Kramer VP-791 Bedienungsanleitung

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VP-791

SDI to DVI/HDMI Scaler

VP-791

Operating Instructions

Version K 1.4

This manual explains how to operate your VP-791 image scaler which is designed to provide

users with a powerful and flexible method of driving large display devices from SD-SDI, HD-SDI

and 3G-SDI source.

If you have any queries relating to this or any other product supplied by Kramer visit our Web

site www.kramerelectronics.com .

For technical support e-mail [email protected] .

translated, or reduced to electronic medium or machine readable form, in whole or in part, without

prior written consent of Kramer Electronics Ltd ("Kramer"). Failure to comply with this condition may

result in prosecution.

Kramer does not warrant that this product package will function properly in every hardware and

software environment.

Although Kramer has tested the hardware, firmware, software and reviewed the documentation,

KRAMER MAKES NO WARRANTY OR REPRESENTATION, EITHER EXPRESS OR IMPLIED,

WITH RESPECT TO THIS HARDWARE, FIRMWARE, SOFTWARE OR DOCUMENTATION, THEIR

QUALITY, PERFORMANCE, MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE.

THIS SOFTWARE AND DOCUMENTATION ARE LICENSED 'AS IS', AND YOU, THE LICENSEE,

BY MAKING USE THEREOF, ARE ASSUMING THE ENTIRE RISK AS TO THEIR QUALITY AND

PERFORMANCE.

IN NO EVENT WILL KRAMER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE

SOFTWARE OR DOCUMENTATION, even if advised of the possibility of such damages. In

particular, and without prejudice to the generality of the foregoing, Kramer has no liability for any

programs or data stored or used with Kramer software, including costs of recovering such programs or

data.

All trade marks acknowledged

Kramer operates a policy of continued product improvement, therefore specifications are subject to

change without notice as products are updated or revised.

E&OE.

Contents

SAFETY WARNING: 󰾡󰾡󰾡󰾡1

INTRODUCTION󰾡󰾡󰾡󰾡󰾡󰾡󰾡󰿁󰿁󰿁󰿁󰾡󰿁󰿁󰿁󰿁󰿁󰿁󰿁󰿁󰾡󰾡󰾡󰾡󰾡󰿁󰾡2󵫓󲗗󱿘

1.1. General Introduction 2

1.2. Packing List 2

VP-791 SYSTEM DESCRIPTION 󰿁󰿁󰿁󰿁 3

2.1. Product Overview 3

2.2. Product Specification 3

2.2.1. Power Supply Requirement 3

2.2.2. 3GSDI Input 3

2.2.3. Display Output 3

VP-791 CONTROL 󰾡󰾡󰾡󰾡 4

3.1. Menu Tree 4

3.2. Introduction 7

3.3. Main Menu 9

3.4. Input 9

3.5. Output 9

3.5.1. Output Mode 9

3.5.2. Location 9

3.5.3. Optimize for Display 10

3.5.4. DVI Range 10

3.5.5. Frame Rate 10

3.5.6. (Available) Frame Rates 11

3.5.5. I/O Lock 11

3.5.6. Native Color Temp 11

3.5.7. Output Gamma 11

3.6. Color 12

3.6.1. Black-Level Offset 12

3.6.2. Black-Level 12

3.6.3. Contrast 12

3.6.4. Saturation 12

3.6.5. Hue 12

3.6.6. RGB values 12

3.6.7. Color Temp 12

3.6.9. Input Gamma 12

3.7. Geometry 13

3.7.1. Horizontal and Vertical Position 13

3.7.2. Aspect Ratio 13

3.7.3. Warp 13

3.7.4. Picture Format 13

3.7.5. Overscan 14

3.7.6. Pan Tilt Zoom 14

3.8. Enhancement 15

3.8.1. Sharpness 15

3.8.2. Detail 15

3.8.3. Video Filters 15

3.9. System 16

3.9.1. User 16

3.9.2. Names and Profiles 16

3.9.3. Test Pattern 16

3.9.4. Display Mode 16

3.9.5. Switching Transition 16

3.9.5. Menu Settings 16

3.9.6. Network Settings 17

3.9.7. Factory Defaults 17

REMOTE CONTROL WEB SERVER 󰾡󰾡󰾡󰾡 18

4.1. Introduction 18

4.2. Installing the Software 18

4.3. Discovery Tool 18

4.4. Software Operation 18

FIRMWARE UPDATE 󰾡󰿁󰾡󰾡19

5.1. Introduction 19

5.2. Updating Firmware 19

ENVIRONMENTAL AND EMC 󰾡󰿁󰾡󰾡20

6.1. Recommended Operating Conditions 20

6.2. Storage 20

6.3. CE and FCC Compliance 20

SAFETY WARNING:

1. THERE ARE NO USER SERVICEABLE PARTS WITHIN THE UNIT. REMOVAL OF THE TOP COVER

WILL EXPOSE DANGEROUS VOLTAGES. DO NOT OPERATE THE UNIT WITHOUT THE TOP COVER

INSTALLED.

