on monitor.

Configure which channel is allowed to record.

There are two modes for video recording,

[Each Mode]:Compress and record each channel video separately,

therefore, user can enlarge single channel video to full

screen display. For example, usercan turn off record

function of CH1 and CH2 and then system only record

CH3 and CH4 video.

Press [ CH1 ],[ CH2 ],[ CH3 ],[ CH4 ] to

switch channel to display when playback recorded

video.

[Quad Mode]:Compress and record all 4 channel video into one file,

therefore usercan not enlarge single channel to full

screen. User can’t use the each mode record in this

mode.

V DVR Setup 5.4 Record Mode

V DVR Setup 5.2 Camera Select

V DVR Setup 5.3 Record Select
