H.264 Digital Video/Audio Recorders

User’s Manual

Models: 16-CH

9-CH

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.

NO USER SERVICEABLE PARTS INSIDE.

PLEASE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

NOTE: This equipment has been tested and found to comply with the limits for a

Class “A” digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the users will be required to correct the

interference at their own expense.

FCC Caution: To assure continued compliance, use only shielded interface cables

when connecting to computer or peripheral devices. Any changes or

modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

This Class A digital apparatus meets all the requirements of the Canadian

Interference Causing Equipment Regulations.

WARNING

TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

LIMITATIONOFLIABILITY

 THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTIBILITY, FITNESS FOR ANY PARTICULAR PURPOSE,

OR NON-INFRINGEMENT OF THE THIRD PARTY’S RIGHT.

 THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR

TYPOGRAPHICAL ERRORS. CHANGES ARE ADDED TO THE INFORMATION

HEREIN, AT ANY TIME, FOR THE IMPROVEMENTS OF THIS PUBLICATION

AND/OR THE CORRESPONDING PRODUCT(S).

DISCLAIMEROFWARRANTY

IN NO EVENT SHALL THE SUPPLIER BE LIABLE TO ANY PARTY OR ANY PERSON,

EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT,

FOR THE CASES, INCLUDING BUT NOT LIMITED TO THE FOLLOWINGS:

 ANY DAMAGE OR LOSS, INCLUDING BUT WITHOUT LIMITATION, DIRECT OR

INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR

RELATING TO THE PRODUCT;

 PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE USE OR

NEGLIGENT OPERATION OF THE USER;

 UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT

BY THE USER;

 ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE,

ARISING OUT OF THE SYSTEM COMBINED WITH THE DEVICES OF THE THIRD

PARTY;

 ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT BYANY PERSON OR

ORGANIZATION BEING A PHOTOGENIC SUBJECT, DUE TO VIOLATION OF

PRIVACY WITH THE RESULT OF THAT SURVEILLANCE-CAMERA’S PICTURE,

INCLUDING SAVED DATA, FOR SOME REASON, BECOMES PUBLIC OR IS USED

FOR THE PURPOSE OTHER THAN SURVEILLANCE.

PRECAUTIONS



Please refer all work related to the installation of this product to qualified service

personnel or system installers.

 Do not operate the appliance beyond its specified temperature, humidity or power

source ratings.

Use the appliance at temperatures between 0oC ~ +45oC(32oF ~ 113oF) and humidity below

85%.

The input power source for this appliance is between 90 ~ 264 VAC, 47 ~ 63 Hz.

Performance and lifetime of hard disk drives are easily affected by heat (used at high

temperature). It is recommended to use this appliance at temperature between +20oC ~

+30oC(68oF ~ 86oF)

 Handle the hard disk drives with care.

It is possible to damage them if they are moved while their motors are still running. Do not

move them just after turning the power on or off (for around 30 seconds).

Protect the hard disk drives from static electricity.

Do not stack them or keep them upright.

Do not use an electric screwdriver to fix them.

 Clean only with dry cloth.

 Do not block any ventilation openings.

 Do not use the appliance near any heat sources such as radiators, heat registers, stoves or

other apparatus that produce heat.

 Protect the power cord from being stepped on or pinched particularly at plugs, convenient

receptacles and the points where they exit from the apparatus.

 Do not drop metallic parts through slots. This could permanently damage the appliance.

Turn the power off immediately and contact qualified service personnel for service.

 Handle the appliance with care. Do not strike or shake, as this may damage the appliance.

 Do not expose the appliance to water or moisture, nor try to operate it in wet areas. Do take

immediate action if the appliance becomes wet. Turn the power off and refer servicing to

qualified service personnel. Moisture may damage the appliance and also cause electric

shock.

 Do not use strong or abrasive detergents when cleaning the appliance body. When the dirt is

hard to remove, use a mild detergent and wipe gently.

 Do not overload outlets and extension cords as this may result in a risk of fire or electric

shock.

 Please make a note of your settings and save them. This will help when you are required to

change the system configuration, or when unexpected failure or trouble occurs.

 Distributing, copying, disassembling, reverse compiling, reverse engineering, and also

exporting in violation of export laws of the software provided with this product, is expressly

prohibited.

