Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Solera®Slider

Installation and

Owner’s Manual

(For Aftermarket Applications)

NOTE: The number of variances for the Solera Slider is

too extensive to list herein and beyond the scope of this

document. Contact LCI Customer Service

at (574) 537-8900 or email: customerservice@lci1.com

to request the appropriate variance applicable to a

specific requirement.

NOTE: If the optional Solera Slider Access Kit was

purchased keep these instructions to reference the parts

list but use the installation instructions that were included

in the Solera Slider Access Kit.

Table of Contents

Introduction ............................................ 2

Safety Information ..................................... 2

Resources Required ................................... 2

Parts List ................................................ 3

Installation .............................................. 4

Installing the Awning Rail .............................. 4

Assemble the Extension Rod and Cap ................ 4

Installing the Solera Slide Topper Assembly ........... 5

Securing the Fabric .................................... 6

Maintenance ............................................ 6

Fabric Care ........................................... 6

Troubleshooting ........................................ 7

Notes .................................................... 8

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Introduction

Solera®Sliders are a high-quality, cost-effective way to

help keep slide-outs free of dirt, leaves and debris. Solera

Sliders are permanently attached to the slide-out and

retract/extend with the room. The easy-to-install kits are

designed to fit rooms from 66" to 192" in length. All Solera

Slider fabric produced before August 2014 allows for a 58"

projection and all fabric produced after that date allows for

a 48" projection. The hardware hole pattern is universal

and will match most competitive brands, which alleviates

the need to patch holes.

• The Solera Slider kit comes complete with mounting

hardware.

• Awning rail included.

• All fabric is 6” shorter than slide topper length, which is

measured from centerline of torsion arm to centerline of

torsion arm.

• Box width is measured on the outside front of the box.

Include the T-molding for a proper fit.

Additional information about this product can be obtained

from lci1.com/support or by using the myLCI app.

Replacement kits can be ordered from https://store.lci1.

com/ or by using the myLCI app.

The myLCI app is available for free on iTunes®for iPhone®

and iPad®and also on Google Play™for Android™users.

iTunes®, iPhone®, and iPad®are registered trademarks of

Apple Inc.

Google Play™and Android™are trademarks of Google Inc.

Safety Information

Read and fully understand all instructions before installing

or operating this product.

Adhere to all safety labels.

This manual provides general installation procedures.

Many variables can change the circumstances of the

procedure, i.e., the degree of difficulty involved in the

service operation and the ability level of the individual

performing the operation.

FAILURE TO FOLLOW THE INSTRUCTIONS

PROVIDED IN THIS MANUAL MAY RESULT IN DEATH,

SERIOUS INJURY, UNIT DAMAGE OR VOIDING OF

THE COMPONENT WARRANTY.

MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP

CLEAR AND USE CAUTION.

This manual cannot begin to plot out procedures for every

possibility, but will provide the general instructions for

effectively installing the system. In the event the skill level

required is too advanced or the procedure too difficult,

a certified technician should be consulted before

performing the necessary installation. Failure to correctly

install the system may result in voiding the warranty,

inflicting injury or even death.

Resources Required

• 1-2 people, depending on task

• Cordless or electric drill or screw gun

• Appropriate drive bits

• Screwdriver

• Tape measure

• Silicone sealant or butyl tape

• Silicone lubricant

ALWAYS WEAR EYE PROTECTION WHEN

PERFORMING SERVICE OR MAINTENANCE TO THE

UNIT. OTHER SAFETY EQUIPMENT TO CONSIDER

WOULD BE HEARING PROTECTION, GLOVES AND

POSSIBLY A FULL FACE SHIELD, DEPENDING ON

THE NATURE OF THE SERVICE.

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

NOTE: Part numbers are shown for identification purposes

only. Not all parts are available for individual sale. All parts

with a link to the Lippert Store can be purchased.