2. ENSURE THAT ALL ELECTRICAL CONNECTIONS (INCLUDING THE MAINS PLUG AND ANY

EXTENSION LEADS) ARE PROPERLY MADE AND COMPLY WITH ELECTRICAL SAFETY

REGULATIONS.

3. ENSURE THAT THE INTEGRITY OF THE EQUIPMENT ISOLATION BARRIER IS MAINTAINED WHEN

CONNECTING TO OTHER EQUIPMENT. THIS MEANS THAT ONLY LOW VOLTAGE ISOLATED

CIRCUITS MAY BE CONNECTED TO THE SIGNAL INPUTS AND OUTPUTS. IF ANY DOUBT EXISTS

CONSULT QUALIFIED SERVICE PERSONNEL.

4. TO PREVENT SHOCK OR FIRE HAZARD DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR

MOISTURE. IF SUCH EXPOSURE OCCURS, REMOVE THE PLUG FROM THE MAINS OUTLET AND

HAVE THE EXPOSED UNIT CHECKED BY QUALIFIED SERVICE PERSONNEL.

5. DO NOT CONTINUE TO OPERATE THE EQUIPMENT IF YOU HAVE ANY DOUBT ABOUT IT

WORKING NORMALLY, OR IF IT IS DAMAGED IN ANY WAY. WITHDRAW THE MAINS PLUG FROM

THE MAINS OUTLET AND CONSULT QUALIFIED SERVICE PERSONNEL.

6. DO NOT REMOVE ANY FIXED COVERS UNLESS YOU ARE QUALIFIED TO DO SO AND EVEN THEN

WITHDRAW THE MAINS PLUG FROM THE MAINS OUTLET BEFORE YOU START.

7. THIS EQUIPMENT CONTAINS NO USER SERVICEABLE PARTS. REFER ALL SERVICING AND

MAINTENANCE TO QUALIFIED SERVICE PERSONNEL.

8. TO AVOID EXPLOSION, DO NOT OPERATE THIS EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE

INTRODUCTION

1.1.

General Introduction

VP-791 is a very flexible image scaler developed specifically for driving large screen displays from SD-

SDI, HD-SDI and 3G-SDI serial digital source.

VP-791 features a state of the art digital image processor which provides market leading HD& SD per-

pixel multiple Iow-angle motion-adaptive de-interlacing and automatic film pull-down correction for 3:2

and 2:2, significantly outperforming the capabilities of benchmark competitor products.

VP-791 features excellent image processing algorithms for the very best scaling, film and video noise

reduction and MPEG artefact reduction.

VP-791 uses a high performance SDI de-serializer with cable equalization.

The output format can be set to I/O Lock mode where it locks the output frame rate to the input frame

rate dynamically without frame rate conversion so as to reduce system latency, or it can be set to a fixed

output frame rate for driving basic screens which are not 50Hz-compatible. Furthermore, the VP-791

can be set to have the output resolution match the input resolution to preserve aspect ratio. A Low

latency mode with non-motion adaptive reduced processing is available to further reduce latency.

Outputs are available in DVI digital formats.

VP-791 supports Pan, Zoom and Tilt to select a part of the input image, fill the screen and pan within it.

VP-791 features embedded warp functions to adjust the image in a projection scenario to match a

rotated, tilted or curved screen. For 9:16 portrait mode signage special predefined warp maps are

available to rotate and stretch a video image to fill a +/-90° rotated display panel.

System control is via an OSD controlled by keys on the front panel or through an intuitive ‘Windows’

application connected via a normal RS232 serial port or via TCP/IP (ethernet).

1.2.

Packing List

VP-791 is supplied with the following:

1) This manual

2) 3 pin plug IEC mains cable

3) DVI-D output cable

4) CD

VP-791 SYSTEM DESCRIPTION

2.1.

Product Overview

VP-791 is designed to accept the input signals:

3GSDI and HDSDI and SDI (Serial Digital Interface) via BNC

2.2.

Product Specification

This section provides technical details of the VP-791 input and output connections.

2.2.1.

Power Supply Requirement

12V DC table top power supply requiring a 100V-264VAC 50 and 60Hz mains connection.

2.2.2.

3GSDI Input

Format: SD-SDI

HD-SDI YCbCr 4:2:2 serial digital component video

3G-SDI 4:2:2 serial digital component video

Input impedance: 75 ohms.

SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant, accepts 484i, 576i, 720, 1080i and 1080p

single link formats at 270Mb, 1.485Gb or 2.97Gb rates.

2.2.3.

Display Output

A DVI-D output connector is provided. The DVI-D connector will support HDMI 1.3 with 36-bit video

when connected to a suitable HDMI 1.3 receiver.

VP-791 CONTROL

3.1.

Menu Tree

VP-791 Menu Tree

1st Level

2nd Level

3rd Level

4th Level
