Owner’s Manual
17
VC4918NRT
New Type Cyclone Vacuum Cleaner
This information contains important instructions for the safe use and maintenance of the vacuum cleaner.
Especially, please read all of the information on page 4,5 for your safety.
Please keep this manual in an easily accessible place and refer to it anytime.
OWNER’S MANUAL
2
Important safety instructions ................................................................................. 4 ~ 5
How to use ................................................................................................................ 6 ~ 14
Assembling vacuum cleaner ................................................................................................................. 6 ~ 7
8
.....................................................................................................................
Operating vacuum cleaner
Using carpet and floor nozzle ................................................................................................................ 9
Using accessory nozzles ....................................................................................................................... 10
Emptying dust tank ................................................................................................................................ 11
Cleaning dust tank ................................................................................................................................. 12
Cleaning air filter and motor safety filter ................................................................................................ 13
Cleaning exhaust filter ........................................................................................................................... 14
............................................. 15
............................................. 15
What to do if your vacuum cleaner does not work?
What to do when suction performance decreases?
Specifications ........................................................................................................... 3
Dimension: 402(mm) x 259(mm) x 275(mm)=L x W x H
Specifications
402
275
259
Table of contents
3
IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
5
2
1
ON/OFF type and Rotary type with advanced telescopic pipe (depending on the model)
Hose Handle
Telescopic pipe
Carpet and floor nozzle
(Depending on model)
1
Telescopic pipe
(Depending on model)
Push the nozzle into the telescopic pipe. • Push telescopic pipe firmly into hose handle.
• Grasp the spring latch to expand.
• Pull out the pipe to desired length.
2
How to use Assembling vacuum cleaner
Spring latchSpring latch
Spring latch
6
3
Attachment Point
Connecting the hose to the vacuum cleaner
3
Push the fitting pipe on the flexible hose into the attachment point
on the vacuum cleaner.
To remove the flexible hose from the vacuum cleaner, press the
button situated on the fitting pipe, then pull the fitting pipe out of the
vacuum cleaner.
Button
7
Cord
reel button
• Pull out the power cord to the
desired length and plug into the
socket.
• Press power switch to start the
vacuum cleaner.
• Slide the rotary control knob to
adjust the suction level.
• The flexible hose handle has a
manual air flow regulator which
allows you to briefly reduce the
suction level.
• Press the cord reel button to
rewind the power cord after use.
How to operate
(Rotary type)
1
How to use Operating vacuum cleaner
Rotary type
(Depending on model)
1
Air Flow Regulator
Open
Close
Plug
Power
switch
Rotary
control knob
Rotary
control knob
MIN MAX
MIN MAX
Park mode
2Storage
3
•
32
To store during vacuuming, for
example to move a small piece
of furniture or a rug, use park
mode to support the flexible
hose and nozzle.
- Slide the hook on the nozzle
into the slot on the side of
vacuum cleaner.
When you have switched off
and unplugged the vacuum
cleaner, press the cord reel
button to automatically rewind
the cord.
You can store your vacuum
cleaner in a vertical position by
sliding the hook on the nozzle
into the slot on the underside
of the vacuum cleaner.
••
•
8
1
How to use Using carpet and floor nozzle
Carpet and floor nozzle
(depending on model)
• The 2 position nozzle
This is equipped with a pedal which
allows you to alter its position according
to the type of floor to be cleaned.
• Carpet or rug position
Press the pedal to lift the brush up.
• Hard floor position (tiles, parquets floor)
Press the pedal to lower brush.
1
9
