Kogan T10 Pro Bedienungsanleitung
T10 PRO CORDLESS 29.6V
STICK VACUUM CLEANER
KAVACSTT10A
When using any electrical appliance, basic safety precautions should always be observed.
Fully charge the appliance before using it for the first time or if it hasn't been used
in a long time.
The operating temperature of the product ranges from 0°C to 40°C.
Do not use the product to clean construction waste.
Do not use the appliance to clean liquids. Do not pour liquids inside the appliance
or clean it under running water.
Never immerse the cord, plug or the appliance in water or other liquids. Should the
appliance fall into water, immediately unplug it from the mains and have it
checked by an expert before using it again. It may cause fire, electric shock, injury
or death.
Do not pick up or operate the appliance if the power supply cord or the plug is
damaged or if the vacuum is malfunctioning or has been dropped or damaged in
any way. In case of damage, contact the after sales service. A damaged cord or
plug must be exclusively replaced by the manufacturer or a qualified person in
order to avoid injuries.
Unplug the vacuum cleaner from the mains when it's fully charged. Do not pull out
the mains plug by tugging the cable.
Never leave the appliance unattended when it is switched on. Keep the appliance
out of the reach of children.
This appliance can be used by children and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Never lift up, carry or unplug the appliance by pulling from the power cord.
Battery Warnings
Do not place the charging station near heat sources.
Do not hit, drop or puncture the battery.
Recycle the battery safely to at an appropriate facility.
Do not use any chargers other than that provided by Kogan.com.
SAFETY & WARNINGS
Part List
1. ON/OFF button
2. Speed control button
3. Motor body
4. Main body release button
5. Tube
6. Brush release button
7. Electric brush
8. Dustbin release button
9. Battery indicator
10. Dustbin button
11. Dustbin
12. 2-in-1 brush
OVERVIEW
1
8
2
9
10
3
11
4
5
12
6
7
1. Place the filters inside the dustbin, turn the cone and align the notches on the cone
with the ridges inside the dustbin.
2. Insert the filter in the cone and then the dustbin into the motor body until you hear
it click.
3. Attach the brush to the lower end of the tube and the tube to the main body.
4. Insert the battery to the main body until you hear it click.
ASSEMBLY
Attaching the accessories to the main unit
To install the 2-in-1 accessory, simply fit it into the hole of the main body until it is securely
attached.
Attaching the accessories to the tube
Insert the round end of the 2-in-1 accessory or the furniture accessory into the lower end of
the tube until it clicks into place.
OPERATION
Turn the vacuum cleaner on and off with the ON/OFF button and use the speed control
button to adjust the power.
The main brush is suitable for most applications and the 2-in-1 accessory is perfect for
cleaning hard-to-reach areas such as couches, corners, stairs, keyboards, furniture, shelves
and electrical appliances – see Assembly.
Charging
Charging time is 4-5 hours.
Place the vacuum cleaner on the wall mount. While charging, an LED indicator will turn on.
When it is fully charged, three lights will be illuminated. If the battery is flat, it should be
charged.
Charge the battery every three months if the vacuum will not be used for an extended
period of time.
Wipe the outer surface of the vacuum cleaner with a soft dry cloth. Do not use a pressure
gun, water or any other liquids to clean the appliance.
Store the appliance away from direct sunlight.
Emptying the dustbin
Press the main body release button to separate the dustbin from the main body. Now press
the dust release button and empty the dustbin.
Cleaning the dustbin
Disassemble the dustbin, removing both the HEPA and plastic filters.
Wash and air dry both filters.
Cleaning the main brush
Slide the tab located on the bottom of the accessory, remove the brush and clean it.
CLEANING & CARE
Issue Possible Cause Solution
Not turning on Battery flat Charge appliance
Being charged Unplug charger
Not enough suction
power.
Dustbin full Empty dustbin
HEPA filter blocked Clear HEPA filter
Poor performance or
dust escaping dustbin
Dustbin full Empty dustbin
HEPA filter blocked Clear HEPA filter
HEPA filter damaged Replace HEPA filter
Battery not charging Battery has reached the end of
its working life Contact Kogan.com
Abnormal sound during
cleaning
Rolling brush may be
entangled with foreign objects Stop operation and clear rolling
brush
Dustbin full Empty dustbin
Voltage 29.6V
Power 0W
Dimensions 1170x255x215
Charging time 4 H
Dustbin capacity 600ml
TROUBLESHOOTING
SPECIFICATIONS
25
-5
Need more information?
This is a Quick Start Guide, and we hope that this
has given you the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
