Kärcher Puzzi 10/1 Bedienungsanleitung
– 1
Please read and comply with
these original instructions prior to
the initial operation of your appliance and
store them for later use or subsequent own-
ers.
– Before initial start-up it is definitely nec-
essary to read the safety information
no. 5.956-077.0!
– The non-compliance of the operating
and safety instructions may lead to
damages of the appliance and to dan-
gers for the operator and other persons.
– In case of transport damage inform ven-
dor immediately.
Notes about the ingredients (REACH)
You will find current information about the
ingredients at:
www.kaercher.com/REACH
!DANGER
Immediate danger that can cause severe
injury or even death.
"WARNING
Possible hazardous situation that could
lead to severe injury or even death.
"CAUTION
Pointer to a possibly dangerous situation,
which can lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation,
which can lead to property damage.
– This spray extraction device is intended
for wet cleaning of carpets.
– This appliance is suited for the commer-
cial use, e.g. in hotels, schools, hospi-
tals, factories, shops, offices, and rental
companies.
Contents
Environmental protection . . . . EN 1
Danger or hazard levels . . . . . EN 1
Proper use . . . . . . . . . . . . . . . EN 1
Overview . . . . . . . . . . . . . . . . . EN 2
Start up . . . . . . . . . . . . . . . . . . EN 2
Operation . . . . . . . . . . . . . . . . EN 3
Cleaning methods . . . . . . . . . . EN 4
Transport. . . . . . . . . . . . . . . . . EN 5
Storage . . . . . . . . . . . . . . . . . . EN 5
Care and maintenance . . . . . . EN 5
Troubleshooting . . . . . . . . . . . EN 5
Accessories and Spare Parts . EN 6
Warranty . . . . . . . . . . . . . . . . . EN 6
EC Declaration of Conformity . EN 6
Technical specifications . . . . . EN 7
Environmental protection
The packaging material can be
recycled. Please do not throw
the packaging material into
household waste; please send it
for recycling.
Old appliances contain valuable
materials that can be recycled;
these should be sent for recy-
cling. Batteries, oil, and similar
substances must not enter the
environment. Please dispose of
your old appliances using appro-
priate collection systems.
Danger or hazard levels
Proper use
11EN
– 2
Illustration
1 Connect spray/suction hose to the el-
bow,
Connect spray/suction hose to the ap-
pliance
2 Prepare cleaning solution,
Fill up the fresh water tank
3 Select operating mode
4 Cleaning
5 Empty the fresh water tank
6 Empty wastewater container
7 Fill fresh water tank (without detergent),
Flush appliance
8 Clean lint trap,
Clean fresh water sieve
9 Allow appliance to dry
Illustration
1 Hand nozzle for upholstery cleaning
(Puzzi 10/1 only)
2 Cable hook
3 Adapter for accessories (homebase)
4 Holder for accessories
5 Power cord
6 Quick start instructions
7 Fresh water tank
8 Fresh water sieve
9 Switch for spraying
10 Switch for vacuuming
11 Casing
12 Nameplate
13 Steering roller
14 Spray hose connection
15 Socket for additional brush washing
head PW 30/1 (Puzzi 10/2 Adv only)
16 Suction hose connection
17 Container for defoaming agent (Puzzi
10/2 Adv only)
18 Cover
19 Storage compartment for detergent
tabs (Puzzi 10/2 Adv only)
20 Carrying handle of the appliance
21 Floor nozzle for carpet cleaning
22 Carpet adapter
23 Unlocking device of the floor nozzle
24 Suction pipe
25 Nozzle mouth piece
26 Union joint
27 Handle
28 Bender
29 Lever on the manifold
30 Spray hose
31 Suction hose
32 Spray/suction hose
33 Dirt water reservoir, detachable
34 Carrying handle of the wastewater con-
tainer
35 Seal on the lid
36 Fluff filter
Check high power cable, extension ca-
bles and hoses for damage every time
before use.
Attach the suction pipe to the floor noz-
zle and hand-tighten the union nut on
the floor nozzle.
If required, slide the handle onto the
suction pipe and hand-tighten it in the
desired position.
