REFRIGERATOR

INSTRUCTION MANUAL

Model No.: MCBR402S

zBefore use, please read this manual carefully.

Before Putting Into Use

zBefore connecting the appliance to the power supply, let it stand for about 2 hours, which will

reduce a possibility of malfunctions in the cooling system due to transport handling.

zClean the appliance, and be thorough, especially in the interior (See “HOW TO CLEAN”).

zIn case the interior accessories are not correctly placed, rearrange them as described in

chapter “NAME OF THE PARTS”.

Instructions for Use

These instructions for use are intended for the user. They describe the appliance and its correct

and safe use. They were prepared for various types/models of refrigerators therefore you may find

in it description of some functions and accessories that your appliance does not have.

Tips for Energy Savings

zTry not to open the door too often, especially when the weather is wet and hot. Once you

open the door, mind to close it as soon as possible.

zEvery now and then check if the appliance is sufficiently ventilated (adequate air circulation

around the appliance).

zSet thermostat from higher to lower settings as soon as possible (depends on how loaded

the appliance is ambient temperature etc).

zBefore loading the appliance with packages of fresh foods, make sure they are cooled to

ambient temperature.

zIce and frost layer increase energy consumption, so defrost the appliance as soon as the

layer is 1/4” thick.

Important

DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:

zTake off the doors.

zLeave the shelves in place so that children may not easily climb inside.

zThe appliance must be correctly connected to the power supply. (See: “HOW TO INSTALL”).

zDo not use an extension cord.

zDo not touch the cooled surfaces while the appliance operates, especially not with wet hands,

because the skin may stick to the cold surfaces.

zDo not freeze bottles containing liquid, especially soft drinks, such as mineral water,

sparkling wine, beer, cola etc., because liquid expands during freezing and the glass bottle is

very likely to blow up.

zDo not eat frozen food (bread, fruit, vegetables), because you can get frostbites.

zIf the food has strange smell or color, throw it away, because it is very likely that it is spoiled

and therefore dangerous to eat.

zDisconnect the appliance from the power supply before repairing it (only a qualified

technician should repair it), before cleaning.

zDo not defrost the appliance with other electric devices (hair dryer etc.) and never scrape the

ice or frost layer with sharp tools.

zThe rating plate is inside the appliance or outside on the rear wall.

NAMES OF THE PARTS

Model No.: MCBR402S

Cabinet Tabletop

Shelf, Freezer Section

Door, Freezer Section

Temperature Control Box

Interior Light Switch

Shelf, Refrigerator Section

Door, Refrigerator Section

Crisper

Leveling Leg

HOW TO OPERATE

Starting Your New Refrigerator

1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the interior with a

clean moist cloth.

2. Insert the power supply cord into the socket.

3. Turn the thermostat dial to “7”. Close the doors and let the refrigerator operate for 15-20

minutes.

Temperature Control

To control the internal temperature, adjust the

thermostat dial. “1” is the warmest setting. “7”

is the coldest.

The Dial may be set any place on the scale. It

does not have to be set exactly on a number.

Note: Wait 3-5 minutes before restarting if you unplug the refrigerator. The unit may fail to

operate properly if restarted too quickly.

How To Defrost

Defrost the freezer compartment when the frost accumulated is about 1/4” thick.

Set the thermostat dial to “0” before defrosting. Remove all contents from the freezer compartment.

Use the attached plastic spade to remove frost and ice. If the ice/frost becomes hard and difficult to

remove, you need to wait with the door open till the ice/frost melted. Do not use hot water or other

electric devices (hair dryer etc.) to heat it. After defrosting, take the water out and wipe the

compartment dry with a soft cloth and then return the thermostat dial to the desired position.

Never use a knife or other metal instrument to scrape ice/frost from the evaporator.

HOW TO CLEAN

Cleaners: Never use harsh, abrasive cleaners, heavy-duty cleaners, or solvents on any surface.

Exterior: Wipe with damp, sudsy cloth, rinse and dry. For stubborn stains and for periodic

waxing, use silicon wax.

Freezer Section: Do not use sharp instruments to scrap off ice/frost.

Refrigeration Section: Wash shelves and other removable parts in warm sudsy water, rinse and

dry. Wash interior with baking soda solution (3 tablespoons to I liter of water) or warm

sudsy water, rinse and dry.

Magnetic Door Seals: Wash with warm sudsy water.

The Finishing Touch: Replace all parts and return thermostat dial to desired setting.

HOW TO INSTALL

zInstall the refrigerator in a convenient

location away from extreme heat and cold.

Allow sufficient clearance between the

refrigerator and side wall so the door(s)

will open without obstruction. Refrigerator

is not designed for recessed installation.

zSelect a space with strong level floor.

zAllow 5 inches of space between the

refrigerator’s side and the wall.

zThe appliance must be correctly

connected to the power supply.

