Kramer VS-42UHD Bedienungsanleitung

USER MANUAL

MODEL:

VS-42UHD

4x2 HDMI Matrix Switcher

P/N: 2900-300609 Rev 1 www.kramerAV.com

VS-42UHD – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions DC 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Using the IR Transmitter 5

3.2 Defining the VS-42UHD 4x2 HDMI Matrix Switcher 6

4Connecting the VS-42UHD 8

4.1 Connecting a Serial Controller via RS-232 9

4.2 Connecting to the VS-42UHD via Ethernet 9

4.3 Connecting the Remote Contact-Closure Switches 12

5Principles of Operation 14

5.1 Automatic Signal Detection 14

5.2 Input Switching Modes 14

5.3 EDID Operation 15

5.4 Step-in Functionality 15

6Operating the VS-42UHD 4x2 HDMI Matrix Switcher 16

6.1 Switching an Input to an Output 16

6.2 Acquiring an EDID from an Output 16

6.3 Muting and Unmuting the Outputs 17

6.4 Locking and Unlocking the Front Panel Buttons 18

6.5 Generating a Test Pattern 18

7Configuring and Maintaining the VS-42UHD 19

7.1 Setting the DIP-Switches 19

7.2 Resetting the VS-42UHD to Factory Default Settings 20

7.3 Upgrading the Firmware 20

8Operating the VS-42UHD Remotely via the Web Pages 21

8.1 Browsing the VS-42UHD Web Pages 21

8.2 Routing Page 23

8.3 EDID Page 27

8.4 Device Setting Page 29

8.5 Firmware Upgrade Page 30

8.6 About Us Page 31

9Wiring the Twisted Pair RJ-45 Connectors 32

10 Technical Specifications 33

11 Default Communication Parameters 34

12 Default EDID 35

13 Protocol 3000 39

13.1 Understanding Protocol 3000 40

13.2 Kramer Protocol 3000 Syntax 42

13.3 Protocol 3000 Commands 43

ii VS-42UHD – Contents

Figures

Figure 1: VS-42UHD 4x2 HDMI Matrix Switcher Front 6

Figure 2: VS-42UHD 4x2 HDMI Matrix Switcher Rear 7

Figure 3: Connecting the VS-42UHD 4x2 HDMI Matrix Switcher 9

Figure 4: Local Area Connection Properties Window 10

Figure 5: Internet Protocol Version 4 Properties Window 11

Figure 6: Internet Protocol Properties Window 12

Figure 7: Remote Contact-closure Switch Connections 13

Figure 8: Available Test Patterns 18

Figure 9: The Loading Page 22

Figure 10: The General Info Page 22

Figure 11: The Routing Page 23

Figure 12: The Output Buttons 24

Figure 13: The Input Buttons 24

Figure 14: The Remote Device Control Window 25

Figure 15: Test Pattern Tab 26

Figure 16: The EDID Page 27

Figure 17: The Device Setting Page 29

Figure 18: The Firmware Upgrade Page 30

Figure 19: The About Us Page 31

Figure 20: TP Pinout Wiring 32

VS-42UHD - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VS-42UHD 4x2 HDMI Matrix Switcher.

This product, which incorporates HDMI™ technology, is ideal for:

•Conference rooms

•Education

•Hospitality

2 VS-42UHD - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Go to www.kramerav.com/downloads/VS-42UHD to check for up-to-date

user manuals, application programs, and to check if

firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighbouring electrical appliances that may adversely

influence signal quality

•Position your VS-42UHD away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions DC

Caution:

There are no operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics power supply that is

provided with the unit

Warning: Disconnect the power and unplug the unit from the wall

before installing

VS-42UHD - Getting Started 3

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at www.kramerav.com/support/recycling/.

4 VS-42UHD - Overview

3 Overview

The VS-42UHD is a high quality, 4x2 matrix switcher for HDMI signals. It reclocks

and equalizes the signals and can route any input to either or both outputs

simultaneously.

In particular, the VS-42UHD features:

•Up to 8.91Gbps data rate (2.97Gbps per graphics channel)

Suitable for resolutions up to UXGA and 4K x 2K

•Support for HDCP (High Definition Digital Content Protection)

•True video clock detection

•Automatic switching modes (last connected and priority switching)

•HDMI Support – 3D, Deep Color, x.v.Color™, Lip Sync , ARC, HEAC pass-

through, Dolby® TrueHD, Dolby Digital Plus, DTS−HD®, and 7.1 multi-

channel audio

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling & processing algorithm ensures Plug and Play operation for HDMI

systems

•Programmable step-in functionality when used in conjunction with compatible

step-in devices, such as SID-X3N, DIP-30 and DIP-31 (using an HDMI cable

that supports HEC, the HDMI Ethernet Channel)

•Non-volatile EDID storage

•Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

•Static or dynamic DHCP IP addressing

•Embedded Web pages that provide remote configuration and operation

•A lock button to prevent unwanted tampering with the buttons on the front

panel

•Support for Kramer Protocol 3000

VS-42UHD - Overview 5

You can control the VS-42UHD using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a PC, touch screen system or other

serial controller

•The Kramer RC-IR3 infrared, remote control transmitter

•A PC connected via a LAN to the Ethernet port on the VS-42UHD

•An optional, external, remote IR receiver (see Section 3.1)

3.1 Using the IR Transmitter

You can use the RC-IR3 IR transmitter to control the machine via the built-in IR

receiver on the front panel or, instead, via an optional external IR receiver (for

example, P/N C-A35M/IRR-50). The external IR receiver can be located up to 15m

away from the machine. This distance can be extended to up to 60m when used

with three extension cables (for example, P/N C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (for example, P/N: 505-70434010-S) with the

3.5mm connector that fits into the REMOTE IR opening on the rear panel. Connect

the external IR receiver to the REMOTE IR 3.5mm connector.