TableofContents

1. Product Overview················································································

1.1 Features··························································································

2. PanelsAnd Remote Controller·····························································

2.1 Front Panel······················································································

2.2 Back Panel······················································································

2.3 Remote Controller············································································

3. Installations·························································································

3.1 Basic Connections············································································

3.2 Optional Connections·······································································

4. Main ScreenAnd Basic Operations·······················································

4.1 Text Input························································································

4.2 Login And Logout············································································

4.3 Basic Operations··············································································

4.4 Digital Zoom···················································································

5. Menu Display·······················································································

5.1 Status Display··················································································

5.2 Volume Control···············································································

5.3 Video Adjustment············································································

5.4 VGA Display··················································································

5.5 Backup Device················································································

5.6 Software Upgrade (Administrator) ····················································

5.7 System Shutdown (Administrator) ····················································

6. Setup (Administrator) ·········································································

6.1 Pre-Camera Setup············································································

6.2 Camera Setup··················································································

6.2.1 Video Loss Setup······································································

6.2.2 Motion Setup···········································································

6.3 Alarm Setup····················································································

6.4 SEQ Display Setup··········································································

6.5 Scheduled Record Setup···································································

6.6 HDD Setup······················································································

6.6.1 HDD Format/Clear···································································

6.6.2Advanced HDD Setup································································

6.6.3 Removable Hard Drive······························································

6.7 Password Setup················································································

6.8 System Setup···················································································

6.9 RS-232/422/485 Setup······································································

6.10 Network Setup···············································································

6.10.1 E-mail Setup··········································································

6.10.2 Advanced Network Setup························································

7. PTZ Control·························································································

8. Search/Playback/Archive (Administrator/Supervisor) ·························

8.1 Search By Time···············································································

8.2 Search By Event / Log Display··························································

8.3 Search Archived Files·······································································

8.4 Playback/Archive For Search By Time···············································

8.5 Playback/Archive For Search By Event··············································

8.6 Playback For Archived Files·····························································

8.7 Playback Procedures ·····························································

9. PC Remote Access················································································

10. 2G ~ 3.5G PDA/Mobile Phone RemoteAccess ····································

Appendix A – MS-Windows HEM player····················································

Appendix B – The mouse operation interface reference·································

Appendix C – Specifications·······································································

Appendix D – Times Zone Table·································································

Appendix E – Recording Table···································································

Appendix F – Compatible HDD List Table··················································

1.ProductOverview

The H.264 digital video/audio recorders are designed for use within a surveillance system and

are a combination of a hard disk recorder, a video multiplexer, and a web server. To achieve

the highest inter-connectivity and inter-operability, this series of digital video/audio recorders

are all based on industry-leading front-end to back-end surveillance infrastructure. With

state-of-the-art system architecture, powerful hardware compression/decompression engine,

and intelligent recording algorithms, sixfold operation can be easily achieved without

sacrificing the increasing demands of functionality, performance, reliability, and availability

in the surveillance industry.

1.1Features

 16/9 color and/or B/W cameras can be connected

 H.264 Baseline Profile video compression/decompression with configurable quality

 Hardware ADPCM audio compression/decompression -2 stereo audio input，2 audio

output

 Real sixfold operation - simultaneous record, live, playback, backup, control, & remote

access

 Record capabilities –

Full-D1: up to 60 (NTSC) / 50 (PAL) IPS for 16/9-CH models,

Half-D1: up to 120 (NTSC) / 100 (PAL) IPS for 16/9-CH models,

CIF: up to 240 (NTSC) / 200 (PAL) IPS for 16/9-CH models,

 Live display, 30 (NTSC) / 25 (PAL) IPS, for each channel

 Event recording, time-lapse recording or both

 Playback search by time or event (alarm, motion, & video loss)

 Versatile display formats: full-screen, 4, 7, 9, 10, 13, and 16 split windows

 Digital zoom, X2 & X4

 Intelligent motion detection with programmable area and sensitivity

 Powerful alarm processor with configurable triggering conditions and reactions

 Up to four hard disk drives

 Video/audio backup to USB2.0 storage devices, including pen drive, DVD+RW, DVD+R,

and DVD-R

 Internal DVD Models: Video/audio backup to internal DVD, including DVD+RW,

DVD+R, and DVD-R

 Ethernet interface for remote access through web browser or proprietary remote software,

remote alarm notification, remote setup, and remote software upgrade

 1 I.E. software for up to 4 DVRs

 PTZ control capabilities & RS-422/RS-485 keyboard control capabilities

 Multi-lingual support

 Multi-level password and authentication key protection to ensure high degree of security

