Keysight Technologies U3020AD01 Handbuch

Keysight Technologies

U3020AD01

User’s and

Service Guide

Notices

This document contains references to

Agilent Technologies. Agilent’s

former Test and Measurement

business has become Keysight

Technologies. For more information,

go to www.keysight.com

2011-2017, 2019

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent from

Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Trademark Acknowledgments

Manual Part Number

U3020-90004

Edition

Print Date: December 2019

Supersedes: August 2019

Printed in:

Printed in USA/Malaysia

Published by:

Keysight Technologies Inc

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.



U.S. Government Rights

The Software is “commercial

computer software,” as defined by

Federal Acquisition Regulation

(“FAR”) 2.101. Pursuant to FAR

12.212 and 27.405-3 and

Department of Defense FAR

Supplement (“DFARS”) 227.7202,

the U.S. government acquires

commercial computer software

under the same terms by which the

software is customarily provided to

the public. Accordingly, Keysight

provides the Software to U.S.

government customers under its

standard commercial license, which

is embodied in its End User License

Agreement (EULA), a copy of which

can be found at http://

www.keysight.com/find/sweula. The

license set forth in the EULA

represents the exclusive authority by

which the U.S. government may use,

modify, distribute, or disclose the

Software. The EULA and the license

set forth therein, does not require or

permit, among other things, that

Keysight: (1) Furnish technical

information related to commercial

computer software or commercial

computer software documentation

that is not customarily provided to

the public; or (2) Relinquish to, or

otherwise provide, the government

rights in excess of these rights

customarily provided to the public to

use, modify, reproduce, release,

perform, display, or disclose

commercial computer software or

commercial computer software

documentation. No additional

government requirements beyond

those set forth in the EULA shall

apply, except to the extent that those

terms, rights, or licenses are

explicitly required from all providers

of commercial computer software

pursuant to the FAR and the DFARS

and are set forth specifically in

writing elsewhere in the EULA.

Keysight shall be under no obligation

to update, revise or otherwise modify

the Software. With respect to any

technical data as defined by FAR

2.101, pursuant to FAR 12.211 and

27.404.2 and DFARS 227.7102, the

U.S. government acquires no greater

than Limited Rights as defined in

FAR 27.401 or DFAR 227.7103-5 (c),

as applicable in any technical data.

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,”

AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN

FUTURE EDITIONS. FURTHER, TO THE

MAXIMUM EXTENT PERMITTED BY

APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES, EITHER

EXPRESS OR IMPLIED WITH REGARD

TO THIS MANUAL AND ANY

INFORMATION CONTAINED HEREIN,

INCLUDING BUT NOT LIMITED TO THE

IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

KEYSIGHT SHALL NOT BE LIABLE

FOR ERRORS OR FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE

FURNISHING, USE, OR

PERFORMANCE OF THIS DOCUMENT

OR ANY INFORMATION CONTAINED

HEREIN. SHOULD KEYSIGHT AND THE

USER HAVE A SEPARATE WRITTEN

AGREEMENT WITH WARRANTY

TERMS COVERING THE MATERIAL IN

THIS DOCUMENT THAT CONFLICT

WITH THESE TERMS, THE WARRANTY

TERMS IN THE SEPARATE

AGREEMENT SHALL CONTROL.

Safety Notices

A CAUTION notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly

performed or adhered to, could

result in damage to the product or

loss of important data. Do not

proceed beyond a CAUTION notice

until the indicated conditions are

fully understood and met.

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly

performed or adhered to, could

result in personal injury or death. Do

not proceed beyond a WARNING

notice until the indicated conditions

are fully understood and met.

Table of Contents

Contents-1

U3020AD01

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Verifying the Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

General Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Environmental Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Equipment Heating and Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Required Conditions for Accuracy Enhanced Measurement .. . . . . . . . . . . . . . . . . . 4

Dimensions and Space Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Maximum Power Levels and Performance Characteristics. . . . . . . . . . . . . . . . . . . . . . . 5

Front and Rear Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Standby Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

LAN Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Attenuation LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

RF Input/Output Ports - 3.5 mm (Female). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Instrument State LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

GPIB Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 8

Line Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Power Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Controlling the Test Set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . 9

Test Set SCPI Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Operational Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Equipment Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Measurement Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Measurement Sequence, Test Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Electrostatic Discharge Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Dynamic Accuracy Test Set System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Controller Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

39495EXT Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Distribution Board (PCB3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

LED Indicator Board (PCB2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Front Panel Instrument State LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

RF Switch Not Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Instrument Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Keysight Connect Expert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Configuring the LAN Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Locating the Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Configuring the GPIB Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Contents-2

Table of Contents

Adding Instruments to the GPIB Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Changing the GPIB Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

LAN and GPIB Interface Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Reset Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

IP Address Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Auto-IP Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

DHCP Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

DNS Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Domain Name Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Gateway Address Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Host Name Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

GPIB Configuration Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Safety Earth Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Connector Care and Cleaning Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Before Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

South Korean Class A EMC Declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .34

Acoustic Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Keysight Support, Services, and Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Service and Support Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Contacting Keysight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Shipping Your Product to Keysight for Service or Repair. . . . . . . . . . . . . . . . . . . . . . .35

U3020AD01

U3020AD01 Introduction

Introduction

This document describes how to use and service the Keysight U3020AD01 Dynamic Accuracy

Test Set.