Place the elbow over the suction pipe
and tighten the union joint on the elbow
fingertight.
Insert the suction hose into the suction
hose connection on the appliance.
Attach the coupling of the spray hose to
the spray hose connection of the appli-
ance and snap in place.
Connect the suction hose to the elbow.
Connect the coupling of the spray hose
with the manifold and snap in place.
"WARNING
Health risk, risk of damage. Observe all in-
dications on the detergent used.
Mix fresh water and detergent in a clean
container (use the concentration rec-
ommended for the detergent).
Dissolve detergent in the water.
Overview
Quick start instructions
Device elements
Start up
Attaching the Accessories
Prepare cleaning solution
12 EN
– 3
Note: Warm water (max. 50°C) will in-
crease the cleaning effect. Verify the tem-
perature resistance of the surface to be
cleaned.
Note: For considerate treatment of the en-
vironment use detergent economically.
Fill detergent solution into the fresh wa-
ter reservoir. The fill level must not ex-
ceed the "MAX" mark.
Note: When cleaning previously sham-
pooed carpets, foam is generated in the
wastewater container. This formation of
foam can be prevented by adding a de-
foaming agent.
Puzzi 10/1 only:
Put defoaming agent (optional accesso-
ry) into the wastewater container.
Puzzi 10/2 Adv only:
Open container for defoaming agent.
Fill in defoaming agent (optional acces-
sory).
Push the unlocking device of the floor
nozzle on one side.
Swivel out and remove the carpet
adapter.
Insert a new carpet adapter and snap
the locking device in place.
Puzzi 10/2 Adv only:
Note: There is an additional socket to con-
nect electrical accessory devices.
!DANGER
Risk of injury and damage! The socket is
only intended for the direct connection of
the additional brush washing head PW 30/
1 to the Puzzi 10/2 Adv. Any other use of
the socket is not permitted.
Plug in the mains plug.
Press the suction switch to turn on the
suction turbine.
Press the spray switch to switch on the
spray pump.
ATTENTION
Risk of damage. Check the object to be
cleaned prior to using the appliance in an
inconspicuous place for colour fastness
and water resistance.
Operate the lever on the manifold in or-
der to spray the cleaning solution.
Run across the surface to be cleaned in
overlapping paths. Pull the nozzle back-
wards (do not push).
In case of work interruptions, the floor
nozzle can be stored in the carrying
handle of the device.
Switch off the spray and suction switches.
Pull out the mains plug.
If the dirt water reservoir is full, switch
off the suction and spray switches.
Remove the lid.
Remove the wastewater container from
the appliance and drain it.
Turn off the appliance.
Shortly activate the lever on bender to
decrease the pressure.
Separate bender from the spray/suction
hose.
Insert the suction hose into the fresh
water reservoir.
Press the suction switch to turn on the
suction turbine.
Empty the fresh water reservoir and
switch the appliance off.
Remove the lid.
Remove the wastewater container from
the appliance and drain it.
Fill up fresh water reservoir
Defoaming agent
Replacing the carpet adapter
Operation
Working with attachments
Turning on the Appliance
Cleaning
Turn off the appliance
Empty wastewater container
Empty the fresh water reservoir
13EN
– 4
Connect the manifold (with suction pipe
and nozzle) to the suction hose.
Connect the coupling of the spray hose
with the manifold and snap in place.
Fill approx. 2 litres of fresh water into
the fresh water reservoir.
Do not add any detergents.
Press the spray switch to switch on the
spray pump.
Hold floor nozzle over a drain.
Activate lever on bender and flush the
appliance for appr. 1 to 2 minutes.
Turn off the appliance.
Flush appliance.
Empty the wastewater container and
clean it under running water.
Empty the fresh water reservoir.
Clean the outside of the appliance with
a damp cloth.
Remove all water from the appliance
prior to longer periods of non-use to
avoid offensive odours.
Allow appliance to dry thoroughly: Re-
move or move lid sideways.
Place the appliance in a dry room and
secure it from unauthorized use.
Spray and suction off detergent solution
in one work cycle.
Note: Repeated suctioning without spray-
ing will shorten the drying time.
