NCA-1515

User Manual

Version: 0.5

Date of Release: 2019-01-30

Network Appliance Platform

NCA-1515 User Manual

The icons are used in the manual to serve as an indication of interest topics or important messages. Below

is a description of these icons:

Note: This check mark indicates that there is a note of interest and is something that you should

pay special attention to while using the product.

Warning: This mark indicates that there is a caution or warning and it is something that could

damage your property or product.

The listed websites are links to the online product information and technical support.

Resources

URL

Lanner

http://www.lannerinc.com

Product Resource

http://www.lannerinc.com/download-center

RMA

http://eRMA.lannerinc.com

to make improvements to the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means

without the prior written permission of the original manufacturer. Information provided in this manual is

intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its

use, nor for any infringements upon the rights of third parties that may result from such use.

Intel® and Intel® Atom® are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other

countries.

Intel® is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Chapter 1: Product Overview

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

Operations in the 5.15-5.25GHz band are restricted to indoor usage only.

This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with minimum distance 20cm between the radiator & your

body.

Note: The country code selection is for non-US model only and is not available to all US model.

Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only.

NCA-1515 User Manual

Follow these guidelines to ensure general safety:

Keep the chassis area clear and dust-free during and after installation.

Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and

roll up your sleeves.

Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.

Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.

Disconnect all power by turning off the power and unplugging the power cord before installing or

removing a chassis or working near power supplies

Do not work alone if potentially hazardous conditions exist.

Never assume that power is disconnected from a circuit; always check the circuit.

Risk of Explosion if Battery is replaced by an incorrect type. Dispose of used batteries according to the

instructions.

Installation only by a trained electrician or only by an electrically trained person who knows all English

Installation and Device Specifications which are to be applied.

Do not carry the handle of power supplies when moving to another place.

Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment

to acceptable operating temperatures without adequate circulation. Be sure that the room in which you

choose to operate your system has adequate air circulation.

Ensure that the chassis cover is secure. The chassis design allows cooling air to circulate effectively. An

open chassis permits air leaks, which may interrupt and redirect the flow of cooling air from internal

components.

Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage occurs

when electronic components are improperly handled and can result in complete or intermittent failures.

Be sure to follow ESD-prevention procedures when removing and replacing components to avoid these

problems.

Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. If no wrist strap is

available, ground yourself by touching the metal part of the chassis.

Periodically check the resistance value of the antistatic strap, which should be between 1 and 10

megohms (Mohms).

Environment:

Do not install and/or operate this unit in any place that flammable objects are stored or used in.

Chapter 1: Product Overview

If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack

environment may be greater than room ambient. Therefore, consideration should be given to installing

the equipment in an environment compatible with the maximum ambient temperature (Tma) specified

by the manufacturer.

Installation of the equipment (especially in a rack) should consider the ventilation of the system’s intake

(for taking chilled air) and exhaust (for emitting hot air) openings so that the amount of air flow required

for safe operation of the equipment is not compromised.

To avoid a hazardous load condition, be sure the mechanical loading is even when mounting.

Consideration should be given to the connection of the equipment to the supply circuit and the effect

that overloading of the circuits might have on over-current protection and supply wiring. Appropriate

consideration of equipment nameplate ratings should be used when addressing this concern.

Reliable earthing should be maintained. Particular attention should be given to supply connections

other than direct connections to the branch circuit (e.g. use of power strips).

Installation & Operation:

The installation of this product must be performed by trained specialists; otherwise, a non-specialist

might create the risk of the system’s falling to the ground or other damages.

Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for

supporting the system or use of inappropriate installation components.

Suivez ces consignes pour assurer la sécurité générale :

Laissez la zone du châssis propre et sans poussière pendant et après l’installation.

Ne portez pas de vêtements amples ou de bijoux qui pourraient être pris dans le châssis. Attachez votre

cravate ou écharpe et remontez vos manches.

Portez des lunettes de sécurité pour protéger vos yeux.

N’effectuez aucune action qui pourrait créer un danger pour d’autres ou rendre l’équipement

dangereux.

Coupez complètement l’alimentation en éteignant l’alimentation et en débranchant le cordon

d’alimentation avant d’installer ou de retirer un châssis ou de travailler à proximité de sources

d’alimentation.

Ne travaillez pas seul si des conditions dangereuses sont présentes.

Ne considérez jamais que l’alimentation est coupée d’un circuit, vérifiez toujours le circuit. Cet appareil

génère, utilise et émet une énergie radiofréquence et, s’il n’est pas installé et utilisé conformément aux

instructions des fournisseurs de composants sans fil, il risque de provoquer des interférences dans les

communications radio.

