H.264 NVR User's Guide
Model: LI-NVR-6209
Rev 1.0
Aug, 2013
H264 NVR User’s Guide
2
Preface
Congratulations on your purchase of this product. Read this manual carefully and keep
it in a safe place for any future reference.
About this manual
This user manual has been designed to provide you with information regarding your
NVR and its many features and functions. Information in this document has been
carefully checked for accuracy; however, no guarantee is given to the correctness of the
contents. The information in this document is subject to change without notice.
Copyright © Copyright 2011
This manual contains proprietary information, protected by copyright. All rights
reserved.
Contact Information
Leopard Imaging Inc.
1130 Cadillac CT
Milpitas, CA 95035
Phone: (408) 263-0988
Fax: (408) 217-1960
Email: sales@leopard-security.com
Web site: www.leopard-security.com
H264 NVR User’s Guide
3
Important Safeguards
1) Please read this manual carefully before installing and using the machine to
ensure your interests.
2) Do not use the power that does not match the power adapter.
3) Make sure to connect the ground to avoid thunder damage to the main chip
before using the product.
4) Do not use the machine where it is likely to be exposed to rain or humid.
5) Do not install the machine in dusty places, and avoid mechanical vibration and
shock.
6) Keep the machine in a well-ventilated place and avoid direct sunlight and high-
temperature.
7) If possible, choose a dedicated NVR hard drive to meet a long time, a large
amount of data read and write.
8) Please buy a hard drive from the formal channels to ensure quality.
9) Disconnect the power of each device to avoid live-swappable before connection
with other devices.
10) If there are objects or liquid accidentally fall into the machine, immediately
disconnect the power supply, and ask qualified technicians test before using it
again.
11) If the machine is not used for a long time, please completely take off the power
and keep the power cord away from the power outlet.
12) This machine is a precision machine and the user can not repair it. Please contact
qualified technical or distributors.
H264 NVR User’s Guide
4
Contents
Introduction...................................................................................................................................5
Package contents...........................................................................................................................5
1. Product Introduction ............................................................................................................6
1.1 Product outline..................................................................................................................6
1.2 Key features.......................................................................................................................6
1.3 Technical Spec ...................................................................................................................7
2. Product Views........................................................................................................................8
2.1 Front panel.........................................................................................................................8
2.2 Rear panel..........................................................................................................................9
2.3 Remote Control ...............................................................................................................10
3. Hard Drive Installation ...................................................................................................... 11
4. Basic Function Operation...................................................................................................12
4.1 System Login ...................................................................................................................12
4.2 Main Menu.......................................................................................................................12
4.3 Record Config..................................................................................................................13
4.4 Playback...........................................................................................................................14
4.5 Backup..............................................................................................................................15
4.6 Motion Detect ..................................................................................................................16
4.7 Network............................................................................................................................18
4.8 Net Server ........................................................................................................................19
4.9 PTZ control......................................................................................................................25
4.10 Add IPCam to NVR........................................................................................................27
5. Restore Factory Setting ....................................................................................................28
H264 NVR User’s Guide
5
Introduction
This section covers unpacking your new NVR, its key features, and basic technical
information about the product. Refer to later chapters for information on setting up and
configuring the product in more detail.
Package contents
The package should contain all the following contents. If anything is missing or appears
damaged, contact your dealer immediately.
1. Network Video Recorder (NVR) (1)
2. 12V DC Power Adapter (1)
3. Remote Control (1)
4. Mouse (1)
5. Software CD (1)
6. User’s Guide (1)
H264 NVR User’s Guide
6
1. Product Introduction
1.1 Product outline
This device is a digital monitoring and recording product specially designed for
the security field. It adopts standalone embedded processor and Linux operating
system.
The device combines with the latest technology in the IT field, such as video and
audio compression/decompression, large capacity HDD record, TCP/IP network
etc. The code is embedded in the FLASH chip, which makes the system running
more steadily. With the use of professional network video surveillance platform
(network) software, it can fully reflect its strong networking and remote
monitoring capability.
It can be used for the security protection in the fields of banking, electronic
power, telecommunications, justice, traffic, residence, factory, warehouse, water
conservancy facilities and other areas and departments.
1.2 Key features
Video Input: Network 9-CH
Video Output: 1-CH CVBS(BNC), 1-CH VGA and 1-CH HDMI
Alarm Input/Output: 8-CH Alarm Input and 1-CH Alarm Output
Compression: H264
Recording Playback: Max support 9-CH 960P or 4-CH 1080P
synchronously playback
Backup: Support HDD,USB Flash Disk store & backup
Support Motion detection and private masking
Support Remote Control
Support view on PC over CMS software
Support remote view over IE interface or Smartphone.
