DATA SHEET

SVR3000

Model No.

Services Router with sixteen

port 10/100 LAN for Linksys

One communications solutions

Services Router with 16-Port

10/100 LAN

Linksys One is a complete, affordable, easy-to-install communications solution for growing businesses,

delivering telephones, data networking, applications, and the Internet through one high-speed connection from

a single provider. Business class communications services are delivered by a Linksys One Services Router, which

requires only one internet connection for all services - including low-cost phone service. The Linksys One

Services Router is the core for your network and is present in all Linksys One solutions.

Linksys One Service Routers are easy and cost-effective to install, manage and expand. It does not require you

to have specialized technical expertise. Linksys One technology is automatic and self-configuring – plug in a

Linksys One phone or other device to the Services Router and your business is ready to communicate. It enables

a high-speed office network and phone service to be up and running in very little time. The Linksys One

SVR3000 services router has onboard software that integrates security, reliability and quality of service to

support business quality Linksys One communications services.

The Linksys One SVR3000 services router delivers 16 ports of fast Ethernet LAN switching with full support

for IEEE 802.3af Power over Ethernet on each port. All Linksys One IP Phones and Voice Gateways may

be fully-powered over these ports without a separate power adapter. Two 10/100 WAN ports provide

access to the internet either directly or through a separate broadband router or bridge device. Two 10/

100/1000 BaseT ports offer cascaded expansion to other switches or application servers so the system

can be easily and cost-effectively expanded as your business grows.

No need to worry about cable type. All LAN and expansion ports have automatic MDI/MDI-X crossover

detection and polarity detection will automatically correct cabling errors. Each port independently and

automatically negotiates for best speed and mode (half- or full-duplex). Head-of-line blocking prevention

keeps high-speed clients from bogging down in lower-speed traffic and fast store-and-forward switching

prevents damaged packets from being passed on into the network. The Services Router enables an easier,

more complete business communications solution.

Enables Linksys One

voice product services

including QoS, VLAN,

SIP ALG and IEEE POE

Provides auto-discovery

and auto-configuration

of Linksys One devices,

including IP phones

Two 10/100 full

duplex WAN ports,

two 10/100/1000

expansion ports

Sixteen 10/100 full

duplex, auto-sensing

MDI/MDI-X LAN ports

Linksys, the Cisco Systems logo, the Linksys logo and the Linksys® One logo are registered trademarks of Cisco Systems, Inc. All other trademarks mentioned in this document are the property of their respective owners.

• System automated voice/data configuration and web admin interface makes solution installation and setup easy

• Supports simplified ease of configuration for all Linksys One voice components such as IP phones

• 16 10/100 LAN ports

• 2 10/100 WAN ports

• 2 10/100/1000BaseTX ports for Gigabit Ethernet expansion and High-speed Server connection

• Supports half duplex and full duplex modes and auto-negotiation for all LAN and expansion ports

• Auto MDI/MDI-X supports cable detection on all LAN and expansion ports

• Support for full IEEE 802.3af Power over Ethernet on all sixteen LAN ports

• Routing engine support for RIP, DNS, DHCP, TCP, UDP and other IP protocols

• Multiple VLAN trunking (on all ports) and voice QoS support using IEEE 802.1p/q and Differentiated Services Code Point (DSCP)

• Traffic classification re-marking for QoS policy enforcement

• Outbound WAN priority queuing, traffic shaping and TCP MSS for ensuring proper QoS handling of high-priority traffic such as voice

• Stateful Packet Inspection (SPI) Firewall with automatic Application Layer Gateway Support for protocols such as SIP for Voice Over IP

• WAN Load-balancing with Fail-over. Traffic can be distributed across two ISP connections and in case of an ISP connection failure all traffic will be sent

across the other active ISP connection.

• WAN DSCP-based Policy Routing with Fail-over - High-priority traffic such as Voice can be routed out a specified ISP connection while low-priority traffic

is routed out the other ISP connection.

• Site-to-Site and Remote Access IPSec VPN with preshared key or embedded digital certificates

• Integrated Windows File Server - An external USB Storage Key can be plugged in and mounted as a Windows share for file storage and sharing

• Secure remote device management

• The DMZ (Demilitarized Zone) Host feature allows one local computer to be exposed to the Internet

• Physical security lock port

• System automated voice/data configuration and web admin interface makes solution installation and setup easy

Features

Package Contents

• SVR3000 - 16-Port 10/100 Services Router

•ACPowerCord

• Rack Mounting Kit with brackets and hardware

• Wall Mounting Kit with brackets and hardware

• USB flash memory key

•CDwithSystemAdministration User Guide

• Quick-Start Installation Guide

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: sales@linksys.com

[email protected]

Web: http://www.linksysOne.com

Specifications are subject to change without notice.

SVR3000-DS-51021 KL

Specifications

Environmental

Model

Standards

Ports

Buttons

Cabling Type

LEDs

Security features

SVR3000 - 16-Port 10/100 Services Router with two 10/100 WAN

IEEE 802.3, 802.1p, 802.1q

16 10/100 RJ-45 LAN POE ports, 2 10/100 WAN ports, 2 10/100/1000 ports

System button for cascaded operation

Cat5 or better

System, Link/Activity

ACL, VPN (50 IPSec tunnels), App Layer Gateway, embedded digital certificate

Dimensions

Unit Weight

Power

Certification

Operating Temp.

Storage Temp.

Operating Humidity

Storage Humidity

12.09" x 11.77" x 1.38" (307 mm x 299 mm x 35 mm)

9.11 lbs. (4.13 kg)

100-240V

UL (UL 1950), CSA (CSA 22.2), CE mark, EN60950 (2001)

32º F to 104º F (0º C to 40º C)

-40º F to 158º F (-40º C to 70º C)

20 to 95% Non-Condensing

5 to 90% Non-Condensing