Apply detergent solution with suction
turbine turned off and soak for 10 to 15
minutes.
Clean the surface just like with normal
soiling.
In order to further improve the cleaning
result, the surface can be recleaned us-
ing clear, warm water.
Puzzi 10/1 only:
Attach hand nozzle instead of the floor
nozzle.
With sensitive materials, use less deter-
gent and spray the surface at a distance
of approx. 200 mm. Then simply vacu-
um off.
– Highly soiled spots should be pre-
soaked and the detergent solution
should soak 5 to 10 minutes.
– Always work from the light to the shade
(from the window to the door).
– Always work from the cleaned to the un-
cleaned surface.
– The more sensitive the surface (oriental
rugs, berbers, upholstery material) the
lower the cleaning solution concentra-
tion should be.
– Rugs with jute backing can shrink if too
much water is used and can bleed col-
ours.
– Brush high-fiber rugs in the direction of
the weave after cleaning (using a fiber
brush or a scrubber).
– Water-proofing the fabric using Care
Tex RM 762 after the wet cleaning pre-
vents a quick resoiling of the textile sur-
face.
– Do not step on cleaned surfaces until
they have dried and do not place furni-
ture on them to avoid pressure spots or
rust stains.
For further information, please request
product information sheet and EU safety
data sheet of the relevant detergent.
Flush appliance
After each operation
Storing the Appliance
Cleaning methods
Normal soiling
Strong soiling or stains
Upholstery cleaning
Cleaning tips
Detergent
Carpet and upholstery
cleaning
RM 760 powder
RM 760 tabs
RM 764 liquid
Defoaming RM 761
Waterproofing carpets RM 762
14 EN
– 5
"CAUTION
Risk of injury and damage! Observe the
weight of the appliance when you transport
it.
Illustration
For transport, place suction pipe on the
carrying handle and place the spray/
suction hose on top of the appliance.
Wind up the mains cable and hook it
into the cable hook.
When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
"CAUTION
Risk of injury and damage! Note the weight
of the appliance in case of storage.
This appliance must only be stored in inte-
rior rooms.
!DANGER
Danger of injury by electric shock.
First pull out the plug from the mains before
carrying out any tasks on the machine.
Remove the lid.
Remove the wastewater container from
the appliance.
Regularly clean the lint trap using a
brush.
Unscrew the fresh water sieve.
Regularly clean the fresh water sieve
under running water.
Unscrew the covering nut.
Clean nozzle mouthpiece.
!DANGER
–Danger of injury by electric shock.
First pull out the plug from the mains be-
fore carrying out any tasks on the ma-
chine.
–Get the electrical components checked
and repaired only by authorised cus-
tomer service persons.
Check the receptacle and the fuse of
the power supply.
Check the power cable and the power
plug of the device.
Turn on the appliance.
Fill up fresh water reservoir.
Check the couplings on the spray hose
for proper seating.
Clean or replace nozzle tip.
Clean the sieve in the fresh water reser-
voir.
Spray pump defective, contact after-
sales service.
Clean nozzle mouthpiece.
Check the correct positioning of the lid.
Clean seal on lid and surface on the ap-
pliance.
Clean the fluff filter.
Check suction hose for blockages;
clean if required.
Fill up fresh water reservoir.
Add the defoaming agent into the
wastewater container or fill up the con-
tainer for the defoaming agent.
Transport
Storage
Care and maintenance
Clean the fluff filter
Cleaning the fresh water sieve
Cleaning the nozzle
Troubleshooting
Appliance is not working
No water exiting from nozzle
Spray stream one-sided
Insufficient vacuum performance
Spray pump loud
Heavy formation of foam in the
wastewater container
15EN
– 6
If malfunction can not be fixed, the de-
vice must be checked by customer ser-
vice.
– Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts
ensures that the appliance can be oper-
ated safely and trouble free.
– At the end of the operating instructions
you will find a selected list of spare parts
that are often required.
– For additional information about spare
parts, please go to the Service section
at www.kaercher.com.
