USER MANUAL







Model:

VS-42HDMI

4x2 HDMI Matrix Switcher

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

3.1

Defining EDID 3

3.2

About HDMI 4

3.3

Recommendations for Best Performance 5

3.4

Terminology Used in this User Manual 5

Your VS-42HDMI 4x2 HDMI Matrix Switcher 5

Installing the VS-42HDMI on a Rack 8

Connecting a VS-42HDMI 4x2 HDMI Matrix Switcher 9

Operating the VS-42HDMI 11

7.1

Acquiring the EDID 11

7.2

Storing and Recalling a Setting 12

7.3

Controlling via RS-232 (for example, using a PC) 13

7.4

Controlling via ETHERNET 14

7.4.1

Connecting the ETHERNET Port directly to a PC (Crossover Cable) 14

7.4.2

Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 16

7.4.3

Control Configuration via the Ethernet Port 16

Technical Specifications 16

Kramer Protocol 2000 17

Figures

Figure 1: VS-42HDMI 4x2 HDMI Matrix Switcher 6

Figure 2: Connecting a VS-42HDMI 4x2 HDMI Matrix Switcher 10

Figure 3: Connecting a PC without using a Null-modem Adapter 13

Figure 4: RJ-45 PINOUT 14

Figure 5: Local Area Connection Properties Window 15

Figure 6: Internet Protocol (TCP/IP) Properties Window 15

Tables

Table 1: Terminology Used in this User Manual 5

Table 2: VS-42HDMI 4x2 HDMI Matrix Switcher Front Panel Features 7

Table 3: VS-42HDMI 4x2 HDMI Matrix Switcher Rear Panel Features 7

Table 4: Crossover Cable RJ-45 PINOUT 14

Table 5: Straight-through Cable RJ-45 PINOUT 16

Table 6: Technical Specifications of the VS-42HDMI 16

Table 7: Protocol Definitions 17

Table 8: Instruction Codes for Protocol 2000 18

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer VS-42HDMI 4x2 HDMI Matrix

Switcher.

The VS-42HDMI is ideal for conference room presentations and advertising

applications, as well as for rental and staging.

Each package includes the following items:

VS-42HDMI 4x2 HDMI Matrix Switcher

Power cord and Null-modem adapter

Windows®-based Kramer control software

Windows®-based Ethernet Configuration Manager and Virtual Serial Port

Manager

Kramer RC-IR1/2Infra-Red Remote Control Transmitter (including the

required batteries and a separate user manual

)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Downloadable from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Getting Started

KRAMER: SIMPLE CREATIVE TECHNOLOGY

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.



Overview

3 Overview

The VS-42HDMI is a high quality 4x2 matrix switcher for HDMI signals.

In particular, the VS-42HDMI:

Supports up to 1.65Gbps bandwidth per graphic channel

Has two sets of input selector buttons

(eight in total) to switch to the outputs

Supports HDCP (High Definition Digital Content Protection)

Includes two OFF buttons

to disconnect each output

Includes a PANEL LOCK button to prevent unwanted tampering with the

buttons on the front panel

Fits in one vertical space of a standard 19” professional rack enclosure

Control the VS-42HDMI using the front panel buttons, or remotely via:

RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

The Kramer infra-red remote control transmitter

The ETHERNET

3.1 Defining EDID

The Extended Display Identification Data (EDID

) is a data-structure,

provided by a display, to describe its capabilities to an HDMI source. The

EDID enables the VS-42HDMI to “know” what kind of monitor is connected

to the output. The EDID includes the manufacturer’s name, the product type,

the timing data supported by the display, the display size, luminance data and

(for digital displays only) the pixel mapping data.