NCA-1515 User Manual

Risque d’explosion si la batterie est remplacée par un type incorrect. Mettre au rebus les batteries

usagées selon les instuctions.

L’installation doit être effectuée par un électricien formé ou une personne formée à l’électricité

connaissant toutes les spécifications d’installation et d’appareil du produit.

Ne transportez pas l’unité en la tenant par le câble d’alimentation lorsque vous déplacez l’appareil.

L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être adéquate pour

refroidir l’équipement à une température de fonctionnement acceptable sans circulation adaptée. Vérifiez

que votre site propose une circulation d’air adéquate.

Vérifiez que le couvercle du châssis est bien fixé. La conception du châssis permet à l’air de

refroidissement de bien circuler. Un châssis ouvert laisse l’air s’échapper, ce qui peut interrompre et

rediriger le flux d’air frais destiné aux composants internes.

Les décharges électrostatiques (ESD) peuvent endommager l’équipement et gêner les circuits

électriques. Des dégâts d’ESD surviennent lorsque des composants électroniques sont mal manipulés et

peuvent causer des pannes totales ou intermittentes. Suivez les procédures de prévention d’ESD lors du

retrait et du remplacement de composants.

Portez un bracelet anti-ESD et veillez à ce qu’il soit bien au contact de la peau. Si aucun bracelet n’est

disponible, reliez votre corps à la terre en touchant la partie métallique du châssis.

Vérifiez régulièrement la valeur de résistance du bracelet antistatique, qui doit être comprise entre 1 et

10 mégohms (Mohms).

Lithium Battery Caution: There is danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type. Dispose of batteries according to the manufacturer's instructions.

Disposal of a BATTERY into fire or a hot oven, or mechanically crushing or cutting of a BATTERY can

result in an EXPLOSION.

Leaving a BATTERY in an extremely high temperature surrounding environment can result in an

EXPLOSION or the leakage of flammable liquid or gas.

A BATTERY subjected to extremely low air pressure may result in an EXPLOSION or the leakage of

flammable liquid or gas.

This equipment must be grounded. The power cord for product should be connected to

a socket-outlet with earthing connection.

Cet équipement doit être mis à la terre. La fiche d'alimentation doit être connectée à une

prise de terre correctement câblée.

Chapter 1: Product Overview

Package Content........................................................................................................................... 8

Ordering Information ................................................................................................................... 8

Optional Accessory....................................................................................................................... 8

System Specifications ................................................................................................................... 9

Front Panel ................................................................................................................................. 10

Rear Panel................................................................................................................................... 11

Block Diagram............................................................................................................................. 12

Installing Nano SIM Card ............................................................................................................ 13

Rack-mounting the System ........................................................................................................ 14

Wall-mounting the System......................................................................................................... 15

Warranty Policy .......................................................................................................................... 18

RMA Service................................................................................................................................ 18

RMA Service Request Form ........................................................................................................ 19

NCA-1515 User Manual

The NCA-1515, a desktop network appliance powered by Intel® Atom® C3000 (codenamed Denverton)

CPU, features robust performance and Intel’s QuickAssist Technology, offering cryptographic acceleration

and commercial-grade LAN functions in a 231mm x 200mm x 44mm (WxDxH) form factor.

Intel® Atom® C3000 (Denverton)

Max. 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass, 2x GbE SFP w/ LED & 2x GbE RJ45 (See SKU)

2x 260-pin SODIMM (by SKU), DDR4 2400/2133/1866MHz ECC SODIMM, Max. 32GB

1x RJ45 Console, 2x USB 2.0, 1x Onboard EMMC 8G, 2x Nano SIM for M.2

2x Mini-PCIe (PCIe / USB 2.0), 1x M.2 2242 B Key (USB 3.0)

Your package contains the following items:

1x NCA-1515 Network Appliance

1x Power Adapter

1x Power Cable (the provided plug type will vary by region)

4x Rubber Pads

Note:

(1) If any component is missing or damaged, please contact your dealer immediately for

assistance. (2) The supplied power adapter and power cable are dedicated to this product only;

do not use them with devices other than this model.

SKU No.

Specification

NCA-1515A

C3758, 2x DDR4 ECC SODIMM, 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass, 2x GbE SFP w/ LED

& 2x GbE RJ45, w/BMC, 60W Adapter

NCA-1515B

C3558, 2x DDR4 ECC SODIMM, 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass & 2x GbE SFP w/

LED, w/ BMC, 60W Adapter

NCA-1515C

C3308, 1x DDR4 ECC SODIMM, 4x GbE RJ45 w/o Bypass, 36W Adapter

Note: Intel® Atom® C3000 processor supports only 2400Mhz RAM. (To use memory with lower

frequencies, please check with your sales representative)

1U Rack-mount kit (Ear Bracket)

HDD Kit

Wall Mount Kit

Chapter 1: Product Overview

Form Factor

Desktop

Platform

Processor Options

Intel® Atom® C3000 (Denverton)

CPU Socket

Onboard

Chipset

SoC

Security Acceleration

Intel® QuickAssist Technology

BIOS

AMI SPI Flash BIOS

System Memory

Technology

DDR4 2400/2133MHz ECC DIMM

Max. Capacity

32GB

Socket

2x 260-pin SODIMM

Networking

Ethernet Ports

4x GbE RJ45 Intel® SoC Integrated MAC

2x GbE RJ45 Intel® i350 and (by SKU)

2x GbE SFP Intel® i350 (by SKU)

Bypass

1 Pair of Gen3 (by SKU)

NIC Module Slot

N/A

LOM

IO Interface

1x RJ45 (By SKU)

OPMA slot

Yes

I/O Interface

Reset Button

LED

Power/Status/Storage

Power Button

1x ATX Power Switch

Console

1x RJ45

USB

2x USB 2.0

LCD Module

N/A

Display

N/A

Power input

1x DC Jack

Storage

HDD/SSD Support

1x 2.5” Bay (Optional)

Onboard Slots

1x EMMC 8GB

Expansion

PCIe

N/A

mini-PCIe

2x Mini-PCIe (PCIe/USB2.0),

1x M.2 2242 B Key (USB3.0)

SIM Card Slot

2x Nano SIM for M.2

Miscellaneous

Watchdog

Yes

Internal RTC with Li-Battery

Yes

TPM

TPM 2.0

Cooling

Processor

Passive CPU heatsink

System

1x Cooling Fan w/ Smart Fan

Environmental Parameters

Temperature

0~40ºC Operating

-20~70ºC Non-Operating

Humidity (RH)

5 to 90% Operating

5 to 95% Non-Operating

System Dimensions

(WxDxH)

231 x 200 x 44 mm

Weight

1.2 kg

Package Dimensions

(WxDxH)

358 x 135 x 290 mm

Weight

2.75 kg

Power

Type/Watts

36W or 60W Power Adapter (By SKU)

Input

AC 100~240V @50~60 Hz

Approvals and Compliance

RoHS, CE/FCC Class A, UL

NCA-1515 User Manual

No.

Description

SIM Card Slot

Insert 1x SIM card for LTE module here

LED Indicators

System Power

System Status

HDD Activity

SFP1

SFP2

LOM

LAN 3~8

Inhaltsverzeichnis

Andere Lanner Netzwerk-Hardware Handbücher

Lanner

Lanner NCA-4112A Bedienungsanleitung

Lanner

Lanner NCA-1611A Bedienungsanleitung

Lanner

Lanner NCA-5210 Bedienungsanleitung

Lanner

Lanner HCP-72i1 Bedienungsanleitung

Lanner

Lanner HTCA-6400 Bedienungsanleitung

Lanner

Lanner FX-3420 Bedienungsanleitung

Lanner

Lanner NCS2-VT04 Bedienungsanleitung

Lanner

Lanner NCA-5710 Bedienungsanleitung

Lanner

Lanner IIOT-I531 Bedienungsanleitung

Lanner

Lanner NCA-4030 Bedienungsanleitung

Lanner

Lanner NCA-1010 Bedienungsanleitung

Lanner

Lanner NCA-1040 Bedienungsanleitung

Lanner

Lanner NCA-4220 Bedienungsanleitung

Lanner

Lanner FW-8771 Bedienungsanleitung

Lanner

Lanner HLM-1101 Bedienungsanleitung

Lanner

Lanner NCA-4035 Bedienungsanleitung

Lanner

Lanner FW-7551 Bedienungsanleitung

Lanner

Lanner LWR-X8460 Bedienungsanleitung

Lanner

Lanner ECA-4025 Bedienungsanleitung

Lanner

Lanner NCA-2523 Bedienungsanleitung

Lanner

Lanner ECA-4027 Bedienungsanleitung

Lanner

Lanner NCA-1011 Bedienungsanleitung

Lanner

Lanner LEC-3340 Bedienungsanleitung

Lanner

Lanner IIOT-I530 Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung

Cantek

Cantek NR310-4 Bedienungsanleitung