Figure 1 U3020AD01 Dynamic Accuracy Test Set

Keysight U3020AD01 User's and Service Guide

U3020AD01 Description

Description

The Keysight U3020AD01 Dynamic Accuracy Test Set is designed for the Keysight PNA-X

network analyzer as a test accessory in performing the power linearity test (dynamic accuracy)

of the network analyzer receivers. As of this manual edition, other Keysight network analyzer

product families have also incorporated the Test Set in their production and service processes.

The U3020AD01 Test Set can only be controlled via the rear panel GPIB or LAN interfaces.

When using the Connection Expert utility program, available on the PNA-X platform and other

computer platforms, the program may identify the Test Set as "L449XA" or "U3020A." The full

Test Set model number can be found on its rear panel serial label.

For more PNA-X network analyzer Dynamic Accuracy measurement information, refer to the

PNA-X Service Guide for the model you have: http://www.keysight.com/find/pna

Verifying the Shipment

To verify the contents shipped with your product, refer to the “Box Content List” included with

the shipment.

Inspect the shipping container. If the container or packing material is damaged, it should be

kept until the contents of the shipment have been checked mechanically and electrically. If

there is physical damage refer to “Contacting Keysight” on page 35. Keep the damaged

shipping materials (if any) for inspection by the carrier and an Keysight Technologies

representative.

Table 1 U3020AD01 Accessories Supplied

Description Part Number

RF cable, Flex 3.5 mm M/F, 61 cm (2 ft.) long 8121-2111

Manual, User's Guide

Quantity

U3020-90004

Keysight U3020AD01 User's and Service Guide

U3020AD01 General Performance

General Performance

The Test Set is used to characterize the receiver power linearity of a network analyzer. Actual

performance of the system is based on your network analyzer and options that are used with the

Test Set. The Test Set is not specified for overall system performance. A functional certificate is

supplied for the U3020AD01.

There are no internal adjustment in the U3020AD01, therefore an annual calibration is not

required.

This product has an autoranging line voltage input. Be sure the supply

voltage is within the specified range.

Power Requirements

Verify that the required AC power is available at all necessary locations before installing the

Test Set and Network Analyzer.

•100-240 V (50/60 Hz)

•The instruments can operate with mains supply voltage fluctuations up to ± 10% of the

nominal voltage.

•Air conditioning equipment (or other motor–operated equipment) should not be placed on

the same ac line that powers the Test Set.

•U3020AD01 maximum power is 50 W.

Keysight U3020AD01 User's and Service Guide

U3020AD01 General Performance

Environmental Requirements

Refer to the Network Analyzer documentation for environmental requirements.

Environmental Tests

The U3020AD01 complies with all applicable safety and regulatory requirements for the

intended location of use.

•Operating Environment (Indoor Use)

•Operating Ambient: Temperature 0 to 40 °C

•Operating Altitude: 0 to 2000 meters (~ 6,562 feet)

•The instrument can safely operate in a relative humidity of 80% for temperatures to

31 degrees C, decreasing linearly to 50% relative humidity at 40 degrees C.

Equipment Heating and Cooling

If necessary, install air conditioning and heating to maintain the ambient temperature within the

appropriate range. Air conditioning capacity must be consistent with the rating listed in the

PNA standard documentation.

Required Conditions for Accuracy Enhanced Measurement

Accuracy–enhanced (error–corrected) measurements require the ambient temperature of the

PNA-X and Test Set to be maintained within ± 1 °C of the ambient temperature at calibration.

Dimensions and Space Requirements

Standard installation of the U3020AD01 and PNA includes configuration and installation on a

customer provided lab bench or table top of adequate size and strength.

Table 2 Test Set Physical Parameters

Item Value

Height 8.8 cm (3.5 in)

Width 42.5 cm (16.73 in)

Depth 58 cm (23 in)

Weight 9 kg (19.8 lb)

Keysight U3020AD01 User's and Service Guide

General Performance

Refer to your PNA-X standard documentation specifications to determine the

maximum input power levels for the PNA-X access and test ports, or to optimize

the power levels in the receivers.

Damage and maximum levels are not necessarily the optimum level.

U3020AD01

Maximum Power Levels and Performance Characteristics

Table 3 Power Levels

RF Input/Output Power Damage Levels:

SRC 1 IN +30 dBm

SRC 2 IN +30 dBm

SRC 2 CPLD OUT +30 dBm

RCVR OUT +30 dBm

Table 4 Performance Characteristics

Parameter Freq. Range (GHz)

Path Insertion Loss:

1.8 - 2.2

SRC1 IN to RCVR OUT

3.5 - 4.0

SRC2 IN to RCVR OUT 1.8 - 2.2

SRC2 IN to SRC2 CPLD OUT

3.5 - 4.0

1.0 - 4.0

Path Isolation:

RCVR OUT to SRC2 CPLD OUT 1.8 - 2.2

RCVR OUT to SRC1 IN 1.8 - 2.2

RCVR OUT to SRC2 IN

SRC1 IN to SRC2 IN 1.8 - 2.2

Port Match:

All Ports 1.8 - 2.2

Typical (dB)

-3 to -9

< -34

-3 to -9

< -38

-14 to -18

< -80

< -45

< -70

< -12

Keysight U3020AD01 User's and Service Guide

1. Unconnected ports must be terminated in 50 Ohms.