1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

2 From INPUT 1 to INPUT 4, TO OUTPUT 1 and from INPUT 1 to OUTPUT 4, TO OUTPUT 2

3 One for each output

4 Defined by a standard published by the Video Electronics Standards Association (VESA)

Overview

KRAMER: SIMPLE CREATIVE TECHNOLOGY

3.2 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the highest high-definition image and sound quality. Note that

Kramer Electronics Limited is an HDMI Adopter

and an HDCP Licensee

In particular, HDMI:

Provides a simple

interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such as a

digital flat LCD / plasma television (DTV), over a single lengthy

cable

Supports standard, enhanced, high-definition video, and multi-channel

digital audio

on a single cable

Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

Benefits consumers by providing superior, uncompressed digital video

quality via a single cable

, and user-friendly connector

Is backward-compatible with DVI (Digital Visual Interface)

Supports two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality such as

automatic configuration and one-button play

HDMI has the capacity to support existing high-definition video formats

(720p, 1080i, and 1080p/60), standard definition formats such as NTSC or

PAL, as well as 480p and 576p.

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 See http://www.hdmi.org/about/adopters_founders.asp

3 See http://www.digital-cp.com/list/

4 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

5 HDMI technology has been designed to use standard copper cable construction at up to 15m

6 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

7 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VS-42HDMI 4x2 HDMI Matrix Switcher

3.3 Recommendations for Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position

your VS-42HDMI away from moisture, excessive sunlight and dust

3.4 Terminology Used in this User Manual

Table 1 defines some terms that are used in this user manual.

Table 1: Terminology Used in this User Manual

Term Definition

802.3 The standard specification for ETHERNET that is maintained by the Institute of Electrical

and Electronics Engineers (IEEE).

Dynamic Host

Configuration

Protocol (DHCP)

Allows the network administrator to distribute IP addresses from a central point and

automatically send a new IP address when an Ethernet point is plugged into a different

network location

Gateway A network position serving as an entry to another network. On the Internet, a node or

stopping point can be either a gateway node or a host (end-point) node.

IP Address A 32-binary digit number that identifies each sender or receiver (within a network via a

particular server or workstation) of data (HTML pages or e-mails) that is sent in packets

across the Internet. Every device connected to an IP network must have a unique IP

address. This address is used to reference the specific unit.

Local Area Network

(LAN)

Computers sharing a common communications line or wireless link, which often share a

server within a defined geographic area.

Media Access

Control (MAC)

Address

A computer's unique hardware number (or address) in a LAN or other network. On an

Ethernet LAN, the (MAC) address is identical to the Ethernet address.

Transmission

Control

Protocol/Internet

Protocol (TCP/IP)

The basic communication language or protocol of the Internet that breaks the message

into appropriately sized packets for the network, and can be used as a communications

protocol in an intranet or an extranet.

4 Your VS-42HDMI 4x2 HDMI Matrix Switcher

Figure 1 illustrates the front and rear panels of the VS-42HDMI. Table 2 and

Table 3 define the front and rear panels of the VS-42HDMI, respectively.

Your VS-42HDMI 4x2 HDMI Matrix Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Figure 1: VS-42HDMI 4x2 HDMI Matrix Switcher

Your VS-42HDMI 4x2 HDMI Matrix Switcher

Table 2: VS-42HDMI 4x2 HDMI Matrix Switcher Front Panel Features

# Feature Function

1 IR Receiver The red LED lights when receiving signals from the

Infra-red remote control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 TO OUTPUT 2 Press an INPUT SELECTOR button to select an input

(from 1 to 4) to switch to output 2

INPUT SELECTOR

Buttons

TO OUTPUT 1 Press an INPUT SELECTOR button to select an input

(from 1 to 4) to switch to output 1

5 TO OUTPUT 1 Press to toggle disconnecting output 1

OFF Buttons

TO OUTPUT 2 Press to toggle disconnecting output 2

7 EDID Button

Press to acquire the EDID

8 STO Button Press to store an input setting

9 RCL Button Press to recall an input setting

10 LOCK Button Press to toggle disengaging the front panel buttons and

to acquire the EDID (see section 7.1)