Parts List

Solera Slide Topper - White

Letter PN Description Qty

A 272455 Drive Head (incl w/ roll tube) 1

B 272454 Idler Head (incl w/ roll tube) 1

C 2724561 Torsion Arm Cap 2

D 362117 Screw, #10 - 16 x 1 1/4” Pan Head,

Self Drilling 10

E 3452071 Extension Rod 2

F 2724411 Extension Rod Bracket 2

G 300247 Screw, #10 - 16 x 3/4”, Hex Washer

Head, Self Drilling 4

H 280648 Screw, 1/4” - 20 x 5/8” Slotted Pan

Head, Self Tapping 2

I 382228 Roll Tube 1

J 675906 Screw, #8 - 18 x 1/2” Pan Head, Self

Drilling (incl w/ roll tube) 8

K 281079 Screw, #6 - 20 x 1/2” Hex Washer,

Self Drilling 2

L 281928 Awning Rail 1

M 252593 Screw, #8 - 18 x 1” Square Pan

Head, Self Drilling 26

A B

C D E

F G H

I J K

Solera Slide Topper - Black

Letter PN Description Qty

A 285149 Drive Head (incl w/ roll tube) 1

B 285148 Idler Head (incl w/ roll tube) 1

C 2724562 Torsion Arm Cap 2

D 362118 Screw, #10 - 16 x 1 1/4” Pan Head,

Self Drilling 10

E 3452072 Extension Rod 2

F 2724412 Extension Rod Bracket 2

G 300247 Screw, #10 - 16 x 3/4”, Hex Washer

Head, Self Drilling 4

H 280648 Screw, 1/4” - 20 x 5/8” Slotted Pan

Head, Self Tapping 2

I 676498 Roll Tube 1

J 276611 Screw, #8 - 18 x 1/2” Pan Head, Self

Drilling (incl w/ roll tube) 8

K 281079 Screw, #6 - 20 x 1/2” Hex Washer,

Self Drilling 2

L 281929 Awning Rail 1

M 364290 Screw, #8 - 18 x 1” Square Pan

Head, Self Drilling 26

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Assemble the Extension Rod and Cap

1. Slide the extension rod (Fig.2A) into the spring head

assembly torsion arm (Fig.2B), aligning the fastener

locations (Fig.2).

2. Slide the spring head assembly torsion arm end cap

(Fig.2C) into the extension rod (Fig.2A), aligning all three

fastener locations (Fig.2). Fasten using the provided

1/4” - 20 x 5/8” slotted pan head, self-tapping screw (Fig.3).

NOTE: Do not secure the second extension rod to the

spring head assembly torsion arm until the Solera Slider is

ready for installation on the unit.

fastener locations

Fig.2

Fig.3

Fig.1

Installation

All screws supporting the awning assembly MUST have a

backer within the structure of the wall of the unit. Refer to

unit manufacturer for proper location.

Installing the Awning Rail

Awning rail included.

1. Position the awning rail along the line where the roof and

wall meet or a minimum of 3” above the upper edge of the

slide room the Solera Slider will cover.

The awning rail must be level and parallel with the top of

slide room box of the unit.

2. After determining the awning rail’s proper location,mark

its position with a non-permanent method of marking.

3. Apply sealant to the back of the awning rail (Fig.1A).

4. Align the awning rail on the wall and secure with

#8 - 18 X 1” screws, using all fastener holes.

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Fig.4

Fig.5

4. Remove packaging from the roll tube and unroll a small

portion of fabric, no more than one turn.

Fig.6

5. Repeat Steps 1-4 for the other end, but do not secure

the second hex extension rod to the spring head assembly

torsion arm until the Solera Slider is ready for installation

on the unit.

Installing the Solera Slider Assembly

1. To prepare for fabric installation, use a screwdriver to

spread open either end of the awning rail on the installation

end (Fig.5A).

2. To protect the fabric from damage during installation,

le any sharp edges or burrs from the awning rail.

3. Spray the inside of the awning rail channel with silicone

lubricant (Fig.5B).

3. Seal the back side of the extension rod bracket screw

holes with sealant so that the sealant is against the unit

when mounting the extension rod bracket.

4. Place the support arm bracket against the bottom

of the T-molding at the top corner of the slide-out.

Make sure to keep the support arm bracket parallel with

the T-molding. Fasten using the provided #10 - 16 x 1 ¼”

self-tapping screws (Fig.4).

UNROLLING THE FABRIC MORE THAN ONE TURN

WILL CAUSE THE SLIDE TOPPER TO LOSE TENSION

AND CREATE SLACK WHEN CLOSING THE SLIDE

ROOM. MAKE SURE TO LEAVE THE SLIDE ROOM

CLOSED OR NOT TO EXTEND MORE THAN 6”.

5. Using at least two people, feed the polycord through the

awning rail channel (Fig.6A).

6. Feed one of the extension rods into the extension rod

bracket. By pulling the extension rod all the way into the

extension rod bracket, the opposite end extension rod can

now slide into the extension bracket or optional access

bracket at the opposite end.