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
5.957-534
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2015/03/01
Customer Service
Accessories and Spare Parts
Warranty
EC Declaration of Conformity
Product: Spray extraction device
Type: 1.100-xxx
Type: 1.193-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
2011/65/EU
Applied harmonized standards
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 1997+A1: 2001+A2: 2008
EN 60335–1
EN 60335–2–68
EN 61000–3–2: 2006+A1: 2009+A2: 2009
EN 61000–3–3: 2013
EN 62233: 2008
EN 50581
Applied national standards
-
CEO Head of Approbation
16 EN
– 7
Technical specifications
Puzzi 10/1 Puzzi 10/2 Adv
Mains voltage V EU: 220-240 EU: 220-240
V GB: 230-240 GB: 230-240
V AU: 240 AU: 240
V AR: 220 AR: 220
Frequency Hz 1~ 50-60 1~ 50-60
Type of protection -- IPX4 IPX4
Protective class II II
Nominal performance of blower motor W 1100 1100
Power (tot.) W -- 1350
Air volume (max.) l/s 54 54
Negative pressure (max.) kPa (mbar) 22 (220) 22 (220)
Spray pump performance W 40 80
Spray pressure MPa 0,1 0,2
Spray pressure (max.) MPa 0,3 0,3
Spray volume I/min 1 2
Temperature of the cleaning solution
(max.)
°C 50 50
Filling quantity of fresh water l 10 10
Fill volume wastewater l 9 9
Appliance socket performance (max) W -- 250
Length x width x height mm 705 x 320 x 435 705 x 320 x 435
Typical operating weight kg 10,7 11,4
Max. ambient temperature °C +40 +40
Values determined to EN 60335-2-68
Sound pressure level LpA dB(A) EU: 74 EU: 74
dB(A) GB: 76 GB: 76
Uncertainty KpA dB(A) 1 1
Hand-arm vibration value m/s2<2,5 <2,5
Uncertainty K m/s20,2 0,2
Power cord H05VV-F 2x1,0 mm2
Part no.: Cable length
EU 6.650-363.0 7,5 m
GB 6.650-380.0 7,5 m
AU 6.650-385.0 7,5 m
AR 6.650-382.0 7,5 m
17EN
Andere Handbücher für Puzzi 10/1
3
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Kärcher Staubsauger Handbücher
Kärcher
Kärcher WD 2 Bedienungsanleitung
Kärcher
Kärcher NT 50/1 Me Classic Bedienungsanleitung
Kärcher
Kärcher K 7 Bedienungsanleitung
Kärcher
Kärcher WD 2 Bedienungsanleitung
Kärcher
Kärcher VC 6 Premium Bedienungsanleitung
Kärcher
Kärcher AD 4 Premium Bedienungsanleitung
Kärcher
Kärcher NT 611 Eco TE Bedienungsanleitung
Kärcher
Kärcher WD 3 V-17/4/20 Bedienungsanleitung
Kärcher
Kärcher AD 2 Bedienungsanleitung
Kärcher
Kärcher IVM 60/36-3 H Bedienungsanleitung
Kärcher
Kärcher FC 7 Cordless Bedienungsanleitung
Kärcher
Kärcher AD 3.200 Bedienungsanleitung
Kärcher
Kärcher WD 2 Bedienungsanleitung
Kärcher
Kärcher VC 3 Bedienungsanleitung
Kärcher
Kärcher WD 5 P Bedienungsanleitung
Kärcher
Kärcher T 8/1 L Bedienungsanleitung
Kärcher
Kärcher WD 3.600 MP Bedienungsanleitung
Kärcher
Kärcher IVS 100/40 Bedienungsanleitung
Kärcher
Kärcher VC 6 Bedienungsanleitung
Kärcher
Kärcher RC 3 Bedienungsanleitung
Beliebte Staubsauger Handbücher anderer Marken
Bissell
Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung
Panasonic
Panasonic MC-YL637S147-AE Bedienungsanleitung
NEFF
NEFF N17XH10 0 Series Bedienungsanleitung
LG
LG A9 Series Bedienungsanleitung
Oreck
Oreck Cordless Captura BK51700 Series Bedienungsanleitung
Kogan
Kogan KAVACROBVWA Bedienungsanleitung