Table 3: VS-42HDMI 4x2 HDMI Matrix Switcher Rear Panel Features

# Feature Function

11 IN HDMI Connectors Connect to the HDMI sources (from 1 to 4)

12 OUT 1 HDMI Connector Connect to the HDMI acceptor 1

13 OUT 2 HDMI Connector Connect to the HDMI acceptor 2

14 RS-232 DB 9F Port Connects to the PC or the RS-232 Remote Controller

15 ETHERNET Connector Connects to the PC or other Ethernet Controller

16 RESET Button Press the ETHERNET factory reset button to reset to the

factory default definitions

IP number 192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

17 Power Connector with Fuse AC connector enabling power supply to the unit

1 Illuminates when configuring the EDID

2 First disconnect the power cord and then connect it again while pressing the RESET button. The unit will power up and load

its memory with the factory default definitions

Installing the VS-42HDMI on a Rack

KRAMER: SIMPLE CREATIVE TECHNOLOGY

5 Installing the VS-42HDMI on a Rack

This section describes what to do before installing on a rack and how to rack

mount.

Before installing on a rack, be sure that the environment is

within the recommended range:

Operating temperature range +5 to +45 Deg. Centigrade

5 to 65% RHL, non-condensing

-20 to +70 Deg. Centigrade

5 to 95% RHL, non-condensing

Operating humidity range

Storage temperature range

Storage humidity range

When installing on a 19" rack, avoid hazards by taking

care that:

It is located within the recommended environmental

conditions, as the operating ambient temperature of a

closed or multi unit rack assembly may exceed the

room ambient temperature.

Attach both ear brackets to the

machine. To do so, remove the

screws from each side of the machine

(3 on each side), and replace those

screws through the ear brackets.

Place the ears of the machine

against the rack rails, and insert the

proper screws (not provided) through

each of the four holes in the rack

ears.

Note that:

Detachable rack ears can be removed

for desktop use

Always mount the machine in the rack

before you attach any cables or

connect the machine to the power

If you are using a Kramer rack adapter

kit (for a machine that is not 19"), see

the Rack Adapters user manual for

installation instructions (you can

download it at:

http://www.kramerelectronics.com)



In some models, the front panel

may feature built-in rack ears

Once rack mounted, enough air will still flow around the

machine.

The machine is placed straight in the correct horizontal

position.

You do not overload the circuit(s). When connecting

the machine to the supply circuit, overloading the

circuits might have a detrimental effect on overcurrent

protection and supply wiring. Refer to the appropriate

nameplate ratings for information. For example, for

fuse replacement, see the value printed on the product

label.

The machine is earthed (grounded) in a reliable way

and is connected only to an electricity socket with

grounding. Pay particular attention to supply

connections other than direct connections to the

branch circuit (for example, the use of power strips),

and that you use only the power cord that is supplied

with the machine.



CAUTION!!

Before Installing on a Rack

How to Rack Mount

To rack-mount a machine:

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer Sierra Pro XL 1608V3 Bedienungsanleitung

Kramer

Kramer VS-162V Bedienungsanleitung

Kramer

Kramer VS-402XL Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1204V5 Bedienungsanleitung

Kramer

Kramer 1616HDEE Bedienungsanleitung

Kramer

Kramer VS-44H Bedienungsanleitung

Kramer

Kramer VP-128H Bedienungsanleitung

Kramer

Kramer VS-44HDCP Bedienungsanleitung

Kramer

Kramer VS-42H2 Bedienungsanleitung

Kramer

Kramer VS-3232DN Bedienungsanleitung

Kramer

Kramer Sierra Video 1204V5 Bedienungsanleitung

Kramer

Kramer MV-4X Bedienungsanleitung

Kramer

Kramer VS-1616DN-EM Bedienungsanleitung

Kramer

Kramer VS-44HN Bedienungsanleitung

Kramer

Kramer VP-2x2 Bedienungsanleitung

Kramer

Kramer VS-606xl Bedienungsanleitung

Kramer

Kramer XL 1616S Bedienungsanleitung

Kramer

Kramer VS-61YC Bedienungsanleitung

Kramer

Kramer VS-88UHD Bedienungsanleitung

Kramer

Kramer VS-5x5 Bedienungsanleitung

Kramer

Kramer XL 1616VS Bedienungsanleitung

Kramer

Kramer Sierra Video 6448V5Sxl Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1208V5S Bedienungsanleitung

Kramer

Kramer VS-84H Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