POWER CORD REPLACEMENT

If the refrigerator’s power cord is damaged, have it replaced by a qualified repair agent.

WHAT TO DO …

When the fridge is not in use for a prolonged period:

zRemove the power plug from the power point.

zRemove all contents from the fridge.

zDry the interior and leave the door open for a few days.

When you wish to move the fridge:

zSecure all movable parts and contents. (Package them separately if necessary.)

zTransport the fridge only in an upright position. In any other position you may damage the

compressor.

Before calling service, please follow the checklist below.

This may save you an expensive service call.

If the refrigerator seems too warm inside:

zCheck that the door has not been opened too frequently or for long.

zCheck that the interior circulation is not obstructed by having too many goods stored. (The

fridge is overloaded)

zDid you store anything hot, without first cooling it to room temperature?

zIs there sufficient clearance around all sides and above the fridge?

If the fridge starts making any unusual noises:

zIs it wobbling? Re-level it and check if it now operates normally.

zHave any objects fallen behind the fridge? If so, remove them and check if operation is now

normal.

zAre any containers inside the fridge vibrating or resonating? If so, rearrange them then check

to see if operation has returned to normal.

WARNING – Improper use of the grounding plug can result in a risk of electric shock. If it is

extremely necessary to use an extension cord, use only a 3-wire extension cord that has a

3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The

marked rating of the extension cord should be AC 115-120V, 10A, or more. If a grounding

adapter is used, make sure the receptacle box is fully grounded.

CHANGING THE REVERSIBLE DOORS

CAUTION: To avoid personal injury to yourself and/or property, we recommend

someone assist you during the door reversal process.

1. Remove the cabinet tabletop.

2. Remove the upper hinge assembly (10) and take out the freezer door.

3. Remove the mid hinge assembly (11) and take out the refrigerator door.

4. To access the lower hinge assembly, tilt back the refrigerator cabinet or lay the refrigerator on its back.

5. Remove both leveling legs located at the front of the cabinet.

6. Remove the lower hinge assembly (12).

7. Re-install the lower hinge assembly (12) and the upper hinge assembly (10) onto the opposite side of the

cabinet.

8. Remove the door plugs each located on the top of the two doors and change them on the opposite side of the

doors (change the door plugs from left side to right side).

9. Remove the door stoppers (13) each located on the bottom of the two doors and change them on the opposite

side of the doors (change the door stoppers (13) from right side to left side).

10. With two doors on the pins of mid hinge assembly (11), re-install the mid hinge assembly (11) and two doors

onto the cabinet. Do not fasten the hinge assembly (11) too tight at this step.

11. Align two doors properly on the cabinet and then fasten the mid hinge assembly (11). If necessary, loosen the

lower hinge assembly (12) and the upper hinge assembly (10) when aligning and then fasten them.

12. Re-install both leveling legs to the cabinet.

13. Re-install the cabinet tabletop.

The process is now complete.

Limited Warranty

MC Sales & Marketing Inc. warrants the following Refrigerators to be free from defective material and

workmanship and agrees to remedy any such defect or to furnish a new part (at the Company’s option)

in exchange for any part or any unit of its manufacture which under normal installation, use and service

disclosed such defect, provided the unit is delivered by the owner to us or to our authorized distributor

form whom purchased or authorized service station, intact, for our examination with all transportation

charges prepaid to our factory. To establish and receive warranty service at our factory or authorized

service facilities, a sales receipt or bill of sales is required for proof of purchase.

Written authorization must be obtained before any merchandise is returned to the factory.

This warranty does not extend to any of our electronic products which have been subjected to misuse,

neglect, accident, incorrect wiring not our own, improper installation, unauthorized modification, or to

use in violation of instructions furnished by us, nor units which have been repaired or altered outside of

our factory, nor to cases where the serial number there of has removed, defaced, or changed.

This warranty is in lieu of all warranties expressed or implied and no representative or person is

authorized to assume for us any other liability in connection with the sales of our electronic products.

For units that are initially defective.

Initial defective is described as when the dealer opens the unit and finds that it is inoperative or an

individual customer opening a new unit and finding that it is initially defective. This unit may be returned

to the factory by the dealer for exchange. Under no circumstances will an individual customer be

permitted to return defective unit directly to factory. Exchange must be directly with the dealer. When

this unit is returned to dealer, a copy of the purchase evidence stating the date of purchase is to be put

in the individual box for dealer’s further control with the factory.

MODEL PARTS LABOR COMPRESSOR

Refrigerator 1year 1year 5years

Model: MCBR402S In-Home Service

Note: For Service or Assistance, please call: 1-888-775-0202 or visit our website

www.magicchef-ewave.com
