INSTRUCTION MANUAL

FOR

THE

Z100-A

CLINICAL

CENTRIFUGE

C0100-A

January 2005

INDEX PAGE

1. GeneralInformation........................................................................................ 2

1.1 Description ............................................................................................ 2

1.2 Safety precautions to be observed before operating the centrifuge ...... 2

1.3 Technical data........................................................................................ 2

1.4 Accessories........................................................................................... 3

1.5 Warranty ................................................................................................ 3

2. Installation....................................................................................................... 3

2.1 Unpackingthecentrifuge....................................................................... 3

2.2 Required space...................................................................................... 3

2.3 CushionInstallation ............................................................................... 3

2.4 CentrifugeInstallation............................................................................ 4

3. Operation ........................................................................................................ 4

3.1 Closingthelid........................................................................................ 4

3.2 Lidrelease ............................................................................................. 4

3.3 Lid lock ................................................................................................ 4

3.4 Startingthecentrifuge............................................................................ 4

4. Proper use of the Rotor

4.1 Overloading the rotor ............................................................................ 5

4.2 Balancingtherotor ................................................................................ 5

5. ServiceandMaintenance ................................................................................ 6

5.1 Service of centrifuge ............................................................................. 6

5.2 Cleaningthecentrifuge .......................................................................... 6

5.3 Disinfection ........................................................................................... 6

5.4 Cleaning the centrifuge after breakage of glass tubes or bottles ........... 6

5.5 Replacing fuses ..................................................................................... 6

6. Troubleshootingguide .................................................................................... 7

7. Chart for determining RCF (g-value).............................................................. 8

1. General Information- This manual is intended for use with the Z100-A

(C0100-A)Centrifuge.

1.1 Description

The Z100-A is a small bench top centrifuge designed for

sedimentation of various samples. The Z100-A has a

builtinanglerotor capable of running up to to 4,000 rpm (1,900 x g.)

This product is for research only.

1.2 Safety precautions to be observed before operating the centrifuge

Do not operate if:

- The centrifuge has not been installed correctly.

- The centrifuge is partly dismantled.

- Service has been attempted by non-authorized or non-qualified

personnel.

- Rotors and accessories are not part of the standard range of accessories

or have been obtained without the prior permission of the

manufacturer.

Exception: tubes and bottles made of glass or plastic normally available

in the laboratory, and designed for centrifugation.

- The centrifuge is to be used in explosive atmospheres.

-You intend to centrifuge combustible and explosive materials.

-Youintendtocentrifugematerialswhicharechemicallyreactive.

If the equipment is used in a manner not specified by the manufacturer, the

protection provided by the equipment may be impaired.

1.3 Technical Data

Model No. C0100-A

Dimensions:

Width 295mm (11.6inch)

Depth 348mm (13.7inch)

Height 101mm (10.1inch)

Weight 5.5kg / 12 lbs

Max. speed 4,000rpm

Max.volume 90ml(6x15ml)

Max.RCF 1,900xg

MaximumAdmiss.density 1.2kg/dm3

Rotor radius 10.62cm

Timer 0 to 30 minutes or continuos

Electricalratings 120V/50-60Hz,1Amp

Themanufacturerreservestherighttomaketechnicalmodifications

1.4 Accessories

Accessories supplied with each centrifuge unit:

- One 6 x 15ml rotor - One Instruction manual

- One Warranty card - Six Rubber Cushions

Aditional accessories available:

C0200-17A - Combination adapters for 5ml and 7ml tubes, (6pk.)

C0230-17A - Combination adapters for 5ml and 7ml tubes, (4pk.)

1.5 Warranty

This centrifuge has been subject to thorough testing and quality control.

In the unlikely event of any manufacturing faults occuring, our one

year warranty (from date of delivery) covers the centrifuge and the

rotors. This warranty becomes void in case of incorrect operation, use

of non-appropriate spare parts or accessories and non-authorized

modificationof the rotor or the centrifuge.

2. Installation

2.1 Unpackingthecentrifuge

The centrifuge is delivered in a carton with two or more formed foam

blocks. Please retain the carton and the blocks until it has been

established that your unit is working properly.

The accessories supplied with the centrifuge should be kept with the

instructionmanualnearthecentrifuge's place of installation.

2.2 Required space

The centrifuge should be installed on a rigid, even surface. The Z100-A

should only be operated on a stable laboratory table/bench etc.

To guarantee sufficient ventilation, please ensure that the centrifuge has

at least 15 cm free space on all sides, including the rear.

It is recommended that the centrifuge is not situated in a location

subject to excessive heat, e.g. strong sunlight, radiators etc. as heat-build-

up can occur within the centrifuge bowl.

2.3 CushionInstallation

Before inserting any tubes into the centrifuge the rubber cushions must

first be properly installed. To install the cushions turn a 10 or 15ml round

bottom tube upside down and place the cushion on top. Then remove the

rotor sheild and place it on top of the tube while pushing the cushion into

the end of the sheild. Then reinsert the shield. 3

3. Operation

ATTENTION:

Never operate the centrifuge if the rotor shows any signs of

corrosion or mechanical damage.

Never operate with strongly corrosive materials.

3.1 Closingthelid

After the rotor has been properly loaded, close the centrifuge

lid.

3.2 Lid release

The "lid" button must be pushed to open the lid after a centrifuge run

has been completed.

3.3 Lid lock

The centrifuge can only be started with the lid closed. Do not attempt to

open the lid until the rotor comes to a complete stop.

3.4 Startingthecentrifuge

To start the centrifuge select the desired run time by turning the time knob

in a clockwise direction. If performing a continuous run turn the time

knob counter clockwise into the "hold" position.

Once a run time is selected a given speed must be selected in order to

startthe centrifuge.

The speed (rpm) can be selected between 1,000 and 4,000 rpm by turning

the knob to the 1, 2, 3 and 4 speed marks. To select a speed, turn the

speed knob to the 2 posistion to activate, then proceed by turning the

knob to the desired speed.

At the end of the preselected time, the centrifuge stops automatically.

To stop the centrifuge prior to the selected time, turn the timer knob to

the "OFF" position.

2.4 CentrifugeInstallation

1. Make certain that the timer is set for the "off" position. Before

operating the centrifuge, check that the power source corresponds to

that on the manufacturer's rating label, then connect the power cord

to a properly grounded outlet

ATTENTION:

Ensure that the timer is in the "OFF" position, before connecting

the power cord.

NOTE: The clinical centrifuge is calibrated at 120 volts line voltage. Operating

the centrifuge at a line voltage other than 120V can significantlly impact the speed

settings below 2,000 RPM.

4. Proper loading of the rotor

4.1 The rotor has been designed to handle samples with a maximum density

of 1.2g/ml. Tubes should not be run with any substance having a density

above1.2g/ml.

A partially loaded rotor may be centrifuged. For example, you may

operate a 6-place rotor with 2, 3 or 4 loaded tubes, but it is important

that the occupied tube shields are symetrically arranged. (see sketchA).

4.2 When loading the rotor you should proceed according to sketch A. Fill

the tubes equally by eye and insert them into the tube shields of the rotor.

The difference in weight between the tubes should not exceed 2 - 3

grams.

empty tube

shields

loaded tube

shields

Sketch A: Examples of properly loaded rotors.

5. Service and Maintenance

5.1 Service of centrifuge

Ther is no routine maintenance or service required on the centrifuge other

thanoccasionalcleaning.

5.2 Generalcleaningofthecentrifuge

Always keep the centrifuge housing, rotor, and rotor accessories clean

by wiping down with a damp cloth. Do not use harsh cleaners or

detergants on the lid or housing surfaces as it may affect the plastic.

After cleaning, ensure that all parts are dried thoroughly by hand or in a

warm-air-cabinet (max. temp. +50°C).

5.3 Disinfection

The centrifuge should be disinfected periodically and before shipping the

unit for service. The centrifuge rotor area and rotor shields should be

wiped with alcohol or other disinfecting agents. Do not allow the alcohol

or disinfectant to sit on the units lid or housing, as it may affect or

discolor the plastic.

5.4 Cleaning the centrifuge after breakage of glass tubes or bottles

With high g-values, there is a possibility that tube breakage can occur.

Should this happen the centrifuge rotor must be thoroughly cleaned

and all broken particles removed. If this is not done, damage could

result to the centrifuge.Be sure to remove the rotor shields and clean

thoroughly. If glass or other material has gotten into the centrifuge

enclosure, the enclosure must be removed for cleaning.

5.5 Replacing fuses

Check the fuse when it is recommended in the "Troubleshooting Guide".

The fuse holder is located underneath the unit. Unplug the unit. Unscrew

the fuse holder and remove the fuse.

Replace a blown fuse with a fuse of equivalant rating and type.

6. Troubleshooting guide

Centrifuge will not start

Possible reason: No power supply.

Solution: Check main power supply and centrifuge fuse.

Possible reason: Blown fuse.

Solution: Check fuse and replace if necessary (see 5.5)

Lid cannot be released:

Possible reason: Lid lock is jammed.

Solution: Push front of lid down while pushing release button.

Centrifuge cannot be started, although power is on:

Possible reason: Lid not closed correctly.

Solution: Close lid correctly, push down on front of lid.

Possible reason: No speed or time has been selected.

Solution: Check and set the time or speed.

Possible reason: Blown fuse.

Solution: Check fuse and replace if necessary (see 5.5).

Should you have any questions about the centrifuge and its accessories, or require

service, please contact the Labnet International Service Department at 1-888 522-

6381. Please have the unit’s serial number (located on the back panel of the instru-

ment) available when calling. Do not send in a unit for service without first calling to

obtain a repair authorization number and a decontamination form. Should the cen-

trifuge need service be sure to decontaminate it and enclose the decontamination

from. The unit should be properly packed to avoid damage. Any damage resulting

from improper packing shall be the responcibility of the user.

7. Chart for determining g-values

See section1.3 forthecorrectradiusofyourrotor. Notetheuseoftubeadapterswillchange

thisradius.. Todeterminetherelativecentrifugalforce(RCF-value).

Thisvalueisthemultipliertothegravitationalpulloftheearth(g)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Labnet Laborausrüstung Handbücher

Labnet

Labnet MPS 1000 Bedienungsanleitung

Labnet

Labnet Spectrafuge 16M Bedienungsanleitung

Labnet

Labnet BioPette PLUS BPP2 Bedienungsanleitung

Labnet

Labnet ENDURO VE10 Bedienungsanleitung

Labnet

Labnet ProBlot Rocker 25 Bedienungsanleitung

Labnet

Labnet Enduro GDS II Bedienungsanleitung

Labnet

Labnet Labpette FX Bedienungsanleitung

Labnet

Labnet Prism Mini Bedienungsanleitung

Labnet

Labnet Labpette R Bedienungsanleitung

Labnet

Labnet BioPette Multichannel Bedienungsanleitung

Labnet

Labnet Prism R Bedienungsanleitung

Labnet

Labnet Excel P3600L-10 Bedienungsanleitung

Labnet

Labnet BioPette PLUS Bedienungsanleitung

Labnet

Labnet Orbit S2030-LS-B-230 Bedienungsanleitung

Labnet

Labnet Spectrafuge 6C Bedienungsanleitung

Labnet

Labnet Spectrafuge 6C Bedienungsanleitung

Labnet

Labnet AccuPlate D0410 Bedienungsanleitung

Labnet

Labnet D1200 Bedienungsanleitung

Labnet

Labnet Orbit S2030-LS-B Bedienungsanleitung

Labnet

Labnet AccuPlate D0300 Bedienungsanleitung

Labnet

Labnet AccuSeal PS1000 Bedienungsanleitung

Labnet

Labnet 35 Bedienungsanleitung

Labnet

Labnet Accublock D1301 Bedienungsanleitung

Labnet

Labnet MPS 1001 Mini Plate Spinner Bedienungsanleitung

Beliebte Laborausrüstung Handbücher anderer Marken

Qiagen

Qiagen DML 3000 Bedienungsanleitung

Queensgate

Queensgate NANOSCAN OP400 Programmierhandbuch

Conviron

Conviron GEN1000-GE Bedienungsanleitung

Parr Instrument

Parr Instrument 4560 Bedienungsanleitung

IKA

IKA IC control Bedienungsanleitung

Integra

Integra DOSE IT Bedienungsanleitung

Agilent Technologies

Agilent Technologies 5800 ICP-OES Bedienungsanleitung

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Bedienungsanleitung

NI PXI-5422 Handbuch

Collomix

Collomix Aqix Bedienungsanleitung

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Bedienungsanleitung

Ocean Insight

Ocean Insight FLAME-NIR+ Bedienungsanleitung

Parker

Parker ALIGN-MG-NA Bedienungsanleitung

BD 644787 Bedienungsanleitung

DENTAURUM

DENTAURUM Compact Megaplus Bedienungsanleitung

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Bedienungsanleitung

VWR

VWR SAS Super IAQ Bedienungsanleitung

illumina

illumina MiSeqDx Bedienungsanleitung