Support ONVIF, it can widely connect network cameras, network video
servers and network speed dome from various well-known brands
H264 NVR User’s Guide
7
1.3 Technical Spec
Model
LI-NVR-6109
System
Main processor
High performance embedded microprocessor-21
Operating system
Embedded LINUX OS
Video
Network Video Input
9-CH
Network video bandwidth
64Mbps
Video output
1-CH CVBS(BNC), 1-CH VGA and 1-CH HDMI
Video compression format
H.264
Display Image Resolution
720P@30fps;960P@30fps;1080P@30fps
Playback Image Resolution
720P@30fps;960P@30fps;1080P@30fps
Motion Detection
Can setup 192(16 x 12)pcs motion detection area
Privacy Masking
Depends on ip camera
Audio
Audio Input
9-CH IPC Composite Audio
Audio Output
1-CH (support two-way audio)
Audio compression format
adpcm
Two-way audio
1-CH
Recording
Recording Mode
Manual, Motion Detection, Time and Alarm
Recording storage
HDD, Network
Frame rate
NTSC 30fps; PAL 25fps
Recording Playback
Max support 9-CH 960P or 4-CH1080P
synchronously playback
Backup Mode
Support HDD,USB Flash Disk store & backup
Alarm
Alarm Input
8-CH Alarm Input
Alarm Output
1-CH Alarm Output
Other
Network
1x10/100Mbps,RJ45 port
RS485
Standard 485 port, support half-duplex, green
terminal port
USB
3 USB 2.0 ports
HDD
Support 2pcs SATA HDD inside
Power
DC +12V /5A
Power consumption
20W(not include HDD and PoE)
Operation temperature
0℃－＋55℃
Operation humidity
10%－90%
Dimension
365mm*426mm*65mm(1.5U height)
Weight
3.5--4.05KG(not include HDD)
H264 NVR User’s Guide
8
2. Product Views
2.1 Front panel
Figure 1: NVR front panel
Buttons
Description
ZOOM+
In PTZ mode, press to zoom in image
ZOOM-
In PTZ mode, press to zoom out image
SEARCH
Press to open Playback interface
STOP
Press to stop the playback
FAST
Press to speed up the playback
SLOW
Press to slow down the playback
FN
Press to open Right-click menu
PTZ
Press to open PTZ control interface
REC
Press to open Record Mode window
MENU
Press to open the main menu or confirm
PLAY
Press to open Playback interface or play/stop the playback
MODE
Press to switch video mode
ESC
Press to back to last step
H264 NVR User’s Guide
9
MENU: Press to open the main menu or confirm
LEFT: Press to move cursor left; in PTZ mode, press to pan
camera left
RIGHT: Press to move cursor right; in PTZ mode, press to
pan camera right
UP: Press to move cursor up; in PTZ mode, press to pan
camera up
DOWN: Press to move cursor down; in PTZ mode, press to
pan camera down
Indicators
Description
POWER
Power Status
HDD
LED will turn on if the NVR includes hard drive
ALARM
LED will turn on if there is alarm
LINK
LED will turn on if view the video over Network
REC
LED will turn on when recording
2.2 Rear panel
Figure 2: NVR Rear panel
Interfaces
Description
ON/OFF
On-off Switch
DC 12V
Power input , DC 12V
RS485
RS485 control interface
LAN
To connect Ethernet
H264 NVR User’s Guide
10
USB
To connect USB device
VGA
To connect VGA monitor
HDMI
HDMI video output interface
Video Output
Video output to connect TV or monitor (BNC)
Audio IN
To connect audio signal input
Audio OUT
To connect audio output
ALARM
Alarm control interface
2.3 Remote Control
Buttons
Description
1
Mute button
2
Search: Press to open Playback
interface
3
Number/Channel buttons: In menu
interface, press buttons 0~9 to enter
values; in live viewing interface, press
to view channels in full-screen.
4
ESC: Press to back to last step
6
Navigation/Menu:
: Move cursor up;
: Move cursor right;
: Move cursor left;
: Move cursor down;
Menu: In menu interface, press to
confirm selections; in playback and
preview interface, press to view system
information.
7
Press to play/pause video playback
9
Fast-forward when playback
10
Press to open Record Mode window
11
Slow-down when playback
