Linksys EFPC2SC Bedienungsanleitung

1000BaseSX SC

Fiber Module

xpand the benefits you enjoy with your PC22224,

PC22604, and EF1704 switches as you expand your net-

work. The Linksys 1000BaseSX SC Fiber Module comple-

ments your network while increasing the value in your invest-

ment by adding functionality to your switch.

Using the standard SC fiber optic connector and multimode

fiber cables, the 1000BaseSX SC Fiber Module allows speeds up

to 1000Mbps. In full duplex mode you'll get potential bandwidth

up to an amazing 2000Mbps! You can connect multiple switch-

es separated by distances of up to 550 meters (1804 feet).

And it's so easy to set up! Simply insert the Fiber Module into

an available expansion slot on your PC22224, PC22604, or

EF1704 switch, tighten the thumbscrews, connect with the

appropriate fiber optic cable and you're up and running.

• 1000Base-SX SC connector type

• Full Duplex speed up to 2000Mbps

• Compact design for use with PC22224, PC22604, and

EF1704 switches

• SC connector type for use with multimode fiber

• On board mini jumper allows for selection between half or

full duplex

• 850 nanometer short wavelength

• Suppports distances up to 550 meters (1804 feet) using 50

micron multimode fiber

• Suppports distances up to 275 meters (902 feet) using 62.5

micron multimode fiber

1000BaseSX SC Fiber Module

Model No.: EFPC2SC

A Gigabit Fiber Expansion Module

for your Linksys Switch

Features

Benefits

• Up to 2000Mbps full duplex data rate over fiber

optic cable

• Works with your PC22224, PC22604, or

EF1704 switch

• Connect multiple switches at high speed as

your network grows

• Easy to set up – no software or drivers

required

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EFPC2SC

Standards IEEE 802.3u

Ports Tx, Rx

Cabling Type Multimode fiber with SC connector

LEDs LINK/ACT, FDX

Environmental

Dimensions 1.95" x 1" x 3.40"

(50 mm x 25 mm x 86 mm)

Unit Weight 0.1 lbs. (0.05 kg)

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• One EtherFast®1000BaseSX SC Fiber Module

• One Registration Card

• One PC22224, PC22604, or EF1704

• Multimode fiber cable with SC connector

type

Minimum Requirements

DS-EFPC2SC-30218NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com