2.PanelsandRemoteController

2.1FrontPanel

1. Front Door

Conceal Hard Disk Tray (and internal DVD for DVD models). For internal DVD, please

open the front door in order not to block the tray from ejecting, esp. while it’s in

backup process. Blocking the tray from ejecting may damage the DVD writer.

2. USB connector (USB)

Connect to USB 2.0 compatible storage device, such as USB 2.0 disk drive, DVD+RW,

card reader, etc.

3. DVR ID Switch

Used to set the DVR ID (1-4) of this unit for one I/R remote controller to control up to 4

sets of digital video/audio recorders.

4. Alpha-numeric Buttons (1-9, 0, *, #)

Press these buttons for camera selection in most circumstances. These buttons can also

be used to enter text and number in the way similar to most of the mobile phones.

5. X2/GOTO Button

In PTZ control, press this button to move the camera to the preset position. In full

screen display, press this button for Digital Zoom (X2/X4).

6. MUTE/NEXT Button

In PTZ control, press this button for the next miscellaneous control. In the other screens,

press this button to mute the audio.

7. Alarm Reset Button

Press this button to cancel alarm activation, and return the system to the condition before

the alarm was activated.

8. SEARCH Button

Press this button to display the search menu in main screen display. In some dialogs,

this button is used as a miscellaneous function key.

9. CALL Button

Press this button to switch to or return from full screen display of the focus camera in

main screen display. In some dialogs, this button is used as a miscellaneous function

key.

10.SEQ Button

Press this button to switch to or return from SEQ display mode in main screen display.

In some dialogs, this button is used as a miscellaneous function key.

11.MODE Button

Press this button to toggle between live mode and playback mode in main screen display.

In some dialogs, this button is used as a miscellaneous function key.

12.LEDs

Indicators for POWER, Normal Recording, Alarm Recording, Net Link, and Net Active.

13.Copy Button ( )

Press this button to copy the playback images to the storage device connected to the USB

port. Press this button again to stop copying.

14.REC Button

Press this button to force manual recording. To stop manual recording, press it again.

15.ESC/PTZ Button

In main screen display, press this button to enter/exit PTZ control if the focus camera is a

PTZ camera. In the other displays, press this button to escape to the upper level display.

16.MENU Button

Press this button to display the main menu.

17.ENTER Button

This button is used as “enter” key in most circumstances. In PTZ control, this button is

used to start/stop the selected PTZ control mode.

18.Left/Right Buttons (◄,►)

In PTZ control, press these buttons to pan the camera. In the other screens, press this

button to move the cursor or focus window.

19.Up/BS Button (▲/BS)

Press this button to move the cursor or focus window in most circumstances. In PTZ

control, press this button to tilt up the camera. In text editing mode, this button is used

as “backspace” key.

20.Down/DEL Button (▼/DEL)

Press this button to move the cursor or focus window in most circumstances. In PTZ

control, press this button to tilt down the camera. In text editing mode, this button is

used as “del” key.

21.Fast Backward Button ( )

Press this button for fast backward playback.

22.Play/Pause Button ( )

Press this button to play the recorded images, or pause the playback.

23.Stop Button ( )

Press this button to stop the playback.

24.Single Step Button ( )

Press this button to play the recorded images frame by frame.

25.Fast Forward Button ( )

Press this button for fast forward playback.

26.(Vol/Zoom) +/- Buttons ( / / )

Press these buttons to change the volume in most circumstances. In PTZ control, press

these buttons to zoom in/out the camera.

27.(Split Windows) +/- Buttons ( )

In split-window display, press these buttons for next/previous split-window display. In

the others, press these buttons to change the contents.

28.Power Buttons

29.IR Window

This receives the IR signal from the remote control. Please make sure nothing is

blocking this window to ensure proper operation of your remote control.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere l-com DVR Handbücher

l-com

l-com network dvr Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung

l-com 16-CH Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken
