USER MANUAL

MODELS:

MTX3-16-M 16x16 8K Modular Matrix

MTX3-34-M 34x34 8K Modular Matrix

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Contents
2

Contents
Introduction 3
Getting Started 3
Overview 4
Typical Applications 6
Defining MTX3-16-M 16x16 8K Modular Matrix 7
Defining MTX3-34-M 34x34 8K Modular Matrix 9
Mounting MTX3-16-M 12
Connecting MTX3-16-M and MTX3-34-M 13
Installing Matrix Cards 14
Identifying Input / Output Ports 15
Providing PoE to Matrix Cards 16
Managing MTX3-16-M via Ethernet 17
Managing MTX3-16-M via RS-232 19
Managing MTX3-16-M via USB (VCOM) 19
Securing MTX3-16-M Operation 20
Standard Certification 20
MTX3-16-M Security Means 20
Managing MTX3-16-M 21
Managing MTX3-16-M via Front Panel Buttons 22
Using MTX3-16-M LCD Display Menu 22
Using TAKE Button to Confirm Actions 30
Locking Front Panel Buttons 30
Managing MTX3-16-M from the Embedded Web UI 31
Opening the Embedded Web UI 32
Routing Inputs to Outputs 33
Defining User Accounts 41
Acquiring EDID 44
Configuring MTX3-16-M 45
Upgrading / Restoring Module Card Firmware 47
Configuring Input / Output Ports 48
Monitoring MTX3-16-M Hardware 50
Viewing the about Page 53
Upgrading Firmware 54
Upgrading Firmware from the Web UI 54
Upgrading Firmware –K-Upload 54
Technical Specifications 56
MTX3-16-M CNTL and Chassis 56
MTX3-34-M CNTL and Chassis 57
Matrix Cards 58
Default Communication Parameters 63
Default EDID 64
Protocol 3000 66
Understanding Protocol 3000 66
Protocol 3000 Commands 67
Result and Error Codes 80

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

•Review the contents of this user manual.

To check for up-to-date user manuals, application programs, and if firmware upgrades are

available (where appropriate):

•For MTX3-16-M, go to www.kramerav.com/downloads/MTX3-16-M.

•For MTX3-34-M, go to www.kramerav.com/downloads/MTX3-34-M.

Achieving Best Performance

•Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

•Do not secure the cables in tight bundles or roll the slack into tight coils.

•Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

•Position your Kramer MTX3-16-M / MTX3-34-M away from moisture, excessive sunlight

and dust.

Safety Instructions

Caution:

•This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

•For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

•There are no operator serviceable parts inside the unit.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Introduction

Warning:

•Use only the power cord that is supplied with the unit.

•Disconnect the power and unplug the unit from the wall before installing.

•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified

personnel only.

•To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which is located on the bottom of the unit.

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

MTX3-16-M and MTX3-34-M are intelligent and high-performance modular matrices for

switching and distribution of multi-format audio-visual signals. Their chassis includes a CTRL

central control card with secured LAN connectivity for remote management and control. All

matrices are flexibly populated by any matrix cards from the same compatible family of multi-

format matrix cards.

MTX3-16-M includes eight horizontal card slots and MTX3-34-M includes seventeen vertical

card slots for flexible insertion of modular matrix cards, accommodating matrix cards with

quad or dual ports of either input or output multi-format signals.

Most of the information included in this user manual is relevant to both MTX3-16-M and to

MTX3-34-M.

Unless specified otherwise, MTX3-16-M is used throughout this user manual to refer to both

devices.

Exceptional Quality

•High Resolution Audio-Visual Experience –MTX3-16-M is a professional, 8K-ready

matrix for switching multi-format AV signals. The modular matrix cards support 4K60

4:4:4 multi-format AV signal distribution and the backplane router is ready for 8K audio-

visual signal switching, enabling future upgrades to 8K-capable matrix cards.

•HDMI™Signal Switching –HDCP 2.2 compliant, supporting deep color, x.v.Color™,

CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K,

and 3D as specified by the HDMI 2.0 standard.

•I-EDIDPro™Kramer Intelligent EDID Processing™–Intelligent EDID management of

each input port by a processing algorithm that manages locking and pass-through and

ensures plug & play operation for HDMI sources and display systems.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Introduction

•Robust Signal Distribution –Kramer Equalization & re-Klocking™technology

professionally rebuilds switched digital signals, preparing them for distribution over long-

distance copper and fiber optic cables.

Advanced and User-friendly Operation

•Comprehensive Matrix Control Options –Control can be remotely, using the Kramer

Control application, for example, or locally.

•A user-friendly web-UI provides high-level remote service control.

•Locally, the RS-232 service port can be used for high-level Protocol 3000 APIs and there

are front panel control buttons and an LCD screen which can perform switching

operations, storage and recall of switching presets and configuration switching.

•Security-certified Operation –The matrix is certified for OWASP-10 (Open Web

Application Security Project) standard compliance, ensuring secured web-UI user

access and communication, and secured remote operation and management.

