Marine PC MPC-ML2DVR Bedienungsanleitung
MPC-ML2DVR
Digital Video Recorder
LCD Monitor
User Manual
www.MarinePC.com
Programmable
N
S
E
W
MARINE PC
MARINE PC
2MPC-ML2DVR-UM(A) 3/2015
Information Disclaimer
This MarinePC User Manual is provided “as-is”, without warranty of any kind, either expressed or implied, includ-
ing but not limited to the implied warranties or merchantability and fitness for a particular purpose.
Documentation Change Notice
The information in this User Manual is subject to change without prior notice in order to improve readability and
reliability as well as design and function. These changes shall be incorporated in a new revision, available from
the product and/or download section of the MarinePC web site, www.marinepc.com.
Liability
In no event shall MarinePC be liable for direct, indirect, special incidental or consequential damages arising out
of the use of or the inability to use MarinePC’s product or its documentation, even if advised of the possibility of
such damages.
Endorsement
Product names mentioned herein are used for identification purposes only and may be trademarks and/or regis-
tered trademarks of their respective companies.
Copyright
This document contains proprietary information protected by copyright. All rights are reserved. No part of this
manual, in whole or part, may be reproduced by any means, in any form, without prior written permission of
MarinePC.
www.marinepc.com
Owner Record
Here is an easy-to-locate form to record the unit’s serial number, and from the invoice,
record the invoice date. The unit’s serial number is located on the back panel.
If the unit ever requires service, please refer to this information when contacting the
MarinePC Service Center.
Product Serial Number Invoice Date
MPC-ML2--DVR ____ / ____ /____
MPC-ML2DVR-UM(A) 3/2015 3
MPC-ML2--DVR
Military Grade
Programmable
Digital Video Recorder
LCD Monitor
8.4”, 10.4”, 12.1”, 15”
User Manual
4MPC-ML2DVR-UM(A) 3/2015
Table of Contents
Introduction.......................................................................................5
General Safety Precautions..............................................................6
Product Care, Maintenance..............................................................8
System Setup and Installation..........................................................9
Display Connectors ........................................................................10
Digital Video Recorder....................................................................13
DVR Main Menu .............................................................................14
Power ON View, Video Feed Record Options ...........................14
Main Menu, Video Input Options ...............................................18
Media Menu, Delete, PC Download, Playback..........................21
PIP/POP/QUAD Options ...........................................................28
Save View, Name View Options ................................................31
Optional NVIS Menu..................................................................33
IBIT Menu ..................................................................................34
Utility, Date/Time, Startup Menus ..............................................36
Programmable Softkeys ................................................................42
Communication Protocol ................................................................47
Internal Heater................................................................................59
Appendix A - Mechanical Drawings ................................................60
Appendix B - NEMA and IP Industry Standards .............................60
MPC-ML2DVR-UM(A) 3/2015 5
With the acquisition of an All-Weather Digital Video Recorder/Monitor, MPC-ML2DVR,
we welcome you to MarinePC’s family of ruggedized professional marine grade prod-
ucts.
You will soon become familiar with the quality difference in this bright sunlight-reada-
ble (~1 nit to 1,000 nits) Monitor, specically designed to meet or exceed MIL-Specs for
use in harsh marine environments. MarinePC has incorporated the latest LED backlight-
ing to increase brightness and super-low dimming without increased heat, and extends
temperature, shock and vibration specications.
The MPC-ML2DVR also integrates full DVR capability directly inside the case of the wa-
terproof monitor, eliminating separate mounting interconnecting cables, saving space
and providing environmental protection and tranportability for the DVR.
In addition, this new release, Series 2, incorporates user programmable function but-
tons conveniently mounted on the bezel to provide customizable multiple functionality
in one ruggedized station.
The MPC-ML2DVR handles a wide-range of severe environments, making it the rst
choice of serious mariners for their demanding applications. Designed to be rugged,
the 800x600 (SVGA) Resolution Flat Panel Display is engineered to mate perfectly to all
leading edge cameras including infrared, image amplied and visible spectrum sources.
Housed in a milled billet aluminum case, the slim-prole MPC-ML2DVR is light weight
and watertight, with fully sealed (IP67) case and standard MIL-C-38999 connectors.
Engineered to be energy efcient to conserve power, the MPC-ML2DVR has three
Composite Video inputs, with a source select button that lets you easily move between
up to three inputs, and also provides one video output. Recorded les can be easily
downloaded in standard .wmv le format via a USB connection.
Our MarinePC Service and Support Team is prepared to assist you – we are MarinePC.
Welcome.
6MPC-ML2DVR-UM(A) 3/2015
General Safety Instructions
• BeforeoperatingtheMPC-ML2DVRDisplay,readthisUserManualthoroughly
• KeepthisUserManualforfutureuse
• Verifythesystemcapability(seeSystemSetup)toensureoperationoftheDisplay
• Forexpeditiousinstallation,followtheseUserManualinstructionsinsequence
• AdheretoallCautionandWarningsonsystemandasstatedinthisUserManual
• UserManualinstructionsforinstallationandoperationshouldbefollowedprecisely
• AdjustonlythosecontrolscoveredbythisUserManual’sinstructions;improperadjust-
mentofothercontrolsvoidsDisplay’swarrantyandmayresultinDisplaydamage,and
• Adheretolocalinstallationcodes.
General DISPLAY Safety
• AlwaysdisconnectDisplayfrompowersourcebeforecleaning
• DonotoperateDisplaywithadamagedcable,and
• DonotoperateifDisplayhasbeendroppedordamaged.Unitshouldbeinspectedby
qualiedMarinePCServicePersonnel.
GENERAL SAFETY PRECAUTIONS
• Powercablemustbeconnectedtoaproperlywiredandgroundedpowersource
• AnysystemtowhichtheDisplayisattachedmustalsobeconnectedto
properly wired and grounded power sources
• DonotconnectordisconnectDisplayduringanelectricalstorm
• DonotopenDisplayenclosure–therearenoUserserviceableparts
• DonotdisassembleormodifyDisplaytoavoidpossibilityofelectricalshock,
damage to electrical components or scratching the Display surface, and
• DisassemblyofDisplayvoidswarranty.
Safety Icons
SafetyiconsaredisplayedthroughouttheUserManualtodrawattentiontospecicUser
CautionandWarningInstructions.
This icon is intended to tell the User of important operating and/or
maintenance instructions.
This icon is intended to tell the User of a potential risk of electrical shock.
WARNING! SHOCK HAZARDS
CAUTION! INSTRUCTIONAL
GENERAL SAFETY
MPC-ML2DVR-UM(A) 3/2015 7
LCD AND ELECTRICAL SAFETY
LCD Display Safety
It is recommended Users adhere to personal safety in the instance the DVR display screen
shouldbeshattered.Asidefromobviousglassshards,theuidsintheLCDareaknownskin
irritant.
Electrical
Product has been engineered to meet or exceed international industry standards
addressing product design and enclosure protection against EMI/RFI.
FLUIDS FROM LCD DISPLAY
• IfDisplayshouldbecomeshattered,donottouchuidsfromLCDScreen
• Ifuidshouldgetonhandsorclothing,immediatelywipeoffwithliquidsoap
orrubbingalcoholonacleantowel;washwithwater;immediatelyconsultwith
a doctor, and
• Ifuidgetsintheeyes,usheyesimmediatelywithwaterforaminimumof
15minutes;immediatelyconsultwithadoctor.
EMI/RFI
Connecting Cables
• DisconnectpowertosystemwhenDisplayisbeinginstalled
• Uponinstallation,verifypowerinputconnectorissecurelyseatedonDisplay
• Positionpowercablesoitisnotincontactwithhotsurfaces
• Donotallowanythingtorestonpowercable,and
• Protectpowercablefromextremeheatsources.
Power Source
• AlwaysconnecttoaproperlygroundedDC(standard)powersource
• UnitmaybepoweredwithaqualiedAC/DCAdapter(askfactoryfordetails)
• AnyequipmenttowhichDisplayisattachedmustalsobeconnectedtoprop-
erly wired and grounded power sources
• Operationalvoltageis10-36VDC(Inputis12,24,28VDCnominal),and
• PowerConsumptionis:30Wattsmaximum.
MPC-ML2DVRpowerconsumptionislistedat30Wattsmaximum.
POWER CONSUMPTION
8MPC-ML2DVR-UM(A) 3/2015
PRODUCT CARE
This DVR Display has been designed to provide optimum performance and service without
anyrequiredscheduledmaintenanceotherthanoccasionalcleaning.
Display Screen Cleaning
• Avinegar-basedcleanerispreferred:preventsstreaking,degradationofcoatings
• Anonabrasiveglasscleanermaybeused,asinprofessionalfoamglasscleaner
• Applycleaningsolutiontoasoftcleancloth,dampeningslightly
• Keep a fresh side of cleaning cloth towards screen surface to avoid scratching it with
accumulated grit as Display screen is made of glass, and
• Tominimizeriskofabrasiontoglassscreen,airdryingisrecommended.