7. Angle the extension rod so that the roll tube will not

be touching the slide room.

8. Secure the second extension rod to the spring head

assembly torsion arm using the provided 1/4” - 20 x 5/8”

slotted pan head, self-tapping screw (Fig.3).

9. Center the Solera Slider over the slide room using a

tape measure.

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

10. Fasten the extension rods to the extension rod brackets

by installing two of the provided #10 - 16 x ¾” self drilling

hex washer head screws in each extension rod bracket

(Fig.7A).

Fig.7

ROLL TUBE SPRINGS ARE UNDER TENSION.

IMPROPERLY SECURED ROLL TUBE SPRINGS CAN

CAUSE PERSONAL INJURY AND/OR PRODUCT

DAMAGE. SLOWLY RELEASE SPRING TENSION

TO AVOID PERSONAL INJURY AND/OR PRODUCT

DAMAGE.

11. Firmly hold the roll tube when removing the spring clip

to relieve spring tension.

Securing the Fabric

1. Extend and retract the room several times to ensure that

the fabric is square on the roll tube.

2. Secure the fabric in the awning rail no more than 1”

inside the edge of the fabric on both ends using a #6 x ½”

hex head screw. Install the screw down through the awning

rail into the fabric and the polycord (Fig.8).

awning rail 1"

fabric stitching

Fig.8

Maintenance

Fabric Care

If the awning is retracted while wet, extend the awning

and let it dry as soon as conditions allow before

retracting. This will help prevent the formation of mildew

and add greatly to the life of the awning. Mildew does not

form on the fabric itself, but on the accumulated dust, dirt

and grime.

Periodically clean vinyl or woven acrylic fabric using a

mixture of ¼cup of dish soap and 5 gallons of warm

water. Liberally apply the mixture on the top of the fabric

and retract the awning for five minutes. This will apply

the mixture to the bottom of the fabric as well. Extend the

awning and hose off with fresh water. Repeat if necessary.

Allow fabric to dry before retracting.

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Troubleshooting

Solera®Slide Topper Troubleshooting Chart

What’s Happening? What Should Be Done?

Rub marks appear on the fabric. Check that there is no debris in the track where fabric goes into the case.

Fabric sags or is loose. Check tension on springs.

Make sure the end caps are properly secured.

Fabric will not roll up. Check tension on springs.

Make sure there are no debris or foreign objects in the fabric opening or case.

Fabric will not unroll. Make sure the spring clips that lock the tension for install have been removed

from both ends of the end caps.

Fabric appears to roll up

at an angle.

Make sure the rail that is mounted to the unit is square with the main housing

of the slide topper.

Make sure fabric is cut square.

lci1.com 574-537-8900 Rev: 05.30.19

Solera®Slider

Installation and Owner’s Manual

(For Aftermarket Applications)

CCD-0001264

Manual information may be distributed as a complete

document only, unless Lippert Components provides

explicit consent to distribute individual parts.

All manual information is subject to change without

notice. Revised editions will be available for free

download at lci1.com. Manual information is considered

factual until made obsolete by a revised version.

Please recycle all obsolete materials and contact

Lippert Components with concerns or questions.

Notes

Inhaltsverzeichnis

Andere Lippert Components Zubehör Handbücher

Lippert Components

Lippert Components SURESHADE ATF Kurzanleitung

Lippert Components

Lippert Components Solera Classic Awning Bedienungsanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Edge Awning Bedienungsanleitung

Lippert Components

Lippert Components Solera 759516 Bedienungsanleitung

Lippert Components

Lippert Components Solera Montageanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Solera Smart Arm Bedienungsanleitung

Lippert Components

Lippert Components 2021130659 Montageanleitung

Lippert Components

Lippert Components Solera Smart Arm Montageanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Solera Classic Montageanleitung

Lippert Components

Lippert Components Solera Power Awning XL Bedienungsanleitung

Lippert Components

Lippert Components Solera 434718 Bedienungsanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Solera Power Awning Bedienungsanleitung

Lippert Components

Lippert Components Solera 3000WS Series Bedienungsanleitung

Lippert Components

Lippert Components Solera 674282 Montageanleitung

Lippert Components

Lippert Components Solera Montageanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Awnbrella Montageanleitung

Lippert Components

Lippert Components Solera Bedienungsanleitung

Lippert Components

Lippert Components Solera TI-278 Bedienungs- und Wartungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