•Simple Professional Management –Compatibility with the Kramer enterprise

management platform enables remote matrix operational management, including matrix

automatic discovery and configuration, remote matrix switching operations, matrix and

card diagnostics and firmware upgrade management.

•Cost-Effective Maintenance –Front-panel LED indicators, an LCD display and a low-

noise field-replaceable fan cooling unit for easy matrix maintenance and troubleshooting.

Local firmware upgrades can be performed via a USB port for convenient, lasting, field-

proven deployment.

•Easy Installation –The compact 3U-only 19” (4U for MTX3-34-M) enclosure is suitable

for rack mounting with a universal 100-240V AC power supply. PoE (Power over

Ethernet) can be provided over HDBT cables to remote connected end-points,

eliminating the need for local mains powering.

Flexible Connectivity

•Any input/output mix –Flexible matrix card slot support for either input or output cards

service. Mix setup and deployment flexibly to match usage needs.

•Multi-format Distribution –The matrix card range supports multiple market-available

audio-visual signals, such as HDMI™, VGA, and SDI, with analog and digital audio

signals. Kramer Core™technology enables long-distance signal distribution over

standard HDBaseT copper cables and fiber optic infrastructure wiring.

•Independent Signal Switching –Modular matrix switching is fully non-blocking, where

any matrix input signal can be distributed to any single or multiple output ports.

•Market-standard Interoperability –The matrix complies with HDBaseT standards and

interoperates with market available HDBaseT-certified end-points. For best reach and

high-resolution distribution performance, use Kramer HDBaseT cables, and Kramer

transmitter and receiver end-points.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Introduction

Typical Applications

MTX3-16-M is ideal for the following typical applications:

•Professional large audio-visual switching systems in large-space facilities.

•Enterprise and government applications requiring flexible and secured large-scale multi-

format AV distribution over long-distances.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Defining MTX3-16-M 16x16 8K Modular Matrix

Defining MTX3-16-M 16x16 8K

Modular Matrix

This section defines MTX3-16-M.

Figure 1: MTX3-16-M 16x16 8K Modular Matrix Front Panel

Feature

Function

Numeric

Keypad

Numbers

1 to 0

←(Move left)

Move the LCD display left (when the display is extended).

→(Move right)

Move the LCD display right (when the display is extended).

Double-Function

Selector

Buttons.

Enabled and lit

after pressing

the MENU

button 4 times.

Menu Button

Functions

ALL

Connect an input to all outputs.

STO

Store the current setup in a preset.

EDID

Assign EDID channels.

ESC

Exit the current operation.

OFF

Turn off an output.

RCL

Recall a preset.

DELAY

Set the delay between confirming an action and the

execution of the action on an output port.

ENTER

Confirm the input-output setup when using a one-

digit number instead of two digits. For example, to

enter input 5, you can press either 05 or 5, ENTER.

TAKE Button

Confirm action.

MENU Button

Enable the ALL, STO, EDID, ESC, OFF, RCL, DELAY and

ENTER buttons. Press again to enter the configuration menu.

EXIT MENU Button

Press to exit a menu or return to switching mode.

LOCK Button

Press and hold for approximately 2 sec to lock/unlock the front

panel buttons.

A short press returns the LCD display to the default window.

DEFAULT SETUP Button

Press to open the reset menu on the display.

SERVICE Mini USB Connector

Connect to a PC to send PK3000 commands to the matrix

switcher.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Defining MTX3-16-M 16x16 8K Modular Matrix

Feature

Function

OUTPUTS/INPUTS LCD Display

(OSD menu)

Displays the outputs (upper row) routed to the selected inputs

(lower row). Displays user interface messages and menus.

POWER LED (PS-1 / PS-2)

Lights green when the power supply is active.

ERROR LED (PS-1 / PS-2)

Lights red when an error is detected. Briefly lights red

immediately following a power disruption (e.g., cable

disconnection, power off, and so on).

Figure 2: MTX3-16-M 16x16 8K Modular Matrix Rear Panel

Feature

Function

Slots for up to 4 Matrix Cards

The left side of MTX3-16-M has 4 slots for insertion of matrix cards

and the right side (26) has another 4 slots.

Hot plugging: Cards can be inserted while the device is operating,

and input/output ports are automatically identified and numbered.

Port input/output settings can be changed and flexibly connected to

other module cards’ input/output ports.

Matrix card ports are identified by ID numbers allocated when they

are inserted (see Identifying Input / Output Ports on page 15).

PS-1 Power Module and

Switch

The PS-1 must be connected to the mains and switched on to use

the device. The PS-1 power LED (17) lights green when powered.

This module has a fuse holder.

RESET Recessed Button

Press to reboot the MTX3-16-M control card.

RS-232 3-pin Terminal Block

Connector

Connect to a remote operation PC or a remote controller.

NET 1 RJ-45 Connector

100Mpbs Ethernet port for device management and control via LAN.

NET 2-1G RJ-45 Connector

100/10000Mbps Ethernet port for matrix connection to LAN.

PS-2 (POE) Power Module

and Switch

48V PoE (Power over Ethernet) supply for inserted matrix cards.