Display Enclosure
• CleanDisplayenclosurewithsoftcleanclothlightlydampenedwithamilddetergentsolu-
tion
• Wipedownwithcleanwater;drywithasoftcleancloth.
Product Care
• Donotuseabrasiveorsolvent-based(ammable)cleanersonDisplay
enclosureoranyotherelectricaldevice(cables,powercable,etc.)
• DonotusepaperproductsastheymayscratchDisplayscreen,and
• DonotdirectlyapplycleaningsolutionstoDisplayscreen.
Disconnect Display from power source before cleaning Display, optional
TouchScreenorDisplay’senclosure.
Long-term Storage
• Forlong-termstorage,itissuggestedDisplaybestoredinanormalindoorenvironment
and Display glass be protected from accidental damage
• Forpedestalmountunits,disconnectcable(s)andloosenarmadjustmenttoapointwhere
ball can be removed from arm, or
• For Flush or Panel Mount units, cover product with a protective covering that will not
scratch or transfer any dyes to Display screen.
Disassembling Display voids warranty. To avoid risk of electrical shock,
donotdisassembleenclosure;Userscannotservice.Usermaintenance
is restricted to cleaning or power cable replacement, as explained.
In marine or similar environments, a benet of a vinegar-based cleaner
is its effectiveness in dissolving mineral and salt deposits.
MPC-ML2DVR-UM(A) 3/2015 9
MAINTENANCE
POWER CABLE
Maintenance
Other Maintenance
OnlyMarinePCQualiedServicePersonnelshouldperformallothermaintenanceexceptfor
cleaning and power cable replacement as described.
Toavoidshockandrehazards,replacedDisplay’spowercableif:
• Insulationbecomesdamaged,or
• Alooseconnectionissuspected.
Protection on Servicing
Servicing - User
• UserServicingislimitedtocleaningtheDisplay
• DonotdisassembleormodifytheDisplaytoavoidthepossibilityofelectricalshock,
damage to its electrical components or scratching the Display surface, and
• Disassemblyvoidsthewarranty.
Servicing - DSE
MarinePCQualiedServicePersonnelmayberequiredtoservicetheDisplayif:
• Doesnotoperatenormallywheninstallationinstructionsarefollowed
• Doesnotoperatenormallywhenoperatinginstructionsarefollowed
• Hasbeendroppedordamaged,or
• Exhibitsadistinctchangeinperformance,indicatinganeedforservice.
Shipping
If Display should need to be shipped to the MarinePC Service Center, the original packing
material should be used to ensure safety of Display in shipping. Repack Display as it would
have originally been received from manufacturer.
Shipping Box Contents
The DVR is shipped in a custom box with enhanced packaging. Installer should save box and
all packaging materials in the instance Display is returned to the MarinePC Service Center.
Shippingboxcontentsare:
• MPC-ML2DVRDisplay
• CablesandRAMArmMounting,ifOrdered
INSTALLATION
TheDVRcanbeinstalledwith:FrontMount(M4),PanelMount(M4);RAMMount(M4),Side
Mount(M4),orVESAMount(75mm/M4).Followknown-goodpracticesduringinstallation.
SYSTEM SETUP
TheDVRacceptsCompositeVideosignals;(4)RS170Inputs;(1)RS170Output.
10 MPC-ML2DVR-UM(A) 3/2015
DISPLAY CONNECTORS
Cables
Withawiderangeofsysteminstallationsrequiringvaryingcablelengths,theDVRdoesnot
shipwithcables.Special-ordercablesareavailable;otherwise,allcablesaresuppliedby
the end user.
Connectors are located on the back of the DVR chassis. See Figure 1, Table 1 for Con-
nector Assignments.
Connectors
Use caution when coupling or uncoupling cables and connectors.
POSITION CONNECTOR CALL - OUT
1POWER J1
2VIDEO IN J2
3VIDEO IN J3
4VIDEO IN J4
5VIDEO IN J5
6VIDEO OUT J6
7VCOM J7
PE PRESSURE EQ. N/A
USB USB USB
Table 1
Figure 1
1
GND
PE
USB
234
67
5
Andere Handbücher für MPC-ML2DVR
1
Inhaltsverzeichnis
Andere Marine PC DVR Handbücher