PoE is supplied when PS-2 is on and PS-1 is off, but MTX3-16-M

itself will not operate.

When switched on and connected to power, the PS-2 power LED

lights green.

Slots for up to 4 Matrix Cards

See for the explanation. The 4 card insertion slots on the right

side of the device use port IDs 9 to 16.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Defining MTX3-34-M 34x34 8K Modular Matrix

Defining MTX3-34-M 34x34 8K

Modular Matrix

This section defines MTX3-34-M.

Figure 3: MTX3-34-M 34x34 8K Modular Matrix Front Panel

Feature

Function

Numeric

Keypad

Numbers

1 to 0

←(Move left)

Move the LCD display left (when the display is extended).

→(Move right)

Move the LCD display right (when the display is extended).

Double-Function

Selector

Buttons.

Enabled and lit

after pressing

the MENU

button 4 times.

Menu Button

Functions

ALL

Connect an input to all outputs.

STO

Store the current setup in a preset.

EDID

Assign EDID channels.

ESC

Exit the current operation.

OFF

Turn off an output.

RCL

Recall a preset.

DELAY

Set the delay between confirming an action and the

execution of the action on an output port.

ENTER

Confirm the input-output setup when using a one-

digit number instead of two digits. For example, to

enter input 5, you can press either 05 or 5, ENTER.

TAKE Button

Confirm action.

Kramer Electronics Ltd.

MTX3-16-M, MTX3-34-M –Defining MTX3-34-M 34x34 8K Modular Matrix

Feature

Function

EXIT MENU Button

Press to exit a menu or return to switching mode.

MENU Button

Enable the ALL, STO, EDID, ESC, OFF, RCL, DELAY and

ENTER buttons. Press again to enter the configuration menu.

DEFAULT SETUP Button

Press to open the reset menu on the display.

LOCK Button

Press and hold for approximately 2 sec to lock/unlock the front

panel buttons.

A short press returns the LCD display to the default window.

OUTPUTS/INPUTS LCD Display

(OSD menu)

Displays the outputs (upper row) routed to the selected inputs

(lower row). Displays user interface messages and menus.

SERVICE Mini USB Connector

Connect to a PC to send PK3000 commands to the matrix

switcher.

POWER LED (MA3-PS)

Lights green when the power supply is active.

ALERT LED (MA3-PS)

Lights red when an alert status is detected. Briefly lights red

immediately following a power disruption (e.g., cable

disconnection, power off, and so on).

Figure 4: MTX3-16-M 16x16 8K Modular Matrix Rear Panel

Feature

Function

Power Supply and Switch (PS-1 and

PS-2)

Supply power to the device and have a fuse holder. Either

PS-1 or PS-2 or both must be connected to the mains and

switched on to power the device.

The power LED (17) lights green.

You can connect PS-1 and/or PS-2 (when installing the optional MA3-PS

instead of the blank panel, under PS-2). If one of them fails to operate, the

other can automatically power the unit.

48V DC Harness Connector

Connect to the MA3-PS-4812 (optional, not included) PoE

power supply add-on to support PoE to the relevant matrix

cards.

RESET Recessed Button

Press to reboot the MTX3-34-M control card.

RS-232 3-pin Terminal Block

Connector

Connect to a remote operation PC or a remote controller.

NET 1 RJ-45 Connector

Connect to a PC or controller via the Ethernet LAN

(100Mb).

NET 2-1G RJ-45 Connector

Connect to a PC or controller via the Ethernet LAN

(100/1000Mb).

Andere Handbücher für MTX3-16-M

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer Sierra Video 4864V5xl Bedienungsanleitung

Kramer

Kramer VS-88SDI Bedienungsanleitung

Kramer

Kramer 1616DEE Bedienungsanleitung

Kramer

Kramer VP-885 Bedienungsanleitung

Kramer

Kramer VP-727 Bedienungsanleitung

Kramer

Kramer Sierra Video 3232V5 Bedienungsanleitung

Kramer

Kramer 88V5 Bedienungsanleitung

Kramer

Kramer VP-88ETH Bedienungsanleitung

Kramer

Kramer 88DS Bedienungsanleitung

Kramer

Kramer Sierra Video 1208V3S Bedienungsanleitung

Kramer

Kramer VP-2x2 Bedienungsanleitung

Kramer

Kramer VS-1616D-MD Bedienungsanleitung

Kramer

Kramer VS-6464DN-EM Bedienungsanleitung

Kramer

Kramer VS-62DT Bedienungsanleitung

Kramer

Kramer Sierra Video 3248V5Sxl Bedienungsanleitung

Kramer

Kramer VP-81SID Bedienungsanleitung

Kramer

Kramer VP-23RC Bedienungsanleitung

Kramer

Kramer VS-62H Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1608V3S Bedienungsanleitung

Kramer

Kramer 88DEE Bedienungsanleitung

Kramer

Kramer BC/VS-2216 Bedienungsanleitung

Kramer

Kramer VS-626 Bedienungsanleitung

Kramer

Kramer Sierra Video 3216V5 Bedienungsanleitung

Kramer

Kramer VS-402XL Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
